Amroad DP101R Installation Manual
Door station
Hide thumbs
Also See for DP101R:
- System integration manual (62 pages) ,
- User manual (44 pages) ,
- Quick installation manual (2 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Amroad DP101R
Summary of Contents for Amroad DP101R
- Page 1 AMROAD DP101R DOOR STATION Installation Manual...
-
Page 3: Table Of Contents
AMROAD DP101R Contents Contents Contents .......... i Package Contents ......1 The Size of Main Unit ...... 2 Rear Side ......... 3 Reset Button ..........3 Installing Procedures ...... 4 Back Plate ..........4 Wire and Cable Connection ..... 5 Screw Main Unit ........ -
Page 4: Package Contents
AMROAD DP101R Package Contents Package Contents Front Panel x1 Wall mounted screw pack (Self tapping screws TP3-L16 x4、Wall plugs x4) Main Unit x1 Terminal Connector x1 Back Plate x1 H type Terminal Connector for Power Wire Screw M4 -L10 x4... -
Page 5: The Size Of Main Unit
AMROAD DP101R The Size of Main Unit The Size of Main Unit... -
Page 6: Rear Side
AMROAD DP101R Rear Side Rear Side Reset Button 3. If press for more than 6 seconds, system 1. The device will be switched to the static IP will clean Master RFID Card, Configuration, mode and reboot itself when the user has and Number Entry Screen data。Network... -
Page 7: Installing Procedures
AMROAD DP101R Installing Procedures Back Plate Installing Procedures Back Plate 4. Connect the ground wire to the Back Plate. 1. Make sure that is able to let the AC wires, Remember to tighten the screws on both Ethernet cable, and Earth Wire pass sides. -
Page 8: Wire And Cable Connection
Wire and Cable Connection Wire and Cable Connection 1. Connect Ethernet Cable. (RJ-45 Connector). 2. Connect the AC wire of DP101R to H-type power connector. Please be careful when you are connecting, be sure to check the AC condition before you start to connect the wires. -
Page 9: Screw Main Unit
AMROAD DP101R Installing Procedures Install Main Unit Install Main Unit 1. After connecting the wires and cables properly, then screw the 4 screws (M4 -L10) and water stoppers that come with the package into the front panel. 2. Make sure Main Unit is attached on the wall for waterproof. -
Page 10: Io Application
AMROAD DP101R IO Application IO Application Electric Lock The DP101R can connect with various electric locks, including Electric Strikes, Electric Bolts and Electromagnetic locks. Wiring Connection and Web Page Setup There are two types of electric door lock applications as below. One is Electric Strike, and the other is Electric Bolt. -
Page 11: Electric Bolt
AMROAD DP101R IO Application Electric Bolt Electric Bolt The Electric Bolt is closed when +12 V is supplied. The Electric Bolt is opened when +12V is not supplied. -
Page 12: Electric Bolt And Open Button
AMROAD DP101R IO Application Electric Bolt Electric Bolt and Open Button The Electric Bolt is closed when +12 V is supplied. The Electric Bolt is opened when +12V is not supplied. -
Page 13: Electric Strike
AMROAD DP101R IO Application Electric Strike Electric Strike The Electric Strike is opened when +12 V is supplied. The Electric Strike is closed when +12V is not supplied. -
Page 14: Electric Strike And Open Button
AMROAD DP101R IO Application IO Application 陰極鎖 Electric Strike Electric Strike and Open Button The Electric Strike is opened when +12 V is supplied. The Electric Strike is closed when +12V is not supplied. -
Page 15: Lighting Condition Function
AMROAD DP101R IO Application Lighting condition Function Lighting condition Function SSR Specification Input Specifications There are many types of SSR in the market; you may refer to the following specifications which - Control Current (Arms)：-- are the one we use on above applications. - Page 16 AMROAD TECHNOLOGY INC. 17F.-1, No.16, Jian 8th Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) 886-2-8226-5686 886-2-8226-5687 info@amroad.com.tw WWW.AMROAD.COM.TW...
