Page 1 Infusion System System Operating Manual For Use with List Number 20837-04, and for List Number 20709-04 Upgraded with 7.x Software Compatible with Software Hospira, Inc. 275 North Field Drive Lake Forest, IL 60045, USA 430-97354-001 (F, 2016-02)
Page 2 LifeCare PCA Infusion System Change History Title Description of Change 430-97354-001 Initial Release (E, 2015-05) 430-97354-001 Added information for upgraded pumps (Cover, (F, 2016-02) Chapter 1, Chapter 11) Updated Programming a Loading Dose instructions (Chapter 5) Updated Clearing Shift Totals instructions...
Page 3: Table Of Contents
LifeCare PCA Infusion System Contents CHAPTER 1 INTRODUCTION ......1-1 ......1-1...
Page 4 Contents ....1-27 IRELESS EVICE AUTION ..1-27 ADIO REQUENCY XPOSURE TATEMENT ..... . 1-28 ARNINGS AND RECAUTIONS .
Page 5 PROGRAMMING INFUSERS WITH HOSPIRA MEDNET SOFTWARE....4-1 ......4-2...
Page 6 Contents PCA + C ..5-13 ROGRAMMING A ONTINUOUS HERAPY ..... . 5-13 URNING N THE NFUSER...
Page 7 LifeCare PCA Infusion System CHAPTER 9 SPECIFICATIONS......9-1 LAN M ......9-6...
Page 8 Contents APPENDIX A GENERATING BAR CODE LABELS (HOSPIRA MEDNET SOFTWARE ENABLED) . . . A-1 QUIPMENT EEDED TO RINT A ... A-2 HARMACY ENERATED ......A-3...
Page 9 LifeCare PCA Infusion System APPENDIX E NETWORK PRINTER SETUP....E-1 ..... E-1...
Page 10 Contents NOTES System Operating Manual...
Page 11: Introduction
Software allows the LifeCare PCA infuser to read pharmacy-generated bar codes on custom-filled vials. The vials are single-use and barcoded, and are either prefilled with a medication by Hospira, or are sterile empty vials which can be custom-filled by the hospital pharmacy (see Appendix A Generating Bar Code Labels (Hospira MedNet Software Enabled)).
Page 12 Prescription Delivery Limits). LifeCare PCA Infusion System with Hospira MedNet Software The LifeCare PCA infusion system is used in conjunction with the server-based Hospira MedNet safety software. Hospira MedNet Software facilitates networked communication between the server and Hospira Mednet-compatible infusers.
Page 13: List Number 20709-04 U
LifeCare PCA Infusion List Number 20709-04 Upgraded to 7.x Software Legacy LifeCare PCA infusion systems list number 20709-04 upgraded to 7.x software are substantially equivalent with list number 20837. Any differences associated with list number 20709-04 upgraded to 7.x software are documented in Chapter 11 Information for Legacy LifeCare PCA Infusers Upgraded with 7.x Software.
Page 14 Introduction CAUTION: A CAUTION USUALLY APPEARS IN FRONT OF A PROCEDURE OR STATEMENT T CONTAINS INFORMATION THAT COULD PREVENT IRREVERSIBLE PRODUCT DAMAGE OR HARDWARE FAILURE AILURE TO OBSERVE A CAUTION COULD RESULT IN SERIOUS PATIENT OR USER INJURY Note: A Note highlights information that helps explain a concept or procedure.
Page 15: Patient Selection
The LifeCare PCA infuser is able to store frequently used prescriptions called protocols (see Chapter 10 Protocols). The protocols are available for Hospira prefilled vials and custom syringes. The protocols must be set up by a hospital-designated authority in the Biomed Mode or through Hospira MedNet Software (if enabled).
Page 16: User Qualifications
Introduction Contraindications For Use The LifeCare PCA infuser should not be used for patient- controlled analgesia by patients who do not have the cognitive ability to understand the use of self-administered pain medication, nor have the physical capacity to operate the patient pendant, if required.
Page 17: Hospira Pre -Filledv
LifeCare PCA Infusion Hospira Pre-Filled Vials Hospira pre-filled vials are available for standalone infusers and Hospira MedNet-enabled infusers. The LifeCare PCA infuser’s bar code reader identifies the bar code and displays the medication name and concentration of that pre-filled vial.
Page 18: Pharmacy -Filled
Hospira MedNet Software allows the LifeCare PCA infuser to read the pharmacy-generated bar code on the custom-filled vial. The bar codes are linked to the rule sets within the Hospira MedNet Software. This ensures that when the custom-filled vial is inserted into the infuser, the displayed medication and concentration are linked to the corresponding rule set.
Page 19: Equipment Description
LifeCare PCA Infusion Equipment Description This section shows the front view, vial cradle assembly, rear view, and buttons and keys of the infuser. Front View Figure 1-1 shows the front view of the LifeCare PCA infuser. Cradle Release Mechanism (Holder) Vial Vial Cradle...
Page 20: Vial Cradle
Introduction Vial Cradle Assembly Figure 1-2 shows a detailed view of the LifeCare PCA vial cradle assembly. Cradle Wireless Release Antenna Mechanism Upper Vial Retainer Bar Code Vial Reader Cradle Window Clips (vial bar code must face Vial toward window) Sensor Switch (Top Vial...
Page 21: Rear View
LifeCare PCA Infusion Rear View Figure 1-3 shows the rear view of the LifeCare PCA infuser. Patient Equipotential Pendant Terminal Nurse Call Jack Jack Patient Pendant Cable Fastener Patient Pendant Ethernet Jack/Printer Connector Pole Clamp with Dual Lock Patient Pendant Button Power Cord...
Page 22: Patient Pendant
Introduction Equipotential Terminal The equipotential terminal (see Figure 1-3) is used to ensure that the infuser is at the same electric potential (voltage) as the other devices in the treatment location. Ideally, the electrical potential is at zero volts, so that no current can inadvertently flow from one device to another through a patient.
Page 23 LifeCare PCA Infusion Figure 1-4. Patient Pendant CAUTION: D O NOT BEND THE PATIENT PENDANT CORD NEAR THE PATIENT PENDANT OR CONNECTOR JACK AT AN ANGLE OR GREATER Figure 1-5. Patient Pendant Cord and Connector Jack System Operating Manual 1-13...
Page 24 Introduction Buttons and Keys Table 1-2 describes LifeCare PCA infuser buttons and keys. Table 1-2. Buttons and Keys The [ON/OFF] button controls the power of the LifeCare PCA infuser The [CLEAR] button is used to clear an entry The [ENTER] button is used to select and accept various screen options The [EXIT] button is used...
Page 25 This button also provides access to the softkey PRINT HISTORY Note: Print History is available for standalone infusers without Hospira MedNet The numeric buttons are used to enter values for any field requiring numeric data The [DECIMAL POINT] button is used when entering numbers with a decimal point (such as 10.5 mg)
Page 26 Introduction Table 1-2. Buttons and Keys When pressed, the softkeys to the right of the main display perform a variety of functions correlating to the description displayed on the screen The battery indicator illuminates continuously when the infuser is running on battery power The AC (mains) power indicator illuminates when the...
Page 27: Battery
LifeCare PCA Infusion Battery Charge Level To access the battery charge level indicators, press the [H ISTORY ] button. ATTERY Table 1-3 describes each battery indicator icon and its associated battery life, power level, and alarm state. Table 1-3. Battery Charge Levels Indicator Description Alarm State...
Page 28 Introduction Wireless Strength To access the wireless strength indicators, press the [H ISTORY ] button. ATTERY Table 1-4 describes the wireless strength indicator icons. Table 1-4. Wireless Strength Indicators Excellent strength Good strength Fair strength Poor strength No signal available 1-18 System Operating Manual...
Page 29: Alarm
LifeCare PCA Infusion Alarm Treatment Alarms are defined as High, Medium, and Low priority. High, medium, and low priority alarm screens display three, two, or one exclamation points, respectively, to indicate alarm priority. Note: The alarm message text will alternate its display over the currently displayed screen.
Page 30: Epidural Administration
Introduction Table 1-5. Alarm Priority Indicators Low Priority The screen flashes at a slower ! ALARM pace, and the infuser emits an audible alarm of two beeps, with an interval of approximately 15 seconds between each audible sequence The 1 exclamation mark (to the left of the centered screen name ALARM) represents a low priority alarm...
Page 31 LifeCare PCA Infusion For epidural administration, the use of administration sets without Y-sites and labeled FOR EPIDURAL USE, indicating ongoing epidural administration, are recommended. Administration of medications via the epidural route should be limited to personnel familiar with associated techniques and patient management.
Page 32: Electrical Artifacts
Refer to the appropriate monitoring equipment system documentation for setup and maintenance instructions. The LifeCare PCA Infusion System is designed to operate normally in the presence of most encountered electromagnetic interference (EMI) conditions. In the event of extreme levels...
Page 33 Increase the separation between the equipment • Connect the equipment into an outlet on a circuit different from that to which the other device(s) is connected • Contact Hospira or field service technician for help CAUTION: P ORTABLE AND MOBILE RF COMMUNICATIONS , 2- EQUIPMENT...
Page 34: Interconnecting Of
Introduction Interconnecting of Equipment Accessory equipment connected to the analog and digital interfaces must be certified according to the respective IEC Standards (for example, IEC 60950 for data processing equipment and IEC 60601-1 for Medical Equipment). If in doubt, consult the technical service department or your local representative.
Page 35: Fcc Information
If the device must be used adjacent to or stacked with other equipment, monitor the devices to verify normal operation. Use only components specifically labeled for use with the LifeCare PCA Infusion System to help ensure the device operates as intended. If you suspect external RF sources or other equipment...
Page 36 • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Hospira could void the user's authority to operate the equipment. 1-26 System Operating Manual...
Page 37: Wireless Device Caution
LifeCare PCA Infusion Wireless Device Caution The wireless 802.11 a/b/g device usage in the 5150-5250 MHz band is limited to indoor use to reduce potential for harmful interference to co-channel mobile satellite systems. In the 5250-5350 MHz and 5650-5850 MHz frequency bands, high power radars are allocated as primary users and these radars could cause interference and/or damage to LE-LAN devices.
