- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE TRANSFORMER ® ITEM: LOWTR-100W-SS 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- Page 2 INSTALLATION INSTRUCTIONS VOLT LOWTR-100W-SS ® IMPORTANT: PLEASE READ BEFORE INSTALLATION Low voltage installation and maintenance is safe and presents no risk for electric shock injury. However, there are regulations that may apply and that should be followed by installers. The following safety points may or may not be included in these regulations - the installer is responsible for ensuring a compliant installation.
- Page 3 IMPORTANT: PLEASE READ BEFORE INSTALLATION WARNING: Risk of Electric Shock. Install power unit 5 feet (1.5 m) or more from a pool, spa, or fountain. Where the power unit is installed (a) indoors within 10 feet (3.05 m) of a pool, spa, or fountain or (b) outdoors, connect power unit to a receptacle protected by a GFCI.
-
Page 4: Package Contents
INSTALLATION INSTRUCTIONS VOLT LOWTR-100W-SS ® PACKAGE CONTENTS A. (1) Transformer D. (1) Wall Anchor B. (1) Riser E. (1) Allen Wrench C. (1) Screw F. (1) Stake PRODUCT DIMENSIONS 4.53” 3.94” 3.54” 7.28” 6.29” 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com... - Page 5 The transformer can be mounted to a wall or the stake. Please refer to relative installation instructions. INSTALL TRANSFORMER TO WALL (OPTION A) Determine your desired location Wall Anchor for mounting the transformer. Keyhole Drill a hole onto the wall surface Screw and insert the wall anchor.
- Page 6 INSTALLATION INSTRUCTIONS VOLT LOWTR-100W-SS ® INSTALL TRANSFORMER AND RISER ON STAKE (OPTION B) Thread the riser onto the stake and hand tighten until snug. Transformer Thread the transformer onto the top end of the riser using the mounting bracket and hand tighten until snug.
- Page 7 WIRE CONNECTIONS 1. Take out terminal blocks. 2. Open the levers on the terminal blocks. 3. Insert one side of the supply Terminal wire into the COM and the Blocks other into the 15V terminal block. Lever 4. Push the levers down to secure the wires. 5. Insert terminal blocks in Supply Wire place.
- Page 8 INSTALLATION INSTRUCTIONS VOLT LOWTR-100W-SS ® TIMER SETTING AND FUNCTIONS 1. When you plug the wire into socket and power on, the “POWER” and “ON” indicators of timer turn green and the timer is on standby. 2. Select a timer mode using the “SET” button. The indicator will scroll through timer modes according to the following sequences: OFF--->DUSK-DAWN--->ON--->2Hrs--->4Hrs--->8Hrs--->OFF--->..
