Page 1: User Guide
Top of Guide ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide ® for the PacketStar PSAX Multiservice Media Gateways Issue 1, October 2003 System Software Release 9.0.0 Doc. No.: 255-700-447...
Page 3: Legal Notices, Safety, And Regulatory Information
This material is protected by the copyright laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fash- ion by any entity (either internal or external to Lucent Technologies), except in accordance with applicable agreements, contracts or licensing, without the express written consent of the originating organization and the business management owner of the material.
Page 4: Regulatory Standards Compliance
Legal Notices, Safety, and Regulatory Information Regulatory Standards Compliance Regulatory Standards Compliance The PacketStar PSAX 2300 Multiservice Media Gateway, model 23S00, is compliant with a number of safety, electromagnetic compatibility (EMC), and telecommunications standards. The applicable standards for this system are ®...
Page 5: Table Of Contents
About Lucent Technologies ........
Page 6 Table of Contents Hardware Description ......... .2-1 Overview of This Chapter .
Page 7 Table of Contents Circuit Emulation Service for the Multiserial Module ..... .3-10 .3-10 Dynamic Bandwidth Circuit Emulation Service......3-10 .3-10 Dynamic CAC.
Page 8 Table of Contents Connection Gateway API Overview........3-29 3-29 PSAX System As a TCP Client/Server for the Connection Gateway API .
Page 9 Table of Contents How the ATM Traffic Shaping Algorithm Works ......3-61 .3-61 Formula for Determining the PCR of an ATM Traffic-Shaped Connection ..3-63 .3-63 Connection Egress Priority on PSAX Modules Supporting ATM Traffic Shaping .
Page 10 Table of Contents Changing Other User Options ......... 5-18 5-18 Configuring the System for Your Site .
Page 11 Table of Contents Switching the Line Timing Source ........5-83 .5-83 Alarm Status Values .
Page 12 Table of Contents Configuring V5.2 European IDLC........8-1 Overview of the V5.2 European IDLC .
Page 13 Table of Contents Configuring the View-based Access Control Model (VACM) ..... .9-15 .9-15 Configuring VACM Access Groups ........9-15 .9-15 Modifying VACM Access Groups .
Page 14 Table of Contents OAM Activation and Deactivation ........11-23 11-23 Backing Up and Restoring PSAX System Files .
Page 15 Table of Contents Upgrading the PSAX System Software ........13-22 .13-22 Manually Selecting I/O and Server Module Firmware Drivers .
Page 16 Table of Contents Interface Type by Input/Output Module Type ....... . . C-31 C-31 ATM Service Categories in the PSAX System .
Page 17 Table of Contents 2-Port DS3 ATM Module (20N02) ........D-16 D-16 Software Features .
Page 18 Table of Contents 1-Port Channelized OC-3/STM-1 CES Module (23N12 (MM)/23N13 (SM)) ..D-28 D-28 Software Features..........D-28 D-28 Hardware Features .
Page 19 Table of Contents Tones ............D-44 D-44 Hardware Features .
Page 20 Table of Contents ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447...
Page 21 List of Figures Field Description Table Example ..........1-4 .1-4 Main Menu Help Window .
Page 22 List of Figures PSAX 2300 Multiservice Media Gateway System Logon Window ..... . 5-2 Console Interface Main Menu Window ......... 5-5 User Options Window—Logged on as Username Root .
Page 23 List of Figures PNNI Node PGL Configuration ..........6-10 .6-10 PNNI Node Timer Configuration Window .
Page 24 List of Figures 7-11 ATM Trunking Data Channel Table ......... . . 7-28 7-28 Site-Specific Menu Window (Feature Turn On/Off Option Selected) .
Page 25 List of Figures 10-5 PNNI Node Table Window ..........10-14 .10-14 10-6 PNNI Node Configuration Window .
Page 26 List of Figures 13-7 Console Interface Main Menu Window (Software Version Configuration Option Selected) 13-23 13-23 13-8 The Software Version Configuration Window (Firmware Version Control Selected) ..13-24 13-24 13-9 Firmware Version Control Window ......... . 13-26 13-26 ETHERNET1 and ETHERNET2 Connector Pin Locations .
Page 27 List of Tables Text Conventions ............1-2 .1-2 Command Description Table Example .
Page 28 List of Tables 5-14 Field Descriptions for the System Date and Time Panel on the Site-Specific Configuration Window ..........5-28 5-28 5-15 Commands for the TCP Server Configuration Window .
Page 29 List of Tables 6-12 Field Descriptions for the PNNI Node SVCC Configuration Window ....6-17 .6-17 6-13 Commands for the PNNI Node Timer Configuration Window ......6-19 .6-19 6-14 Field Descriptions for the PNNI Scope Mapping Configuration Window .
Page 30 List of Tables 6-52 Field Descriptions for the PNNI Neighbor Peer Configuration Window ....6-65 6-65 6-53 Commands for the PNNI Neighbor Peer Port Table Window ......6-67 6-67 6-54 Field Descriptions for the PNNI Neighbor Peer Port Table Window .
Page 31 List of Tables 8-12 Field Descriptions for the V5 Interface Table Window ......8-23 .8-23 8-13 Commands for the V5 Interface Configuration Window .
Page 32 List of Tables 9-16 Commands for the Vacm Access Configuration Window ......9-18 9-18 9-17 Field Descriptions for the Vacm Access Configuration Window .
Page 33 List of Tables 10-23 Commands for the ATM Security Statistics Window ......10-49 .10-49 10-24 Field Descriptions for the ATM Security Statistics Window .
Page 34 List of Tables 13-14 Field Descriptions for the Firmware Version Control Window ..... . 13-27 13-27 CPU4 Module CONSOLE Connector Pin Assignments ......A-1 CPU4 Module ETHERNET1 and ETHERNET2 Connector Pin Assignments .
Page 35: Getting Started
Getting Started Purpose of This Guide ® The PacketStar PSAX 2300 Multiservice Media Gateway User Guide provides a description of the PSAX 2300 system and its functions and features. It also provides information about using the console interface to: • Configure basic system parameters and managing the PSAX 2300 system •...
Page 36: Related Reading
Related Reading Product Information Library To install, operate, and configure your PSAX system and I/O and server mod- ules, read the PSAX publications provided on your Lucent Technologies PacketStar PSAX Multiservice Media Gateways Products, Product Information Library CD-ROM. Printed Documents...
Page 37: Icons And Symbols
Chapter 1 Getting Started Conventions Icons and Symbols Follow all safety guidelines in this document to help prevent personal injury to you and damage to the PSAX 2300 Multiservice Media Gateway system. Standard icons and symbols to alert you to dangers, warnings, cautions, and notes are described as follows: DANGER: Warnings for a personal injury hazard are identified by this format.
Page 38: Selecting Options, Fields, And Commands
Chapter 1 Getting Started Conventions Identifies editable fields Identifies initial field Describes the function of the field or display-only fields on value default and special instructions for screens configuring modules Field Name Field Values Description Interface Type Default: 0 Specifies the type of end-to-end connection Range: 0-22 protocol that governs the transmission parameters Format: Numeric...
Page 39: Help Information
Chapter 1 Getting Started Help Information Table 1-3. System Responses to Selecting Options, Fields, or Commands For a selected... the following occurs: option name The window corresponding to the option name is displayed. field The following variations occur: • The field entry area is blank or contains the default or previously entered value.
Page 40: Main Menu Help Window
Chapter 1 Getting Started Help Information ® recorded in a trap log. See the PacketStar PSAX Simple Network Management Protocol (SNMP) Trap Reference Guide for details on displaying the trap log and obtaining explanations of the trap messages. To view the Help windows from the Console Interface Main Menu window, perform the following procedure.
Page 41: Technical Support
For More Information To learn more about the PacketStar PSAX family of Multiservice Media Gate- ways and the complete line of Lucent Technologies products, visit our Web site at http://www.lucent.com. About the PacketStar PSAX Product Family Lucent Technologies provides a complete range of PSAX Multiservice Media Gateways in the PacketStar PSAX family.
Page 42: Psax 1250 Multiservice Media Gateway
PSAX 2300 Multiservice Media Gateway The PacketStar PSAX 2300 Multiservice Media Gateway offers carrier-grade, high-density multiservice ATM access functions. Designed as the multiservice media gateway for the central office or for a large enterprise customer, the PSAX 2300 system provides network access for time-division multiplex voice, frame relay, 10/100BASE-T Ethernet, and ATM data applications.
Page 43: Comments On This Guide
Chapter 1 Getting Started Comments on This Guide media gateway, the PSAX 4500 system provides highly reliable network access for time-division multiplex voice, frame relay, 10/100BASE-T Ether- net, and ATM data applications. When it is functioning in a redundant operating mode and after it has experi- enced a single-point failure, the PSAX 4500 system provides up to 4.2 Gbps of ATM cell bus capacity.
Page 44 Chapter 1 Getting Started Comments on This Guide ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 1-10 255-700-447...
Page 45: Hardware Description
Hardware Description Overview of This Chapter This chapter presents a description of the PacketStar PSAX 2300 Multiservice Media Gateway system hardware. System Features The PacketStar PSAX 2300 Multiservice Media Gateway provides high-capac- ity, universal connectivity over an asynchronous transfer mode (ATM) wide area network (WAN).
Page 46: Functional Description
Chapter 2 Hardware Description Functional Description • Input/output (I/O) and server modules (see your Lucent Technologies account manager for ordering information). • Blank faceplate modules—required for empty I/O and server slots T IV T IV T IV T IV T IV...
Page 47: Backplane
Chapter 2 Hardware Description Functional Description modules reside below the cable turndown loops and air filter compartment in the middle of the chassis. The rear panel provides power and ground termi- nations for the chassis and additional module slots for future enhancements. The chassis includes a midplane printed circuit board (PCB) designed to pro- vide an interface between the front and rear panel slots.
Page 48: Stratum 3-4 Module
Chapter 2 Hardware Description Functional Description Figure 2-2. -48 V dc Power Supply Module Stratum 3–4 Module The PSAX 2300 Stratum 3–4 ANSI-compliant module provides synchroniza- tion and common equipment monitoring for the PSAX 2300 system. While fulfilling the normal clock-timing role, the module also serves as a switch, connecting Stratum A to bus A and Stratum B to bus B on each of the three segments of the backplane.
Page 49: Cpu4 Module
Chapter 2 Hardware Description Functional Description CPU4 Module The CPU4 module (model 23N20) is a next generation CPU module for the PSAX 2300 system. With respect to the current CPU2 module, it has increased processing power, more SDRAM, a larger flash disk, and a second Ethernet port for future growth capabilities.
Page 50: Cpu2 Module
Chapter 2 Hardware Description Functional Description Figure 2-3. CPU4 Module CPU2 Module Operating in a nonload-sharing, active/standby mode, the CPU2 module (see Figure 2-4) provides the processing, switching, and storage functions for the system. With a RISC-based microprocessor, the module has the processing power to maintain data flow, perform numerical calculations, and manage the direct memory access (DMA) interfaces.
Page 51: Alarm Module
Chapter 2 Hardware Description Functional Description The standby module supports complete console and SNMP interfaces, in the same way the active module supports them, except that the standby module blocks all set operations. FAIL ACTIVE Figure 2-4. CPU2 Module Alarm Module The Alarm module (see Figure 2-5) provides two connectors that allow for connections with external facility sensor inputs (doors, temperature, and so on), chassis alarm outputs (visible and audible), external device controls...
Page 52: Alarm Module
Chapter 2 Hardware Description Functional Description CRITICAL MAJOR MINOR Figure 2-5. Alarm Module Critical Major Minor ALARM CRITICAL CO Alarms MAJOR MINOR Alarms Output Temp. Sensor Input Cold Figure 2-6. Example Configuration with the Alarm Module ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447...
Page 53: Hardware Specifications
Chapter 2 Hardware Description Hardware Specifications Hardware Specifications Chassis Specifications The chassis specifications for the PSAX 2300 chassis are given in Table 2-1. Table 2-1. Chassis Hardware Specifications Specification Description Slot configuration 19 module slots (15 for user-selected I/O and server mod- ules, 2 for CPUn modules, and 2 for Stratum 3–4 mod- ules) and 2 Power Supply module slots Dimensions...
Page 54: Power Supply Module Specifications
Chapter 2 Hardware Description Hardware Specifications Power Supply Module Specifications The specifications for the PSAX 2300/4500 -48 V dc Power Supply module are given in Table 2-3. Table 2-3. -48 V dc Power Supply Module Specifications Specification Description Slot Configuration Two dedicated slots below module slots Power -42.5 to -56.5 V dc...
Page 55: Cpu4 Module Specifications
Chapter 2 Hardware Description Hardware Specifications CPU4 Module Specifications The specifications for the CPU4 module are given in Table 2-5. Table 2-5. CPU4 Module Specifications Specification Description Slot configuration Slots 16 and 17 Dimensions 17.3 cm H x 2.4 cm W x 24.1 cm D (6.8 in.
Page 56: Packetstar I/O And Server Modules Specifications
Chapter 2 Hardware Description Hardware Specifications Table 2-7. Physical Hardware Specifications for the Alarm Module Specification Description Dimensions 17.3 cm H x 2.41 cm W x 23.2 cm D (6.8 in. H x 0.95 in. W x 9.13 in. D) Weight 360 g (0.8 lb.) Maximum Relay and Sensor Power 1 A at 48 V dc typical, 60 W maximum, 2 A dc maximum...
Page 57: Performance And Power Specifications For The Psax Modules
Chapter 2 Hardware Description Hardware Specifications Table 2-9. Performance and Power Specifications for the PSAX Modules Total Module Maximum Maximum Output Chassis Module Amount of Program and Input Power † ‡ Buffer Speed SDRAM Data Space Buffer Consumption DS1/T1 Interface Modules 20N33 6-Port DS1 16 MB...
Page 58 Chapter 2 Hardware Description Hardware Specifications Table 2-9. Performance and Power Specifications for the PSAX Modules (Continued) Total Module Maximum Maximum Output Chassis Module Amount of Program and Input Power † ‡ Buffer Speed SDRAM Data Space Buffer Consumption 20N03 1-Port 8 MB 4 MB...
Page 59 Chapter 2 Hardware Description Hardware Specifications Table 2-9. Performance and Power Specifications for the PSAX Modules (Continued) Total Module Maximum Maximum Output Chassis Module Amount of Program and Input Power † ‡ Buffer Speed SDRAM Data Space Buffer Consumption 20N13 1-Port OC-3c 8 MB 3 MB...
Page 60 Chapter 2 Hardware Description Hardware Specifications Table 2-9. Performance and Power Specifications for the PSAX Modules (Continued) Total Module Maximum Maximum Output Chassis Module Amount of Program and Input Power † ‡ Buffer Speed SDRAM Data Space Buffer Consumption 20N93 1-Port 32 MB 8 MB...
Page 61 Chapter 2 Hardware Description Hardware Specifications Table 2-9. Performance and Power Specifications for the PSAX Modules (Continued) Total Module Maximum Maximum Output Chassis Module Amount of Program and Input Power † ‡ Buffer Speed SDRAM Data Space Buffer Consumption 23N28 Tones and 1 MB 512 KB...
Page 62 Chapter 2 Hardware Description Hardware Specifications ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 2-18 255-700-447...
Page 63: System Features
• An advanced queuing and cell-switching algorithm, provided by the AQue- Man (adaptive queue management) firmware algorithm, a patented tech- nology offered by Lucent Technologies to differentiate voice, video, and data requirements. The AQueMan algorithm maximizes bandwidth effi- ciency while ensuring QoS on a congested network.
Page 64: Interface Architecture
Chapter 3 System Features Interface Architecture • A connection gateway application programming interface (API) that pro- vides an interface to the PSAX 2300 by which an external workstation (gateway) can control the PSAX 2300 ATM switching, using non-native ATM networking protocols Through the use of the API, the gateway and the PSAX 2300 can combine to perform powerful interworking among ATM, Integrated Services Digital Network (ISDN), Signaling System 7 (SS7), channel associated signaling...
Page 65: Connections Supported
Chapter 3 System Features Connections Supported • Physical media access—The physical media access layer handles functions specific to each physical interface, connecting each user port to other users or network elements. • Service protocol translation—The service protocol translation process per- forms segmentation and reassembly (SAR) to adapt non-native ATM ser- vices to ATM-based services and back again.
Page 66: Spvc Reconnection Priority Scheme
Chapter 3 System Features Connections Supported Specifically, an SPVC is established and released between the two network interfaces serving the PVC. The user assigns unique ATM addresses, including the SEL octet in the case of a private ATM address (see Section 3.1 of the UNI 4.0 signaling specification), to the corresponding NIs, thus identifying the starting point and ending point of the SPVC.
Page 67: Sample Spvc Reconnection Prioritization Scheme
Chapter 3 System Features Connections Supported Table 3-1. Sample User-Defined Priority Scheme for Reconnecting SPVC ATM IMA Links User-Assigned Traffic Type Typical ATM Service Type Priority Code TDMA/CDMA control channels CBR-1 or VBR-express AMPS channel reserved for 911 CBR-2 emergency calls GSM control channels VBR-express Digital voice channels...
