Digital Projector
User Manual
Portable Entertainment Series | GS2
V 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Portable Entertainment Series and is the answer not in the manual?

Questions and answers

Related Manuals for BenQ Portable Entertainment Series

Summary of Contents for BenQ Portable Entertainment Series

  • Page 1 Digital Projector User Manual Portable Entertainment Series | GS2 V 1.00...

  • Page 2: Copyright And Disclaimer

    Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of BenQ Corporation to notify any person of such revision or changes. This user manual aims to provide the most updated and accurate information to customers, and thus all contents may be modified from time to time without prior notice.

  • Page 3: Statement Regarding Hyperlinks And Third-Party Websites

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.

  • Page 4: Table Of Contents

    Table of contents Copyright and disclaimer ...................................2 Copyright ........................................... 2 Disclaimer ..........................................2 Warranty............................................ 2 Statement regarding hyperlinks and third-party websites ..........................3 Package contents .......................................11 Standard accessories ......................................11 Introduction ........................................13 Projector features ........................................13 Projector exterior view ...................................... 15 Front, top, and left side view..........................................
  • Page 5 The BenQ Launcher home screen........................................42 Navigating the BenQ Launcher home screen....................................43 Using the source menu............................................44 Using the app shortcuts ............................................45 Using the BenQ Launcher Settings menus ....................................46 Inputting text ................................................46 Connections ....................................... 48 Wireless Connections ......................................50 Connecting the projector to a wireless network ....................................50...
  • Page 6 wireless Hotspot ........................................59 Wired Connections.......................................63 Connecting a device with HDMI or USB-C™ with DisplayPort ..............................63 Connecting a flash drive ............................................66 Media Player ................................................67 Bluetooth Connections .......................................75 Pairing/Connecting to a Bluetooth speaker or headphones ................................. 75 Using the Projector as a Bluetooth speaker....................................78 Navigating the Settings menu ................................80 About the Settings menu....................................80 Using the Settings menu ....................................
  • Page 7 System Boots ..............................................105 Recent Apps ..............................................106 BenQ Smart Control ........................................... 107 System Update ....................................... 108 Maintenance ......................................110 Care of the projector ......................................110 Cleaning the lens..............................................110 Storing the projector ............................................110 Transporting the projector ..........................................111 Extending LED life ..............................................
  • Page 8 Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. 1.
  • Page 9 8. Do not place liquids near or on the projector. Liquids spilled into the projector will void your warranty. If the projector does become wet, disconnect it from the power point and call BenQ to have the projector repaired. 5. Do not block the vents holes while the projector is on (even in power-saving mode).
  • Page 10 Moisture condensation 12. This projector is capable of displaying inverted images for ceiling installation. Never operate the projector immediately after moving it from a cold location to a hot location. When the projector is exposed to such a change in temperature, moisture may condense on the crucial internal parts.

  • Page 11: Package Contents

    Package contents Carefully unpack and verify that you have the items below. Some of the items may not be available depending on your region of purchase. Please check with your place of purchase. Standard accessories Remote Control Wireless Dongle (WDR02U) GS2 Projector (with One CR2032 Battery) Carry Bag...
  • Page 12 Quick Start Guide Regulatory Statement Quick Start Guide Warranty Card • Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice. • Some of the accessories may vary from region to region. •...

  • Page 13: Introduction

    Introduction Projector features • Instant Wireless Projection Release your hands and eyes to enjoy binge-watching on a big screen. If you have access to an internet connection, you can cast the screen from a mobile device through GS2 instantly. With GS2, you can just sit back, relax and enjoy some well-earned downtime. ®...
  • Page 14 • Portable Media Player GS2 supports a maximum of 3-hour projection in battery mode, and two powerful 2-W chamber speakers. You can take it everywhere to share enjoyment without the hassle of power adapters and various cables. It can also play as a Bluetooth speaker for you to enjoy your favorite music anytime.

  • Page 15: Projector Exterior View

    Projector exterior view Front, top, and left side view 1. Auto light shut off sensors Automatically turns off the LED light source when an object is detected within a distance of 30 centimeters (11.8 inches) in front of the projector for more than one second.

