- Page 1 INSTALLATION INSTRUCTIONS 2015 NISSAN MURANO 2.5” A-BAR PART# DCNI-523-32 Hardware Hardware Mounting Brackets Z-Bolts Screws Nuts Lock Washers Flat Washers ( Big flat washers*2, Small flat washers*14 ) © Broadfeet Motorsport Equipment P a g e...
- Page 2 STEP1: Verify all parts are present. Read instructions carefully before starting installation. Z-Bolt © Broadfeet Motorsport Equipment P a g e...
- Page 3 Bracket Rear on the vehicle. Tighten the hardware. (Fig2) Fig 2 © Broadfeet Motorsport Equipment P a g e...
- Page 4 STEP4: Use a bolt, a lock washer, a small flat washer and a big flat washer to attach the Bracket Middle on the vehicle. Tighten the hardware. (Fig3, Fig4) Fig 3 Fig 4 © Broadfeet Motorsport Equipment P a g e...
- Page 5 Fig 5 STEP6: Use bolts, lock washers, flat washers and nuts to attach the A-Bar to mounting brackets. Level and adjust A-bar properly. Tighten all hardware at this time. (Fig6) Fig 6 © Broadfeet Motorsport Equipment P a g e...
