Part Identification Number: DCKI-395-32-40S |
Hardware Included:
Quantity
Hardware
1
Bumper Guard
2
Mounting Bracket
2
U-Bolt
Note:
• Professional installation is highly recommended
• Review and understand the installation hardware and procedure before beginning
• Periodically check the tightness and alignment of the parts for proper adjustment after completion
Diagram 1.A: Refer to the diagram below when fastening nut to bolt. For fastening procedures that does not require
a bracket or bumper, remember the concept demonstrated. The spring should be in between the washer and nut.
Broadfeet Motorsport Equipment
Installation Instruction
2015-2017 KIA SEDONA | A-Bar Nudge Bar
Quantity
12
8
8
4
WWW.BROADFEET.COM
Hardware
Large Washer
Spring Washer
Hexagon Nut
Hexagon Bolt
Installation Instruction
Advertisement
Related Manuals for Broadfeet DCKI-395-32-40S
Summary of Contents for Broadfeet DCKI-395-32-40S
- Page 1 Installation Instruction 2015-2017 KIA SEDONA | A-Bar Nudge Bar Part Identification Number: DCKI-395-32-40S | Hardware Included: Quantity Hardware Quantity Hardware Bumper Guard Large Washer Mounting Bracket Spring Washer U-Bolt Hexagon Nut Hexagon Bolt Note: • Professional installation is highly recommended • Review and understand the installation hardware and procedure before beginning •...
- Page 2 Step 1: Remove under shield plastic skid cover to gain access to the chassis frame Step 2: Insert U-Bolt as shown. Attach mounting bracket fasten with washer and nut. (Passenger side shown) Step 2: Install U-Bolt and mounting bracket onto the driver side. (Driver side shown) Broadfeet Motorsport Equipment WWW.BROADFEET.COM Installation Instruction...
- Page 3 Step 3: Once the mounting brackets are fastened to the U-Bolt, attach the bumper guard. Refer to diagram on Page 1 Passenger Side: (Outer side shown on left image. Inner side shown on right image) Driver Side: (Outer side shown on left image. Inner side shown on right image) Broadfeet Motorsport Equipment WWW.BROADFEET.COM Installation Instruction...
- Page 4 Step 4: Adjust and balance the bumper guard and then secure all the hexagon nuts. Step 5: Re-attach the plastic under skid shield cover. Additional Diagram: Broadfeet Motorsport Equipment WWW.BROADFEET.COM Installation Instruction...
- Page 5 Broadfeet Motorsport Equipment WWW.BROADFEET.COM Installation Instruction...
- Page 6 Step 5: Once all bolts and nuts are fastened, balance and adjust the bumper guard before it is tightened into place. Step 6: Re-attach the hitch receiver cover and plastic under shield. Broadfeet Motorsport Equipment WWW.BROADFEET.COM Installation Instruction...
