SECTION 6 TROUBLESHOOTING
Table 6-2. Error Codes Requiring Technical Service
Error Malfunction
Code Description
60-1 Plunger motor position
flag stuck high during
re-synchronization
60-2 Plunger motor position
signal is continuous
low during
re-synchronization
61-1 Input/output motor
position flag is
continuous high during
re-synchronization
61-2 Input/output motor
position signal is
continuous low during
re-synchronization
62-1 Primary/secondary
motor position flag is
continuous high during
re-synchronization
62-2 Primary/secondary
motor position signal is
continuous low during
re-synchronization
63-1 Plunger motor phase loss
430-00587-008 (Rev. 2/05)
Possible Cause
Position sensor failure
Plunger motor not moving
Position sensor failure
Enable circuit failed
Plunger motor not moving
Position sensor failure
Input/output motor
not moving
Position sensor failure
Enable circuit failure
Input/output motor
not moving
Position sensor failure
Primary/secondary
motor not moving
Position sensor failure
Enable circuit failure
Primary/secondary
motor not moving
Plunger motor does not
have enough torque
Mechanical assembly
failure
6 - 8
Corrective Action
Replace mechanism
assembly
(Section 7.2.9.2)
Check connection
at J7 on MCU PWA
If condition recurs,
contact Hospira
Replace mechanism
assembly
(Section 7.2.9.2)
Check connection
at J7 on MCU PWA
If condition recurs,
contact Hospira
Replace mechanism
assembly
(Section 7.2.9.2)
Check connection
at J8 on MCU PWA
If condition recurs,
contact Hospira
Replace mechanism
assembly
(Section 7.2.9.2)
Check connection
at J8 on MCU PWA
If condition recurs,
contact Hospira
Replace mechanism
assembly
(Section 7.2.9.2)
Check connection
at J9 on MCU PWA
If condition recurs,
contact Hospira
Replace mechanism
assembly
(Section 7.2.9.2)
Check connection
at J9 on MCU PWA
If condition recurs,
contact Hospira
Replace mechanism
assembly
(Section 7.2.9.2)