Page 68: Modification Of Parameters For Active Spvc Connections
Chapter 3 System Features Connections Supported • The maximum total number of AAL2 SPVC trunk connections in the chas- sis must not exceed 32. • The ATM uplink must be a 6-Port DS1 IMA module. • The PSAX with the priority system enabled will work with a PSAX with passive side SPVCs that has the priority system disabled.
Page 69: Svc Functional Description
Chapter 3 System Features Connections Supported SVC Functional SVC signaling, per ATM Forum UNI 3.0 and UNI 3.1, is selectable on a per- Description port basis. Call control is performed on the CPU module, including manage- ment of the call-state transitions for each of the calls. This process allows on- demand allocation of bandwidth and connection resources.
Page 70 Chapter 3 System Features Connections Supported Call States Description #0—Null No call exists. • User—The user has requested that the system establish an #1—Call initiated outgoing call on the network. • Network—The network has received the call establishment request, but has not yet responded to the outgoing call. #3—Outgoing call •...
Page 71: User Interfaces
Chapter 3 System Features User Interfaces The following state transition messages are used for ATM point-to-point call and connection control: • Call proceeding Call establishment messages: • Connect • Connect acknowledgment • Setup • Release Call clearing messages: • Release complete Miscellaneous messages: •...
Page 72: Spvc Support For Ces
Chapter 3 System Features User Interfaces Forum standard for G.704 CAS. M13 multiplexing capabilities are also sup- ported, providing the ability to perform circuit emulation on a T1 or E1 link connected to a TDM network and convert it into ATM cells, in accordance with the ATM Forum CAS specification af-saa-0032.000.
Page 73: Dynamic Cac
Chapter 3 System Features User Interfaces Dynamic CAC Connection Admission Control (CAC) is used to determine if a connection set-up request can be supported by available resources. When a PSAX system initializes, the CAC algorithm determines, in a static sense, the maximum available bandwidth for each interface.
Page 74: Interim Interswitch Signaling Protocol (Iisp) Interface
Chapter 3 System Features User Interfaces instead of using time division multiplexing (TDM). By inverting the HDLC frame bits, fewer bit value 1s (ones) are transmitted in the backhaul data, providing additional savings. The bit inversion process uses the new 5ESS switches that support a mixture of inverted and standard HDLC passthrough interfaces.
Page 75: Pnni Features Supported By The Psax Systems
Chapter 3 System Features User Interfaces Phase 3 of the Private Network-Network Interface feature enhancement includes the additions of functionality from the ATM Forum PNNI standard af-pnni-0055.000 Annex F, Hierarchy Configuration, and Appendix G, Minimum Subsets (all border node capable switching systems features). Ten hierarchal levels are supported.
Page 76: Pnni Topology State Element (Ptse) Information
Chapter 3 System Features User Interfaces • Allows up to 10 levels in a hierarchy but does not require them. It is also possible to deploy PNNI with one peer group encompassing all switches within a network. • Sends hello packets across interswitch network-to-network interface (NNI) links that enable switches in the same peer group to discover one another.
Page 77 Chapter 3 System Features User Interfaces In networks that use a PNNI hierarchy, the switches at each level elect one switch as a peer group leader (PGL). This PGL concurrently belongs to its own level and to the next highest level, where it acts as a logical group node (LGN) that represents and summarizes topology information needed to reach any of the lower-level switches.
Page 78: Atm Maintenance
Chapter 3 System Features User Interfaces Grandparent Peer Group Logical Link Logical Group Node Highest Level Peer Group Peer Group Leaders Parent Peer Group PG (A) PG (B) Child Peer Groups PG(A.2) A.2.3 PG(B.1) PG(B.2) A.2.2 PG(A.1) PG(C) B.2.1 A.2.1 B.1.1 PG(A.4) B.2.2...
Page 79: Integrated Link Management Interface (Ilmi)
Chapter 3 System Features User Interfaces away from the PNNI link with the high administrative weight, sending it to the preferred connection with lower administrative weight. The freed-up interface can then be reconfigured. ATM Maintenance Mode is a way of rerouting SPVCs and SVCs from an ATM port running PNNI.
Page 80: Ilmi Over Pnni Overview
Chapter 3 System Features User Interfaces With System Software Release 6.5.0, VPI and VCI range negotiation is sup- ported. Release 6.5.0 also determines the operational status of the logical port. ILMI is supported for all ATM UNI 3.0 and ATM UNI 3.1 interfaces. ILMI over PNNI The ILMI over PNNI feature supports VPI and VCI range negotiation using Overview...
Page 81: Inverse Multiplexing Over Atm (Ima)
Chapter 3 System Features User Interfaces Major highlights of ATM UNI 4.0 include: • Individual QoS parameters • Elements to support narrowband ISDN over ATM • Procedures,connection scope selection information element, and new MIB object to support the ATM AnyCast capability. •...
Page 82 Chapter 3 System Features User Interfaces ~ In order to change any group configuration parameters, the group must be completely unconfigured. ~ There may be difficulties if the IMA group is configured for symetric operation but has asymetric link delays. For example, one end may con- sider links A, B, and C to have problems, while the other end considers D, E, and F to have problems.
Page 83: Frame Relay-To-Atm Interworking
Chapter 3 System Features User Interfaces Frame Relay-to-ATM Interworking Frame relay-to-ATM interworking is performed at the network level, Frame Relay Implementation Agreement FRF.5, and at the service level, FRF.8. This allows a PacketStar Multiservice Media Gateway to adapt and concentrate traffic from one frame relay network and transmit it to other frame relay or ATM networks.
Page 84 User Interfaces Lucent Stinger™ DSLAM, a CellPipe™ IAD or AdTran TA624.850, and a cen- tral office voice switch, such as the Lucent Technologies 5ESS switch, or with a Nortel DMS switch. Operating on T1 circuits, the GR-303 digital loop carrier service has provi- sions for both an open interface network architecture and a digital loop car- rier system.
Page 85: Fax/Modem Master/Slave Support
Chapter 3 System Features User Interfaces The 6-port DS1/T1, 1-port Channelized DS3,and 1-port Channelized STS-1e modules, used in conjunction with the DSP2C Voice Server module and also with the Lucent Stinger DSLAM and CellPipe IAD, provide a complete end-to-end communications solution that fully complies with the GR-303 interface standard.
Page 86: Dynamic Bandwidth Allocation
Chapter 3 System Features Dynamic Bandwidth Allocation The following modules have been certified as interoperable with the PSAX 2300 system, the Stinger DSLAM, the CellPipe IAD, and the Nortel DMS CO switch. • 1-Port Channelized DS3 Multiservice • DSP2C Voice Server •...
Page 87: Network Management
Chapter 3 System Features Network Management NORMAL OPERATIONS Interface 12-Port MD DS1/E1/DS0A CES Module Backplane Traffic Allowed INHIBITED OPERATIONS Interface 12-Port MD DS1/E1/DS0A CES Module Backplane Traffic Inhibited Normal Traffic No Traffic Figure 3-3. DBA-Controlled Backplane Traffic The DBA feature is supported on the following module: 24N64 12-Port Medium-Density DS1/E1/DS0A CES (DS1 mode only)
Page 88: Network Management Options
Chapter 3 System Features Network Management In conjunction with the visual indicators displayed on the front panels of the individual modules, the system offers a full complement of SNMP trap mes- sages that alert the user to faults in the PSAX system. Usage-based messages collected on the CPUn module allow a service provider to collect cell counts for traffic and performance monitoring, and for fault detection.
Page 89: Simple Network Management Protocol Version 3
Chapter 3 System Features Network Management tion is set up using an I/O module with an ATM cell bearing port (for example, the OC-3c, STM-1, DS1, DS3, E1, and E3 modules). Three basic types of configuration are possible: • Direct connection •...
Page 90: Navis Aqueview ® Element Management System
Chapter 3 System Features PSAX System Software Features ® ® Navis AQueView Element Management System ® ® The Navis AQueView Element Management System (EMS) is a GUI-based element management tool that is used to provision the PacketStar PSAX 1000, PSAX 1250, PSAX 2300, and PSAX 4500 systems. The AQueView EMS enables a network of PSAX devices to be managed and provisioned from a single location, using easy-to-use windows.
Page 91: Connection Gateway Api
Chapter 3 System Features PSAX System Software Features This feature polls the PSAX MIB every seconds and stores the information in memory. The number of records that can be stored is initially set at 1,000. At the end of the user-specified measurement period, the collected data is sent via FTP to the statistics server.
Page 92: Psax System As A Tcp Client Device
Chapter 3 System Features PSAX System Software Features Ethernet ATM I/O Module Module In-band In-band Local Access Concentrator Management Management (Primary TCP Client) PVC Connection PVC Connection Ethernet Hub Ethernet ATM I/O ATM I/O Call Controller Module Module Module Device (Computer) (TCP Server) Local Access Concentrator Remote Access Concentrator...
Page 93: Fractional Pri Support
Chapter 3 System Features PSAX System Software Features Fractional PRI In the area of ISDN deployment, there are times when a full PRI (23B+D Support channels) is both unnecessary and wasteful. For instance, a small branch office with 15 phone lines can probably be served comfortably by only 10 B- channels and 1 D-channel.
Page 94: Ds0A Non-Latched Loop Codes
Chapter 3 System Features PSAX System Software Features ment (CPE) products at the edge of an ATM network. The PSAX system also generates alarm indication signals on all affected DS1 connections whenever a loop is activated. DS0A Non-Latched Loop Codes In addition to the no loopback and the line loopback modes of operation present in the 12-Port Medium-Density DS1/E1/DS0A module (DS0A mode) in Release 7.1.3, three new, user-configurable, loopback modes have been...
Page 95: Psax System Traffic Protection Capabilities
Chapter 3 System Features PSAX System Software Features PSAX System Traffic Protection Capabilities 1:1 Traffic Protection The 1:1 protection capability of the PSAX systems provides traffic protection Patch Panel Module by configuring the system with two 1:1 protection capable I/O modules, such as the 24-Port High-Density DS1 Multiservice module, and the PSAX 24-Port RJ Protection Patch Panel.
Page 96 Chapter 3 System Features PSAX System Software Features The user can manually switch traffic from the working module to the pro- tection module (see Chapter 3 of the module user guide). This action might be taken in preparation for removing the working module from the chassis for maintenance purposes or testing the working module for diagnostic purposes.
Page 97: Aps/Msp Protection On The Optical Modules
Chapter 3 System Features PSAX System Software Features Restoring Service to the Working Module After automatic or manual switchover has been performed and the replace- ment or testing of the working module is completed, the user manually switches the traffic back from the protection module to the working module, which resumes Active mode.
Page 98: Interface Protection Group Feature
Chapter 3 System Features PSAX System Software Features Interface Protection The Interface Protection Group feature provides the capability to configure Group Feature interface protection groups of ATM interfaces that support PVC and SPVC connections on PSAX modules. Interface protection groups can be configured as primary (active) and standby (idle).
Page 99: Alternate Rerouting Using Dual-Homed Pvcs
Chapter 3 System Features PSAX System Software Features PSAX 2300 Primary 1 Group 1 Primary 2 Group 1 Primary 3 Group 1 AX4000 Primary 4 Group 1 Gen/Ana Primary 5 Group 1 Primary 6 Group 1 Figure 3-7. Typical Interface Protection Group Configuration This software feature moves connections within a defined group whenever a failure condition occurs or the user issues a switchover/switchback com- mand.
Page 100 Chapter 3 System Features PSAX System Software Features The DHPVC feature enables users to set up a primary and a standby connec- tion using one interface on the PSAX system. In other words, users do not need to configure a separate interface that functions solely for a standby con- nection.
Page 101: Firmware Release Control
Chapter 3 System Features PSAX System Software Features Application A pair of PSAX systems, acting as an originating node and a terminating node, cooperatively accomplish the networkwide rerouting regardless of the number of connections affected by the network outage. The PSAX system can switch traffic on a primary connection to a standby connection within one second, avoiding service interruptions under reasonably likely network congestion conditions.
Page 102: Forward Error Correction
Chapter 3 System Features PSAX System Software Features PSAX I/O modules released with PSAX system software Release 6.0.0 and subsequent releases are supported by the Firmware Release Control feature. The I/O modules that were released before PSAX system software Release 6.0.0 will work in the PSAX system, but are not supported by the Firmware Release Control feature.
Page 103: H.248 Media Gateway Access Protocol
Chapter 3 System Features PSAX System Software Features • 1/4 rate For each set of three data cells, the encoder creates four encoded cells. This rate provides correction of payload cells with 10 BER to 0 BER. • 1/8 rate For each set of seven data cells, the encoder creates eight encoded cells.
Page 104: Interface And Connection Naming
Chapter 3 System Features PSAX System Software Features ® The PacketStar PSAX Multiservice Media Gateways support the following H.248 functions: • PSTN terminations to PSTN terminations • Transcoding of media streams between TDM network and ATM packet net- works • Terminations processed: ~ PSTN-to-PSTN terminations ~ PSTN-to-ATM terminations •...
Page 105: Internet Protocol (Ip) Throttling
Chapter 3 System Features PSAX System Software Features • PRI ISDN UNI and NNI • Terminal emulation The PVC and SPVC connection configuration windows provide access to the new Connection Name Assignment window where the user creates the con- nection name. All named connections in the PSAX system can be viewed on the new Connection Name Table window, which is accessed from the Con- nection Configuration Menu window.
Page 106: Lanet Protocol
Chapter 3 System Features PSAX System Software Features Rate field on the IP Throttling window. The feature has no impact on the IP data path if the feature is disabled. The IP Throttling feature processes only ingress traffic, not egress traffic. LANET Protocol The LANET (limitless ATM network) protocol, coupled with a simple error- tolerant addressing scheme, facilitates reliable delivery of ATM cells in a...
Page 107: Relationship Between Lanet And The Osi Model
Chapter 3 System Features PSAX System Software Features SERVICE-INDEPENDENT ARCHITECTURE Voice Video Images Data Layer 7 Layer 6 Layer 5 Layer 4 CELL-BY-CELL ENCRYPTION Layer 3 Layer 2 LANET Protocol Layer 1 Encryption Error Correction Bit Interleaf Satellite Radio Land Lines From bits per second to megabits per second Figure 3-9.
Page 108: Lanet Frame Structure
Chapter 3 System Features PSAX System Software Features encodes the header address within the same 10-nibble header space of stan- dard ATM cells. In addition, it avoids the extra delay (detrimental to CBR traffic) required of multiple header-encoding schemes. In practice, to tolerate 2-bit random errors or 5-bit burst errors requires set- ting up 526 addresses for each channel.
Page 109: Operations, Administration, And Maintenance (Oam)
Chapter 3 System Features PSAX System Software Features Operations, Administration, and Maintenance (OAM) Overview of OAM The Operations, Administration, and Maintenance (OAM) feature, available on all PSAX systems gives Public Service Providers a way to detect and receive reports on abnormal behavior in virtual path connections (VPCs) and virtual channel connections (VCCs) in an ATM network.
Page 110: Oam Atm Layer Flows
Chapter 3 System Features PSAX System Software Features Header Payload OAM Function Type Reserved Header 360 bits (45 bytes) Function-specific field Error Cell Detection Type Code Figure 3-11. OAM Cell Fields • Header: this is the same as the ATM cell header •...
Page 111: Oam F4 Flows
Chapter 3 System Features PSAX System Software Features Figure 3-12. OAM Hierarchy OAM F4 Flows OAM flows for F4 in-band maintenance are defined at the ATM layer for the VPC level. It is used for path level connections, where the virtual path (VP) flows are identified by reserved values within the path.
Page 112: Atm Layer Oam Functions
Chapter 3 System Features PSAX System Software Features • Existence in the same physical route for fault correlation and performance information User cells at the F5 level carry VCI cells which are defined below: (Payload Type Indicator) PTI=4 is a segment OAM F5 flow cell. This flow is identified by its standardized PTI, and is used for end-to-end VCC operations communication.
Page 113: Packet Pipe Aal5-To-Aal2 Wireless Trunking For Mobile Voice
Chapter 3 System Features PSAX System Software Features • Segment-endpoint: Sends a loopback cell from a designated segment to a designated segment end-point. • Next-connection-point: Sends segment OAM cells within designated segments to check the connectivity between the segment point from where the cell was issued to the next immediate connection point.
Page 114: Snmp Trap Descriptions
Chapter 3 System Features PSAX System Software Features This feature supports packet switched wireless backhaul networks for inter- connecting Lucent MSCs and Series II base stations using the Lucent propri- etary packet pipe protocol over land lines. This protocol performs encapsula- tion within ATM AAL2 for various cell site sizes.
Page 115: Cbr And Vbr Service-Level Priorities
Chapter 3 System Features PSAX System Software Features ties. One queue set addresses avoidance of cell loss, which is normally a con- cern for data traffic, while the other set manages cell transfer delay, which is critical to voice and some video traffic. Within each set of queues, The AQueMan algorithm assigns internal priori- ties even more specialized than the ATM Forum class definitions.
Page 116: Atm Traffic Management
Chapter 3 System Features PSAX System Software Features ATM Traffic Management Guaranteed Frame The Guaranteed Frame Rate feature for ATM traffic management provides Rate the GFR.2 service type on ATM PVC connections. The GFR.2 service type enables users to specify a cell transmission rate up to the PCR rate, but the network can commit to only carry cells in complete unmarked frames at the MCR rate.