Page 38: Warnings And Precautions
Introduction Warnings and Precautions Hospira will be responsible for the safety effect, reliability, and performance of this device only if adjustments, modifications, or repairs are performed by persons authorized by Hospira, electrical setup at the point of use complies with appropriate local requirements, and the device is used in accordance with the instructions for use identified in this operating manual.
Page 39 MAY IMPACT DEVICE PERFORMANCE. CAUTION: U SE PROPER CARE DURING UNPACKING AND INSTALLATION TO PREVENT DAMAGE ONTACT HOSPIRA AND DO NOT USE THE INFUSER IF IT APPEARS DAMAGED IN ANY WAY CAUTION: D O NOT PLACE THE LIFECARE PCA INFUSER...
Page 40: Malfunction Alarm
Introduction CAUTION: D O NOT USE SHARP OBJECTS SUCH AS PENS SCISSORS OR FINGERNAILS TO PRESS KEYS UCH OBJECTS MAY DAMAGE KEYS AND CAUSE A MALFUNCTION CAUTION: R E M O V E A L L A I R F R O M T H E V I A L A N D ADMINISTRATION SET PRIOR TO PLACING THEM INTO THE INFUSER CAUTION: A...
Page 41: Battery Operation
LifeCare PCA Infusion Battery Operation WARNING UNPLUG THE AC POWER CORD BEFORE REMOVING THE BATTERY DOOR. CAUTION: W HEN THE LIFECARE PCA INFUSER IS CONNECTED TO A PATIENT DO NOT OPERATE THE INFUSER WITH THE BATTERY REMOVED USE OF A PROPERLY MAINTAINED AND CHARGED BATTERY HELPS ENSURE PROPER OPERATION The battery may not be fully charged upon receipt.
Page 42 Introduction NOTES 1-32 System Operating Manual...
Page 43: Chapter 2 Setup And Operation
Infuser Configurations on an IV Pole The Hospira heavy duty IV Pole with locking casters (list number 39001-21) has been tested for stability according to the requirements of IEC 60601-1:2012. An IV pole with six locking...
Page 44 Setup and Operation 78 inches (198.1 cm) 56 inches (142.2 cm) 44 inches (111.8 cm) Figure 2-1. Infuser Configurations on an IV Pole System Operating Manual...
Page 45: Attaching An Infuser To An Iv Pole
LifeCare PCA Infusion System Attaching an Infuser to an IV Pole The LifeCare PCA infuser uses a locking pole clamp to prevent unauthorized removal of the infuser from the IV pole. The PCA key must be placed in the lock and turned to the unlocked position for attaching and removing the infuser from an IV pole.
Page 46 Setup and Operation 5. Press down and pull up on the infuser to confirm that it is clamped tightly to the IV pole with no vertical or rotational slippage (see Figure 2-3). If the infuser is not clamped tightly, realign the infuser with the IV pole and tighten the pole clamp knob.
Page 47: Removing An Infuser From An Iv Pole
4. With the pole clamp retracted, remove the infuser from the pole. Administration Sets Hospira LifeCare PCA administration sets are disposable and designed for single-patient use. Fluid pathways and surfaces beneath unopened...
Page 48 Setup and Operation WARNING FAILURE TO USE A COMPATIBLE HOSPIRA VIAL/INJECTOR AND HOSPIRA LIFECARE PCA ADMINISTRATION SET WITH INTEGRAL PRESSURE ACTIVATED VALVE MAY CAUSE AN INACCURATE DOSE DELIVERY TO THE PATIENT. WARNING H O S P I R A R E C O M M E N D S T H A T H I G H L Y V I S C O U S...
Page 49 LifeCare PCA Infusion System The LifeCare PCA administration set shown in Figure 2-4 is available in varying configurations and can be used in any delivery mode. Figure 2-5 shows the injector assembly. KVO SIDE (PIGTAIL) PCA LINE 1. Pressure activated valve with cap 5.
Page 50: Priming The Administration Set
Setup and Operation Priming the Administration Set CAUTION: A LWAYS PRIME THE ADMINISTRATION SET TO REMOVE AIR FROM THE SET PRIOR TO CONNECTING TO THE PATIENT Manually Priming the Administration Set Prior to priming, inspect the vial for damage, including leaks and cracks, and inspect the administration set for anomalies and/or irregularities.
Page 51: Priming The Administration Set On The Infuser
LifeCare PCA Infusion System 8. Close the orange slide clamp on the PCA side of the administration set. 9. To prime the KVO side of the set, close the slide clamp below the vial and open the clamp on the KVO side. Attach the...
Page 52 Setup and Operation 2. The ISCONNECT ET FROM ATIENT MORPHINE screen displays. Disconnect 5 mg/mL MEDSURG administration set from patient DISCONNECT > and press CONTINUE SET FROM PATIENT AND PRESS CONTINUE CONTINUE 3. Confirm the administration set MORPHINE is disconnected from the patient, 5 mg/mL MEDSURG >...
Page 53 LifeCare PCA Infusion System 5. The screen RIME OMPLETE MORPHINE displays. 5 mg/mL MEDSURG Priming is complete when all PRIME COMPLETE? air has been removed and fluid is observed at the end of the administration set. > If prime is complete, select YES to continue.
Page 54: Loading A Vial
Setup and Operation 8. The screen displays OCKED MORPHINE and the infuser indicates to press 5 mg/mL MEDSURG the [START] button to infuse. DOOR LOCKED If a loading dose was programmed, PRESS the loading dose will infuse. START BUTTON TO BEGIN Once the loading dose is delivered, the infuser prompts the user to press [START] to begin delivery of...
Page 55 LifeCare PCA Infusion System 4. Squeeze the top of the cradle release mechanism and move down until the vial injector snaps into the bottom bracket. CAUTION: G RASP THE CRADLE RELEASE MECHANISM AND SQUEEZE COMPLETELY ONTINUE TO SQUEEZE THE RELEASE MECHANISM DURING MOVEMENT OF THE...
Page 56 Setup and Operation Figure 2-6. Loading a Vial 2-14 System Operating Manual...
Page 57: Vial Changes And Discontinuing Therapy
LifeCare PCA Infusion System Vial Changes and Discontinuing Therapy This section applies to both standalone infusers and Hospira MedNet enabled devices. WARNING ALWAYS CLOSE THE SLIDE CLAMP ON THE LIFECARE PCA ADMINISTRATION SET BEFORE REMOVING OR REPLACING THE SYRINGE, AND BEFORE DISCONTINUING INFUSION.
Page 58: Changing Or Removing A Vial With Different Medication And/Or Concentration
Setup and Operation CAUTION: V ERIFY MEDICATION AND CONCENTRATION WITH PHYSICIAN ORDER 7. Verify the medication and MORPHINE concentration, then select 1 mg/mL > CONFIRM CONFIRM 1 mg/mL MORPHINE 8. Close and lock the door TO RX REMOVE VIAL and press [START]. IF NOT CORRECT CONFIRM Changing or Removing a Vial with Different...
Page 59 LifeCare PCA Infusion System 6. The screen displays options MORPHINE PF to CLEAR HISTORY , CLEAR RX , 1 mg/mL CLEAR BOTH , or CONTINUE . > Press CONTINUE to automatically clear the current program. CLEAR HISTORY CLEAR RX Note: Press CLEAR HISTORY >...
Page 60: Discontinuing Apca Therapy
7. Clean and store the infuser. CAUTION: T O PROLONG THE LIFE OF THE LIFECARE PCA INFUSER HOSPIRA RECOMMENDS STORING THE INFUSER CONNECTED TO AC MAINS POWER 2-18 System Operating Manual...
Page 61: Chapter 3 Modes Of Delivery
• PCA ONLY • CONTINUOUS ONLY • PCA + CONTINUOUS To program these modes for LifeCare PCA infusers using Hospira MedNet Software, see Chapter 4 Programming Infusers with Hospira MedNet Software. To program these modes for standalone LifeCare PCA infusers,...
Page 62: Continuous
Modes of Delivery The screen message alerts the user that the LifeCare PCA infuser is not available, and a different audible tone occurs if the patient pendant button is pressed (unless deactivated in Biomed Mode). Note: On infusers with the default drug library, dose limit periods are specified as 1 and 4 hours.
Page 63: Pca + Continuous
LifeCare PCA Infusion System PCA + Continuous A programmed PCA + Continuous infusion is started by pressing [START/STOP] after the door is closed and locked. Once the message appears, the patient may initiate a PCA dose VAILABLE by pressing the patient pendant button.
Page 64: Dose Limit
Modes of Delivery Dose Limit To program a dose limit, see Chapter 4 Programming Infusers with Hospira MedNet Software Chapter 5 Programming Infusers without Hospira MedNet Software. The dose limit is a value prescribed by the physician to limit the total dosage delivered in a 4-hour or 1-hour period.
Page 65: Programming Infusers With Hospira Mednet Software
Hospira MedNet Software This chapter describes how to program the LifeCare PCA infuser with the Hospira MedNet custom drug library. The drug library is based on hospital-defined best practices and is customized and downloaded into the infuser by authorized hospital personnel.
Page 66: Warnings And Cautions
Programming Infusers with Hospira MedNet Software Warnings and Cautions This section presents known infuser programming cautions. WARNING FOR CUSTOM SYRINGES, CONFIRM THAT THE DISPLAYED CONCENTRATION (mg/mL) OR (mcg/mL) EXACTLY MATCHES THE CONCENTRATION VALUE AND MEDICATION NAME ON THE SYRINGE. IF THEY DO NOT MATCH, UNDER/ OVERDOSAGE MAY RESULT.
Page 67: Loading Dose/Dose Limits
1. Press [ON/OFF] to turn on LifeCare PCA the infuser. SELF TEST Upon initial start up, the self test begins. It may take several seconds for the Hospira logo to appear on the screen. System Operating Manual...