  • Page 16: Rear And Bottom Side View

    Rear and bottom side view Connections on page 48 for connection details. 7. Speaker 8. Rear vent 9. Power adapter port Please only use the supplied power adapter to avoid possible dangers such as electric shock and fire. 10. Bottom vent 11.

  • Page 17: Controls And Functions

    Back button Used to return to the previous layers. 5. Ambient light sensor and rear IR sensor 6. OK button Used to confirm the selection on the BenQ Launcher menu. Menu button Launches the BenQ Launcher settings menu. Home button...

  • Page 18: Ports

    Ports 1. Wireless dongle port Insert the BenQ WDR02U USB wireless dongle to enable wireless and Bluetooth connections. See Installing the wireless dongle on page 30 for details. The projector only supports wireless and/or Bluetooth connections when the wireless dongle is installed into this slot.

  • Page 19: Led Indicators

    LED Indicators There are one red/green LED (LED 1) and two green LEDs (LED 2 and LED 3) on the top of the projector. Refer to the table below for definitions of various LED behaviors. LED 1 LED 2 LED 3 Scenario Status LED Behavior...
  • Page 20 LED 1 LED 2 LED 3 Scenario Status LED Behavior Schema LED Behavior Schema LED Behavior Schema Battery capacity < 5% Battery capacity < 16% Red - solid Battery Mode Battery capacity = 16 - 33% Green - solid Battery capacity = 33 - 66% Green - solid Green - solid Battery capacity = 66 - 100% Green - solid...

  • Page 21: Remote Control

    Menu Launches the BenQ Launcher settings menu. Home Press this key to enter the BenQ Launcher home menu. This key is only active when the projector is under BenQ Launcher mode. Volume Down Decreases the projector volume. Focus/Mouse Cursor Short press this key to start auto focus; long press to enable the mouse cursor.

  • Page 22: Activating The Remote Control Battery

    Activating the remote control battery Before you can begin to use the remote control, you must first remove the clear plastic battery sticker between the battery and the contact on the remote control. 1. Use a flat-tipped instrument to rotate the battery cover counter-clockwise to the unlocked position. 2.

  • Page 23: Replacing The Remote Control Battery

    Replacing the remote control battery 1. Use a flat-tipped instrument to rotate the battery cover counter-clockwise to the unlocked position. 2. Remove the battery cover from the remote control. 3. Carefully dislodge the used battery from underneath the retention coil and slide it out from the remote control. 4.

  • Page 24: Remote Control Effective Range

    Remote control effective range The projector has two IR remote control sensors. One is located at the front and the other at the top of the projector, both with a range of 8 meters (~26 feet) at an angle of 30-degrees (left and right) and 20-degrees (up and down). The remote control can be used either by pointing it directly at the IR sensors at the front or top of the projector or by reflecting the IR signal off of a wall.

  • Page 25: Installation

    Installation Choosing a location Before choosing an installation location for your projector, take the following factors into consideration: • Size and position of your screen • Electrical outlet location • Location and distance between the projector and the rest of your equipment •...
  • Page 26 3. Rear Table: Select this location with the projector placed near the floor behind the screen. Turn on the projector and select the following settings: Installation > Projector Installation > Rear Table A special rear projection screen is required. 4. Rear Ceiling: Select this location with the projector elevated from the ceiling behind the screen.

  • Page 27: Obtaining A Preferred Projected Image Size

    Obtaining a preferred projected image size The projected image size is determined by the distance from the projector lens to the screen, and the video format. The data in the table below is based on a normal projection method and not the result of adjusting the projection angle (1-15 degrees). Projection dimensions Use the illustration and tables below to help you determine the projection distance.
  • Page 28 Screen size Projector distance (mm) Diagonal H (mm) W (mm) Average Inch 1524 1329 1727 1651 1439 1871 1778 1550 2015 1905 1661 2159 2032 1771 2303 2159 1882 1058 2447 2286 1993 1120 2591 2413 2104 1182 2735 2540 2214 1245 2879...

  • Page 29: Installing The Projector On A Tripod (Purchased Separately)

    Installing the projector on a tripod (purchased separately) Use a tripod plate to mount the projector onto a tripod: 1. Install the tripod’s quick release plate to the projector’s tripod screwhole and tighten the plate’s screw. 2. Install the projector onto the tripod.

