1.5.Tools

Hex Wrench-2.0mm X1
Large Cross-head Screwdriver X1
Winding Pipe X1
Ribbon X1

1.6.Self-prepared Parts

18650 Battery X2
18650 battery specification:
It is recommended to use lithium battery above 3000mAh and without overcurrent protection.
The power supply current requirement is above 3A. Using 18650 lithium battery with overcurrent
protection function, 18650 battery whose capacity is less than 1700mAh, 18650 battery specially
for strong-light flashlight, 18650 battery with power shortage or counterfeit lithium battery
produced by informal manufacturers will cause the unstable work of the robot,power cut and
even damage to the Raspberry Pi and robot.
The robot can be turned on normally,but the Raspberry Pi will automatically restart or shut down
after, also because of the problem caused by the 18650 battery.
6
Cross Screwdriver X1
Raspberry Pi X1
Cross Socket Wrench X1
