5

Electrical, Reliability and Operating Characteristics

5.1 Electronic Characteristics
Absolute maximum rating for digital and analog pins of SIM5360 are listed in the following table:
Table 41: Absolute maximum ratings
Parameter
Voltage at digital pins (1.8v digital I/O)
Voltage at VBAT
Voltage at VRTC
Voltage at USB_VBUS
Table 42: Recommended operating ratings
Parameter
Voltage at digital pins (1.8v digital I/O)
Voltage at VBAT
Voltage at VRTC
Voltage at USB_VBUS
The operating temperature and power specification is listed in the following table.
Table 43: Operating temperature
Parameter
Normal operation temperature
Extended operation temperature
Storage temperature
Note: The module is fully functional in all the temperature range. Temperatures outside of the range
-30℃ ~ +80℃ might slightly deviate from ETSI specifications.
Functional: the module is able to make and receive voice calls, data calls, SMS and make
GPRS/WCDMA/HSPA+ traffic.
5.2

Operating Mode

The following table summarizes the various operating modes, each operating modes will be referred to in
the following chapters.
SIM5360_Hardware Design_V1.06
Smart Machine Smart Decision
Min
-0.3
-0.5
-
-0.5
Min Typ
0 1.8
3.4 3.8
2 -
3 5
Min Typ
-30 25
-40 25
-45 25
59
Max Unit
2.1 V
6.0 V
3.25 V
6.0 V
Max Unit
1.95 V
4.2 V
3.2 V
5.25 V
Max Unit
80
℃
85
℃
+90
℃