  • Page 30: Operations

    Operations Installing the wireless dongle 1. Open the IO port cover. 2. Remove the cap from the provided wireless dongle (WDR02U).
  • Page 31 3. Orient the dongle so that the dongle's LED is facing up and then insert the dongle into the wireless dongle port. 4. Re-install the IO port cover.

  • Page 32: Charging The Battery

    Charging the battery 1. Connect the power cord to the power adapter. 2. Orient the adapter connector so that the TOP print on the connector is facing up, and then connect the adapter to the projector. 3. Charge the projector’s battery by connecting the power cord to a power outlet. The power LED indicator will illuminate according to its charge status, for a full charge wait until the indicator lights up solid green (see LED Indicators on page 19...

  • Page 33: Starting Up The Projector

    Starting up the projector 1. Install the provided wireless dongle into the wireless dongle port on the right side of the projector. See Installing the wireless dongle on page 30 for details. 2. Charge the battery or supply power to the projector as indicated in Charging the battery on page 3.
  • Page 34 4. Connect any video equipment supporting HDMI or DisplayPort (version 1.1 or above) or a storage device to the USB-C™ or USB-A port on the right side of the projector. If you want to project video via a wireless connection or if you want to access the BenQ Launcher, you do not need to connect any video equipment.
  • Page 35 Step 2: Choosing a Language settings. Available languages may vary by the product supplied for your region and may be updated without prior notice. Step 3: Adjusting Keystone.
  • Page 36 Step 4: Configure the wireless settings by selecting the wireless network and entering the password. To connect to a hidden wireless network select Add a new network and enter the SSID, security setting, and password for the network. Step 5: Specify Time zone settings.
  • Page 37 Step 6: Read the Personal information declaration and press Agree. You’ve completed the setup wizard; you may now connect a device to the projector to project video. See Connections on page 48 for more information.

  • Page 38: Shutting Down The Projector

    Shutting down the projector 1. Press and hold the power key on the projector or your remote control for 3 seconds. The projector displays a shutdown confirmation message. 2. The power LED indicator turns off and will illuminate again according to its charge status if the adapter is connected to the projector (see Indicators on page 19).

  • Page 39: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with a pivoting head which changes the image height and projection angle. To adjust the projection angle: • Pivot the head upwards or downwards until the image is positioned as desired. 15°...

  • Page 40: Fine-Tuning The Image Clarity

    • Do not look into the lens while the lamp is on. The strong light from the lamp may cause damage to your eyes. • You may also fine tune the image in BenQ Launcher. See Auto Focus on page 93...

  • Page 41: Correcting Keystone

    Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To adjust the Keystone: 1. Press the down arrow key on the remote control three times to navigate to the settings menus.

  • Page 42: Benq Launcher

    The BenQ Launcher home screen When the projector is not projecting an image from a connected source it will display BenQ Launcher by default. If the projector is projecting from a source, you can return to BenQ Launcher mode by pressing on your remote control.

  • Page 43: Navigating The Benq Launcher Home Screen

    The BenQ Launcher home screen features five main sections: • Status Bar icons - Icons that display the time, wireless and battery status. You may hide the battery status icon from the home screen. See Battery on page 104 for details.

  • Page 44: Using The Source Menu

    Press the down button on the remote control from the BenQ Launcher home screen to access the Source menu, which displays the input source options: File Manager, HDMI, and USB Type C. Press OK to select the desired input source. See...

  • Page 45: Using The App Shortcuts

    Press the down button on the remote control twice from the BenQ Launcher home screen to access the app shortcuts section, which displays the pre-installed Aptoide app market for streaming apps, as well as other apps that have been installed on the projector. Other default apps may appear based on language settings.

  • Page 46: Using The Benq Launcher Settings Menus

    Press the down button three times on the remote control from the BenQ Launcher home screen to access the settings menus section, which features a button for the projector’s full settings menu as well as shortcut buttons for various sub-menus within the settings menus.
  • Page 47 2. Press OK on your remote control, and a full alphanumeric keyboard will appear on screen. 3. Press / / / on your remote control to navigate the keyboard, and press OK to select the letter/key/symbol you want to enter into the text field.

