Front-Panel
Buttons/LEDs
Reboot button
RST / UPG button
PWR
CFG
USB
MPEG-2
AVC
MP2
AAC
Dolby Digital
For
recording IP
NACE:
610-429-1511
| sales@datatronix.biz | www.datatronix.biz | | DT-HDIPSS Manual v1.0
Description
Reboots the device (unsaved settings will be lost)
To reset all the settings of the device to factory default:
1.Press and hold the RST/UPG button and boot-up the device
2.Hold the button until CFG led to flashes 10 times (about 10 seconds)
3.After the CFG led stops flashing release the button
To upgrade firmware using the USB port:
1.Plug-in the USB drive with the upgraded firmware image
("hdip_upg.img")
2.Press and hold the RST/UPG button and boot-up the device
3.USB led will flash while copying the image from USB drive (about 3~5
seconds)
4.Wait until the CFG led stop flashing
5.Release the RST/CFG button and wait for the device to reboot and
upgrade the firmware (about 1 minute)
Power is ON
Indicates device is in configuration mode
Indicates USB drive is mounted
Indicates device is encoding video using MPEG-2
Indicates device is encoding video using AVC
Indicates device is encoding audio using MPEG-1 Layer 2
Indicates device is encoding audio using AAC
Indicates device is encoding audio using Dolby Digital
Page 7
