SPECIFICATIONS

Interfaces Ethernet (output)
USB
Video Input
Audio Input
Encoding Output Video Format
Output Audio Format
Resolution
Output Video Bitrate
Output Audio Bitrate
Streaming Protocols
USB Media
Player File Format Supported
Digital Living Network
MISC Alliance (DLNA)
Closed Caption
Power Supply
Consumption
Operating Temperature +32°F to +113°F ( 0°C to +45°C)
Storage Temperature
Dimension
Weight
*Manufactured under license from Dolby Laboratories. * Specifications subject to change without notification.
NACE: 610-429-1511 | sales@datatronix.biz | www.datatronix.biz | | DT-HDIPSS Manual v1.0
Combined IP Output Port (1Gbps)/Management Port 10Mbps)
USB 2.0
HDMI, YPbPr, CVBS
Analog, Coaxial SPDIF, Optical SPDIF
MPEG-2, H.264
MPEG-1 Layer 2(MP2), MPEG-2 A AC, MPEG-4 A AC,
Supports Dolby® Digital encoding*
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
MPEG-2HD: 10-20 Mbps, MPEG-2 SD: 2-8 Mbps,
H.264 HD: 2-10 Mbps, H.264 SD: 1-4 Mbps
96, 128, 192, 256, 384 Kbps
HTTP, UDP/RTP multicast, UDP/RTP unicast, TCP unicast
A MPEG Transport Stream file (with file name suffix ".ts"),
A Matroska or WebM file (with file name suffix "mkv" or ",webm")
An Ogg file (with file name suffix ".ogg", ".ogv", or "opus")
A MPEG-1 or 2 Program Stream file (with file name suffix "mpg")
A MPEG-4 Video Elementary Stream file (with the name suffix "m4e")
A H.264 Video Elementary Stream file (with the name suffix ".264")
A H.265 Video Elementary Stream file
MediaServer 1.5
Yes
12VDC 1.5AMP
500mA
+14°F to +140°F ( -10°C to +60°C)
9.29" x 6.10" x 1.37" (236mm x 155mm x 35mm)
2 lbs. and 1.1575 oz. (940g)