Page 68 Programming Infusers with Hospira MedNet Software 2. When the self test is complete, LifeCare PCA > select SYSTEM SETTINGS to view SELF TEST menu. ELECT ETTING TO HANGE COMPLETE RAM..... FLASH..OK CPU ID..CPU..... TIMER..OK SYSTEM SETTINGS CONTINUE >...
Page 69: Adjusting Contrast Of Main Display
LifeCare PCA Infusion Adjusting Contrast of Main Display > 1. Select CONTRAST SELECT SETTING TO CHANGE CONTRAST TIME/DATE CONTINUE > > 2. Press the LIGHTER or DARKER softkey repeatedly until contrast ADJUST LCD is optimized for viewing, CONTRAST TO DESIRED LEVEL &...
Page 70: Adjusting Time And Date
Programming Infusers with Hospira MedNet Software Adjusting Time and Date WARNING CHANGING THE TIME OR DATE WILL CLEAR ALL TOTALS. THE CURRENT PROGRAM WILL REMAIN INTACT WHEN THE TIME/DATE FUNCTION IS ACCESSED. LOCKOUTS OR LIMITS IN PLACE WHEN THE TIME/DATE IS CHANGED WILL REMAIN IN EFFECT.
Page 71 LifeCare PCA Infusion 3. Using the numeric keypad, set the time in four-digit format SET TIME WITH (HH:MM). For example, enter NUMBER BUTTONS 10:43 PM as 10:43. TOGGLE AM/PM > Select AM to alternate 10:43 PM between AM and PM. AM/PM Time may be displayed using the NEXT...
Page 72: Programming Apca Therapy
Programming Infusers with Hospira MedNet Software Programming a PCA Therapy For detailed startup information including vial insertion, clearing settings, and setting a Loading Dose, see Loading a Vial. Turning On the Infuser The LifeCare PCA infuser can be turned on in either of two ways...
Page 73 LifeCare PCA Infusion 2. Once the self test is complete, LifeCare PCA > select CONTINUE to advance SELF TEST to the next screen. COMPLETE RAM..... Note: To change contrast and/or FLASH..OK CPU ID..time and date, see System CPU..... Settings.
Page 74 Programming Infusers with Hospira MedNet Software Note: If the wrong CCA is unintentionally chosen, turn the infuser off, then on, and select the correct CCA. For changing a CCA and selecting a CCA when using protocols, Changing the CCA. Once the CCA is selected, the...
Page 75 LifeCare PCA Infusion 6. Set loading dose (if desired) MORPHINE PF > by selecting YES 1 mg/mL MEDSURG > In this example, YES is selected. SET LOADING DOSE? If no loading dose is desired, > select NO to proceed with programming.
Page 76 Programming Infusers with Hospira MedNet Software 9. Using the numeric keypad, MORPHINE PF enter the desired PCA dose, 1 mg/mL then press [ENTER]. ENTER PCA DOSE THEN PRESS ENTER BUTTON 2 mg milligrams PREVIOUS 10. Enter a lockout interval value.
Page 77 LifeCare PCA Infusion CAUTION: V ERIFY PROGRAM VALUES 12. Verify loading dose settings, MORPHINE PF > then select CONFIRM 1 mg/mL PCA ONLY LOADING DOSE 2 mg CONFIRM PREVIOUS 13. Verify program values, then select MORPHINE PF > CONFIRM 1 mg/mL PCA ONLY PCA DOSE 14.
Page 78 Programming Infusers with Hospira MedNet Software 16. The screen displays OCKED MORPHINE 5 mg/mL and the infuser indicates to press MEDSURG the [START] button to infuse. DOOR LOCKED Note: Open the slide clamp on the PRESS START BUTTON LifeCare PCA administration set TO INFUSE prior to starting the therapy.
Page 79: Programming Apca + Continuous Therapy
Upon initial startup, SELF TEST the self test begins. It may take several seconds for the Hospira logo to appear on the screen. This screen is followed by a self test information screen that includes time, date, software version, and drug library.
Page 80 Programming Infusers with Hospira MedNet Software 3. The screen displays ATIENT if the infuser has been off for 5 > > PATIENT? hours or less. Select YES or NO > If YES is selected, the History and Rx settings are cleared.
Page 81 LifeCare PCA Infusion Once the CCA is selected, ISTORY AND ETTINGS LEARED screen displays briefly, then HISTORY AND transitions to the medication RX SETTINGS CLEARED confirmation screen. CAUTION: ERIFY MEDICATION AND C O N C E N T R A T I O N W I T H PHYSICIAN ORDER 5.
Page 82 Programming Infusers with Hospira MedNet Software 7. Using the numeric keypad, enter MORPHINE PF a loading lose, then press [ENTER] 1 mg/mL MEDSURG to continue. ENTER LOADING DOSE To correct an entry, press [CLR], THEN PRESS ENTER BUTTON re-enter the value, then press [ENTER].
Page 83 12. Using the numeric keypad, enter MORPHINE PF the dose limit, then press [ENTER]. 1 mg/mL ENTER 4 HOUR Note: The Hospira MedNet DOSE LIMIT Software/Drug Library dose limit THEN PRESS ENTER BUTTON periods may be defined as 1, 4, 6, or 12 hours, or as No Dose Limit.
Page 84 Programming Infusers with Hospira MedNet Software CAUTION: V ERIFY PROGRAM VALUES 13. Verify Loading Dose settings, MORPHINE PF > then select CONFIRM 1 mg/mL PCA ONLY LOADING DOSE 2 mg CONFIRM PREVIOUS 14. Verify program settings, then select MORPHINE PF >...
Page 85 LifeCare PCA Infusion 16. Once the door is closed and MORPHINE locked, the RIME UBING 5 mg/mL MEDSURG screen displays. > In this example, NO is selected. PRIME TUBING? Note: To prime the administration set on the infuser, see Chapter 2 Setup and Operation.
Page 86: Programming A Continuous Therapy
Programming Infusers with Hospira MedNet Software The dose is delivered when the patient presses the patient pendant button. If the patient pendant button is partially pressed, a message appears. This is corrected ENDANT AULT by releasing the patient pendant button.
Page 87: Programming A Loading Dose
1. Power on the infuser. Upon initial LifeCare PCA startup, the self test begins. SELF TEST It may take several seconds for the Hospira logo to appear on the screen. This screen is followed by a self test information screen that includes time, date, software version, and drug library.
Page 88 Programming Infusers with Hospira MedNet Software Note: The (Clinical Care Area) screen ELECT displays if a drug library is installed with more than one CCA. Select the option appropriate for the patient. If there is only one CCA, this screen will not display.
Page 89 LifeCare PCA Infusion CAUTION: V ERIFY MEDICATION AND CONCENTRATION WITH PHYSICIAN ORDER 5. Verify that the displayed MORPHINE PF medication and concentration 1 mg/mL > are correct, then select CONFIRM CONFIRM 1 mg/mL MORPHINE PF Note: If the medication is not TO RX correct, remove the vial and REMOVE VIAL...
Page 90 Programming Infusers with Hospira MedNet Software 8. The screen ELECT ELIVERY MORPHINE PF > appears. Select CONTINUOUS 1 mg/mL MEDSURG to continue. SELECT DELIVERY MODE PCA ONLY PCA + CONT. CONTINUOUS PROTOCOLS PREVIOUS 9. Using the numeric keypad, MORPHINE PF...
Page 91 LifeCare PCA Infusion 11. Verify loading dose settings, MORPHINE PF > then select CONFIRM 1 mg/mL PCA ONLY LOADING DOSE 2 mg CONFIRM PREVIOUS 12. Verify program settings, then select MORPHINE PF > > CONFIRM , or, select PREVIOUS 1 mg/mL PCA+CONT.
Page 92 Programming Infusers with Hospira MedNet Software 15. The screen displays OCKED MORPHINE 5 mg/mL and the infuser indicates to press MEDSURG the Start button to infuse. DOOR LOCKED Note: Open the slide clamp on the PRESS START BUTTON LifeCare PCA administration set TO INFUSE prior to starting the therapy.
Page 93: Drug Library: Soft Limit, Hard Limit, And Rule Set
LifeCare PCA Infusion Drug Library: Soft Limit, Hard Limit, and Rule Set Hospira MedNet Software provides the ability to build a drug library based on hospital-defined best practices. The customized drug library is downloaded into the infuser by authorized hospital personnel.
Page 94: Hard Limit Violation
Programming Infusers with Hospira MedNet Software The Upper and Lower MORPHINE 5 mg/mL soft limit override symbols MEDSURG are displayed during delivery PCA+CONT. to inform the user that one PCA AVAILABLE NO 4 HR LIMIT or more soft limits have been 40 mg overridden.
Page 95: Rule Sets Caution
LifeCare PCA Infusion Rule Sets Caution MORPHINE PF The Caution symbol is displayed 1 mg/mL MEDSURG on the infusion screen to advise the user to program with caution because PCA+CONT. PCA AVAILABLE the established rule set does not have NO 4 HR LIMIT 40 mg any soft or hard safety limits.
Page 96 Programming Infusers with Hospira MedNet Software > 2. Select CHANGE CCA to change MORPHINE PF the setting. 1 mg/mL CARDIOLOGY PAUSED PCA + CONT. LOCK DOOR TO BEGIN CHANGE RX CLEAR SHIFT CHANGE CCA 3. The screen displays, TTENTION MORPHINE PF...
Page 97: Updating The Drug Library
New drug libraries are available for installation when turning off the infuser. Note: If communication is lost with Hospira MedNet, a new drug library will not be able to be downloaded. The following section describes how to accept a new drug library on the infuser.
Page 98: Auto-Programming
For example, if a soft limit violation is encountered, proceed as in manual programming. Note: If communication is lost with Hospira MedNet, the infuser will not be able to receive auto-programs and report events or alarms to the HIS/EMR system until the connection is re-established.
Page 99 LifeCare PCA Infusion The Wireless symbol is displayed MORPHINE to inform the user that the LifeCare 1 mg/mL MEDSURG PCA infuser has an active connection WAITING FOR to the wireless network. AUTO PROGRAM The wireless icon is only displayed on the AITING FOR ROGRAM screen.