  • Page 48: Connections

    Connections You can connect your device to the projector in various ways to project video content. Wireless Connection • Smartphone, tablet, laptop/PC Wired Connection (HDMI port) • A/V device. • Smartphone, tablet, laptop/PC Wired Connection (USB-A port) • USB-A flash drive Wired Connection (USB-C™...
  • Page 49 Wireless Connection: Bluetooth Laptop/PC Tablet Smartphone Wireless AP Speakers Smartphone or Tablet Wireless Dongle DWR02U Devices with USB-C™ DisplayPort Speakers Laptop/PC A/V Devices The illustration above is for reference only.

  • Page 50: Wireless Connections

    Installing the wireless dongle on page 30). 2. Power on the projector (see Starting up the projector on page 33). 3. On the home screen of the BenQ Launcher interface, select Wireless Network Settings and press OK to access the wireless settings.
  • Page 51 4. Select Wireless Network and press OK to enable wireless connectivity. 5. Select the SSID for the wireless AP you want to connect to and press OK. • To connect to a hidden wireless network select Add A New Network and enter the SSID, security setting, and password for the network. •...
  • Page 52 7. Once you have successfully connected to the wireless AP a wireless connection icon will appear at the top right corner of the BenQ Launcher interface. You can now connect your devices wirelessly to the projector to project videos..

  • Page 53: Wireless Projection For Ios & Macos

    To connect an iOS device to the projector and project video via AirPlay: 1. On the home screen of the BenQ Launcher interface, select Wireless Projection for iOS & macOS and press OK. 2. On your iOS mobile device’s network menu connect to the wireless network shown on the Wireless Projection for iOS & macOS screen...
  • Page 54 3. Follow the instructions shown on the Wireless Projection for iOS & macOS screen to project your iOS device’s screen via AirPlay. 4. Select Finished on the Wireless Projection for iOS & macOS menu to finish the tutorial and return to the home screen. Once you have finished projecting, disable AirPlay on your iOS device to end the connection.

  • Page 55: Wireless Projection For Android

    To connect an Android™ device to the projector and project video: 1. On the home screen of the BenQ Launcher interface, select Wireless Projection for Android™ and press OK. 2. On your Android mobile device’s network menu connect to the wireless network shown on the Wireless Projection for Android™ screen...
  • Page 56 3. Follow the instructions shown on the Wireless Projection for Android™ screen to project your Android device’s screen. 4. Select Finished on the Wireless Projection for Android™ screen to finish the tutorial and return to the home screen. Once you have finished projecting, disable screencasting on your Android device to end the connection.

  • Page 57: Wireless Projection For Pc

    To connect a PC to the projector and project video: 1. On the home screen of the BenQ Launcher interface, select Wireless Projection for PC and press OK. 2. On your PC’s network menu connect to the wireless network shown on the Wireless Projection for PC screen and then select Next.
  • Page 58 3. Follow the instructions shown on the Wireless Projection for PC screen to project your PC’s screen. 4. Select Finished on the Wireless Projection for PC screen to finish the tutorial and return to the home screen. Once you have finished projecting, disable screencasting on your PC to end the connection.

  • Page 59: Wireless Hotspot

    2. Power on the projector (see Starting up the projector on page 33). 3. On the home screen of the BenQ Launcher interface, press the down arrow key on the remote control three times to navigate to the settings menus.
  • Page 60 5. Select Hotspot and press OK. 6. (Optional) Select Hotspot Password and press OK to change the password of the wireless hotspot. The Hotspot Name and the Hotspot Password can only be changed when Hotspot is disabled.
  • Page 61 7. Select Hotspot and press OK to enable wireless hotspot. 8. Once wireless hotspot is enabled, use the name shown in the Hotspot Name field as the SSID to connect to from your mobile device’s network menu and use the password shown in the Hotspot Password field as the connection password.
  • Page 62 9. If the wireless hotspot can not be found by your device, select Normal(2.4G) under the Internet Quality heading. After the wireless hotspot is setup, follow the corresponding connection instructions described in the previous section(s) to connect to the projector directly and project video.