Page 117: Early Packet Discard
Chapter 3 System Features PSAX System Software Features 23N73 1-Port OC-12c/STM-4c Single-Mode 20N72 1-Port OC-3c 1+1 APS Multimode 20N73 1-Port OC-3c 1+1 APS Single-Mode 20N92 1-Port STM-1 1+1 MSP Multimode 20N93 1-Port STM-1 1+1 MSP Single-Mode 24N70 2-Port OC-3c/STM-1 ATM Multimode 24N71 2-Port OC-3c/STM-1 ATM Single-Mode 24N72...
Page 118: Cell Bus Traffic Shaping Occurs On Egress To The Backplane
Chapter 3 System Features PSAX System Software Features Note: The feature that was formerly known as “Traffic Shaping” is now called “Cell bus traffic shaping”to distinguish it from the “ATM Traffic Shaping” feature, which was formerly called “Rate Shap- ing”. Cell bus traffic shaping ensures that VBR traffic entering the Multiservice Media Gateway system (via the OC-3c TS and STM-1 TS modules) complies with the parameters of established service contracts.
Page 119: Cell Bus Traffic Shaping Using The Input Cell-Selection Algorithm
Chapter 3 System Features PSAX System Software Features (and hence high packet loss). With the traffic shaping feature of the OC-3c TS and the STM-1 TS modules, the Multiservice Media Gateway system effec- tively smooths bursty input LAN traffic to comply with the carrier traffic con- tract.
Page 120: Atm Traffic Shaping
Chapter 3 System Features PSAX System Software Features The algorithm processes traffic moving out of the input cell selection buffer according to the SCR of the particular VPC/VCC. The MBSs of traffic shaped output are set as follows: Sustained Cell Rate Maximum Burst Size (MBS) of Traffic (SCR) of VPC/VCC Shaped Output...
Page 121: Configuring Atm Traffic Shaping For Hdlc, Frame Relay, And Ethernet Virtual Channels
Chapter 3 System Features PSAX System Software Features 4-Port Ethernet Module Side A PSAX Chassis Backplane or A to B Side Ingress Midplane Tx/Rx Bursty PCR to 6 MB Egress B to A Side Traffic Shaping does not occur on egress B to A side direction 2-Port or 4-Port OC-3c/STM-1 Module Side B Ingress...
Page 122: Task Summary For Implementing Atm Traffic Shaping
Chapter 3 System Features PSAX System Software Features 23N73 1-Port OC-12c/STM-4c Single-Mode 24N70 2-Port OC-3c/STM-1 ATM Multimode 24N71 2-Port OC-3c/STM-1 ATM Single-Mode 24N72 4-Port OC-3c/STM-1 Multimode 24N73 4-Port OC-3c/STM-1 Single-Mode 23N74 3-Port DS3/E3 ATM For frame relay traffic, the PSAX system software automatically calculates egress peak cell rate based on frame relay traffic parameters.
Page 123: Atm Traffic Shaping For Cbr And Vbr-Rt
Chapter 3 System Features PSAX System Software Features interface (for more information, see the earlier section ”VBR ATM Traffic Shaping Priorities”). Note that the ATM Traffic Shaping feature does not use the connection's MBS. This, in effect, creates a ‘guard band’ around the con- nection to minimize the probability that a CBR or VBR-rt cell will be trans- mitted at the same time a ATM traffic-shaped cell is scheduled to be transmit- ted.
Page 124: Atm Traffic Shaping Table Sample Queue 1 Values
Chapter 3 System Features PSAX System Software Features Example Example Example Box 80,000 Box 3 Box 1 Box 2 Queue 1 = 6 Queue 1 = n Queue 1 = 1999 Queue 1 = 386 2046 2046 2046 2046 Figure 3-17. ATM Traffic Shaping table Sample Queue 1 Values ATM Traffic Shaping The example below follows the ATM traffic shaper action for boxes 1–3 on Software in Action...
Page 125: Formula For Determining The Pcr Of An Atm Traffic-Shaped Connection
Chapter 3 System Features PSAX System Software Features Traffic-shaped queues have the priority of "VBR-shaping" which is below VBR-rt2 and above VBR-nrt1. Generally, in an AQueMan environment, traf- fic from all CBR queues and VBR-rt queues will be sent before the traffic shaped queues are examined.
Page 126: Atm Traffic Shaping Capabilities By Psax Module
Chapter 3 System Features PSAX System Software Features 24N71 2-Port OC-3c/STM-1 ATM Single-Mode 24N72 4-Port OC-3c/STM-1 Multimode 24N73 4-Port OC-3c/STM-1 Single-Mode Connections employing the ATM Traffic Shaping feature have egress priority above VBRnrt and UBR connections but below that of CBR and VBRrt con- nections on the following modules: 20N72 1-Port OC-3c 1+1 APS Multimode...
Page 127 Chapter 3 System Features PSAX System Software Features Table 3-4. ATM Traffic Shaping Capabilities by Module (Continued) Max. No. Release in Precision of Min. PCR of VCs Which Traffic Queue Modules Using Priority Traffic Shaping for Traffic Size Traffic Shaping Shaping †...
Page 128: Virtual Interfaces
Chapter 3 System Features PSAX System Software Features Virtual Interfaces Virtual interfaces (VIs) are configured on a module’s physical ports and allow virtual channels (VCs) to be assigned to virtual trunks, each with its own pri- ority queues. By using VIs instead of physical connections, it is possible to achieve an advanced bandwidth management capability allowing for fully flexible service provisioning.
Page 129: Configuration Compatibility For Atm Traffic Shaping, Upc, And Vi
Chapter 3 System Features PSAX System Software Features 24N73 4-Port OC-3c/STM-1 Single-Mode 23N74 3-Port DS3/E3 ATM 45N74 3-Port DS3/E3 ATM Protection Configuration Compatibility for ATM Traffic Shaping, UPC, and VI Configuration compatibility among the ATM Traffic Shaping, UPC Support, and VI Support features is shown in Table 3-5. In the table, Yes indicates that the two features coinciding in the matrix can be configured in the same interface, and No indicates that they cannot.
Page 130: Voice Compression
Chapter 3 System Features PSAX System Software Features I/O Module 1 Ingress Path VI or TS Egress Path Chassis Backplane I/O Module 2 Ingress Path VI or TS Egress Path Figure 3-19. Combining the UPC Feature and Either the TS or VI Feature on a Connection Voice Compression Voice compression over AAL2 works for any voice channel using A-Law or...
Page 131: Voice Processing
Chapter 3 System Features Voice Processing • Bearer traffic and CAS using AAL2, where CAS is carried in the same AAL2 channel as the associated bearer traffic • Bearer traffic and CCS using AAL2, where CCS for the control of narrow- band services is carried in a specific AAL2 channel that does not carry bearer traffic, within the same ATM VCC as the associated bearer traffic.
Page 132: Wireless Mobile Voice Backhaul
Chapter 3 System Features Voice Processing Wireless Mobile Voice Backhaul In a wireless TDMA system, using an HDLC passthrough interface over AAL5 for backhauling between the BS and the MSC provides cost benefits over a TDM-based backhauling system currently in use. The PacketPipe AAL5-to- AAL2 Wireless Trunking feature addresses this need.
Page 133: Virtual Routing
Chapter 3 System Features Voice Processing PSAX 4500 in MSC PSAX 1000 Cell Sites Pure Voice HDLC AAL2 Trunks AAL5 Backhauled via Land Lines Cellular Data/Voice in Same Packet Data/AAL5 TDM Voice/AAL1 5ESS 168 Channels PacketPipe 48 Channels TDM/AAL2 Bit Inverted HDLC/AAL2 C 384 Channels AAL2 G 672 Channels/AAL2 384 Channels TDM/AAL1...
Page 134: Virtual Router Concept
Chapter 3 System Features Voice Processing Each Enterprise/Service Provider Enterprise 1/ Enterprise 2/ Enterprise 3/ occupies its own Service Provider 1 Service Provider 2 Service Provider 3 virtual router space. The Enterprise/Service Provider consist of one or more physical connections. Interfaces are assigned through configuration mechanisms Ingress/Egress...
Page 135: Secure Telephone Unit Third Generation (Stu-Iii) Secure Mode
Chapter 3 System Features Voice Processing Secure Telephone Unit Third Generation (STU-III) Secure Mode This feature permits the DSP2D and DSP2E Voice Server modules to detect the transition of a voice call from 8 kbps or 32 kbps mode to a STU-III secure mode and to transmit the subsequent data stream in a compressed 32 kbps rate.
Page 136: Gsm Voice Traffic Compression
Chapter 3 System Features System Performance GSM Voice Traffic Compression The primary objective of GSM Idle Channel (No Speech Frame) Suppression and GSM Idle Speech Frame Suppression is to minimize the number of GSM voice traffic circuits between the cell sites (BTS) and the BSC. Suppressing the idle traffic will allow for greater trunk utilization and greater operational expense savings to wireless carriers.
Page 137: Synchronization Of Psax System Software On Redundant Cpun Modules
Chapter 3 System Features System Performance 24N72 4-Port OC-3c/STM-1 Multi- 500 PVC and SPVC connections mode configured (STM-1 mode only) 24N73 4-Port OC-3c/STM-1 500 PVC and SPVC connections Single-Mode configured (STM-1 mode only) 23N34 21-Port High-Density E1 IMA 50 PVC and SPVC connections configured Synchronization of PSAX System Software on Redundant CPUn Modules The Synchronize Standby CPU feature provides the user the ability to syn-...
Page 138: Maintenance Testing On Ds1 Interfaces
Chapter 3 System Features System Security Maintenance Testing on DS1 Interfaces The Maintenance Tests feature provides the capability to perform out-of-ser- vice maintenance testing on full-rate DS1 interfaces (E1 interface support will be added in phase 2). Capabilities of this feature include the following: •...
Page 139: Psax System Access Authentication Via Radius Servers
Chapter 3 System Features System Security PSAX system User Options window, users can set parameters for user name authentication on the primary and the secondary RADIUS servers. Users must also set up user names and other parameters on the RADIUS servers. The PSAX system supports three security levels: •...
Page 140: Atm Security On Interfaces And Connections
4.0 and ATM PNNI 1.0 interfaces The ATM Security feature is available only to users in certain countries. Con- tact your Lucent Technologies sales representative to find out whether your country is eligible to use the ATM Security feature. PSAX Module Features For descriptions of the I/O and server modules available for use in the ®...
Page 141: Using Vt100 Terminal Emulation
Using VT100 Terminal Emulation Overview of This Chapter VT100 terminal emulation is used in configuring and managing the PSAX 2300 system from the serial interface port labeled CONSOLE on the faceplate of the CPUn module. The PSAX 2300 system software supports the following terminal emulation software: •...
Page 142: Connection Description Window
Chapter 4 Using VT100 Terminal Emulation Setting Up The Windows HyperTerminal Emulator The Connection Description window is displayed (see Figure 4-1). Figure 4-1. Connection Description Window 2 In the Name field, enter a name for the new connection. 3 In the Icon field, click an icon symbol to identify this new connection. 4 Click OK.
Page 143: Com1 Properties Window
Chapter 4 Using VT100 Terminal Emulation Setting Up The Windows HyperTerminal Emulator The COM1 Properties window is displayed (see Figure 4-3). Figure 4-3. COM1 Properties Window 7 Enter the appropriate values for the fields on this window according to the information provided in Table 4-2. Table 4-2.
Page 144: Connecting A Dialup Modem To The Chassis
Chapter 4 Using VT100 Terminal Emulation Connecting a Dialup Modem to the Chassis Figure 4-4. PSAX 2300 Multiservice Media Gateway System Logon Window Connecting a Dialup Modem to the Chassis The following procedure requires the following items to dial-in to the PSAX 2300 system: •...
Page 145 Chapter 4 Using VT100 Terminal Emulation Connecting a Dialup Modem to the Chassis DTR on, DCD on, CTS on, 8-bit character length, 9600 baud, no par- ity, and no echo. e Disconnect the computer from the modem. f Connect the RJ-12-to-DB9 or RJ-12-to-DB25 adapter to the modem. g Connect the RJ-12-to-RJ-12 cable between the modem and the CON- connector on the CPUn module.
Page 146 Chapter 4 Using VT100 Terminal Emulation Connecting a Dialup Modem to the Chassis ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447...
Page 147: Site-Specific Configuration
Site-Specific Configuration Overview of This Chapter This chapter describes how to: • Log onto the PSAX system • Configure the basic site-specific parameters of the PSAX 2300 system • Configure call control resource allocations • Enable/disable systemwide features • Configure interface protection groups •...
Page 148: Psax 2300 Multiservice Media Gateway System Logon Window
Chapter 5 Site-Specific Configuration Logging onto the System To log onto the PSAX 2300 system, perform the following procedure. Begin 1 Configure your VT100 terminal emulator (see Chapter 4 for details). 2 To start the console session, press Enter. The PSAX 2300 Logon window is displayed (see Figure 5-1). 3 Enter the username and password on this window according to the infor- mation provided in Table 5-1.
Page 149: Field Descriptions For The Psax System Logon Window
Chapter 5 Site-Specific Configuration Logging onto the System Table 5-1. Field Descriptions for the PSAX System Logon Window Field Name Field Values Description Username Default: N/A Specifies the user name for logging onto the PSAX sys- tem, which provides three levels of access to the sys- Range: N/A tem.
Page 150 Chapter 5 Site-Specific Configuration Logging onto the System Table 5-1. Field Descriptions for the PSAX System Logon Window (Continued) Field Name Field Values Description readwrite Indicates the user name with the medium level of access. If you log on with the user name readwrite, you can do the following: •...
Page 151: Console Interface Main Menu Options
Chapter 5 Site-Specific Configuration Console Interface Main Menu Options Figure 5-2. Console Interface Main Menu Window Note: At the time of initial configuration, the Console Interface Main Menu window displays a field with a pair of opposing square brackets in the upper right corner. This field contains the site name, which you will enter during site-specific configuration (see “Configuring System Identification Information”...
Page 152: Setting Up Radius Server Access Authentication For The Psax System
Chapter 5 Site-Specific Configuration Setting Up RADIUS Server Access Authentication for the PSAX System Table 5-2. Console Interface Main Menu Options and Commands (Continued) For information on using this option... see... User Options “Setting Up RADIUS Server Access Authentica- tion for the PSAX System” on page 5-6 and “Changing the System Password and Other User Options”...
Page 153: Configuring Radius Server Options On The Psax System
Chapter 5 Site-Specific Configuration Setting Up RADIUS Server Access Authentication for the PSAX System b Set the vendor type to 1, which is defined as PSAX-security-level. c Set the PSAX-security-level attributes to 0 (super user), 1 (read- write), and 2 (readonly) 3 Add each user name and specify the appropriate PSAX-security-level attribute (0, 1, or 2) for each user name.
Page 154: User Options Window-Logged On As Username Root
Chapter 5 Site-Specific Configuration Setting Up RADIUS Server Access Authentication for the PSAX System Figure 5-3. User Options Window—Logged on as Username Root Figure 5-4. User Options Window—Authentication Mode Hybrid Selected Table 5-3. Commands for the User Options Window Command Function Apply User Configuration Applies the configuration field values you entered.
Page 155: Commands For The User Options Window
Chapter 5 Site-Specific Configuration Setting Up RADIUS Server Access Authentication for the PSAX System Table 5-3. Commands for the User Options Window (Continued) Command Function Reset to System Defaults Resets the values in the fields to the system default values. Go Back to Main Menu Redisplays the Console Interface Main Menu window.
Page 156: System
Chapter 5 Site-Specific Configuration Setting Up RADIUS Server Access Authentication for the PSAX System Table 5-4. Field Descriptions for the User Options Window (RADIUS Server Fields) (Continued) Field Names Field Values Description Server Max Retry Default: 0 Specifies the number of times the PSAX system tries to obtain logon authentication from the Range: 0–9 RADIUS server.
Page 157: Changing The System Password And Other User Options
Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Changing the System Password and Other User Options The following functions are available on the User Options window: • Changing the system password for the PSAX system usernames •...
Page 158: Permissions For Psax-Defined Usernames
Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options The three levels of permissions for changing user options on this window are described in Table 5-5. Table 5-5. Permissions for PSAX-defined Usernames If you logged on you can change the following fields on the User Options with username...
Page 159: User Options Window-Logged On As Username Root
Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Figure 5-5. User Options Window—Logged on as Username Root Figure 5-6. User Options Window—Logged on as Username Readwrite ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447 5-13...
Page 160: User Options Window-Logged On As Username Readonly
Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Figure 5-7. User Options Window—Logged on as Username Readonly Table 5-6. Commands for the User Options Window Command Function Apply User Configuration Applies the configuration field values you entered. Reset to System Defaults Resets the values in the fields to the system default values.
Page 161 Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Table 5-7. Field Descriptions for the User Options Window (Password and Miscellaneous User Options Fields) (Continued) Field Names Field Values Description Trap Display Default: Enabled Specifies whether or not you see the trap message displayed at the bottom of the window.
Page 162 Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Table 5-7. Field Descriptions for the User Options Window (Password and Miscellaneous User Options Fields) (Continued) Field Names Field Values Description Change Password Panel Note: It is very important that you change the default passwords for the usernames during your first logon session on the User Options window.
