INSTALLATION INSTRUCTIONS
VOLT
®
VOLT
®
VAL-2013-BBK
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2022, VOLT
customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
Lusitano Mini Brass Lanai Light
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Related Manuals for Volt VAL-2013-BBK
Summary of Contents for Volt VAL-2013-BBK
- Page 1 VAL-2013-BBK Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2022, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
-
Page 2: Important Safety Instructions
INSTALLATION INSTRUCTIONS VOLT Lusitano Mini Brass Lanai Light ® VAL-2013-BBK Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. -
Page 3: Product Dimensions
Package Contents A. (1) Fixture C. (2) Screws B. (2) Anchors D. (1) Allen Wrench Parts Required (Sold separately) A. (1) MR11 Lamp Product Dimensions 3.89” 1.82” 1.82” 2.95” 1.04” 3.08” 1.58” 2.57” customersupport@voltlighting.com • 813.978.3700 - 3 -... - Page 4 INSTALLATION INSTRUCTIONS VOLT Lusitano Mini Brass Lanai Light ® VAL-2013-BBK Remove Glare Guard Loosen the thumb screw to remove glare guard from the Fixture Body fixture body. Glare Guard Thumb Screw Remove Lens Rotate the lens counter-clockwise Fixture Body and remove it from the fixture body.
-
Page 5: Install Lens
Install Lens Place the lens back onto the fixture body and rotate it Fixture Body clockwise to lock it in place. Lens Install Glare Guard Place the glare guard back Fixture Body onto the fixture body and secure with previously removed screw. -
Page 6: Wire Connection
INSTALLATION INSTRUCTIONS VOLT Lusitano Mini Brass Lanai Light ® VAL-2013-BBK Install Fixture Body Determine the desired location Anchor for the fixture. Mark points on Mark Screw the desired location from the holes on the backplate of the fixture body. Remove the fixture body, drill holes from the marks and insert anchors completely. - Page 7 Adjust Glare Guard Direction Loosen the knuckle screw at Screw the joint and rotate the glare guard to the desired direction. Tighten the knuckle screw once the glare guard direction Glare Guard is achieved. Allen Wrench Rotate Install/Replace MR11 Lamp Please reverse Step 3 - Step 5 to expose the MR11 lamp and replace it with correct wattage and type marked on fixture label.
- Page 8 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2022, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
