PacketStar
PSAX Multiservice Media Gateways
PSAX 1000 3-Port Line Interface Module Description and Specifications
Model 10N01
Purpose of This Document
Identifying the Module
Figure 1. PSAX 1000 3-Port Line Interface Module (LIM3–1)
®
PacketStar
PSAX Multiservice Media Gateways
PSAX 1000 3-Port Line Interface Module Description and Specifications
Part Number: 559M0A0001Z1
This document identifies and describes the PSAX 1000 3-Port Line Interface
Module (LIM3–1) module and related safety information. It also includes proce-
dures for installation and removal of the module from the PSAX chassis and veri-
fication of the initial module startup, as well as information on obtaining trouble-
shooting assistance. Regulatory standards compliance is also described for the
module.
The PSAX 1000 LIM3–1 module is illustrated in Figure 1.
The PSAX 1000 LIM3–1 module has been tested and verified by Lucent Technol-
ogies to operate with the following PSAX system software versions:
COMCODE
Software Release
109564716
10.0 and subsequent
Model
Faceplate Label
10N01
LIM3-1
Document Number: 255-700-360
Page 1 of 6
Advertisement
Related Manuals for Lucent Technologies PacketStar PSAX Series
Summary of Contents for Lucent Technologies PacketStar PSAX Series
- Page 1 ® PacketStar PSAX Multiservice Media Gateways PSAX 1000 3-Port Line Interface Module Description and Specifications Model 10N01 Purpose of This Document This document identifies and describes the PSAX 1000 3-Port Line Interface Module (LIM3–1) module and related safety information. It also includes proce- dures for installation and removal of the module from the PSAX chassis and veri- fication of the initial module startup, as well as information on obtaining trouble- shooting assistance.
-
Page 2: Safety Information
Safety Information When installing the LIM3–1 module, follow the safety guidelines provided in the ® PacketStar PSAX Multiservice Media Gateway Safety Guidelines, which accompanies this product, to help prevent serious personal injury and damage to the module. Please read all warnings and instructions supplied before beginning installation of the module. -
Page 3: Installing The Module
Table 1. LIM3-1 Module Specifications Specification Description Slot configuration Slot 4 on rear panel Dimensions 18.8 cm W by 10.4 cm D by 2.3 cm H (7.4 in. W by 4.1 in. D by 0.9 in. H) • Operating temperature range: System Environmental For AC-powered systems: 0°... -
Page 4: Configuring The Module
3 Hand tighten the two captive screws on the module, then tighen with a flat- head screwdriver. 4 Connect the appropriate cables to the module. Verifying the Initial Startup Verify that the status indicators ( ) on the module are not illuminated during normal traffic flow. - Page 5 Regulatory Standards Compliance, Safety and Electromagnetic Compatibility (EMC) The PSAX 1000 PSAX 1000 3-Port Line Interface module (model 10N01) is com- pliant with applicable safety and EMC standards when configured with the ® PSAX 1000 chassis (model 10S00). Please refer to the PacketStar PSAX 1000 Mul- tiservice Media Gateway Installation Guide for details.
- Page 6 Lucent Technologies, Inc. is not responsible for any damage or loss to your data or equipment resulting either directly or indirectly from use of this document.