  • Page 63: Wired Connections

    Wired Connections Connecting a device with HDMI or USB-C™ with DisplayPort Using an HDMI or USB-C™ Gen3.1 cable you can connect a device that is equipped with HDMI or DisplayPort capabilities to broadcast videos and images on the projector. Not all devices with a USB-C™ cable have DisplayPort functionality. Check your device’s documentation for clarification. To connect a device with HDMI or USB-C™...
  • Page 64 3. The projector will attempt to connect to the device’s signal. 4. The video from the device will automatically be displayed full screen once the signal from the device is detected.
  • Page 65 BenQ Launcher home screen directly. 7. If the device remains connected and you wish to display its signal again, navigate to the Input Source button on the BenQ Launcher home screen and press OK. Select the device and press OK.

  • Page 66: Connecting A Flash Drive

    Connecting a flash drive Connect a USB-A or USB-C™ flash drive to the USB 2.0 or USB-C™ port on the right side of the projector to view media files stored on the flash drive. To connect a flash drive: 1. Connect the flash drive to the USB 2.0 or USB-C™ port on the right side of the projector. 2.

  • Page 67: Media Player

    Media Player The Source menu on the BenQ Launcher interface allows you to access images, videos, and audio files for projection once a USB-C™ or USB-A flash drive or mobile device without DisplayPort capabilities is connected. See Connecting a flash drive on page 66 for more information on connecting such devices to the projector.
  • Page 68 The Media Player will show selections for your connected devices. Each selection has a sub-directory that lists files for each of the following categories: All, Video, Picture and Audio. If no supported media files are on the connected device then a message “Not Available” will appear.
  • Page 69 Using the Media Player to play video files: 1. Select Video in the sub-directory list for the connected device and press OK. 2. Use the up and down arrow keys ( / ) to choose the video file to be displayed and press OK. 3.
  • Page 70 4. In the viewing window you can choose one of the following options: • Press the OK key on the button to pause the video. Press it again to resume playing. • Press the OK key on the button to rewind the video. •...
  • Page 71 Using the Media Player to play image files: 1. Select Picture in the sub-directory list for the connected device and press OK. 2. Use the up and down arrow keys ( / ) to choose the image file to be displayed and press OK. 3.
  • Page 72 4. In the viewing window you can choose one of the following options: • Press the OK key on the button to stop playing the playlist. • Press the OK key on the button to play the previous image in the playlist. •...
  • Page 73 Using the Media Player to play audio files: 1. Select Audio in the sub-directory list for the connected device and press OK. 2. Use the up and down arrow keys ( / ) to choose the audio file to be played and press OK. 3.
  • Page 74 4. In the viewing window you can choose one of the following options: • Press the OK key on the button to start or stop playing the audio file. • Press the OK key on the button to play the previous audio file in the playlist. •...

  • Page 75: Bluetooth Connections

    Bluetooth Connections The projector allows the following types of Bluetooth connections: • Connect to a Bluetooth-enabled speaker or headphones to output audio directly for greater sound particularly in outdoor settings. • Connect a mobile device to the projector to broadcast audio through the projector’s speakers. Pairing/Connecting to a Bluetooth speaker or headphones Pairing is the process by which your projector creates a connection to a Bluetooth speaker or headphones for the first time.
  • Page 76 5. Select Bluetooth and press OK to enable Bluetooth. 6. Activate Bluetooth-pairing mode on the speaker or headphones. 7. Select the speaker or headphones from the Available Devices in the Bluetooth setting menu and press OK. 8. When the projector and speaker or headphones have successfully connected the device listing in the Bluetooth setting menu will be labeled Connected, you can now output the audio from the projector to the speaker or headphone.
  • Page 77 Ending the Bluetooth connection In cases where you want to disconnect a speaker or headphones from the projector and connect to another speaker or headphones follow the steps below: 1. Press the down arrow key and right arrow key on the remote control to navigate to the settings sub-menu shortcuts. 2.

  • Page 78: Using The Projector As A Bluetooth Speaker

    Using the Projector as a Bluetooth speaker 1. Install the provided wireless dongle into the wireless dongle port (see Installing the wireless dongle on page 30). 2. Activate Bluetooth-pairing mode on the external device. 3. Power on the projector (see Starting up the projector on page 33).
  • Page 79 8. Select OK to confirm the setting. Once you have successfully paired your mobile device with the projector, pairing information will be stored on both devices and a connection will automatically be made when Bluetooth is enabled on both devices and both devices are within range of each other. Ending the Bluetooth connection In cases where you want to disconnect the mobile device from the projector either: •...