Page 163: Ascii Characters Permitted For Use In Passwords
Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Table 5-8. ASCII Characters Permitted for Use in Passwords Char Description Char Description Uppercase P space Exclamation mark Uppercase Q " Quotation mark Uppercase R Cross hatch (number sign) Uppercase S Dollar sign Uppercase T...
Page 164: Changing Other User Options
Chapter 5 Site-Specific Configuration Changing the System Password and Other User Options Table 5-8. ASCII Characters Permitted for Use in Passwords (Continued) Char Description Char Description Uppercase E Lowercase u Uppercase F Lowercase v Uppercase G Lowercase w Uppercase H Lowercase x Uppercase I Lowercase y...
Page 165: Configuring The System For Your Site
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Configuring the System for Your Site Before proceeding with your site configuration, you must first determine the actual values you will use for the following configuration identifiers: • Site name •...
Page 166: Descriptions For Site-Specific Menu Options
Chapter 5 Site-Specific Configuration Configuring the System for Your Site The Site-Specific Menu window provides access to the functions that the PSAX system uses to manage the various systemwide features. Table 5-9. Descriptions for Site-Specific Menu Options Menu Option Description Note: Menu options shown between brackets [ ] are not available until the feature is Enabled by using the Feature Turn ON/OFF option on this same menu, saving the configuration, and rebooting the chassis.
Page 167 Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-9. Descriptions for Site-Specific Menu Options (Continued) Menu Option Description [H.248 Management and Con- Accesses the H.248 Management and Configuration win- figuration] dow on which you configure the media gateway control- ler on a CES-to-ATM AAL1 SVC.
Page 168: Configuring System Identification Information
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-9. Descriptions for Site-Specific Menu Options (Continued) Menu Option Description Trap Activation Configuration Accesses the Trap Activation Table window on which you turn on or off the display of specific minor, information, and system response indicators in the trap log.
Page 169: Site-Specific Configuration Window
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Figure 5-9. Site-Specific Configuration Window Table 5-10. Commands for the Site-Specific Configuration Window Command Function Configure TCP Server Displays the TCP Server Configuration window. Apply Site-Specific Configuration Applies the values you entered on this window. Reset Site-Specific Display Sets the values in this window to the last saved (applied) set of values.
Page 170: Rules For Configuring Ip Addresses
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-11. Field Descriptions for the Master ATM Address and OAM Related Data Panel on the Site-Specific Configuration Window (Continued) Field Name Field Values Description Address Type Default: Nsap Specifies the type of address used for the master node ATM address.
Page 171: Rules For Configuring Ip Address Masks
Chapter 5 Site-Specific Configuration Configuring the System for Your Site 5. If the CPU IP, switch IP, and in-band IP addresses are not zero, then they must be valid IP addresses. 6. If the switch IP address is not zero, then the system will respond to the switch IP address;...
Page 172: Field Descriptions For The Master Atm Address And Oam Related Data Panel On The Site-Specific Configuration Window
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-12. Field Descriptions for the Master ATM Address and OAM Related Data Panel on the Site-Specific Configuration Window Field Name Field Values Description Master Node Addr Default: 0000.0000. Specifies the master node address where the 0000.0000.0000.
Page 173: Field Descriptions For The System Identification Panel On The Site-Specific
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-13. Field Descriptions for the System Identification Panel on the Site-Specific Configuration Window Field Name Field Values Description [Chassis Type] Default: N/A Displays the type of PSAX system you are config- uring.
Page 174: Configuring System Date And Time
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Configuring System Date and Time Perform the following procedure to date and time for your PSAX 2300 from the Site-Specific Configuration window. Begin 1 Enter values in the fields on the System Date and Time panel according to the information provided in Table 5-14.
Page 175: Configuring The Psax System As A Tcp Server Or A Tcp Client
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-14. Field Descriptions for the System Date and Time Panel on the Site-Specific Configuration Window (Continued) Field Name Field Values Description Time from UTC Default: -00 : 00 Specifies the differential between the local time and the UTC (GMT) time.
Page 176: Tcp Server Configuration Window (Psax System As A Tcp Client)
Chapter 5 Site-Specific Configuration Configuring the System for Your Site 4 To return to the Site-Specific Configuration window, select the Go Back to Site-Specific Screen command. Figure 5-10. TCP Server Configuration Window (PSAX System as a TCP Client) Figure 5-11. TCP Server Configuration Window (PSAX System as a TCP Server) The commands on this window have the following functions: ®...
Page 177: Commands For The Tcp Server Configuration Window
Chapter 5 Site-Specific Configuration Configuring the System for Your Site Table 5-15. Commands for the TCP Server Configuration Window Command Function Apply TCP Server Configu- Applies the configuration. ration Reset TCP Server Display Resets the display. Go Back to Site-Specific Redisplays the Site-Specific Configuration Screen window.
Page 178: Configuring Call Control Resource Allocation
Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-16. Field Descriptions for the TCP Server Configuration Window Field Name Field Values Description Keep Alive Timer Default: 0 Specifies the interval of time that elapses before (secs) the TCP server sends a query message to deter- Range: 1–100 mine whether the connection is still active.
Page 179: Site-Specific Menu Window
Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation 6 Perform the chassis reboot procedure at this time. The path to follow is from the Console Interface Main Menu > Diagnostics > Reboot Hardware Components > Reboot Chassis. Figure 5-12. Site-Specific Menu Window Figure 5-13.
Page 180: Configuration Guidelines
Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-17. Commands for the Call Control Resource Allocation Configuration Window Command Function Apply Configuration Applies the values you entered on this window. Go Back to Site-Specific Menu Redisplays the Site-Specific Menu window. Configuration Guidelines Table 5-18.
Page 181: Field Descriptions For The Call Control Resource Allocation Configuration Window
Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-18. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description If you have already configured your PSAX system and you are considering changing the Important: sum of the values in the SPVC point-to-point calls fields, keep in mind that the sum of these values cannot be less than the actual number of SPVC connections already configured in the PSAX system...
Page 182 Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-18. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description spvcAtmPtToPtCalls Default: 002000 Specifies the maximum number of SPVC ATM point- to-point calls to be supported by the PSAX system. Set Range: 0–10000 the values in the SPVC point-to-point call fields Format: Numeric...
Page 183 Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-18. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description aal2CirAtmSpvcVcc Default: 001000 Specifies the maximum number of circuit emulation- Calls to-ATM standard AAL2 SPVC calls to be supported by Range: 0–4000 the PSAX system.
Page 184 Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-18. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description atmTrunkVccs Default: 000100 Specifies the maximum number of VCCs supported by ATM trunking. Range: 1–4096 If you select the value SPVC Priority Configurations:...
Page 185 Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Table 5-18. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description cgSvcCutThrough- Default: cgSvcAcIm- Specifies whether the PSAX system or the connection Option plicitCutThrough gateway device (connection manager) sends a cut- through message to initiate an SVC connection.
Page 186: Saving The Configuration And Rebooting The System
Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation † When using both SPVC and SVC connection types, you can set up any combina- tion of calls as long as you do not exceed 100% of the call control resource mem- ory allocation (callContrlResAllocUsage field on the Call Control Resource Alloca- tion Configuration window).Refer to the configuration guidelines in the field description table for this window.
Page 187: Diagnostics Menu
Chapter 5 Site-Specific Configuration Configuring Call Control Resource Allocation Figure 5-14. Diagnostics Menu Figure 5-15. Remote Reboot Configuration Window ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447 5-41...
Page 188: Backing Up Configuration Data
Chapter 5 Site-Specific Configuration Configuring GR-303 Backing Up Configuration Data You can back up the data on the Call Control Resource Allocation window by backing up the file ssid.def, which resides on the CPU module system disk. We highly recommend that you back up the ssid.def file, which contains your configuration data.
Page 189: Site-Specific Menu Window (Feature Turn On/Off Option Selected)
Chapter 5 Site-Specific Configuration Enabling and Disabling PSAX System Features 3 Select the desired interface feature in the Feature Id column and press Enter. Pressing Enter changes the Desired Status column from Disable to Enable and vice versa. This action also displays the following message in the status line: Are you SURE that you want to change the desired status? (y/n)
Page 190: Feature Turn On/Off Window
Chapter 5 Site-Specific Configuration Enabling and Disabling PSAX System Features Figure 5-17. Feature Turn On/Off Window The commands on this window have the following functions: Table 5-20. Commands for the Feature Turn ON/OFF Table Window Command Function Page Up Scrolls up one page. Page Down Scrolls down one page.
Page 191: Field Descriptions For The Feature Turn On/Off Table
Chapter 5 Site-Specific Configuration Enabling and Disabling PSAX System Features Table 5-21. Field Descriptions for the Feature Turn On/Off Table Field Name Field Values Description Total: 0/0 Default: N/A First number: Indicates which Feature ID is cur- rently selected in the table. Range: 1–6 Second number: Indicates the total number of Format: Numeric...
Page 192: Rebooting Cpun Modules In Redundant And Nonredundant Systems
Chapter 5 Site-Specific Configuration Rebooting CPUn Modules in Redundant and Nonredundant Systems Table 5-21. Field Descriptions for the Feature Turn On/Off Table (Continued) Field Name Field Values Description desired status Default: Enable or Displays whether the feature is to be made opera- Disable (depends tional or not.
Page 193: Rebooting The Redundant Psax System
Chapter 5 Site-Specific Configuration Rebooting CPUn Modules in Redundant and Nonredundant Systems Figure 5-18. Console Interface Main Menu Window (Save Configuration Option Selected) The following message is displayed in the status line: T-SaveConfiguration: saveConfigurationReasonCode=All-OK In a PSAX system with redundant CPUn modules, this command causes the backup (standby) CPUn module to reboot.
Page 194: Remote Reboot Configuration Window (Primary Switchover Option Selected)
Chapter 5 Site-Specific Configuration Rebooting CPUn Modules in Redundant and Nonredundant Systems Begin Note: Performing this procedure does NOT interrupt traffic running through the PSAX chassis. 1 On the Console Interface Main Menu window, select the Diagnostics option. The Diagnostics Menu window is displayed. 2 On the Diagnostics Menu window, select the Reboot Hardware Compo- nents option.
Page 195: Rebooting The Nonredundant Psax System
Chapter 5 Site-Specific Configuration Rebooting CPUn Modules in Redundant and Nonredundant Systems Rebooting the Nonredundant PSAX System The following procedure applies typically to all nonredundant PSAX systems. Begin WARNING: Rebooting the PSAX system with a single (nonredundant) CPUn module will interrupt all traffic running through the PSAX chassis. 1 On the Console Interface Main Menu window, select the Diagnostics option.
Page 196: Configuring Isdn Q.921 User Adaptation (Iua) Layer Protocol
Chapter 5 Site-Specific Configuration Configuring ISDN Q.921 User Adaptation (IUA) Layer Protocol Figure 5-20. Remote Reboot Configuration Window (Reboot Primary CPU Option Selected) Configuring ISDN Q.921 User Adaptation (IUA) Layer Protocol Perform the following procedure to configure the IUA layer. Begin 1 From the Site-Specific Menu window, select the IUA Layer Configuration option.
Page 197: Sample Iua Layer Configuration For The Omg And Tmg Sides
Chapter 5 Site-Specific Configuration Configuring ISDN Q.921 User Adaptation (IUA) Layer Protocol Figure 5-21. Sample IUA Layer Configuration for the OMG and TMG Sides Table 5-22. Commands for the IUA Layer Configuration Window Command Function Apply IUA Configuration Applies the user-assigned IUA configuration values. Go To AS Table Displays the IUA AS Table window.
Page 198: Configuring Interface Protection Groups
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Table 5-23. Field Descriptions for the IUA Layer Configuration Window (Continued) Field Name Field Values Field Description [Max Peer ASs] Default: 1 Specifies the maximum number of remote peer application servers. Range: Format: Numeric [Max Outgoing Default: 251...
Page 199: Setting Up An Interface Protection Group Id
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups • Creating a group ID for the interface protection group • Adding interfaces to the protection group Note: Before configuring an interface protection group, you must first make sure you have configured the ports and channels on the modules you want to include in the protection group.
Page 200: Interface Protection Feature Configuration Window
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Figure 5-22. Interface Protection Feature Configuration Window The menu options on this window have the following functions. Table 5-24. Commands for the Interface Protection Feature Configuration Window Option Description Protection Group Table Displays the Protection Group Table window.
Page 201: Protection Group Table Window
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Figure 5-23. Protection Group Table Window The commands on this window have the following functions. Table 5-25. Commands for the Protection Group Table Window Command Function Page Up Scrolls up one page. Page Down Scrolls down one page.
Page 202: Protection Group Configuration Window
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Figure 5-24. Protection Group Configuration Window The commands on this window have the following functions. Table 5-26. Commands for the Protection Group Configuration Window Command Function Add to Protection Group Creates a new protection group ID and applies the values in the fields.
Page 203: Creating An Interface Protection Group
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Table 5-27. Field Descriptions for the Protection Group Configuration Window (Continued) Field Names Field Values Description Switchback Method Default: Auto Specifies the method used to switch traffic from a standby interface to its corresponding recovered Range: N/A primary interface.
Page 204: Interface Protection Table Window
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups 4 To add the interface to the protection group, select the Add to interface protection group command. Note: Switchover and switchbacks can be initiated only when configur- ing the primary interface protection. Figure 5-25.
Page 205: Interface Protection Configuration Window
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Figure 5-26. Interface Protection Configuration Window The commands on this window have the following functions. Table 5-29. Commands for the Interface Protection Configuration Window Command Function Add to Interface Protection Adds an interface to an interface protection Group group.
Page 206: Field Descriptions For The Interface Protection Configuration Window
Chapter 5 Site-Specific Configuration Configuring Interface Protection Groups Table 5-30. Field Descriptions for the Interface Protection Configuration Window Field Names Field Values Description Group ID Default: 0 Specifies the group ID that represents a unique protection group within the PSAX system. You Range: 1–9999 must first set up this group ID on the Protection Format: numeric...
Page 207: Internet Protocol (Ip) Throttling
Chapter 5 Site-Specific Configuration Internet Protocol (IP) Throttling Internet Protocol (IP) Throttling Perform the following procedure to configure the call control resource alloca- tions for your Multiservice Media Gateway system. Begin 1 From the Console Interface Main Menu, select the Site-Specific Configu- ration option.
Page 208: The Ip Throttling Window (Disabled)
Chapter 5 Site-Specific Configuration Internet Protocol (IP) Throttling Figure 5-28. The IP Throttling Window (Disabled) Figure 5-29. The IP Throttling Window (Enabled) The commands on this window have the following functions: Table 5-31. Commands for the IP Throttling Configuration Window Command Function Apply Configuration...
Page 209: Field Descriptions For The Ip Throttling Configuration Window
Chapter 5 Site-Specific Configuration Internet Protocol (IP) Throttling Table 5-31. Commands for the IP Throttling Configuration Window (Continued) Command Function Reset Statistics Resets all statistics counters for this window to 0. Go Back to Site-Specific Menu Redisplays the Site-Specific Menu window. Table 5-32.
Page 210 Chapter 5 Site-Specific Configuration Internet Protocol (IP) Throttling Table 5-32. Field Descriptions for the IP Throttling Configuration Window (Continued) Field Name Field Values Description Allowed Rate Default: 2000 fps Specifies the maximum bandwidth allowed to pass through the ETHERNET or in-band management vir- Range: 100–2000 fps tual port into the PSAX system in the unit of frames per second (fps).
Page 211: Snmp Trap Activation And Deactivation
Chapter 5 Site-Specific Configuration SNMP Trap Activation and Deactivation Table 5-32. Field Descriptions for the IP Throttling Configuration Window (Continued) Field Name Field Values Description In Packets Default: N/A The total number of input packets that are received (display only) from both the ETHERNET port of the CPU module and...
Page 212: Enabling And Disabling Snmp Trap Messages
Chapter 5 Site-Specific Configuration SNMP Trap Activation and Deactivation Enabling and Disabling SNMP Trap Messages To enable or disable the generation of specific SNMP trap messages in the PSAX system. On the Trap Activation Table window, deactivate the trap mes- sage(s) you wish by selecting them and pressing Enter once.
Page 213: Trap Activation Table
Chapter 5 Site-Specific Configuration SNMP Trap Activation and Deactivation Figure 5-30. Trap Activation Table Table 5-33. Commands for the Trap Activation Table Window Command Function PgUp Displays the previous page in the trap names table. PgDown Displays the next page in the trap names table. Displays the beginning page in the trap names table.
Page 214: Field Descriptions For The Trap Activation Table Window
Chapter 5 Site-Specific Configuration SNMP Trap Activation and Deactivation Table 5-34. Field Descriptions for the Trap Activation Table Window Field Name Field Values Description Total: / Default: 1/xxx where Displays the number of the selected trap name (display only) xxx represents the and the total number of trap names in the table.
Page 215: Collecting Bulk Statistics
Chapter 5 Site-Specific Configuration Collecting Bulk Statistics Collecting Bulk Statistics Overview of Tasks To collect bulk statistics on ATM and frame relay interfaces on the PSAX sys- tem to be sent to a remote statistics server, you need to perform the following tasks: 1.
Page 216: Bulk Statistics Configuration Window
Chapter 5 Site-Specific Configuration Collecting Bulk Statistics Figure 5-31. Bulk Statistics Configuration Window Table 5-35 describes the commands on this window. Table 5-35. Commands for the Bulk Statistics Configuration Window Command Function Apply Bulk Statistics Configu- Applies the configuration values you entered on this win- ration dow.