Page 100 Programming Infusers with Hospira MedNet Software Note: If the scanned medication does not exist in the Hospira MedNet Meds medication library, or if the custom drug is disabled in Biomed mode, an invalid bar code alarm will be activated CAUTION: V ERIFY PROGRAM VALUES >.
Page 101 LifeCare PCA Infusion Rejected Auto-Program Should you scan a medication vial which does not match the physician order entry, the infuser displays the following: Message: Med does not match order. Remove the vial and insert the correct vial. Corrective Action: Remove the incorrect medication vial. Scan the correct vial, then load the vial into the infuser.
Page 102 Programming Infusers with Hospira MedNet Software NOTES 4-38 System Operating Manual...
Page 103: Programming Infusers Without Hospira Mednet Software
Programming Infusers without Hospira MedNet Software This chapter describes how to program the LifeCare PCA infuser using the default drug library and a Hospira pre-filled and pharmacy-filled (custom) vial. Programming instructions will be provided for the following: • Loading Dose •...
Page 104: Warnings And Precautions
Programming Infusers without Hospira MedNet Software Warnings and Precautions WARNING FOR CUSTOM SYRINGES, CONFIRM THAT THE DISPLAYED CONCENTRATION (mg/mL) OR (mcg/mL) EXACTLY MATCHES THE CONCENTRATION VALUE AND MEDICATION NAME ON THE SYRINGE. IF THEY DO NOT MATCH, UNDER/ OVERDOSAGE MAY RESULT.
Page 105: Loading Dose/Dose Limits
LifeCare PCA Infusion System Loading Dose/Dose Limits • The loading dose is always included in the total dose delivered. • Setting a new dose limit will not erase the previous dose history. • Always monitor the LifeCare PCA infuser when delivering medication with the door open.
Page 106 Programming Infusers without Hospira MedNet Software 1. Open the security door and press LifeCare PCA [ON/OFF] to turn on the infuser. SELF TEST Upon initial startup, the self test begins. It may take several seconds for the Hospira logo to appear on the screen.
Page 107: Adjusting Time And Date
LifeCare PCA Infusion System > 4. Select CONTRAST . Press the > > LIGHTER or DARKER softkey ADJUST LCD CONTRAST TO repeatedly until contrast DESIRED LEVEL is optimized for viewing, & > then select SAVE EXIT LIGHTER DARKER CANCEL SAVE & EXIT...
Page 108 Programming Infusers without Hospira MedNet Software 3. Using the numeric keypad, set the time in four-digit format SET TIME WITH (HH:MM). For example, enter NUMBER BUTTONS 10:43 PM as 10:43. TOGGLE AM/PM > Select AM to alternate 10:43 PM between AM and PM.
Page 109: Programming Apca Therapy
LifeCare PCA Infusion System Programming a PCA Therapy For detailed startup information including priming the LifeCare PCA administration set, loading a vial, and programming a Loading Dose, see Loading a Vial. For information on adjusting system values such as contrast,...
Page 110 1. Power on the infuser. Upon initial LifeCare PCA startup, the self test begins. SELF TEST It may take several seconds for the Hospira logo to appear on the screen. This screen is followed by a self test information screen that includes time, date, software version, and drug library.
Page 111 LifeCare PCA Infusion System > In this example, the YES option is selected. The ISTORY AND screen displays ETTINGS LEARED HISTORY AND briefly, then transitions to the RX SETTINGS CLEARED medication confirmation screen. CAUTION: ERIFY MEDICATION AND C O N C E N T R A T I O N W I T H PHYSICIAN ORDER 4.
Page 112 Programming Infusers without Hospira MedNet Software 7. The screen ELECT ELIVERY MORPHINE PF > appears. Select PCA ONLY 1 mg/mL MEDSURG to continue. SELECT DELIVERY MODE PCA ONLY PCA + CONT. CONTINUOUS PROTOCOLS PREVIOUS 8. Using the numeric keypad, enter...
Page 113 LifeCare PCA Infusion System 10. The screen ET A IMIT MORPHINE PF displays. Set a specific dose 1 mg/mL > limit by selecting YES SET A DOSE advance to the IMIT NTER LIMIT? screen. ALUE > Note: Select NO to choose no dose limit.
Page 114 Programming Infusers without Hospira MedNet Software 13. Verify program values, then select MORPHINE PF > CONFIRM 1 mg/mL PCA ONLY PCA DOSE 14. Close and lock the door. 2 mg Place the key in a secure location. LOCKOUT 5 min...
Page 115: Programming Apca + Continuous Therapy
LifeCare PCA Infusion System After a PCA dose is delivered, MORPHINE PF PCA L the infuser enters the OCKOUT 1 mg/mL PCA ONLY interval. After the lockout time has elapsed, the next PCA dose PCA LOCKOUT NO 4 HR LIMIT is available.
Page 116 Programming Infusers without Hospira MedNet Software 1. Power on the infuser. Upon initial LifeCare PCA startup, the self test begins. SELF TEST It may take several seconds for the Hospira logo to appear on the screen. This screen is followed by...
Page 117 LifeCare PCA Infusion System > If the YES option is selected, ISTORY AND ETTINGS LEARED screen displays briefly, then HISTORY AND transitions to the medication RX SETTINGS CLEARED confirmation screen. CAUTION: ERIFY MEDICATION AND C O N C E N T R A T I O N W I T H PHYSICIAN ORDER 4.
Page 118 Programming Infusers without Hospira MedNet Software 7. The screen appears. Select PCA ELECT ELIVERY .> CONT to continue (see Modes of Delivery). 8. Using the numeric keypad, enter the desired PCA dose, then press [ENTER]. 9. Using the numeric keypad, enter a desired lockout interval value, then press [ENTER].
Page 119 LifeCare PCA Infusion System 12. Using the numeric keypad, enter MORPHINE PF the dose limit value (the range 1 mg/mL is displayed on the screen), ENTER 4 HOUR then press [ENTER]. DOSE LIMIT THEN PRESS ENTER BUTTON The dose limit periods may be...
Page 120 Programming Infusers without Hospira MedNet Software 16. Once the door is closed and locked, MORPHINE screen displays. RIME UBING 5 mg/mL MEDSURG > For this example, NO is selected. Note: To prime the administration PRIME TUBING? set on the infuser, see...
Page 121: Programming A Continuous Therapy
LifeCare PCA Infusion System Note: The infuser will deliver medication only when the door is closed and locked. Note: To stop a continuous mode delivery in progress, press the [START/STOP] button. When the patient presses the PCA patient pendant button, the PCA dose is delivered.
Page 122: Turning On The Infuser
Programming Infusers without Hospira MedNet Software Turning On the Infuser The LifeCare PCA infuser can be turned on in either of two ways after opening the security door: Press the [ON/OFF] button, Loading the medication vial into the cradle will automatically...
Page 123 LifeCare PCA Infusion System 3. The screen displays if ATIENT the infuser has been off for 5 hours > > PATIENT? or less. Select YES or NO > If YES is selected, the History and Rx settings are cleared. >...
Page 124 Programming Infusers without Hospira MedNet Software > Select PREVIOUS to return to the preceding screen if programming changes need to be made. 8. Using the numeric keypad, enter MORPHINE PF the Continuous rate, then press 1 mg/mL [ENTER]. ENTER PCA DOSE...
Page 125 LifeCare PCA Infusion System 12. Verify program values, MORPHINE PF > then select CONFIRM 1 mg/mL CONTINUOUS > Note: Select PREVIOUS to return to the preceding screen. CONT. RATE 13. Close and lock the door. 2 mg/hr 4 HOUR LIMIT Place the key in a secure location.
Page 126: Programming With A Pharmacy-Filled (Custom) Vial
A custom vial is a sterile empty vial which is filled by the hospital pharmacy. Custom vials without a pharmacy-generated bar code can only be used with the default drug library (without Hospira MedNet software). displays, indicating that the custom vial is filled by the THER hospital pharmacy.
Page 127 LifeCare PCA Infusion System 2. Once the self test is complete, LifeCare PCA > select CONTINUE to advance SELF TEST to the next screen. COMPLETE RAM..... FLASH..OK CPU ID..CPU..... TIMER..OK SYSTEM SETTINGS CONTINUE 3. The screen displays if...
Page 128 Programming Infusers without Hospira MedNet Software After verifying medication and concentration, > select CONFIRM 5. Select desired units of measure. OTHER DRUG For demonstration purposes > MILLIGRAMS is selected. SELECT UNITS OF MEASURE Note: When using micrograms (mcg), only whole numbers may MILLIGRAMS be entered.
Page 129 LifeCare PCA Infusion System 8. Set the loading dose (if desired) OTHER DRUG > by selecting YES . If no loading 10 mg/mL > dose is desired, select NO SET LOADING to proceed with programming. DOSE? 9. Using the numeric keypad, enter...
Page 130 Programming Infusers without Hospira MedNet Software NOTES 5-28 System Operating Manual...
Page 131: Reviewing And Changing Rx Supplemental
LifeCare PCA Infusion System Chapter 6 Reviewing and Changing Rx Supplemental Loading Dose The following is consistent throughout all programming: To correct an entry during programming, press [CLR], • re-enter the value, then press [ENTER]. • During initial programming, select PREVIOUS> to return to the preceding display and enter the desired setting.
Page 132: Changing The Current Program
Reviewing and Changing Rx Supplemental Loading Dose Changing the Current Program 1. Stop the infuser by pressing the !! ALARM [START/STOP] button. The NFUSER INFUSER screen displays. Unlock TOPPED STOPPED and open the door. CLOSE TUBING SLIDE CLAMP WHEN WARNING HANDLING VIAL PRESS START C L O S E T H E T U B I N G...
Page 133 LifeCare PCA Infusion System 4. Once the desired setting has been MORPHINE PF selected (in this example, PCA 1 mg/mL Dose), using the numeric keypad, ENTER enter the desired PCA dose, PCA DOSE then press [ENTER]. THEN PRESS ENTER BUTTON...