  • Page 80: Navigating The Settings Menu

    Navigating the Settings menu About the Settings menu To let you make various adjustments or settings on the projector, its wireless connections, and the projected image, BenQ Launcher provides a Settings menu. Under the Settings menu are menus for various settings.

  • Page 81: Using The Settings Menu

    Use the home button to return to the BenQ Launcher home screen. If the projector is not of the latest version of firmware, a red dot will appear on the About icon. In such a circumstance, users can go to the About menu and then select System Update >...

  • Page 82: Network

    Network The following table describes the items available in the Network menu: Item Options and descriptions Enables wireless connection for the projector. See Connecting the projector to a wireless network on page 50 for details. Wireless Network This function is only available when Hotspot is disabled. Speed Test Tests the speed of the projector’s Internet connection.

  • Page 83: Sounds

    Sounds The following table describes the items available in the Sounds menu: Item Options and descriptions Feedback Enables/Disables feedback on the audio provided by the projector. Utilizes sound enhancement technology, which incorporates Waves’ algorithms to deliver great effects of the bass and treble and Sound Mode provide you with immersive cinematic audio experience.

  • Page 84: Bluetooth

    Bluetooth The following table describes the items available in the Bluetooth menu: Item Options and descriptions Bluetooth Enables Bluetooth for the projector, allowing the projector to output its audio to a Bluetooth speaker or headphones. Lists the available Bluetooth devices which the projector can pair and connect to. My Devices This function is only available when Bluetooth is enabled.

  • Page 85: Bluetooth Speaker Mode

    Bluetooth Speaker Mode Select OK to enable the Bluetooth speaker mode. See Using the Projector as a Bluetooth speaker on page 78 for more details.

  • Page 86: All Apps

    All Apps Select the All Apps menu to access all the apps that have been installed on the projector. • Select an app and press OK on the remote control to launch the app. • Select an app and press the menu button ( ) on the remote control to uninstall the app.

  • Page 87: Hotspot

    Sets the name for the projector’s wireless hotspot, which appears in the wireless network list for devices looking to connect directly to the projector. Hotspot Name The default name for the projector’s wireless hotspot is “BenQ GS2-xxxx”. The final four digits are the last four digits of its Mac Address. Sets the password for the projector’s wireless hotspot. Hotspot Password The password needs to be 8 characters.

  • Page 88: About

    Resolution, Color System, Light Usage Time, and Firmware Version. About Privacy Displays the BenQ privacy announcement. A red dot at the top right of the About icon indicates that a newer version of the projector's firmware is available. In such circumstances, users can select System Update >...

  • Page 89: Picture

    Picture The following table describes the items available in the Picture menu: Item Options and descriptions Selects a preset picture mode to suit your operating environment and input signal picture type. The preset picture modes are described as below: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high Bright brightness is required, such as using the projector in well lit rooms.
  • Page 90 Item Options and descriptions Well-balanced color saturation and contrast, slightly darker than Cinema mode, this mode is designed for Bed Time creating a comfortable mood similar to a warn-toned night lamp. User Recalls the customized settings. Selects the projector lamp power from the following modes: Normal Provides full lamp brightness.
  • Page 91 Item Options and descriptions The options available for Color Temperature settings vary according to the connected input signal. There are many different shades that are considered to be “white” for various purposes. One of the common methods of representing white color is known as the “color temperature”.

  • Page 92: Wall Color

    Wall Color The following table describes the items available in the Wall color menu: Item Options and descriptions Wall Color Adjust the color settings of the image to suit the color of the wall on which the image is projected. Selects a wall color among Light Yellow, Pink, and Blue.

  • Page 93: Auto Focus

    Auto Focus The following table describes the items available in the Auto Focus menu: Item Options and descriptions Enable this function to allow the projector to automatically adjust the sharpness settings when powered on. Auto Focus Focus Manually adjusts the focus settings for the projected image by the use of left and right keys on your remote control.