Page 217: Using The Equipment Configuration Window
Chapter 5 Site-Specific Configuration Using the Equipment Configuration Window Table 5-36. Field Descriptions for the Bulk Statistics Configuration Window (Continued) Field Name Field Values Description Directory Default: None Specifies the directory pathname on the network server to which the PSAX system will send the bulk Range: N/A statistics.
Page 218: Accessing The Equipment Configuration Window
Chapter 5 Site-Specific Configuration Using the Equipment Configuration Window Accessing the Equipment Configuration Window Perform the following procedure to access the Equipment Configuration win- dow. Begin 1 On the Console Interface Main Menu window, select the Equipment Configuration option. The Equipment Configuration window is displayed (see Figure 5-32 and Figure 5-33).
Page 219: Sample Equipment Configuration Window On A Psax 1000, Psax 2300, Or Psax 4500
Chapter 5 Site-Specific Configuration Using the Equipment Configuration Window Figure 5-33. Sample Equipment Configuration Window on a PSAX 1000, PSAX 2300, or PSAX 4500 System (Page 2) Commands The commands on this window are described in Table 5-37. Table 5-37. Commands for the Equipment Configuration Window Command Function Update Equipment Display...
Page 220: Field Descriptions For The Equipment Configuration Window
Chapter 5 Site-Specific Configuration Using the Equipment Configuration Window Table 5-38. Field Descriptions for the Equipment Configuration Window Field Name Field Values Description Slot Default: N/A Displays the slot number in the PSAX chassis. Range: 1–25, depend- ing on chassis type Format: Numeric Module Type Default: N/A...
Page 221: Alarm Status Values
Chapter 5 Site-Specific Configuration Using the Equipment Configuration Window Table 5-38. Field Descriptions for the Equipment Configuration Window (Continued) Field Name Field Values Description SW # Default: N/A Displays the version of PSAX system software with which the modules’ firmware was released. Range: (from module The software version is encoded in the module firmware)
Page 222: Configuring The Stratum 3-4 Module
Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Table 5-39. Alarm Status Descriptions for Modules on the Equipment Configuration Window Module Type Alarm Status Description Affected NoAlarm I/O and Server Indicates that no alarms have been detected for the mod- ule in this slot.
Page 223: Setting The Stratum Configuration Values
Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Setting the Stratum Configuration Values To configure the Stratum 3–4 module synchronization source, clock accu- racy, and clock failure backup reference, perform the following procedure. Begin 1 On the Console Interface Main Menu window, select the Equipment Configuration command.
Page 224: Stratum Configuration Window (Linetiming Synchronization)
Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Figure 5-35. Stratum Configuration Window (LineTiming Synchronization) Commands The commands in the Stratum Configuration window are described in Table 5-40. Table 5-40. Commands for the Stratum Configuration Window Command Function Switch Line Timing Source Switches between the primary and secondary line timing sources specified in the Primary Line Source and Secondary Line Source fields.
Page 225: Field Descriptions For The Stratum Configuration Window
Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Table 5-41. Field Descriptions for the Stratum Configuration Window Field Name Mode of Operation Description [Primary Stratum Default: Holdover Indicates the current mode of operation for the pri- Mode] mary Stratum 3–4 module. Range: N/A Format: Predefined Holdover...
Page 226 Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Table 5-41. Field Descriptions for the Stratum Configuration Window (Continued) Field Name Mode of Operation Description [Line Timing Sta- Default: None Indicates the current line timing status for the tus] module. Range: N/A Format: Predefined None...
Page 227 Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Table 5-41. Field Descriptions for the Stratum Configuration Window (Continued) Field Name Mode of Operation Description [Backup Stratum Default: Unconfig- Indicates the status of the input T1BITS or E1ETSI T1/E1 Port Status] ured clock source connected to the external clock con- nector on the baclup Stratum 3–4 module.
Page 228 Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Table 5-41. Field Descriptions for the Stratum Configuration Window (Continued) Field Name Mode of Operation Description Synchronization Default: LineTiming Indicates the synchronization source to be used by Source the chassis and specified I/O modules. The I/O Range: NA modules use this source when LocalTiming is Format: Alphabetical...
Page 229: Switching The Line Timing Source
Chapter 5 Site-Specific Configuration Configuring the Stratum 3–4 Module Table 5-41. Field Descriptions for the Stratum Configuration Window (Continued) Field Name Mode of Operation Description Secondary Line Default: Slot: 00 Port: Specifies the secondary line source when LineTim- Source ing is selected in the Synchronization Source field. Enter the values for the slot and the port of the Range: Chassis/mod- desired I/O module port that is providing line tim-...
Page 230: Alarm Status Values
Chapter 5 Site-Specific Configuration Saving the Equipment Configuration Values and Logging Off Alarm Status Values I/O and server modules display the status value of Primary if they are con- figured, or Unknown if they are unconfigured. The Alarm Status column for unconfigured modules still can have a number listing the ports that are avail- able to be configured.
Page 231: Save Configuration [Modified] (Before Saving)
Chapter 5 Site-Specific Configuration Saving the Equipment Configuration Values and Logging Off Figure 5-36. Save Configuration [Modified] (Before Saving) 2 Select the Save Configuration command or press Ctrl+A. Wait a few seconds while the system writes the values to the PSAX sys- tem database.
Page 232 Chapter 5 Site-Specific Configuration Saving the Equipment Configuration Values and Logging Off After saving the configuration values, the indicator [Modified] is no longer displayed next to the Save Configuration command. 3 You can now safely exit the current session by selecting the Leave Con- sole Interface command.
Page 233: Configuring Atm Pnni
Configuring ATM PNNI Overview of ATM PNNI Systemwide Configuration For an overview of ATM PNNI and the ATM PNNI features supported on the PSAX 2300 system, see Chapter 3. To configure a ATM PNNI node for your PSAX 2300 system, perform the fol- lowing procedure.
Page 234: Pnni System-Wide Configuration Menu Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node If you need to take the node out of service, you must first delete any ATM PNNI interfaces you have configured on your PSAX 2300 system. 8 Select the Go Back to Previous Screen command (or press Ctrl+B). The PNNI Node Table (see Figure 6-2) is displayed, showing your current node index, node level, and operating status.
Page 235 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Table 6-1. Commands for the PNNI System-Wide Configuration Window (Continued) Menu Option Name Function PNNI Map Link Information Displays the mapping for the nodes and their links, and all original port and remote port PNNI topology state element (PTSE) identifiers and the metrics tag number.
Page 236: Pnni Node Table Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Figure 6-2. PNNI Node Table Window The commands on this window have the following functions: Table 6-2. Commands for the PNNI Node Table Window Command Function Page Up Scroll up one page. Page Down Scrolls down one page.
Page 237: Field Descriptions For The Pnni Node Table Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Table 6-3. Field Descriptions for the PNNI Node Table Window Field Name Description Total: 0/0 Displays the first number in this field indicates the identifica- tion number of the connection table entry on the first line of the currently displayed window.
Page 238: Commands For The Pnni Node Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Figure 6-4. PNNI Node Configuration Window (After Configuration) The commands on this window have the following functions: Table 6-4. Commands for the PNNI Node Configuration Window Command Function Create Node Entry Creates a new PNNI node.
Page 239: Field Descriptions For The Pnni Node Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Table 6-5. Field Descriptions for the PNNI Node Configuration Window Field Name Field Values Description Node Index Default: 000000 Displays the node index that identifies a logical PNNI entity in the PSAX system. Enter the index Range: 1–400 number of each node in this field.
Page 240 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Table 6-5. Field Descriptions for the PNNI Node Configuration Window (Continued) Field Name Field Values Description Node Lowest Default: True Indicates whether or not this node is the root node. Range: N/A Format: Predefined True...
Page 241: Modifying An Atm Pnni Node Configuration
Chapter 6 Configuring ATM PNNI Modifying an ATM PNNI Node Configuration Table 6-5. Field Descriptions for the PNNI Node Configuration Window (Continued) Field Name Field Values Description [Admin Status] Default: N/A Displays the administrative status for this node. Range: N/A Format: Predefined The node is currently active.
Page 242: Pnni Node Pgl Configuration
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Peer Group Leader (PGL) 2 Enter the values for this window according to the information provided in Table 6-8. 3 After all values are selected and entered, select Apply Configuration press Ctrl+A.
Page 243 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Peer Group Leader (PGL) Table 6-8. Field Descriptions for the PNNI Node PGL Configuration Window Field Name Field Values Description Node PGL Information Upper Panel [Node Index] Default: 0 Displays the node index that identifies a logical PNNI entity in the PSAX system.
Page 244 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Peer Group Leader (PGL) Table 6-8. Field Descriptions for the PNNI Node PGL Configuration Window (Continued) Field Name Field Values Description Upper Panel (display only) [State] Default: OperPgl Displays the status of this node PGL. Range: N/A Format: predefined OperPgl...
Page 245: Configuring An Atm Pnni Node Timer
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Timer Table 6-8. Field Descriptions for the PNNI Node PGL Configuration Window (Continued) Field Name Field Values Description [Preferred Pgl] Default: 0 Displays the preferred PGL. To select, any node com- pares the leadership priorities and node IDs advertised Range: N/A in the PTSEs in the topology database, and determines...
Page 246: Pnni Node Timer Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Timer Figure 6-6. PNNI Node Timer Configuration Window The commands on this window perform the following functions: Table 6-9. Commands for the PNNI Node Timer Configuration Window Command Function Apply Configuration Applies the values you set on this window.
Page 247 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node Timer Table 6-10. Field Descriptions for the PNNI Node Timer Configuration Window (Continued) Field Name Field Values Description Hello Holddown.. Default: 00010 Indicates the initial value for the Hello Hold- (100 msec) down timer, which is used by a node to limit the Range: 0–65535...
Page 248: Configuring An Atm Pnni Node Svcc
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node SVCC Table 6-10. Field Descriptions for the PNNI Node Timer Configuration Window (Continued) Field Name Field Values Description Avcr Minimum Default: 03 Indicates the available cell rate (Avcr) minimum Threshold threshold (MT), which is used in the algorithm Range: 1–99 that determines significant change for average...
Page 249: Pnni Node Svcc Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Node SVCC Figure 6-7. PNNI Node SVCC Configuration Window The commands on this window perform the following functions: Table 6-11. Commands for the PNNI Node Timer Configuration Window Command Function Apply Configuration Applies the values you set on this window.
Page 250: Configuring Atm Pnni Node Scope Mapping
Chapter 6 Configuring ATM PNNI Configuring ATM PNNI Node Scope Mapping Table 6-12. Field Descriptions for the PNNI Node SVCC Configuration Window (Continued) Field Name Field Values Description Calling Integrity Default: 35 Indicates the calling integrity time, which is the Time amount of time this node will wait for an SVCC Range: 0–65535...
Page 251: Pnni Scope Mapping Configuration
Chapter 6 Configuring ATM PNNI Configuring ATM PNNI Node Scope Mapping Figure 6-8. PNNI Scope Mapping Configuration The commands on this window perform the following functions: Table 6-13. Commands for the PNNI Node Timer Configuration Window Command Function Apply Configuration Applies the values you set on this window.
Page 252: Configuring An Atm Pnni Route Address
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route Address Table 6-14. Field Descriptions for the PNNI Scope Mapping Configuration Window (Continued) Field Name Field Values Description Intra Site Default: 80 Indicates the highest level of PNNI hierarchy (or (display only) the smallest PNNI routing level) that lies within Range: 0–104...
Page 253: Pnni Route Address Table Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route Address Begin Note: If you are configuring an SPVC as ActiveSvc, do not configure a route address. If you configuring an SPVC as PassiveSvc, config- ure a route address. 1 From the PNNI System-Wide Configuration menu, select the PNNI Route Address Configuration option or press Ctrl+A.
Page 254: Pnni Route Address Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route Address Table 6-15. Commands for the PNNI Route Address Table Window Command Function Find.. Searches this table by the values you enter in the Node Index, Prefix Length, Address Index, and Route Address fields.
Page 255: Field Descriptions For The Pnni Route Address Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route Address Table 6-17. Field Descriptions for the PNNI Route Address Configuration Window Field Name Field Values Description Route Address Information Panel Node Index Default: 000000 Displays the node index that identifies a logical PNNI entity in the PSAX system.
Page 256 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route Address Table 6-17. Field Descriptions for the PNNI Route Address Configuration Window (Continued) Field Name Field Values Description Address Type Default: Exterior Indicates the type of domain address. Range: N/A Format: Predefined Exterior Indicates a connection from the advertising node...
Page 257: Configuring Atm Pnni Metrics
Chapter 6 Configuring ATM PNNI Configuring ATM PNNI Metrics Table 6-17. Field Descriptions for the PNNI Route Address Configuration Window (Continued) Field Name Field Values Description [Address Proto] Default: Mgmt Displays the protocol by which connectivity from the advertising node to the address prefix was Range: N/A learned.
Page 258: Pnni Metrics Table Window
Chapter 6 Configuring ATM PNNI Configuring ATM PNNI Metrics service categories, bandwidth, and so on. You can also view traffic patterns and other information about routes advertised on other nodes on the Route Address Table window. Begin 1 From the PNNI Route Address Configuration window, select View Met- rics Table.
Page 259: Pnni Metrics Configuration Window
Chapter 6 Configuring ATM PNNI Configuring ATM PNNI Metrics Table 6-18. Commands for the PNNI Metrics Table Window Command Function Find.. Searches this table by the values you enter in the Node Index, Metrics Direction, Metrics Tag, or Metrics Index fields. Add Metrics Entry Displays the PNNI Metrics Configuration window.
Page 260 Chapter 6 Configuring ATM PNNI Configuring ATM PNNI Metrics Table 6-20. Field Descriptions for the PNNI Metrics Configuration Window Field Name Field Values Description Metrics Information Panel Node Index Default: 000000 Displays the node index that identifies a logical PNNI entity in the PSAX system. Range: 1–400 Format: numeric Metrics Tag...
Page 261: Configuring An Atm Pnni Route Tns
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route TNS Table 6-20. Field Descriptions for the PNNI Metrics Configuration Window (Continued) Field Name Field Values Description Available Cell Rate Default: 0xFFFFFFFF Indicates the available bandwidth on this inter- face, in hexadecimal notation. Range: N/A Format: hexadecimal Max Cell Tx Delay...
Page 262: Pnni Route Tns Table Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route TNS The PNNI Route TNS Configuration window is displayed. 3 Enter the values for this window according to the information provided in Table 6-22. 4 After setting all the values on the window, select the Add Route TNS Entry command (or press Ctrl+A).
Page 263: Pnni Route Tns Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route TNS Table 6-21. Commands for the PNNI Route TNS Table Window (Continued) Command Function Add Route TNS Entry Displays the PNNI Route Address Configuration window. Go Back to Previous Screen Redisplays the PNNI System-Wide Configuration window.
Page 264: Pnni Route Tns Configuration Window
Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route TNS The commands on this window perform the following functions: Table 6-23. PNNI Route TNS Configuration Window Command Function Add Route TNS Entry Displays the PNNI Route Address Configuration window. Delete Route TNS Entry Deletes the route TNS entry.
Page 265 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route TNS Table 6-24. Field Descriptions for the PNNI Route TNS Configuration Window (Continued) Field Name Field Values Description Adv Port Id Default: 0 Indicates the Advertised port identifier. For an SVC endpoint, enter the slot, port, and channel).
Page 266 Chapter 6 Configuring ATM PNNI Configuring an ATM PNNI Route TNS Table 6-24. Field Descriptions for the PNNI Route TNS Configuration Window (Continued) Field Name Field Values Description Org Advertisement Default: True Indicates that the transit network specified by this entry is to be advertised by the local node into its Range: N/A PNNI routing domain.
Page 267: Viewing Atm Pnni Map Tns Information
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map TNS Information Viewing ATM PNNI Map TNS Information The PNNI Map transit network string (TNS) Table window contains a list of all reachable transit networks from each node visible to the local node. The Local Node Index, Advertising Node ID, Advertised Port ID, Transit Network Type, Transit Network Plan, and Transit Network ID are combined to form an instance ID for this table.
Page 268: Field Descriptions For The Pnni Map Tns Table
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map TNS Information Table 6-25. Commands for the PNNI Map TNS Table Window (Continued) Command Function Total: 0/0 The first number in this field indicates the identification number of the TNS table entry on the first line of the cur- rently displayed window.
Page 269: Pnni Route Tns Table Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map TNS Information Figure 6-16. PNNI Route TNS Table Window The PNNI Map TNS Configuration window lists information on six parame- ters of the selected node address on the Map TNS Table. The table is read- only, as reachable addresses are discovered during dynamic operation of the PNNI protocol, not manually configured.
Page 270: Configuring A Summary Address
Chapter 6 Configuring ATM PNNI Configuring a Summary Address Table 6-28. Field Descriptions for the PNNI Map TNS Configuration Window (Continued) Field Name Field Values Description [TNS Type] Default: National- Displays the type of network ID used for the transit NetworkId network.
Page 271: Pnni Summary Address Table Window
Chapter 6 Configuring ATM PNNI Configuring a Summary Address Figure 6-17. PNNI Summary Address Table Window The commands in this window have the following functions: Table 6-29. Commands for the PNNI Summary Address Table Window Command Function Find.. Searches this table by the values you enter in the Node Index, Prefix Length, Summary Type, and Summary Address fields.