Page 134 Reviewing and Changing Rx Supplemental Loading Dose 7. The screen displays OCKED MORPHINE 5 mg/mL and the infuser indicates to press MEDSURG the [START] button to infuse. DOOR LOCKED If a loading dose was programmed, PRESS START BUTTON the loading dose will infuse first. TO INFUSE 2 mg LOADING DOSE...
Page 135: Programming A Supplemental Loading Dose
LifeCare PCA Infusion System Programming a Supplemental Loading Dose A supplemental loading dose (clinician-activated bolus) can be programmed anytime after initiation therapy. After a loading or supplemental loading dose delivery, the patient cannot receive any additional patient-requested boluses until the...
Page 136 LOADING DOSE THEN PRESS ENTER BUTTON To make additional programming changes, select PREVIOUS> 2 mg to return to the preceding screen. milligrams Note: The value range is displayed PREVIOUS on the screen for devices without Hospira MedNet Software. System Operating Manual...
Page 137 LifeCare PCA Infusion System 5. Press SAVE & EXIT> to advance MORPHINE to the Confirmation screen. 1 mg/mL MEDSURG SELECT SETTING TO CHANGE LOADING DOSE MODE CONT. RATE NEXT SAVE & EXIT CAUTION: V ERIFY PROGRAM VALUES 6. Verify loading dose entry, MORPHINE PF then select CONFIRM>.
Page 138 Reviewing and Changing Rx Supplemental Loading Dose 7. Verify program settings, then select MORPHINE PF > CONFIRM>, or select PREVIOUS 1 mg/mL PCA ONLY to return to the preceding screen. PCA DOSE 2 mg LOCKOUT 5 min 4 HOUR LIMIT 40 mg CONFIRM PREVIOUS...
Page 139: Battery And Wireless Status History And Event Log
Note: For facilities using Hospira MedNet Software, the data is stored both on the infuser and on the facility’s server. For more information on reporting capabilities, see the Hospira MedNet Meds User Guide. System Operating Manual...
Page 140 Battery and Wireless Status History and Event Log The [HISTORY/BATTERY] button is used to display the following events: • Battery strength indicator and wireless strength indicator status • Current program settings for the clinician to review and verify the current physician order •...
Page 141: Data Retention
LifeCare PCA Infusion System Note: PCA requested doses (patient demands) as recorded in the history display and event log may not reflect the total number of demands. (Maximum of 100 patient demands per 10-minute interval.) Data Retention Delivery program settings and programming option selections are retained in memory unless erased.
Page 142 Battery and Wireless Status History and Event Log The [HISTORY/BATTERY] button is used to display the following events: • Current program settings for the clinician to review and verify the current physician order • Shift totals, 1-hour totals, 24-hour totals •...
Page 143 LifeCare PCA Infusion System and the history totals HOUR-BY-HOUR LAST 1 & 24 HOUR represent a dynamic summation of past delivery of drugs and events. Data is accumulated in 10-minute increments. • measures from the top of the hour to the HOUR-BY-HOUR next (for example, 08:00A-09:00A;...
Page 144 Battery and Wireless Status History and Event Log ******************************************** HOSPIRA LifeCare PCA PATIENT RECORD ******************************************** SERIAL NUMBER: 00000143 SOFTWARE VERSION: PATIENT NAME: DRUG ADMINISTERED: PM 04:52 MAY 17 201 MODE: PCA + CONTINUOUS SETTINGS: MORPHINE PF 1 mg/mL CCA :...
Page 145 LifeCare PCA Infusion System 04:51P CHECK SYRINGE ALARM 04:51P CHECK INJECTOR ALARM 04:51P CHECK SYRING ALARM 04:51P CHECK VIAL ALARM 04:51P BAR CODE NOT READ ALARM 04:51P CHECK VIAL ALARM 04:50P BAR CODE NOT READ ALARM 04:50P CHECK SYRINGE ALARM...
Page 146 Battery and Wireless Status History and Event Log 12:14P START INFUSION 12:14P DOOR LOCKED 12:14P CONFIRM 4 HR LIMIT 55 mg 12:14P CONFIRM CONT. RATE 1 mg/hr 12:14P CONFIRM PCA LOCKOUT 15 min 12:14P CONFIRM PCA DOSE 3 mg 12:14P CONFIRM PCA + CONT. MODE 12:14P MORPHINE PF 1 mg/mL 12:14P SET 4 HR LIMIT...
Page 147 LifeCare PCA Infusion System 08:20A NEW PATIENT NOT SELECTED 08:19A BATTERY AVAILABLE 08:19A USING BATTERY 08:19A CHECK INJECTOR ALARM 08:19A POWER ON MAY 17 08:18A POWER OFF MAY 17 08:18A DOOR OPENED 08:18A CHECK SETTINGS ALARM 08:18A DOOR LOCKED 08:18A DOOR OPENED...
Page 148: Checking History And Settings
Note: The Print History option SCROLL THROUGH is only available for infusers HISTORY without Hospira MedNet Software. PRINT HISTORY Note: See the Hospira MedNet User Guide to generate reports. 3. If MORE is displayed, continue MORPHINE to press [HISTORY/BATTERY] 1 mg/mL PCA+CONT.
Page 149: Clearing Shift Totals
LifeCare PCA Infusion System Note: Partial boluses can be the result of interrupting delivery by pressing [START/STOP] (PCA + Cont.), opening the door (PCA Only), loss of power, reaching the dose limit, emptying the vial, or a malfunction alarm. 4. Press [EXIT] to return to the screen.
Page 150 Battery and Wireless Status History and Event Log 3. Select CLEAR SHIFT> to display MORPHINE PF screen. LEAR HIFT OTALS 1 mg/mL Select YES> to clear shift totals CLEAR SHIFT TOTALS? and return to the previous screen. Select NO> to return to previous screen.
Page 151: Chapter 8 Maintenance
LifeCare PCA Infusion System Chapter 8 Maintenance This chapter addresses the following: • Cleaning and Disinfecting • Battery Maintenance • Service • Product Handling and Disposal • Storage Cleaning and Disinfection Clean and disinfect the LifeCare PCA infuser between each patient use.
Page 152 Maintenance WARNING DISCONNECT THE INFUSER FROM AC POWER PRIOR TO OPENING THE DEVICE, CHANGING THE BATTERY, OR CLEANING THE DEVICE. FAILURE TO COMPLY WITH THIS WARNING COULD RESULT IN ELECTRICAL SHOCK. WARNING FAILURE TO CLEAN THE INFUSER’S OUTSIDE SURFACES AFTER PATIENT USE MAY SPREAD INFECTION. HOSPITAL INFECTION CONTROL POLICIES SHOULD BE FOLLOWED.
Page 153: Cleaning
Enzymatic Detergent Use per manufacturer's ™ ASP Enzol recommendations and instructions in this manual Note: At the time of publication, Hospira recommends only the cleaning solution in Table 8-1. For updated listings of approved cleaners, visit www.hospiraparts.com. System Operating Manual...
Page 154 Maintenance Cleaning Supplies To clean the infuser, use clean, soft, lint-free cloths moistened with an approved cleaning solution or commercial wipes (see Table 8-1). To remove soil from hard-to-reach areas, use cotton-tipped or foam-tipped swabs. Note: If using cotton-tipped swabs, ensure they do not leave a fiber residue.
Page 155 LifeCare PCA Infusion System General Cleaning Instructions To clean the infuser, use the methods shown in Table 8-2. Table 8-2. Cleaning Methods Type of Cleaning Method Instrument Lint-Free Cloth 1. Wearing gloves, dampen the cloth with the approved cleaning solution and wipe in an outward spiral pattern on the desired surface(s).
Page 156 Maintenance Table 8-2. Cleaning Methods Type of Cleaning Method Instrument Foam 1. Wearing gloves, dip a swab in an approved or Cotton-Tipped cleaning solution. Swab 2. Press the tip against the solution container to remove excess fluid. 3. Use the swab to clean hard to reach areas. Change swabs as needed.
Page 157 LifeCare PCA Infusion System Table 8-3 describes time intervals, in minutes, for cleaning. Table 8-3. Time Intervals for Cleaning Enzol Enzol Enzol Tap Water Total Dry Wiping Brushing Swabbing Rinsing Time Time Time Time Time (min) (min) (min) (min) (min) 1/surface Wiping, Brushing, Rinsing, and Dry time is per infuser.
Page 158 Maintenance 5. Using lint-free cloths dampened in the approved cleaning solution or wipes, wipe the top and side surfaces. Use a combination of brush and swab as needed to clean the seam that joins the front and rear parts of the infuser case highlighted in Figure 8-1.
Page 159 LifeCare PCA Infusion System Note: Do not allow fluid into any ports or vents on the infuser. Note: Do not allow fluid to flow behind the pole clamp knob. 5. Using a lint-free cloth dampened in the approved cleaning solution or wipes, wipe areas around the power cord outlet, the power cord, and the plug, including prongs.
Page 160 Maintenance To clean the front of the infuser, proceed as follows: 1. Turn the infuser upright to view the front of the infuser (see Figure 8-3). 2. Using a lint-free cloth dampened in the approved cleaning solution or wipes, carefully wipe the keypad and display screen highlighted in Figure 8-3.
Page 161 LifeCare PCA Infusion System 3. Using a lint-free cloth dampened in the approved cleaning solution (see Table 8-1) or wipes, wipe the vial compartment door, including the door hinge, all interior and exterior surfaces, and the infuser housing vial door recess highlighted Figure 8-4.
Page 162 Maintenance Cleaning the Vial Compartment Spilled fluid that is not cleaned properly and promptly at the patient site may accumulate and dry. If sticky or high-viscosity fluids are spilled in the vial compartment, clean the infuser as soon as possible. Dried, built-up residue from these types of fluids can affect the operation of the vial sensor pin, injector sensor pin, and cradle mechanism.
