OVERVIEW OF THE EQUIPMENT
1
6
8
7
13
REF
1 User control interface
2 Column A pressure gauge
3 Column B pressure gauge
4 N2 Outlet pressure gauge
5 Air inlet pressure gauge
6 Cable glands
7 Mains supply cable gland
11
DESCRIPTION REF DESCRIPTION
8 O2 Analyser calibration port
9 N2 Outlet port to buff er (G½ )
10 N2 inlet port from buff er vessel (G½ )
11 N2 Outlet port (G½ )
12 Air Inlet port (G½ )
13 Silencer