Page 272: Pnni Summary Address Configuration Window
Chapter 6 Configuring ATM PNNI Configuring a Summary Address Figure 6-18. PNNI Summary Address Configuration Window The commands in this window have the following functions: Table 6-30. Commands for the PNNI Summary Address Configuration Window Command Function Create Summary Address Adds the route address to the PNNI Summary Address Entry Table window.
Page 273: Viewing Atm Pnni Map Information
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Information Table 6-31. Field Descriptions for the PNNI Summary Address Configuration Window (Continued) Field Name Field Values Description Summary Address Default: Internal Indicates whether address is inside or outside a Type PNNI routing domain.
Page 274: Pnni Map Table Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Information Begin 1 On the PNNI System-Wide Configuration window, select the PNNI Map Information command. The PNNI Map Table window is displayed (see Figure 6-19). 2 Select the node for which you want to view information. The PNNI Map Information window is displayed (see Figure 6-20).
Page 275: Pnni Map Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Information The PNNI Map Table window displays the Node Index, Originating Node Identifier, Org Port ID (originating port identifier), and Map Index fields for various maps. The Originating Node Identifier is the node identifier of the node whose con- nectivity within itself or to other nodes is being described.
Page 276: Field Descriptions For The Pnni Map Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Information Table 6-34. Field Descriptions for the PNNI Map Information Window Field Name Field Values Description [Node Index] Default: N/A Displays the node index identifies a logical PNNI entity in the PSAX system. Range: 1–400 Format: Numeric [Org.
Page 277: Viewing Atm Pnni Map Node Information
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Node Information Table 6-34. Field Descriptions for the PNNI Map Information Window (Continued) Field Name Field Values Description [VP Capability] Default: True Indicates whether virtual path connections (VPCs) can be established across this PNNI entity. Range: N/A Format: Predefined True...
Page 278: Pnni Map Node Table Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Node Information Figure 6-21. PNNI Map Node Table Window The PNNI Map Node Table contains a list of nodes as seen from the per- spective of a local node, and all information learned by the local node from nodal information PNNI topology state elements (PTSEs).
Page 279: Pnni Map Node Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Node Information Table 6-36. Field Descriptions for the PNNI Map Node Table Window Field Name Field Value Description Total: 0/0 Default: The first number in this field indicates the identifica- tion number of the connection table entry on the first Range: line of the currently displayed window.
Page 280: Field Descriptions For The Pnni Map Node Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Node Information Table 6-38. Field Descriptions for the PNNI Map Node Information Window Field Name Field Values Description Node Index Default: 0 Displays the node index identifies a logical PNNI (display only) entity in the PSAX system.
Page 281 Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Node Information Table 6-38. Field Descriptions for the PNNI Map Node Information Window (Continued) Field Name Field Values Description Restricted Branch- Default: False Displays whether the originating node is able to support additional branches.
Page 282: Viewing Atm Pnni Map Address Information
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Address Information Table 6-38. Field Descriptions for the PNNI Map Node Information Window (Continued) Field Name Field Values Description Parent ATM Default: 0 Displays the ATM address of the parent LGN Address when the originating node is a peer group leader.
Page 283: Pnni Map Address Table Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Address Information Figure 6-23. PNNI Map Address Table Window The commands on this window perform the following functions: Table 6-39. Commands for the PNNI Map Address Table Window Command Function Find.. Searches this table by the values you enter in the Node Index, Advertised Node Id, Advertised Port Id, and Address Index fields.
Page 284: Pnni Map Address Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI Map Address Information The descriptions for the display-only fields on this window are provided in Table 6-42. The PNNI Map Address Information window is read-only, as reachable addresses are discovered during dynamic operation of the PNNI protocol, not manually configured Figure 6-24.
Page 285: Viewing The Atm Pnni Link Table
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Link Table Table 6-42. Field Descriptions for the PNNI Map Address Entry Window (Continued) Field Name Field Values Description [Address Index] Default: N/A Displays an arbitrary index generated by the CPU that is used to number all of the map addresses Range: N/A advertised by the specified node.
Page 286: Pnni Link Table Window
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Link Table The PNNI Link Table window is displayed (see Figure 6-25). Figure 6-25. PNNI Link Table Window The PNNI Link Table window displays the node index and link port identifier for various PNNI links.
Page 287: Pnni Link Information Window
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Link Table Figure 6-26. PNNI Link Information Window The command in this window has the following function: Table 6-44. Commands for the PNNI Link Information Window Command Function Go Back to Previous Screen Redisplays the PNNI System-Wide Configuration window. Table 6-45.
Page 288 Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Link Table Table 6-45. Field Descriptions for the PNNI Link Configuration Window (Continued) Field Name Field Values Description [Link Version] Default: Version1p Displays the version of PNNI routing protocol used to oint0 exchange information over this link for horizontal and outside links between lowest-level nodes and for links of...
Page 289 Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Link Table Table 6-45. Field Descriptions for the PNNI Link Configuration Window (Continued) Field Name Field Values Description Attempt Indicates either no Hellos or Hellos with mismatch infor- mation have been received recently from the neighbor. In this state, attempts are made to contact the neighbor by periodically sending the neighbor Hellos with the period Hello Interval.
Page 290 Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Link Table Table 6-45. Field Descriptions for the PNNI Link Configuration Window (Continued) Field Name Field Values Description [Remote Port Id] Default: N/A Displays the port identifier of the port at the remote end of the link as assigned by the remote node.
Page 291: Viewing Atm Pnni Svcc Rcc Information
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI SVCC RCC Information Viewing ATM PNNI SVCC RCC Information Begin 1 On the Console Interface Main Menu, select the Site-Specific Configu- ration option and press Enter (or press Ctrl+P). The Site-Specific Menu is displayed. 2 Select the PNNI System-Wide Configuration option and press Enter (or press Ctrl+N).
Page 292: Field Descriptions For The Pnni Svcc Rcc Table Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI SVCC RCC Information Table 6-46. Commands for the PNNI SvccRcc Table Window (Continued) Command Function Bottom Displays entries at the bottom of the table. Total: 0/0 The first number in this field indicates the identification number of the SvccRcc Table entry on the first line of the cur- rently displayed window.
Page 293: Pnni Svcc Rcc Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI SVCC RCC Information Figure 6-28. PNNI SVCC RCC Information Window Table 6-48 describes the commands on this window. Table 6-48. Commands for the PNNI SVCC RCC Information Window Command Function ATM Security Statistics Displays the ATM PNNI SVCC RCC Security Statistics win- Go Back to Previous Screen Redisplays the PNNI SvccRcc Table window.
Page 294: Viewing The Atm Pnni Neighbor Peer Table
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Neighbor Peer Table Table 6-49. Field Descriptions for the PNNI SVCC RCC Information Window (Continued) Field Name Field Values Description [Svcc Hello State] Default: TwoWayIn- Displays the state of the Hello protocol exchange side over the SVCC-based RCC.
Page 295: Pnni Neighbor Peer Table Window
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Neighbor Peer Table Begin 1 On the Console Interface Main Menu window, select the Site-Specific Configuration option. The Site-Specific Menu window is displayed. 2 Select the PNNI System-Wide Configuration option. The PNNI System-Wide Configuration window is displayed. 3 Select the PNNI Neighbor Peer Information command and press Enter.
Page 296: Pnni Neighbor Peer Information Window
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Neighbor Peer Table The PNNI Neighbor Peer Remote Node Id field is the node identifier of the neighboring peer node. The commands in this window have the following functions: Table 6-50. Commands for the PNNI Neighbor Peer Table Window Command Function Find...
Page 297: Field Descriptions For The Pnni Neighbor Peer Configuration Window
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Neighbor Peer Table Table 6-52. Field Descriptions for the PNNI Neighbor Peer Configuration Window Field Name Field Values Description [Node Index] Default: N/A Displays the node index that identifies a logical PNNI entity in the PSAX system.
Page 298: Viewing The Atm Pnni Neighbor Peer Port Table
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Neighbor Peer Port Table Table 6-52. Field Descriptions for the PNNI Neighbor Peer Configuration Window (Continued) Field Name Field Values Description [NbrPeer Port Default: N/A Displays a count of the total number of ports that Count] connect to the neighboring peer.
Page 299: Pnni Neighbor Peer Port Table Window
Chapter 6 Configuring ATM PNNI Viewing the ATM PNNI Neighbor Peer Port Table The PNNI System-Wide Configuration window is displayed. 3 Select the PNNI Neighbor Peer Port Information command (or press Ctrl+I). The PNNI Neighbor Peer Port Table is displayed (see Figure 6-31). 4 Access configuration information on any entry on the Neighbor Peer Port Table by a search using the Find command or by selecting an entry on the table and and pressing Enter.
Page 300: Viewing Atm Pnni Ptse Information
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI PTSE Information Table 6-53. Commands for the PNNI Neighbor Peer Port Table Window (Continued) Command Function Total: 0/0 The first number in this field indicates the identification number of the peer port table entry on the first line of the currently dis- played window.
Page 301: Pnni Ptse Table Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI PTSE Information The PNNI PTSE Table is displayed (see Figure 6-32). The fields in the PNNI PTSE Table window are provided in Table 6-56. 2 To view information about an entry on this table, select an entry. The PNNI PTSE Information window is displayed (see Figure 6-33).
Page 302: Pnni Ptse Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI PTSE Information Table 6-55. Commands for the PNNI PTSE Table Window (Continued) Command Function Org. Node Id: Enter the 11-octet organizational node ID address to be searched. Go Back to Previous Screen Redisplays the PNNI System-Wide configuration window.
Page 303: Field Descriptions For The Pnni Ptse Information Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI PTSE Information Table 6-58. Field Descriptions for the PNNI PTSE Information Window Field Name Field Values Description Node Index Default: N/A Displays the node index that identifies a logical (display only) PNNI entity in the PSAX system. Range: 1–400 Format: Numeric Originating Node...
Page 304: Viewing Atm Pnni System Statistics
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI System Statistics Table 6-58. Field Descriptions for the PNNI PTSE Information Window (Continued) Field Name Field Values Description Sequence Number Default: N/A Displays the sequence number of the instance of (display only) the PTSE as it appears in the local topology data- Range: N/A base.
Page 305: Pnni System Statistics Screen Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI System Statistics Figure 6-34. PNNI System Statistics Screen Window The commands in this window have the following functions: Table 6-59. Commands for the PNNI System Statistics Screen Window Command Function Continuous Update Updates the values in the fields on this window continuously.
Page 306: Field Descriptions For The Pnni System Statistics Window
Chapter 6 Configuring ATM PNNI Viewing ATM PNNI System Statistics Table 6-60. Field Descriptions for the PNNI System Statistics Window Field Name Values Description [Dtl Count Origina- Default: 0 The total number of designated transit list (DTL) tor] stacks that the PSAX system has originated as the Range: N/A DTL originator and placed into signaling mes- Format: numeric...
Page 307 Chapter 6 Configuring ATM PNNI Viewing ATM PNNI System Statistics Table 6-60. Field Descriptions for the PNNI System Statistics Window (Continued) Field Name Values Description [Route Fail Unreach Default: 0 The total number of times where the PSAX sys- Org.] tem failed to compute a viable DTL stack as the Range: N/A DTL originator because the destination was...
Page 308 Chapter 6 Configuring ATM PNNI Viewing ATM PNNI System Statistics ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 6-76 255-700-447...
Page 309: Configuring Atm Trunking
Configuring ATM Trunking Overview of This Chapter ATM trunking configuration supports switched and nonswitched IWF trunks. Configuring Switched IWF Trunks For configuring IWF trunks in switched mode, the following list describes the tasks you need to perform: 1. Configuring the local IWF node 2.
Page 310: Site-Specific Menu Window-Atm Trunking Configuration Option Selected
Chapter 7 Configuring ATM Trunking Configuring the Local IWF Node 3 Enter values for the fields on this window according to the information provided in Table 7-2. 4 To apply the configuration values, select the Apply Configuration command. 5 Select the Bring Admin Status Up command to bring the administra- tive status of the local IWF up.
Page 311: Atm Trunking Local Node Configuration Window
Chapter 7 Configuring ATM Trunking Configuring the Local IWF Node Figure 7-2. ATM Trunking Local Node Configuration Window The commands on this window have the following functions: Table 7-1. Commands for the ATM Trunking Local Node Configuration Window Command Function Apply Configuration Applies the values you set on this window.
Page 312: Configuring A Remote Iwf Node
Chapter 7 Configuring ATM Trunking Configuring a Remote IWF Node Table 7-2. Field Descriptions for the ATM Trunking Local Node Configuration Window Field Name Field Values Description Local IWF ID Default: 0 Specifies the local interworking function (IWF) identifier for the local endpoint. Range: 1–255 The Cell Site and the MSC Wireless Applications:...
Page 313: Atm Trunking Remote Iwf Table Window
Chapter 7 Configuring ATM Trunking Configuring a Remote IWF Node The following message in displayed in the status line of the window: This configuration is added. Note that the following commands are now displayed in the window: Go to Bearer VCC Table, Go to Data Channel Table. 5 Select the Bring Admin Status Up command to bring the administra- tive status of the remote IWF you just added into service.
Page 314: Atm Trunking Remote Iwf Configuration Window
Chapter 7 Configuring ATM Trunking Configuring a Remote IWF Node Note: At the time of initial installation, the ATM Trunking Remote IWF Table window is empty. After you have added remote IWF nodes, this window displays all the remote IWF IDs in the PSAX system. The fields on this window are described below.
Page 315: Field Descriptions For The Atm Trunking Remote Iwf Configuration Window
Chapter 7 Configuring ATM Trunking Configuring a Remote IWF Node Table 7-5. Commands for the ATM Trunking Remote IWF Configuration Window (Continued) Command Function Bring Admin Status Down When the value in the [Admin Status] field is Up, brings the remote IWF node to the status Down. Delete and Return Deletes the remote IWF node that is not in service.
Page 316: Adding A Signaling Vcc Identifier
Chapter 7 Configuring ATM Trunking Adding a Signaling VCC Identifier Table 7-6. Field Descriptions for the ATM Trunking Remote IWF Configuration Window (Continued) Field Name Field Values Description Remote IWF MAX Default: 60 Indicates the maximum number of new calls per Call Rate second within this remote IWF.
Page 317: Atm Trunking Sig Vcc Table Window
Chapter 7 Configuring ATM Trunking Adding a Signaling VCC Identifier 6 Repeat Steps 2–5 to add additional signaling VCC IDs. Figure 7-5. ATM Trunking Sig VCC Table Window The commands on this window have the following functions: Table 7-7. Commands for the ATM Trunking Sig VCC Table Window Command Function Add ATM Trunking Entry...
Page 318: Atm Trunking Sig Vcc Configuration Window
Chapter 7 Configuring ATM Trunking Adding a Signaling VCC Identifier Table 7-8. Field Descriptions for the ATM Trunking Sig VCC Table Window Field Names Description Rmt IWF ID This column displays all the remote IWF IDs in the PSAX system. VCC ID This column displays all the corresponding VCC IDs, which are assigned by the owners of the signalling VCC.
Page 319: Field Descriptions For The Atm Trunking Sig Vcc Configuration Window
Chapter 7 Configuring ATM Trunking Adding a Signaling VCC Identifier Table 7-9. Commands for the ATM Trunking Sig VCC Configuration Window (Continued) Command Function Delete and Return Deletes the remote IWF node that is not in service. Go Back to Previous Redisplays the ATM Trunking Sig VCC Table window.
Page 320 Chapter 7 Configuring ATM Trunking Adding a Signaling VCC Identifier Table 7-10. Field Descriptions for the ATM Trunking Sig VCC Configuration Window (Continued) Field Name Field Values Description Fwd/Bwd PCR Default: 0 / 0 Forward and backward peak cell rate (cells per (cps) second) for the connection.
Page 321: Adding A Bearer Vcc Identifier
Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-10. Field Descriptions for the ATM Trunking Sig VCC Configuration Window (Continued) Field Name Field Values Description [Oper Status] Default: Idle Displays the operational status of the local IWF. Range: N/A Format: Predefined alphanumeric...
Page 322: Atm Trunking Bearer Vcc Table Window
Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier The ATM Trunking Bearer VCC Table window is displayed (see Figure 7-7). Note: At the time of initial installation, the ATM Trunking Bearer VCC Table window is empty. After you have added bearer VCC IDs, this window displays all the bearer VCC IDS by remote IWF ID in the PSAX system.
Page 323: Atm Trunking Bearer Vcc Configuration Window
Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-11. Commands for the ATM Trunking Bearer VCC Table Window Command Function Find . . .Rmt IWF ID: VCC: Searches the table for a specific remote IWF ID with a specific VCC ID.
Page 324: Commands For The Atm Trunking Bearer Vcc Configuration Window
Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier The commands on this window have the following functions: Table 7-13. Commands for the ATM Trunking Bearer VCC Configuration Window Command Function Add Configuration Applies the values you set on this window. Delete Configuration Deletes the configuration.
Page 325: Field Descriptions For The Atm Trunking Bearer Vcc Configuration Window
Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description Service Type Default: Cbr-1 Specifies the service type for the connection. Range: N/A For any CBR type selected, the CAC only allows 1 DS0 per connection.