Page 163 LifeCare PCA Infusion System Figure 8-5. Cleaning the Vial Compartment 3. Turn the infuser upright and open the vial compartment door. 4. Clean the bar code reader window. • Use recommended CleanTex CT 811 OpticPad Optic Surface Cleaner or a soft, lint-free cloth moistened with a streak-free optical glass cleaner for cleaning, and wipe until visibly clean.
Page 164 Maintenance 5. Using swabs, carefully clean the cradle release mechanism, vial cradle, vial cradle clips, and injector flange retainer, including the vial and injector sensor pins, without tilting the infuser backwards. See highlighted region in Figure 8-5. Note: If a sensor pin is damaged or broken off, return the infuser to the Biomed.
Page 165 LifeCare PCA Infusion System Injector Switch Pin Hole Figure 8-6. Injector Switch Pin Location When a syringe is loaded into the infuser with the injector flange outside of the injector flange retainer and the CHECK INJECTOR alarm message does not display, inspect the injector switch pin...
Page 166 Maintenance Recommended tools and materials for this procedure are cotton swabs and a brush. See Table 8-3 for cleaning time intervals. To clean the injector switch pin, proceed as follows: 1. Using a cotton swab, clean any fluid spillage from around the injector flange retainer.
Page 167 LifeCare PCA Infusion System Use a cloth or brush to dislodge soil if needed. Wipe off excess cleaning fluid, and let the strap air dry. Cleaning Infuser Accessories Use the cleaning supplies, and follow the general cleaning instructions in Table 8-2 to clean the infuser accessories.
Page 168: Disinfection
Do not exceed 1 part ™ Clorox bleach in 10 parts water Germicidal Bleach (8.25 % concentration) Note: At the time of publication, Hospira recommends only the disinfecting solution in Table 8-4. For updated listings of approved cleaners, visit www.hospiraparts.com. 8-18 System Operating Manual...
Page 169 LifeCare PCA Infusion System Disinfection Supplies To disinfect the infuser, use clean, soft, lint-free cloths moistened with an approved disinfectant, or disposable commercial wipes (see Table 8-4). To disinfect hard-to-reach areas, use cotton-tipped or foam- tipped swabs. Note: If using cotton-tipped swabs, ensure they do not leave a fiber residue.
Page 170 Maintenance Table 8-5. Disinfection Methods Type of Disinfection Method Instrument Lint-Free Cloth 1. Wearing gloves, dampen the cloth with approved disinfecting solution (see Table 8-4) and wipe in an outward spiral pattern on the desired surfaces. 2. When the cloth becomes soiled, start wiping with the unsoiled part of the cloth.
Page 171 LifeCare PCA Infusion System Table 8-5. Disinfection Methods Type of Disinfection Method Instrument Foam 1. Wearing gloves, dip a swab in the approved disinfecting solution Cotton-Tipped Swab (see Table 8-4). 2. Press the tip against the solution container to remove excess fluid.
Page 172 Maintenance Table 8-6. Minimum Time Intervals for Disinfecting Brushing/swabbing (hard to reach areas): 15 minutes Wiping: 15 minutes Rinsing with purified water (PURW): 3 minutes Brushing/swabbing, wiping, and rinsing times are per infuser. Apply disinfectant as often as needed to keep surfaces visually moist/wet during disinfection.
Page 173 LifeCare PCA Infusion System 9. Use brushes and swabs to disinfect hard to reach areas highlighted in Figure 8-2. 10. Using a lint-free cloth dampened in the approved disinfecting solution or wipes, wipe areas around the power cord outlet, the power cord, power cord strap, and the plug.
Page 174 Maintenance To disinfect the vial compartment door and receptacle, proceed as follows: 1. Open the vial compartment door. 2. Clean the bar code reader window. • Using CleanTex CT 811 OpticPad Optic Surface Cleaner or a streak-free optical glass cleaner, clean the bar code reader window.
Page 175 LifeCare PCA Infusion System 2. If necessary, use a lint-free cloth to force disinfectant into the fabric. Using a clean, lint-free cloth, wipe off excess disinfecting fluid and let the strap air dry. Disinfecting Accessories Use the disinfection supplies, and follow the general disinfecting...
Page 176: Cleaning Spills
Maintenance Cleaning Spills The following procedure describes how to clean non-hazardous spills or soil during the course of patient care. • Non-hazardous fluid spills should be wiped up as soon as possible, and not allowed to dry on the infuser. •...
Page 177: Battery Maintenance
LifeCare PCA Infusion System Battery Maintenance The LifeCare PCA infuser is battery powered for emergency backup and temporary portable operation. If the batteries are to be stored for more than 6 months, they should be charged to prevent damage (sulfation) to the batteries during low charge conditions.
Page 178: Service
(rated for 5 years) and SLA battery (rated for 2 years). All servicing or adjustments to the LifeCare PCA infuser should be referred to qualified technical personnel. A technical service manual may be ordered from the local Hospira sales office. Product Handling and Disposal Comply...
Page 179: Infuser Storage
LifeCare PCA Infusion System Infuser Storage To prolong the life of the LifeCare PCA infuser, observe the following storage precautions: • Store the LifeCare PCA infuser away from excessive heat, cold, and humidity • Store the LifeCare PCA infuser connected to AC (mains) power •...
Page 180 Maintenance NOTES 8-30 System Operating Manual...
Page 181: Chapter 9 Specifications
LifeCare PCA Infusion System Chapter 9 Specifications This system operating manual complies with 21 CFR 807.87(e), 21 CFR Part 801, and 21 CFR 801.109. Administration Use only compatible Hospira LifeCare Sets: PCA administration sets with Integral Pressure Activated Valves Atmospheric...
Page 182 Specifications Casing: High-impact plastic Dimensions: Approximately 8 in. W x 13 in. H x 6 in. D (excluding pole clamp and power cord) Weight: Approximately 13 lbs. with battery Delivery Rates: Table 9-1. Delivery Rates Mode Delivery Rate Approximately 1 mL in 35 seconds CONTINUOUS Variable from 0.1 x concentration (mg/hr or mcg/hr)
Page 183 LifeCare PCA Infusion System Electrical Safety: Meets IEC 60601-1 standard Table 9-2. Electrical Safety Specification Description Class 1 AC (mains) supply equipment using protective earth Type BF applied parts are those parts suitable Type BF for direct patient connections Type BF parts are not suitable for direct...
Page 184 Specifications Electrical Risk current limits meets standard Leakage: IEC 60601-1 Fuse: 1.6 A, 250 V; Slo-Blo Lockout Interval 5 to 120 minutes in 1-minute increments Range: Maximum Infusion 45 psi Pressure: Maximum The maximum overinfusion under single Overinfusion: fault conditions is 25% Occlusion Alarm 12.5 psi +2.5/-3.5 psi Pressure:...
Page 185 LifeCare PCA Infusion System Recharge: The battery charges whenever the infuser is connected to AC power After discharge to the LOW BATTERY operative limit, the battery will recharge to at least 80% of its full charge capacity within 16 hours, provided it is plugged...
Page 186: Wireless Lan Module
Specifications Wireless LAN Module Device Name: Hospira MedNet 802.11 a/b/g Wireless Module Standards: IEEE 802.11 a/b/g Transmit Power: 802.11 b/g - 17 dBm 802.11 a - 16 dBm Antenna: Integrated surface mount antenna Certifications: FCC Part 15.247, 15.407 IC RSS-210, RSS-102...
Page 187: Stored Occlusion Volume
LifeCare PCA Infusion System Stored Occlusion Volume Table 9-3. Stored Occlusion Volume Delivery Pressure Limit Stored Volume Rate (Average) (Average) 0.1 mL/hr 11.4 psi 0.77 mL 5 mL/hr 11.6 psi 0.81 mL 20 mL/hr 11.6 psi 0.80 mL PCA Dose 11.4 psi...
Page 188: Delivery Rate Accuracy
Specifications Delivery Rate Accuracy Delivery accuracy is ± 5% at continuous delivery rates greater than 1 mL/hr. This accuracy is valid within the operating temperature range stated in this chapter. For accuracy data at other flow rates, see the typical trumpet curves shown Figure 9-2.
Page 189: Trumpet Curves
LifeCare PCA Infusion System Trumpet Curves The typical trumpet curve graphs shown in Figure 9-2 show representative maximum and minimum percent flow rate deviation from the programmed rate over time. This information was developed in accordance with IEC 60601-2-24:2012, Sub- Clause 201.12.1.102.
Page 190: Example
Specifications Example From the trumpet curve graph example (see Figure 9-1), find the 5-minute interval (A) at the horizontal axis and read the corresponding points (B) and (C) on the vertical axis. The values are approximately +2.8% and -0.5%. This means that at the rate of 25 mL/hr, the average maximum flow rate fluctuation for any 5-minute time interval during the 2nd hour of operation was within the limits of +2.8% and -0.5% from the nominal rate.
Page 191: Trumpet Curves
LifeCare PCA Infusion System Trumpet Curves 0.1 mL/hr, 0 mmHg DELIVERY HEAD, START UP (Typical) -0.1 -0.2 -0.3 -0.4 Time (minutes) Actual Rate Programmed Rate 0.1 mL/hr, 0 mmHg DELIVERY HEAD (Typical) 100.0% 80.0% 60.0% 40.0% 20.0% 0.0% -20.0% -40.0% -60.0%...
Page 192 Specifications 0.5 mL/hr, 0 mmHg DELIVERY HEAD, START UP (Typical) 0.75 0.25 -0.25 -0.5 -0.75 Time (minutes) Actual Rate Programmed Rate 0.5 mL/hr, 0 mmHg DELIVERY HEAD (Typical) 25.0% 20.0% 15.0% 10.0% 5.0% 0.0% -5.0% -10.0% -15.0% -20.0% -25.0% Interval (minutes) Maximum (%) Minimum (%) Mean(%)
Page 193 LifeCare PCA Infusion System 1.0 mL/hr, 0 mmHg DELIVERY HEAD, START UP (Typical) -0.5 -1.5 Time (minutes) Actual Rate Programmed Rate 1.0 mL/hr, 0 mmHg DELIVERY HEAD (Typical) 25.0% 20.0% 15.0% 10.0% 5.0% 0.0% -5.0% -10.0% -15.0% -20.0% -25.0% Interval (minutes)
Page 194 Specifications 5.0 mL/hr, 0 mmHg DELIVERY HEAD, START UP (Typical) -2.5 -7.5 Time (minutes) Actual Rate Programmed Rate 5.0 mL/hr, 0 mmHg DELIVERY HEAD (Typical) 25.0% 20.0% 15.0% 10.0% 5.0% 0.0% -5.0% -10.0% -15.0% -20.0% -25.0% Interval (minutes) Maximum (%) Minimum (%) Mean(%) 5.0 mL/hr, 0 mm Hg DELIVERY HEAD...