  • Page 94: Keystone

    Keystone The following table describes the items available in the Keystone menu: Item Options and descriptions Enable this function to allow the projector to automatically adjust the keystone settings when powered on. See Correcting Auto Keystone keystone on page 41 for more details.

  • Page 95: Screen Settings

    Item Options and descriptions Sets which app shortcuts to be displayed on the BenQ Launcher home screen and their sequence. The home screen requires at least one shortcut and allows up to ten shortcuts. Enables the projector to automatically arrange the sequence of app shortcuts on the home screen so that the most recently used app will appear first in the row.
  • Page 96 Item Options and descriptions Sets which settings menu shortcuts to be displayed on the BenQ Launcher home screen and their sequence. The home screen requires at least one shortcut and allows up to eight shortcuts. Settings Enables the user to manually arrange which settings menu shortcuts to be displayed on the home screen and their Manual sequence.

  • Page 97: Date & Time

    Date & Time The following table describes the items available in the Date & Time menu: Item Options and descriptions Refer to Sets the projector’s date and time using the Internet. Internet Time Zone Sets the time zone for the projector. Format Sets the date and time format as either HH:MM or YYYY/MM/DD HH:MM.

  • Page 98: Language

    Language Sets the language for BenQ Launcher.

  • Page 99: Keyboard

    Displays current keyboard information as either AOSP BenQ Keyboard Keyboard Sets the projector’s virtual keyboard for inputting text Keyboard Settings To input Chinese characters, set the language preference to traditional Chinese or simplified Chinese, and set the keyboard to BenQ Keyboard.

  • Page 100: Parental Control

    Parental Control The following table describes the items available in the Parental Control menu: Item Options and descriptions Enable/Disable a System Passcode to configure the Auto Power Off and Key Lock settings. System Passcode The passcode needs to be 8 characters. Changes the System Passcode.
  • Page 101 Item Options and descriptions Sets the time interval in which the projector will automatically power off when inactive. The timer is set up in the format of HH:MM and should be at least 5 minutes long. Timer Setting Auto Power Off This function in only available when is enabled.

  • Page 102: Installation

    Installation The following table describes the items available in the Installation menu: Item Options and descriptions The projector can be installed in a high location or behind a screen. See Choosing a location on page 25 for details. Front Table Select this location with the projector placed near the floor in front of the screen.
  • Page 103 Item Options and descriptions The native display resolution of this projector is in a 16:9 aspect ratio. However you may use this function to display projected pictures in a different aspect ratio. Aspect Ratio settings can only be adjusted when HDMI is selected as the source. Scales a picture proportionally to fit the projector’s native resolution in its horizontal and vertical width.

  • Page 104: Battery

    Battery Shows or hides the battery charge icon on the BenQ Launcher home screen. Different Picture Mode and Light Mode settings will change battery power consumption speed.

  • Page 105: Other Settings Menu

    Other settings menu The other settings menu are available in the settings menu on the front page. System Boots Clears out the memory of unnecessary files and boosts available RAM.

  • Page 106: Recent Apps

    Recent Apps Select the Recent Apps menu to access a list of apps that have been recently used. • Select any icon and press the down button ( ) on the remote control to remove the icon from the list of recently used apps. •...

  • Page 107: Benq Smart Control

    BenQ Smart Control Displays the QR code for downloading BenQ Smart Control app which allows you to control the projector remotely with a smart phone.

  • Page 108: System Update

    Over-the-Air (OTA) updates to install the update file wirelessly. When a new version is available on the BenQ OTA server, a message will pop up once the projector is connected to a wireless network. Follow the steps below to begin updating the firmware:...
  • Page 109 If you select CANCEL when the system upgrade message appears, a red dot will appear at the top right of the Settings > About menu, as a reminder that a newer version of firmware is available on the BenQ OTA server. Users can use the System Update > Update function in the...

  • Page 110: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you have to do on a regular basis is keep the lens clean. Never remove any parts of the projector. Contact your dealer or local customer service center if the projector fails to operate as expected. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface.

  • Page 111: Transporting The Projector

    Transporting the projector It is recommended that you ship the projector with its original packing or equivalent. Extending LED life The projection LED is an 200AL LED bulb which features a light-source life far beyond traditional bulbs, yet it is still a consumable item. To keep the lamp life as long as possible, you can change the following settings via the settings menu.
  • Page 112 Setting Auto Power Off This function allows the projector to turn off automatically if no action is detected after a set period of time. 1. Select Settings > Parental Control > Auto Power Off and press OK. 2. Press ( / ) to select a time period. 3.