Page 326 Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description Fwd/Bwd MBS Default: 1/1 Specifies the forward and backward maximum burst size (cells) (cells) for the connection.
Page 327 Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description [VCC Interface Default: 00/00/00 Identifies the VCC interface ID for the outgoing interface. The trunk bearer VCC does not become active until both Range: N/A the local and remote trunk terminations are configured...
Page 328 Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description Inactive Timer Default: 3600 Specifies the time period during which no activity is tak- ing place before the signaling side of the connection Range: 0–9999999 clears the call.
Page 329 Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description Dsp Iwf Type Default: None Specifies the Interworking function type on assigning AAL2 connections to compatible DSP chips on the DSP2C Range: N/A through DSP2F Voice Server modules.
Page 330 Chapter 7 Configuring ATM Trunking Adding a Bearer VCC Identifier Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description Dsp Card Slot Id Default: 0 Specifies the slot number of the DSP2x Voice Server mod- ule from which the software DSP Resource Manager Range: Chassis selects DSPs to reroute and reconnect DSP-processed...
Page 331: Adding A Narrowband Address
Chapter 7 Configuring ATM Trunking Adding a Narrowband Address Table 7-14. Field Descriptions for the ATM Trunking Bearer VCC Configuration Window (Continued) Field Name Field Values Description [Oper Status] Default: Idle Displays the operational status of the bearer VCC. Range: N/A Format: Predefined Idle Indicates that the bearer VCC is not transmitting.
Page 332: Atm Trunking Narrowband Routing Table Window
Chapter 7 Configuring ATM Trunking Adding a Narrowband Address Figure 7-9. ATM Trunking NarrowBand Routing Table Window The commands on this window have the following functions: Table 7-15. Commands for the ATM Trunking Narrowband Routing Table Window Command Function Find: Searches for the ATM address entry with a value you specify.
Page 333: Adding A Broadband Address
Chapter 7 Configuring ATM Trunking Adding a Broadband Address Table 7-16. Field Descriptions for the ATM Trunking Narrowband Routing Table Window (Continued) Field Name Field Values Description Add an Entry: Default: User pro- The NSAP address up to 20 bytes (160 bits). Type vided an address in hexadecimal format up to 20 bytes (160 bits) long (10 groups of 4 characters each),...
Page 334: Atm Trunking Broadband Routing Table Window
Chapter 7 Configuring ATM Trunking Adding a Broadband Address Figure 7-10. ATM Trunking Broadband Routing Table Window The commands on this window have the following functions: Table 7-17. Commands for the ATM Trunking Broadband Routing Table Window Command Function Find: Searches for the ATM address entry with a value you specify.
Page 335: Viewing Atm Trunking Information
Chapter 7 Configuring ATM Trunking Viewing ATM Trunking Information Table 7-18. Field Descriptions for the ATM Trunking Broadband Routing Table Window (Continued) Field Name Field Values Description Add an Entry: Default: User pro- The NSAP address up to 20 bytes (160 bits). Type vided an address in hexadecimal format up to 20 bytes (160 bits) long (10 groups of 4 characters each),...
Page 336: Atm Trunking Data Channel Table
Chapter 7 Configuring ATM Trunking Viewing ATM Trunking Information Figure 7-11. ATM Trunking Data Channel Table The commands on this window have the following functions: Table 7-19. Commands for the ATM Trunking Data Channel Table Window Command Function Find... Rmt IWF ID: VCC ID: Searches the table for a specific remote IWF ID with a specific VCC ID.
Page 337 Chapter 7 Configuring ATM Trunking Viewing ATM Trunking Information Table 7-20. Field Descriptions for the ATM Trunking Data Channel Table Window (Continued) Field Name Description VCC Owner This column displays the corresponding owner of the signaling VCC. NB Intf This column displays the corresponding VCC ID, which is assigned by the owners of the signaling VCC.
Page 338 Chapter 7 Configuring ATM Trunking Viewing ATM Trunking Information ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 7-30 255-700-447...
Page 339: Configuring V5.2 European Idlc
Configuring V5.2 European IDLC Overview of the V5.2 European IDLC The application of the V5.2 Integrated Digital Loop Carrier standard (IDLC) on the PSAX system includes the implementation of two services: • Integrated Services Digital Network (ISDN) • Public Switched Telephony Network (PSTN) The configuration sequence for these two types of services is the same, but the values entered on some of the windows are different, especially on the User Port Configuration windows, the last part of the configuration on the...
Page 340 Chapter 8 Configuring V5.2 European IDLC V5.2 PSTN Implementation 4. Return to the Console Interface Main Menu window and select the Save Configuration [Modified] command to save your configuration. After you select this command, [Modified] is no longer displayed on the win- dow.
Page 341: V5.2 User Side Configuration Summary
Chapter 8 Configuring V5.2 European IDLC V5.2 PSTN Implementation 19. At a minimum, enter values for these fields: Link Id, Phys Id, and LELink Id. 20. Select the Add V5E1Link to table command. 21. Change the Admin Status field to value Unblocked. 22.
Page 342: V5.2 Iwf Device Interoperability
Chapter 8 Configuring V5.2 European IDLC V5.2 IWF Device Interoperability • VC algorithm depends on encode profile used. • Tone detect bypass. • Translate type: alaw to alaw. Note: You must choose DSP parameters compatible with the Encod- ing Profiles 10.
Page 343: V5.2 Isdn Implementation
Chapter 8 Configuring V5.2 European IDLC V5.2 ISDN Implementation Table 8-2. V5.2 IAD Interoperability (Continued) Software LAN Interface Type Port Vendor and Model Signaling Interface Release Limits Type Verilink NetEngine 3.4.10-R1 CCS/ELCP ADSL 4 or 8 analog FXO ports 6104/6108 Verilink NetEngine 6104i 3.4.10 CCS/ELCP ADSL...
Page 344: Site-Specific Menu Window (Feature Turn On/Off Option Selected)
Chapter 8 Configuring V5.2 European IDLC PSTN Configuration Pressing Enter changes the Desired Status column from Disable to Enable and vice versa. This action also displays the following message in the status line: Are you SURE that you want to change the desired status? (y/n) 4 To accept the change in status, press Y.
Page 345: Feature Turn On/Off Window
Chapter 8 Configuring V5.2 European IDLC PSTN Configuration Figure 8-2. Feature Turn On/Off Window The commands on this window have the following functions: Table 8-3. Commands for the Feature Turn ON/OFF Table Window Command Function Page Up Scrolls up one page. Page Down Scrolls down one page.
Page 346 Chapter 8 Configuring V5.2 European IDLC PSTN Configuration Table 8-4. Field Descriptions for the Feature Turn On/Off Table Field Name Field Values Description Total: 0/0 Default: N/A First number: Indicates which Feature ID is cur- rently selected in the table. Range: 1–6 Second number: Indicates the total number of Format: Numeric...
Page 347: Setting Call Control Resource Allocation Values
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-4. Field Descriptions for the Feature Turn On/Off Table (Continued) Field Name Field Values Description desired status Default: Enable or Displays whether the feature is to be made opera- Disable (depends tional or not.
Page 348 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Applying the resource allocation configuration... Resource allocation configuration has been applied. Need to save configuration and reboot system to take effect. 5 Press Ctrl+G to return to the Console Interface Main Menu window, and save the configuration.
Page 349: Call Control Resource Allocation Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Figure 8-4. Call Control Resource Allocation Configuration Window The commands on this window have the following functions: Table 8-5. Commands for the Call Control Resource Allocation Configuration Window Command Function Apply Configuration...
Page 350: Configuration Guidelines
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Configuration Guidelines Table 8-6. Field Descriptions for the Call Control Resource Allocation Configuration Window Field Name Field Values Description The ranges of values for numeric fields are software imposed. When changing the val- Important: ues in these fields, keep in mind that the PSAX system calculates the percentage of the memory allocation usage from the combination of values you have entered in the fields.
Page 351 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-6. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description If you have already configured your PSAX system and you are considering changing the Important: sum of the values in the SPVC point-to-point calls fields, keep in mind that the sum of these values cannot be less than the actual number of SPVC connections already configured in the PSAX system...
Page 352 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-6. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description spvcAtmPtToPtCalls Default: 002000 Specifies the maximum number of SPVC ATM point- to-point calls to be supported by the PSAX system.
Page 353 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-6. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description aal2CirAtmSpvcVcc Default: 001000 Specifies the maximum number of circuit emulation- Calls to-ATM standard AAL2 SPVC calls to be supported by Range: 0–4000...
Page 354 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-6. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description atmTrunkVccs Default: 000100 Specifies the maximum number of VCCs supported by ATM trunking.
Page 355 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-6. Field Descriptions for the Call Control Resource Allocation Configuration Window (Continued) Field Name Field Values Description cgSvcCutThrough- Default: cgSvcAcIm- Specifies whether the PSAX system or the connection Option plicitCutThrough gateway device (connection manager) sends a cut-...
Page 356: Accessing The V5 Resource Allocation Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values † When using both SPVC and SVC connection types, you can set up any combina- tion of calls as long as you do not exceed 100% of the call control resource mem- ory allocation (callContrlResAllocUsage field on the Call Control Resource Alloca- tion Configuration window).Refer to the configuration guidelines in the field description table for this window.
Page 357: V5 Resource Allocation Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-8. Commands for the V5 Interface Configuration Menu Window Menu Option Description V5 Interface Configuration Displays the V5 Interface Configuration window. V5 Variant Table Displays the V5 Variant Table. [V5 Statistics] The V5 Statistics window is not currently supported.
Page 358: V5 Resource Allocation Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-9. V5 Resource Allocation Configuration Window Command Function Apply Configuration Applies the configuration values you entered in the fields on the window.. Go Back to V5 Menu screen Re-displays the V5 Interface Configuration window. Table 8-10.
Page 359 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-10. Field Descriptions for the V5 Resource Allocation Configuration Window Field Name Values Description SetSA7Bit Timer Default: 050 This timer is used to guarantee that the SA7 bit is set to zero before the message is sent to LE that Range: 50–200 says the bit has been set.
Page 360: Accessing The V5 Interface Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-10. Field Descriptions for the V5 Resource Allocation Configuration Window Field Name Values Description Target DSP Over Default: 20000% Specifies the limit of the DSP resource oversub- Subscription scription for V5 voice calls.
Page 361: V5 Interface Table Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Accessing the V5 Interface Configuration Window, Part 1 Begin 1 From the Console Interface Main Menu, select > Site Specific Menu> V5 Interface Configuration option. The V5 Interface Table is displayed (see Figure 8-7).
Page 362: Adding New Interfaces
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-12. Field Descriptions for the V5 Interface Table Window (Continued) Command Function Admin Status Specifies whether the interface is up or down. Total 0/0 The first number in this field indicates the num- ber of the V5 Interface ID Data Link on the first line of the window.
Page 363: V5 Interface Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Figure 8-8. V5 Interface Configuration Window Table 8-13. Commands for the V5 Interface Configuration Window Command Function Create Interface Creates the V5 interface. Apply Configuration Applies the values entered on the fields on the window. Update Updates the window values after a field value change.
Page 364: Field Descriptions For The V5 Interface Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-14. Field Descriptions for the V5 Interface Configuration Window Field Name Field Value Description V5Intf ID: Default: 0 Specifies the ID the PSAX uses internally for the interface after the interface is created.
Page 365: Accessing The V5 Variant Table
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Accessing the V5 Variant Table Perform the following procedure to view available V5 variants and create new variants. Begin 1 From the V5 Interface Configuration window, select the Variant Table command.
Page 366: Accessing The V5 Interface Variant Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-15. Commands for the V5 Intf Variant Table Window (Continued) Command Function Add Variant Entry Displays the V5 Interface Variant Configuration window. Go Back to Previous screen Displays the V5 Interface Configuration window.
Page 367: V5 Interface Variant Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values 3 Remain on this window and continue with the next procedure. Figure 8-10. V5 Interface Variant Configuration Window Table 8-17. Commands for the V5 Interface Variant Configuration Window Command Function Add PhysChnl Table to Variant...
Page 368: Field Descriptions For The V5 Interface Variant Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-18. Field Descriptions for the V5 Interface Variant Configuration Window Field Name Field Value Field Description V5 Intf ID Default: 0 Specifies the V5 interface identifier. Range: 1–10 Format: Numeric Default: 0 Specifies the V5 variant identifier.
Page 369 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-18. Field Descriptions for the V5 Interface Variant Configuration Window (Continued) Field Name Field Value Field Description Align Ports Method Default: V5SecondE Indicates type of flag used for port alignment ditionPortAlign method to use along with interface type.
Page 370: Accessing The V5 Physical C-Channel Configuration Table
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Accessing the V5 Physical C-Channel Configuration Table Begin 1 From the V5 inft Variant Configuration window, select the Add Phy- sChnl Table to Variant command. The V5 PhysCChannel Configuration Table displays (see Figure 8-11). Table 8-19 describes the commands and Table 8-20 describes the fields on this window.
Page 371: Accessing The V5 Physical C-Channel Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-20. Field Descriptions for the V5 Physical C-Channel Configuration Table Window Command Function Total: 0/0 The top number shows which table entry is selected; the bottom number shows total number of entries on the table.
Page 372: V5 Physical C-Channel Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Figure 8-12. V5 Physical C-Channel Configuration Window Table 8-21. Commands for the V5 Physical C-Channel Configuration Window Command Function Add V5PhysCChn to the table Adds the V5 physical C-channel entry to the V5 PhysCChannel Configuration Table.
Page 373: Field Descriptions For The V5 Physical C Channel Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-22. Field Descriptions for the V5 Physical C Channel Configuration Window Field Name Field Value Description Interface ID Default: 0 This index identifies the V5 Interface configura- tion table.
Page 374 Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-22. Field Descriptions for the V5 Physical C Channel Configuration Window (Continued) Field Name Field Value Description Protection Group Default: Pg-1 Specifies whether this logical/physical channel belongs to Protection Group Number 1 or 2. Pro- Range: N/A tection Group 1 always uses the user-assigned Format: Predefined...
Page 375: Accessing The V5 E1 Link Configuration Table
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Accessing the V5 E1 Link Configuration Table Begin 1 From the V5 Interface Variant Configuration window, select the Add E1 Link table to Variant command. The V5 E1Link Configuration Table displays (see Figure 8-13).
Page 376: Accessing The V5 E1 Link Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-24. Field Descriptions for the V5 E1 Link Configuration Table Window Command Function Intf ID Displays the interface ID. Variant ID Displays all the variant IDs for the Interface ID. LinkID Displays the link ID of the interface ID.
Page 377: V5 E1 Link Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Figure 8-14. V5 E1 Link Configuration Window Table 8-25. Commands for the V5 E1 Link Configuration Window Command Function Go To Timeslot Channel Table Displays the Timeslot Channel Table window. Go Back to Previous Screen Returns to the previous window.
Page 378: Accessing The V5 E1 Interface Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-26. Field Descriptions for the V5 E1 Link Configuration Window Field Name Field Values Description Administrative Sta- Default: Force- Specifies the administrative status of the call pro- Blocked cessing functions on the E1 Link.
Page 379: V5 E1 Interface Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values 2 Make a note of the timeslot data on the table that you want to change. Remain on the window and continue to the next procedure. Figure 8-15. V5 E1 Interface Configuration Window Table 8-27.
Page 380: Accessing The V5 Time Slot Table
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-28. Field Descriptions for the V5 E1 Interface Configuration Window Field Name Field Values Description [Channel1] Default: 0 Specifies a C-Channel which carries signalling information. Generally, this channel should be Range: specified on a single E1 in a V5 interface group Format: Numeric...
Page 381: Accessing The V5 Data Link Configuration Table
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Figure 8-16. V5 Time Slot Table Table 8-29. Commands for the V5 Timeslot Table Window Command Function Bring All Interfaces Into Service Brings all interfaces into service. Take All Interface Out Of Service Takes all interfaces out of service.
Page 382: V5 Data Link Configuration Table
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Figure 8-17. V5 Data Link Configuration Table Table 8-30. Commands for the V5 Data Link Configuration Table Window Command Function Page Up Scrolls up one page. Page Down Scrolls down one page.
Page 383: Accessing The V5 Data Link Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Accessing the V5 Data Link Configuration Window Begin 1 From the V5 Data Link Configuration Table, select the Add Data Link Config Entry command. The V5 Data Link Configuration window dis- plays (see Figure 8-18).
Page 384: Field Descriptions For The V5 Data Link Configuration Window
Chapter 8 Configuring V5.2 European IDLC Setting Call Control Resource Allocation Values Table 8-32. Commands for the V5 Data Link Configuration Window (Continued) Command Function Delete V5 Data Link and return Deletes a selected data link and returns to the V5 Data Link Table.
Page 385: User Side Configuration Summary
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary User Side Configuration Summary The next part of V5.2 configuration is to configure the User Side. The follow- ing steps are a summary; actual configuration begins with the Accessing the User Port Table procedure below.
Page 386: Accessing The V5 User Port Table
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Accessing the V5 User Port Table Begin See the “Accessing the V5 Interface Configuration Window” on page 8-22 to start this procedure. 1 From the V5 Interface Variant Configuration window, select the Add User Port Table to Variant command.