Page 195 LifeCare PCA Infusion System 20.0 mL/hr, 0 mmHg DELIVERY HEAD, START UP (Typical) Time (minutes) Actual Rate Programmed Rate 20.0 mL/hr, 0 mmHg DELIVERY HEAD (Typical) 25.0% 20.0% 15.0% 10.0% 5.0% 0.0% -5.0% -10.0% -15.0% -20.0% -25.0% Interval (minutes) Maximum (%)
Page 196 Specifications Table 9-5. Bolus Delivery Accuracy Calculated Maximum Maximum Set Value (Bolus Average Positive Negative Administration Volume Deviation Deviation Deviation Set Tested in mL) from from from Set Value Set Value Set Value Minimum: List Number 3.176% 10.4% -8.3% 0.1 mL 14277 Maximum: List Number...
Page 197: Protocols
Should your facility choose to use protocols, hospital personnel will determine the protocol parameters (drug, dose, mode of delivery, etc.). Protocols can be used for Hospira pre-filled drug vials and pharmacy-filled (custom) vials. Only protocols associated with the inserted drug vial will be available.
Page 198: Programming Protocols
1. Power on the infuser. Upon initial LifeCare PCA start up, the self test begins. SELF TEST It may take several seconds for the Hospira logo to appear on the screen. 2. Once the self test is complete, LifeCare PCA >...
Page 199 LifeCare PCA Infusion 3. The N ? screen displays. ATIENT > > Select YES or NO PATIENT? > If YES is selected, the History and Rx settings are cleared. > If NO is selected, the History and RX settings are kept. Note: The N ? screen will ATIENT...
Page 200 > 6. Select NO to continue. MORPHINE PF 1 mg/mL If a loading dose is desired, MEDSURG Chapter 4 Programming SET LOADING DOSE? Infusers with Hospira MedNet Software Chapter 5 Programming Infusers without Hospira MedNet Software. 10-4 System Operating Manual...
Page 201 LifeCare PCA Infusion 7. The screen ELECT ELIVERY MORPHINE PF > appears. Select PROTOCOLS 1 mg/mL MEDSURG to continue. SELECT DELIVERY MODE > Note: Select PREVIOUS to return PCA ONLY to the preceding screen if PCA + CONT. programming changes need CONTINUOUS to be made.
Page 202: Infusers Without Hospira Mednet
Approximately 10 seconds after the door is locked, the message disappears. OCKED Infusers without Hospira MedNet Protocols are created in Biomed mode for Hospira pre-filled drug vials and pharmacy-filled (custom) vials, for infusers without Hospira MedNet Software. Should your facility choose to use protocols, hospital personnel will determine the protocol parameters (drug, dose, mode of delivery, etc.).
Page 203: Programming Protocols
1. Power on the infuser. Upon initial LifeCare PCA startup, the self test begins. SELF TEST It may take several seconds for the Hospira logo to appear on the screen. 2. Once the self test is complete, LifeCare PCA >...
Page 204 Protocols 3. The screen displays. ATIENT > > Select YES or NO PATIENT? > If YES is selected, the History and RX settings are cleared. > If NO is selected, the History and RX settings are kept. Note: The screen will ATIENT not display if the infuser has been powered off for more than five (5)
Page 205 LifeCare PCA Infusion > 5. Select NO to continue. For more information on loading dose, see Chapter 4 Programming Infusers with Hospira MedNet Software Chapter 5 Programming Infusers without Hospira MedNet Software. > In this example, NO is selected. 6. The...
Page 206 Protocols CAUTION: V ERIFY PROGRAM VALUES 8. Verify the chosen protocol settings, MORPHINE PF then select CONFIRM>, or select 1 mg/mL > PCA+CONT. PREVIOUS to return to the PCA DOSE preceding screen. 2 mg LOCKOUT 10 min 9. Close and lock the door. Place CONT.
Page 207: Information For Legacy
LifeCare PCA Infusion System Chapter 11 Information for Legacy LifeCare PCA Infusers Upgraded with 7.x Software Legacy LifeCare PCA infusion systems with list number 20709-04 upgraded to 7.x software are substantially equivalent with list number 20837. When the software is upgraded, only the keypad and front enclosure labeling are upgrading to ensure alignment with the software.
Page 208: Iec 60601-1 Compliance
Information for Legacy LifeCare PCA Infusers Upgraded with 7.x Software IEC 60601-1 Compliance Instead of evaluation to IEC 60601-1:2012 Edition 3.1 as indicated on the back cover of this manual, the following statement applies: Infuser has been evaluated to IEC 60601-1:1998 Edition 2 - Medical Electrical Equipment - Part 1: General Requirements for Basic Safety and Essential Performance.
Page 209: Specifications
LifeCare PCA Infusion System Replace the reference on the back cover of this manual with: IPX1 Protected against dripping water Specifications Information provided in Chapter 9 Specifications applies with the exceptions included below and in the following subsections. Fuse: Fuse, 0.5 A, 250 V, Slo-Blo...
Page 210: Time From Occlusion To Alarm
Information for Legacy LifeCare PCA Infusers Upgraded with 7.x Software Time from Occlusion to Alarm Instead of the information in Table 9-4, the following information applies: Time to Occlude Pressure Limit Delivery Rate (Average, (Average) hh:mm:ss) 0.1 mL/hr 13.7 psig 15:04:59 5 mL/hr 13.7 psig...
Page 211: Generating Bar Code Labels (Hospira Mednet Software Enabled
LifeCare PCA Infusion System Appendix A Generating Bar Code Labels (Hospira MedNet Software Enabled) Hospira recommends that the hospital or pharmacy department develop clear policies and procedures for the following: • Generating bar code labels • Applying generated bar code labels to pharmacy-filled (empty sterile/custom) vials •...
Page 212: Equipment Needed To Print A Pharmacy-Generated Bar Code
Generating Bar Code Labels Equipment Needed to Print a Pharmacy- Generated Bar Code Bar code thermal printer (300 DPI or higher) Bar code label software capable of producing labels: • ANSI X3.182-1990 • EAN/UCC Code 128, Code Set C (numeric characters only) •...
Page 213: Label Diagram
For use only with a compatible Hospira PCA infuser set with injector and a compatible Hospira infusion device. CAUTION: To prevent overdose, vial and injector must be securely locked into the infuser.
Page 214: Validation Of The Pharmacy-Generated Bar Code
Bar Code The label diagram shown in Figure A-1 represents Hospira’s recommendation for placement of the bar code and drug name/ concentration on a 3 inch x 2 inch label. The guidelines ensure the device’s integral bar code reader will align correctly with the bar code on the LifeCare PCA sterile empty vial.
Page 215 Dispose the needle or transfer device and injector per facility protocol. Cover the vial with “Yellow Cap for use with Hospira PCA Vial”. 5. Label the vial according to facility protocol. Do not obscure graduations or bar code.
Page 216 Generating Bar Code Labels NOTES System Operating Manual...
Page 217: Appendix Badministration Sets
This appendix outlines the list numbers and descriptions of administration sets and accessories available for use with the LifeCare PCA infuser. For a current list, contact a Hospira sales representative, or visit the website: www.hospira.com/products_and_services/index Refer to vial and administration set package inserts for precautions and information on proper handling.
Page 218 Administration Sets and Accessories Table B-1. Administration Sets List Number Description 14277 LifeCare PCA Set, 67 in./170 cm Mini-Bore tubing with integral PAV and injector assembly Approximate priming volume 2.3 mL Non-DEHP; manufactured without latex For use in PCA, Continuous, and PCA + Continuous modes via intravenous route 14278 LifeCare PCA Extension Set,10 in./25 cm;...
Page 219: Accessories
LifeCare PCA Infusion System Accessories The accessories described in Table B-2 are available for use with the LifeCare PCA infuser. Table B-2. Accessories List Number Description 04831 Injector 06021 Sterile empty vial and injector 19361 Yellow cap for use with vial...
Page 220 Administration Sets and Accessories NOTES System Operating Manual...
Page 221: Appendix Ctroubleshooting
LifeCare PCA Infusion System Appendix C Troubleshooting The LifeCare PCA infuser is programmed to display status and alarm messages and to sound an audible tone for alarm conditions. These messages and alarm conditions are described in the following sections. •...
Page 222 Troubleshooting Table C-1. Alarm Priority Levels Audible Visual Visual Alarm Indicator Indicator Indicator Priority Number Display Backlight of Beeps High Flashing rapidly + Message between High and Normal intensity Medium Flashing slowly + Message between High and Normal intensity Normal intensity + Message for 30 seconds (no flashing)
Page 223: Invalid Keypress
LifeCare PCA Infusion System The infuser stops delivery when any of following alarms occur: • • CHECK INJECTOR OCCLUSION • • CHECK VIAL DEAD BATTERY • • CHECK SYRINGE MALFUNCTION • EMPTY SYRINGE Invalid Keypress The LifeCare PCA infuser emits a single sound of four notes when an invalid keypress occurs.
Page 224: Adjusting The Audio Alarm Volume
Troubleshooting Adjusting the Audio Alarm Volume The alarm volume can only be adjusted in Biomed mode. Contact the Biomed to adjust alarm volume. WARNING E N S U R E T H A T T H E A L A R M V O L U M E L E V E L IS APPROPRIATE FOR THE CURRENT PATIENT AND...