  • Page 113: Troubleshooting

    3 seconds to turn it on. On the BenQ Launcher home screen, select the Aptoide, instead of Google Play, is No Google Play. Aptoide icon to access the app market and download provided for streaming apps download.
  • Page 114 Problem Cause Remedy The projector has one USB-C™ port. and no USB-A The storage device is not connected to the port. Use a certified USB-A to USB-C™ adapter to projector properly. connect the projector to devices with USB-A ports. The projector cannot play files in storage Media Player on page 67 for more details.
  • Page 115 Problem Cause Remedy The connection cables are not securely Correctly connect the cables to the appropriate connected to the projector or the signal terminals. source. The Internet bandwidth is limited or Connect to another wireless AP or to an Internet Image or audio is unstable.
  • Page 116 Problem Cause Remedy • For 2.4G frequency, make sure the wireless mode of The handshaking between the projector and the router is configured as 802.11g/n or 802.11n. The projector cannot connect to the desired the router does not follow IEEE 802.11 SSID.

  • Page 117: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. GS2 Projector Specifications Projection System DLP 3438 DMD Type 0.3” Native Resolution 1280 x 720 pixels Brightness 500 lm Contrast Ratio (FOFO) 100,000:1 Display Color 1.07 Billion Colors Aspect Ratio Native 16:9 (5 aspect ratios selectable) Light Source Osram Q8A LED...
  • Page 118 GS2 Projector Specifications Android 6.0 2G LPDDR3 Flash 8G EMMC IEEE 802.11 a/b/g/n/ac, 2.4G/5G WLAN A and C SKU Ch1-Ch11 E SKU Band1: Ch36, Ch40, Ch44, Ch48 A and C SKU Band4: Ch149, Ch153, Ch157, Ch161, Ch165 E SKU Band1: Ch36, Ch40, Ch44, Ch48 Bluetooth •...
  • Page 119 GS2 Projector Specifications • IPX2, • Parental Control, • LumiExpert™, ® • Wireless Projection (for iOS/macOS , for Android™, for PC), Feature • USB-C™ DisplayPort and USB-A Reader, • 15 Degrees Tiling Stand, • Auto Focus, • Auto Vertical Keystone, •...
  • Page 120 : Lamp life results will vary depending on environmental conditions and usage. • : The wireless projection and Bluetooth features are supported by detachable BenQ Wireless Dongle, WDR02U. • : Maximum resolution: 1080P (1920 * 1080) 60Hz. Maximum data transfer speeds: 2.7Gbps.

  • Page 121: Dimensions

    Dimensions 139 (W) x 144 (H) x 139 (D) mm...

  • Page 122: Timing Chart

    Timing chart Supported timing for video input Timing Resolution H. Frequency (KHz) V. Frequency (KHz) Dot Clock Frequency (MHz) DMT0659 640 x 480p 31.469 59.94 25.175 480p 720 x 480p 31.469 59.94 720p 1280 x 720p 74.25 1080i 1920 x 1080i 33.75 74.25 480i...
  • Page 123 Resolution Mode Refresh Rate (Hz) H. Frequency (KHz) Dot Clock Frequency (MHz) 800 x 600 SVGA_60 60.317 30.879 1024 x 768 XGA_60 60.004 48.363 1280 x 720 WXGA_60 74.25 1280 x 1024 SXGA_60 60.02 63.981 1360 x 768 1360 x 768_60 60.015 47.712 85.5...

  • Page 124: Supported File Formats

    Supported file formats File type File extension Documents .txt Photos JPG(.jpg, .jpeg), PNG(.png), BMP(.bmp) Music MP3(.mp3), AAC(.aac) XVID(.avi) Video MPEG-4(3gp, mp4) H.263(3g2, .avi, .mkv, .webm, 3gp, mp4) Subtitles Bit rate range: If the peak bit rate of a video file is larger than 10MB, it might cause video playback lag.

This manual is also suitable for:

Gs2

Table of Contents
