Case 3: TCP/UDP/RTP Unicasting
Network Setup Example:
ex. VLC media player
ex. VLC media player
udp://@:1234
udp://@:1234
Step 1: Select Protocol: UDP/RTP or TCP using the drop-down tool
Step 2: Enter Destination IP
Step 3: Enter Destination Port
Step 4: Click 'Add'
Image above shows Destination IP/Port listed in the Casting List window.
Note: Click on an IP Address then 'Remove' to remove a Destination IP addresses.
NACE:
610-429-1511
| sales@datatronix.biz | www.datatronix.biz | | DT-HDIPSS Manual v1.0
Page 32