Page 225 LifeCare PCA Infusion System 3. When inserting the bottom of the glass vial into the middle black bracket, ensure that the bar code label faces the bar code reader on the right side of the vial compartment. CAUTION: D O NOT POSITION THE VIAL INTO THE...
Page 226: Occlusion Alarm
Network Connectivity The reliability of a wireless connection between the infuser and Hospira MedNet depends upon many complex issues related to the overall configuring of the facilities network. If the infuser has recurring issues with its network connection, both the infuser and the network should be checked by the Biomed for proper operation.
Page 227: Status Messages
LifeCare PCA Infusion System Status Messages WARNING CLOSE THE TUBING SLIDE CLAMP WHEN HANDLING THE VIAL. Displayed status messages are defined in Table C-2. Table C-2. Status Messages Message Displayed Definition on the Screen 4 HR LIMIT REACHED Message displayed if a dose limit has been...
Page 228: Alarms And Messages
Troubleshooting Alarms and Messages Table C-3 lists high priority infuser alarms that can be cleared by the operator taking appropriate action. Table C-3. Alarms and Messages HIGH PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen DEAD DEAD None...
Page 229 LifeCare PCA Infusion System Table C-3. Alarms and Messages HIGH PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen CHECK CHECK Initial 30 The syringe Properly install SYRINGE SYRINGE second (vial and the syringe by...
Page 230 Troubleshooting Table C-3. Alarms and Messages HIGH PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen Properly install CHECK VIAL CHECK VIAL Initial 30 An Injector is the vial by second detected and CLOSE TUBING inserting the mute no vial is...
Page 231 LifeCare PCA Infusion System Table C-3. Alarms and Messages HIGH PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen Open the door OCCLUSION OCCLUSION An occlusion minute is detected Squeeze the OPEN DOOR during infusion...
Page 232 Troubleshooting Table C-3. Alarms and Messages HIGH PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen BATTERY BATTERY The battery Send the FAULT FAILURE minutes may be infuser to defective or the Biomed SHORT the battery is for servicing DETECTED...
Page 233 LifeCare PCA Infusion System Table C-4 lists medium priority infuser alarms that can be cleared by the operator taking appropriate action. Table C-4. Alarms and Messages MEDIUM PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen...
Page 234 Troubleshooting Table C-4. Alarms and Messages MEDIUM PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen INVALID INVALID A custom DDL Power off BAR CODE BAR CODE minute vial is inserted, the infuser the default CUSTOM VIAL Remove drug library...
Page 235 LifeCare PCA Infusion System Table C-4. Alarms and Messages MEDIUM PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen CHECK CHECK The door is Unlock and SETTINGS SETTINGS minute unlocked and open the door...
Page 236 Troubleshooting Table C-4. Alarms and Messages MEDIUM PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen OPEN DOOR DOOR OPEN None The infuser Close and lock is on and the the door CLOSE TUBING door has been SLIDE CLAMP left open...
Page 237 LifeCare PCA Infusion System Table C-4. Alarms and Messages MEDIUM PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen INFUSER INFUSER Infusion Press [START/STOP] STOPPED STOPPED minutes paused for more than to resume CLOSE TUBING...
Page 238 Troubleshooting Table C-5 lists low priority infuser alarms that can be cleared by the operator taking appropriate action. Table C-5. Alarms and Messages LOW PRIORITY ALARMS Message Alarm Muting Possible Corrective Displayed Name Time Cause Action on the Screen LOW BATTERY Battery life has Connect to BATTERY...
Page 239: Default Drug Library And Prescription Delivery Limits
Prescription Delivery Limits The default drug library contains the drug name and concentration only, and is replaced by the user-defined drug library when connected to Hospira MedNet. Table D-1 lists the LifeCare PCA default drug library. Table D-1. Default Drug Library...
Page 240 Default Drug Library and Prescription Delivery Limits Table D-2. Prescription Delivery Limit Ranges Table D-3. Example of Prescription Delivery Limit Ranges System Operating Manual...
Page 241: Appendix Enetwork Printer Setup
LifeCare PCA Infusion System Appendix E Network Printer Setup This appendix provides information about the LifeCare PCA infuser printing function. The infuser history Event Log can be printed to a network printer or to a personal computer (PC) program. The network printer can be directly connected to the infuser with an Ethernet network cable, or it can be connected through a router on a wired network.
Page 242: Setup Procedure
Network Printer Setup Setup Procedure 1. Using the printer operating instructions, configure the printer Ethernet interface with a static IP address, subnet mask, and TCP/IP port (see Figure E-1). Figure E-1. Connectivity Configuration for Directly Connected Printer • IP address: 192.168.0.222 (arbitrary) •...
Page 243: Printing Procedure
LifeCare PCA Infusion System 4. Configure the infuser connectivity engine settings so that the printer IP address and printer port settings match the values in Step 1. • Print Enabled: Checked • Printer Host/IP Address: 192.168.0.222 • Printer Port: 9100 •...
Page 244: Network Printer
Network Printer Setup Network Printer This section describes how to configure the infuser for a network printer that is connected through a network switch, hub, or router. Note: The infuser must be connected with a wired Ethernet cable as the printing function is disabled when the CE wireless network is active.
Page 245 LifeCare PCA Infusion System Figure E-2. Connectivity Configuration for Networked Printer • Print Enabled: Checked • Printer Host/IP Address: 192.168.0.222 • Printer Port: 9100 • Directly Connected Printer: Unchecked 4. Save the infuser configuration changes and restart the CE. 5. Connect the infuser to the network with an Ethernet network cable between the infuser and the network printer.
Page 246: Printing Procedure
Network Printer Setup Printing Procedure WARNING DISCONNECT THE INFUSER FROM THE PATIENT BEFORE CONNECTING THE INFUSER TO A PRINTER OR COMPUTER. Note: After the infuser A/C power is applied or the CE is restarted by changing the Ethernet cable, allow 2 to 3 minutes for the infuser CE to complete the start-up initialization before attempting to print the Event Log.
Page 247: Equipment Needed
LifeCare PCA Infusion System Equipment Needed • Infuser • Personal computer with a terminal program (for example, Tera Term, etc.) • Ethernet network cable • Ethernet network crossover cable (for configuration) Preparation Connect the Ethernet network cable from the infuser to the computer, then connect the infuser to AC power.
Page 248 Network Printer Setup Figure E-3. Connectivity Engine Settings 3. On WebConfig, under the Ethernet Properties menu, configure the infuser as shown in Figure E-4 Figure E-5. • Ethernet DHCP Enabled: [required by your setup] • Ethernet IP Address: [required by your setup] •...
Page 249 LifeCare PCA Infusion System Figure E-4. Ethernet Properties Figure E-5. Hospira MedNet Server Suite Properties System Operating Manual...
Page 250 Network Printer Setup 4. Save the infuser configuration changes and restart the infuser 5. Connect the infuser to the wired network. Identify the infuser DHCP assigned IP address (if applicable). 6. Connect the PC to the wired network. 7. Start the PC terminal program. Open a new TCP/IP connection.
Page 251 LifeCare PCA Infusion System 8. Specify the infuser IP address and TCP/IP port configured on the infuser in Step 2 (or the DHCP assigned IP address from Step 4) and start the new connection. Figure E-7 shows Tera Term options for a new connection.
Page 252: Printing Procedure
Network Printer Setup The infuser and terminal program are now set up and ready for PC terminal printing on a wired Ethernet network. Note: The Tera Term terminal program window will close after the printing session is completed because the TCP/ IP socket is disconnected.
Page 253: Glossary
LifeCare PCA Infusion System Appendix F Glossary This appendix lists definitions of general and clinical terms and acronyms used in this manual. Term Definition Accuracy The degree to which the instrument is capable of delivering the volume of analgesic drug that is displayed...
Page 254 Continuous Infusion program characterized by a constant, fixed-rate dose Custom Syringe A bar coded Hospira sterile empty vial or Vial that is custom-filled by a pharmacy Default Drug Library A pre-programmed drug library embedded...
Page 255 LifeCare PCA Infusion System Term Definition History/Battery The History function displays Rx Settings, PCA Summary, and the Event Log The Battery function accesses the Battery Charge indicator and the Wireless Strength indicator Hospira MedNet Network based application software used Software...
Page 256 PCA Vial Vial compatible with the infuser that is either prefilled with drug by Hospira (standard vial) or filled by the hospital pharmacy (custom vial) Prime Removing air from the syringe...
Page 257 LifeCare PCA Infusion System Term Definition Rx Settings The current programmed therapy Includes PCA Dose, PCA Lockout Interval, Continuous Rate, Loading Dose, and Dose Limit amount Softkeys The five keys to the right of the device’s display Each key’s function is dependent...
Page 258 Glossary NOTES System Operating Manual...
Page 259: Warranty
Warranty Subject to the terms and conditions herein, Hospira, Inc., herein referred to as Hospira, warrants that (a) the product shall conform to Hospira's standard specifications and be free from defects in material and workmanship under normal use and service for...
Page 260 In providing any parts for repair or service of the product, Hospira shall have no responsibility or liability for the actions or inactions of the person performing such repair or service, regardless of whether such person has been trained to perform such repair or service.
Page 261 United States, contact Hospira. 1-800-241-4002 For additional services and technical training courses, visit the website: www.hospira.com For technical assistance and services outside the United States, contact the local Hospira sales office. System Operating Manual...
Page 262 Contact Information NOTES System Operating Manual...
Page 263 LifeCare PCA Infusion System WARNING EXPLOSION HAZARD EXISTS IF THE INFUSION SYSTEM IS USED IN THE PRESENCE OF FLAMMABLE SUBSTANCES. CAUTION: F (USA) EDERAL LAW RESTRICTS THIS INFUSER TO SALE BY OR ON THE ORDER OF A PHYSICIAN OR OTHER...
Page 264 LifeCare PCA Infusion System Indicates that Federal (USA) law restricts this device to sale by or on the order of a physician or other license The patient pendant handle and button are applied parts for the LifeCare PCA infuser. The patient...
