Operating Manual
Holter
1
Safety
Part 2: Hardware, description of device for custo watch
Operating characteristics:
For 3-channel holter,
up to 72 hours
MHW 0008 – DK 1695
Version 002 – 21/08/2019
2
Hardware
3
Software
4
Hygiene

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the custo watch and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Custo Med custo watch

Summary of Contents for Custo Med custo watch

  • Page 1 Operating Manual Holter Safety Hardware Software Hygiene Part 2: Hardware, description of device for custo watch Operating characteristics: For 3-channel holter, up to 72 hours MHW 0008 – DK 1695 Version 002 – 21/08/2019...
