INSTRUCTIONS–PARTS LIST
This manual contains important
warnings and information.
READ AND RETAIN FOR REFERENCE
50:1 Ratio Fire-Ball Pumps
FOR LUBRICATING PRODUCTS ONLY
8000 psi (560 bar) Maximum Fluid Working Pressure
160 psi (11 bar) Maximum Air Working Pressure
CHASSIS LUBE PUMPS
With Lifetime Guarantee*
1.
This guarantee is offered to the original purchaser for his
entire lifetime. It covers all Fire-Ball and President Series
lubrication pumps manufactured by Graco Inc., USA,
when used in pumping non-corrosive and non-abrasive
lubricants and greases.
2.
Graco will repair or replace such pumps free of charge
when inspection by Graco reveals defective materials or
workmanship. Normal wear of packings and seals is not
considered to be defective workmanship.
3.
Graco will repair or replace such pumps at a reasonable
charge if inspection by Graco reveals that damage was
the result, in whole or in part, of causes other than defec-
tive materials or workmanship.
4.
Pumps for which guarantee claims are made must be
returned prepaid to the factory, factory branch or service
agency accompanied by proof of purchase, establishing
the owner as the original purchaser.
5.
The foregoing is in lieu of all other warranties, expressed
or implied, and the manufacturer neither assumes nor
authorizes any person to assume for it any other obliga-
tion or liability in connection with said equipment.
*30 years to corporations and purchasers other than natural
persons. See page 6 for available models.
WARNING
These systems are designed to be used only in
pumping non-corrosive and non-abrasive lubricants
and greases. Any other use of the system can
cause unsafe operating conditions and result in
component rupture, fire, or explosion, which can
cause serious injury, including fluid injection.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1995, GRACO INC.
306–517
Rev. S
Supersedes P
and PCN R
04188
