Contents Overview ..................................1 Specifications................................2 TBPL-24-H Dimensions ............................... 4 Technician Settings Index ............................5 Operating Instructions ..............................7 Quick Guide ................................7 Turning the thermostat ON and OFF ........................8 Selecting temperature scale ..........................8 Adjusting the Setpoint temperature ........................8 Selecting system mode ............................
Page 4
Contents Technician Settings P45 to P46 ........................51 Technician Settings P47 to P48 ........................52 Technician Settings P49 to P51 ........................53 Technician Settings P52 to P57 ........................54 Technician Settings P60 to P64 ........................55 Technician Settings P65 to P70 ........................56 Technician Settings P71 to P75 ........................
As part of an MS/TP network of BACnet Thermostats that can be managed from a BMS front-end system As part of a BACnet MS/TP network connected to the Carrier Corporation BACnet router in a i-Vu® system. The router’s control programs provide trending and alarming of the BACnet Thermostat’s data.
By default, the BACnet Device Instance Number is generated automatically by the thermostat (Vendor ID + MAC address). For example, Carrier Corporation vendor ID is 16, and if the MAC address is 075, the BACnet Device Instance Number is 16075.