Page 387: Accessing The V5 User Port Configuration Window, Pstn Port Type
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Table 8-34. Commands for the V5 User Port Table Window (Continued) Command Function Add User Port configuration Adds the User Port configuration values of Entry a specific entry. Go back to Previous Screen Returns to the V5 Interface Variant Con- figuration window.
Page 388: V5 User Port Configuration Window For Pstn As Port Type
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Figure 8-20. V5 User Port Configuration Window for PSTN as Port Type Table 8-35. Commands for the V5 User Port Configuration Window Command Function Display Next V5 User Port Configu- Displays the next V5 User Port configuration in the ration database.
Page 389: Field Descriptions For The V5 User Port Configuration Window
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Table 8-36. Field Descriptions for the V5 User Port Configuration Window Field Name Values Description Interface Id Default: 0 Specifies the ID the PSAX uses internally for the interface after the interface is created. Range: 1–10 Note: Although the status line on your window Format: Numeric...
Page 390 Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Table 8-36. Field Descriptions for the V5 User Port Configuration Window Field Name Values Description ISDN B1 channels Default: [160] Specifies the Cid value of ISDN Bearer-1 channels that the PSAX is dynamically allocating. Range: 16–233 Although the field is editable, do not enter any Format: Numeric...
Page 391 Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Table 8-36. Field Descriptions for the V5 User Port Configuration Window Field Name Values Description [ISDN Port Type] Default: Bra Specifies whether rate interface supported is Bra or Pra. This field displays only when Port Type is Range: N/A Isdn.
Page 392 Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Table 8-36. Field Descriptions for the V5 User Port Configuration Window Field Name Values Description [Operation Status] Default: Blocked Specifies the operational status of the user port on both LE and LES sides. See Admin Status field Range: See Admin on lower left panel.
Page 393: Accessing The V5 User Port Configuration Window, Isdn Port Type
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Table 8-36. Field Descriptions for the V5 User Port Configuration Window Field Name Values Description Tone Detection Default: Disabled Specifies whether fax/modem tone detection is Algo disabled or bypassed. Range: N/A Format: Predefined Disabled Fax modem tone detection is disabled.
Page 394: V5 User Port Configuration Window, Port Type Isdn Selected
Chapter 8 Configuring V5.2 European IDLC User Side Configuration Summary Figure 8-21. V5 User Port Configuration Window, Port Type ISDN Selected ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 8-56 255-700-447...
Page 395: Configuring Snmp Authentication Options
Configuring SNMP Authentication Options Overview of This Chapter This chapter provides an overveiw of SNMP and instructions for using the console interface to perform the following tasks: • Accessing SNMP Configuration Options • Modifying an SNMP Community String Password • Configuring the User-based Security Model (USM) •...
Page 396: Accessing Snmp Configuration Options
Chapter 9 Configuring SNMP Authentication Options Accessing SNMP Configuration Options SNMPv1/v2C community strings are automatically entered in the Vacm Security to Group Table window. To configure SNMPv3 authentication: • Assign a user a security model using the Usm User Creation menu option •...
Page 397: Site-Specific Menu Window, Snmp Agent Selected
Chapter 9 Configuring SNMP Authentication Options Accessing SNMP Configuration Options Figure 9-1. Site-Specific Menu Window, SNMP Agent Selected Figure 9-2. SNMP Agent System-Wide Configuration Window, Non-Root User View ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447...
Page 398: Modifying An Snmp Community String Password
Chapter 9 Configuring SNMP Authentication Options Modifying an SNMP Community String Password Figure 9-3. SNMP Agent System-Wide Configuration Window, Root User View Table 9-1. Menu Options for the SNMP Agent System-Wide Configuration Window Menu Option Description Trap Notification Configuration Displays the Notification Table window. USM User Configuration Displays the Usm User Table window.
Page 399: Community String Table Window
Chapter 9 Configuring SNMP Authentication Options Modifying an SNMP Community String Password The Community String Table window is displayed (see Figure 9-4). The commands for this window are described in Table 9-2. The fields for this window are described in Table 9-3. 2 On the Community String Table window, select the entry to modify and press Enter.
Page 400: Community String Configuration Window
Chapter 9 Configuring SNMP Authentication Options Modifying an SNMP Community String Password Table 9-3. Field Descriptions for the Community String Table Window Field Name Field Values Description ReadOnlyCommu- Default: public The ReadOnlyCommunityString provides read- nityString only access to the PSAX system using Range: 1–32 charac- SNMPv1/v2C.
Page 401: Configuring The User-Based Security Model (Usm)
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Table 9-5. Field Descriptions for the Community String Configuration Window Field Name Field Values Description ReadOnlyCommu- Default: public The ReadOnlyCommunityString provides read- nityString only access to the PSAX system using Range: 1–32 charac- SNMPv1/v2C.
Page 402: Usm User Table Window
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Note: Once a USM user has been defined, only the authentication and privacy passwords may be changed. To change other parameters, delete the USM user and recreate it using the new parameters. Begin 1 On the SNMP Agent System-Wide Configuration window, select the USM User Configuration option.
Page 403: Usm User Creation Window
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Table 9-7. Commands for the Usm User Table Command Function Page Up Displays the previous page of the table. Page Down Displays the next page of the table. Displays the first page of the table.
Page 404: Commands For The Usm User Creation Window
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Table 9-9. Commands for the Usm User Creation Window Command Function Create User Creates the USM user. Go Back to Previous Screen Redisplays the Usm User Table window. Table 9-10.
Page 405: Changing A Usm User's Passwords
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Table 9-10. Field Descriptions for the Usm User Creation Window (Continued) Field Name Field Values Description Security Level Default: NoAuthNo- Indicates the level of security for remote SNMP Priv messages or remote SNMP operations.
Page 406: Usm User Key Change Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Note: Once a USM user has been defined, only the authentication and privacy passwords may be changed. To change other parameters, delete the USM user and recreate it using the new parameters. Begin 1 On the SNMP Agent System-Wide Configuration window, select the USM User Configuration option.
Page 407: Commands For The Usm User Key Change Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Table 9-11. Commands for the Usm User Key Change Configuration Window Command Function Apply Key Change Applies the password change for the speci- fied key type. Delete this User and Return Deletes the displayed user and redisplays the Usm User Table window.
Page 408: Deleting Usm Users
Chapter 9 Configuring SNMP Authentication Options Configuring the User-based Security Model (USM) Table 9-12. Field Descriptions for the Usm User Key Change Configuration Window (Continued) Field Name Field Values Description Key Type Default: Authenti- Indicates the key type password to be changed. cation Range: N/A Format: Predefined...
Page 409: Configuring The View-Based Access Control Model (Vacm)
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Configuring the View-based Access Control Model (VACM) The PSAX system has predefined the default VACM access groups shown in Table 9-13. Table 9-13. Default VACM Access Groups Security VACM Group Name Security Level...
Page 410: Vacm Access Table Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Figure 9-9. Vacm Access Table Window Table 9-14. Commands for the Vacm Access Table Window Command Function Page Up Displays the previous page of the table. Page Down Displays the next page of the table.
Page 411: Field Descriptions For The Vacm Access Table Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-15. Field Descriptions for the Vacm Access Table Window Field Name Field Values Description Group Name Default: N/A Displays the name assigned to the VACM group. Range: 1-32 A unique combination of the fields Vacm Group Name, Vacm Access Security Model, and Vacm...
Page 412: Vacm Access Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Figure 9-10. Vacm Access Configuration Window Table 9-16. Commands for the Vacm Access Configuration Window Command Function Apply/Add Adds an entry to the Vacm Access Table window when the VACM Group or Secu- rity information is created or modified.
Page 413: Field Descriptions For The Vacm Access Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-17. Field Descriptions for the Vacm Access Configuration Window Field Name Field Values Description Vacm Group Name Default: N/A Specifies the name to be assigned to the VACM group.
Page 414 Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-17. Field Descriptions for the Vacm Access Configuration Window (Continued) Field Name Field Values Description Vacm Access Read Default: None Indicates the read privileges for the group. A read View operation occurs when processing a retrieval Range: N/A...
Page 415: Modifying Vacm Access Groups
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-17. Field Descriptions for the Vacm Access Configuration Window (Continued) Field Name Field Values Description Vacm Access Notify Default: None Indicates the notification privileges for the group. View Notification occurs when the PSAX sends a trap.
Page 416: Deleting Vacm Access Groups
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) 2 On the Vacm Access Table window, select the entry to modify and press Enter. The Vacm Access Configuration window is displayed (see Figure 9-10). 3 On the Vacm Access Configuration window, modify the values in the fields according to the information provided in Table 9-15.
Page 417: Valid Vacm Group Assignment For Usm Security Level
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-18. Default VACM Access Group Assignments (Continued) Security Model VACM Access VACM Group VACM Read VACM Write VACM User Name for User Group Security Level View View Notify View v3readonly...
Page 418: Vacm Security To Group Table Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Figure 9-11. Vacm Security to Group Table Window Table 9-20. Commands for the Vacm Security to Group Table Window Command Function Page Up Displays the previous page of the table. Page Down Displays the next page of the table.
Page 419: Field Descriptions For The Vacm Security To Group Table Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-21. Field Descriptions for the Vacm Security to Group Table Window Field Name Field Values Description Name Default: N/A Displays the VACM security name. Note: If the Model is set to V1 or V2C, then this Range: 1–32 field value must match one of the Security Name Format: Alphanu-...
Page 420: Vacm Security To Group Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Figure 9-12. Vacm Security to Group Configuration Window Table 9-22. Commands for the Vacm Security to Group Configuration Window Command Function Apply/Add Applies when a change is made to the Vacm Group Name.
Page 421: Field Descriptions For The Vacm Security To Group Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Table 9-23. Field Descriptions for the Vacm Security to Group Configuration Window Field Name Field Values Description Vacm Security Default: N/A Specifies the VACM security name. You can spec- Name ify alphanumeric characters including A-Z, a-z, 0- Range: 1-32...
Page 422: Re-Assigning A User To A Different Vacm Access Group
Chapter 9 Configuring SNMP Authentication Options Configuring the View-based Access Control Model (VACM) Re-assigning a User to a Different VACM Access Group To modify the assignment of USM users and/or SNMP communities to VACM security groups, perform the steps in the following procedure. Begin 1 On the SNMP Agent System-Wide Configuration window, select the VACM Security to Group Configuration option.
Page 423: Configuring Snmp Notification
Chapter 9 Configuring SNMP Authentication Options Configuring SNMP Notification The information is deleted and the Vacm Security to Group Table win- dow is displayed. Configuring SNMP Notification You can send SNMP trap or inform messages to remote network manage- ment systems (NMSs). To define the IP address and notification type for an NMS destination, perform the steps in the following procedure.
Page 424: Notification Table Window
Chapter 9 Configuring SNMP Authentication Options Configuring SNMP Notification Figure 9-13. Notification Table Window Table 9-24. Commands for the Notification Table Window Command Function Page Up Displays the previous page of the table. Page Down Displays the next page of the table. Displays the first page of the table.
Page 425: Notification Configuration Window
Chapter 9 Configuring SNMP Authentication Options Configuring SNMP Notification Figure 9-14. Notification Configuration Window Table 9-26. Commands for the Notification Configuration Window Command Function Apply Sets the displayed configuration values. Go Back to Previous Screen Redisplays the Notification Table window. Table 9-27.
Page 426 Chapter 9 Configuring SNMP Authentication Options Configuring SNMP Notification Table 9-27. Field Descriptions for the Notification Configuration Window (Continued) Field Name Field Values Description Notify Type Default: V1Trap Indicates the type of notification to be sent. An inform is an acknowledged notification. A trap is Range: N/A an un-acknowledged notification.
Page 427 Chapter 9 Configuring SNMP Authentication Options Configuring SNMP Notification Table 9-27. Field Descriptions for the Notification Configuration Window (Continued) Field Name Field Values Description Retry Times Default: 3 Specifies the number of retries to be attempted when a response is not received for a generated Range: 0–255 message.
Page 428: Configuring V3 Informs
Chapter 9 Configuring SNMP Authentication Options Configuring SNMP Notification Configuring V3 Informs Configuring SNMPv3 informs requires that you know the remote SNMP Engine ID of the system that will provide the acknowledgement. The follow- ing procedure only shows the configuration options needed for V3 Informs. Begin 1 On the SNMP Agent System-Wide Configuration window, select the USM User Configuration option.
Page 429: Configuring Atm Security Agents
Availability of the ATM Security Feature The ATM Security feature is available only to users in certain countries. Con- tact your Lucent Technologies sales representative to find out whether your country is eligible to use the ATM Security feature. Prerequisites for Configuring ATM Security Agents...
Page 430: Configuring Atm Security For Atm Uni Interfaces
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Configuring ATM Security for ATM UNI Interfaces Accessing ATM Security for an ATM UNI Interface To access the ATM UNI Interface ATM Security window on which you begin configuration of an ATM security agent for an ATM UNI interface, perform the steps in the following procedure.
Page 431: Atm Uni Interface Atm Security Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Figure 10-1. ATM UNI Interface ATM Security Window Table 10-1 describes the commands on this window. Table 10-1. Commands for the ATM UNI Interface ATM Security Window Command Function ATM UNI Security Configura-...
Page 432: Configuring An Atm Security Agent For An Atm Uni Interface
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-2. Field Descriptions for the ATM UNI Interface ATM Security Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on security is being configured.
Page 433: Atm Uni Interface Atm Security Configuration Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces 3 To view the statistics for this ATM security agent, go the procedure in the next section, “Viewing ATM Security Agent Statistics for an ATM UNI Interface”. Figure 10-2.
Page 434: Commands For The Atm Uni Interface Atm Security Configuration Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-3 describes the commands on this window. Table 10-3. Commands for the ATM UNI Interface ATM Security Configuration Window Command Function Bring Sec Admin Status Into Brings the security configuration on the specified interface Service into service, making the encryption operational.
Page 435: Field Descriptions For The Atm Uni Interface Atm Security Configuration Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-4. Field Descriptions for the ATM UNI Interface ATM Security Configuration Window Field Name Field Values Description Service Profile Default: Integrity- Specifies the service type that is provided by the ATM security agent on this signaling or routing PVC according to the ATM Forum Specification Range: N/A...
Page 436 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-4. Field Descriptions for the ATM UNI Interface ATM Security Configuration Window Field Name Field Values Description SessKeyLength Default: Key-128- Specifies the length of the integrity session key. bits Select a value from 40 to 256 bits (in increments of 8 bits).
Page 437: Viewing Atm Security Agent Statistics For An Atm Uni Interface
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-4. Field Descriptions for the ATM UNI Interface ATM Security Configuration Window Field Name Field Values Description InitSessKeyA Default: 0 Specifies the initial session key for confidentiality security service for communication from this Range: N/A security agent to the peer security agent (side A...
Page 438: Atm Uni Interface Atm Security Statistics Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces 3 To view all configured ATM security agents in the PSAX system, go the procedure in the section, “Viewing All ATM Security Agents in the Sys- tem” on page 10-45. Figure 10-4.
Page 439: Field Descriptions For The Atm Uni Interface Atm Security Statistics Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-6. Field Descriptions for the ATM UNI Interface ATM Security Statistics Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on security is being configured.
Page 440 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM UNI Interfaces Table 10-6. Field Descriptions for the ATM UNI Interface ATM Security Statistics Window (Continued) Field Name Field Values Description Integrity Current Default: 0 Displays the number of minutes since the session Session Key A key for integrity security service for communica- Range: N/A...
Page 441: Configuring Atm Security For Atm Pnni Svcc Rcc Nodes
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Configuring ATM Security for ATM PNNI SVCC RCC Nodes Accessing ATM Security for an ATM PNNI SVCC RCC Node To access the ATM PNNI SVCC RCC Security Configuration window on which you configure an ATM security agent for an ATM PNNI SVCC RCC node, perform the steps in the following procedure.
Page 442: Configuring An Atm Security Agent For An Atm Pnni Svcc Rcc Node
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Figure 10-5. PNNI Node Table Window Figure 10-6. PNNI Node Configuration Window Configuring an ATM Security Agent for an ATM PNNI SVCC RCC Node To configure an ATM security agent for an ATM PNNI SVCC RCC node, per- form the steps in the following procedure.
Page 443: Atm Pnni Svcc Rcc Security Configuration Window (Integrity Security Service Only)
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Begin 1 On the PNNI Node Configuration window, make sure you have already created an ATM PNNI node by selecting the Create Node Entry com- mand (see Chapter 6 for more information).
Page 444: And Confidentiality Security Services)
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Figure 10-8. ATM PNNI SVCC RCC Security Configuration Window (Both Integrity and Confidentiality Security Services) Table 10-7 describes the commands on this window. Table 10-7. Commands for the ATM PNNI SVCC RCC Security Configuration Window Command Function Bring Sec Admin Status Into...
Page 445: Field Descriptions For The Atm Pnni Svcc Rcc Security Configuration Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Table 10-8. Field Descriptions for the ATM PNNI SVCC RCC Security Configuration Window Field Name Field Values Descriptions [Peer Grp Id] Default: 0 Displays the first 12 bytes (default) of the ATM address.
Page 446 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Table 10-8. Field Descriptions for the ATM PNNI SVCC RCC Security Configuration Window (Continued) Field Name Field Values Descriptions [SKU Encryption Default: MD5 Specifies the encryption algorithm used for Algorithm] encrypting session keys that need to be for- Range: N/A...
Page 447 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Table 10-8. Field Descriptions for the ATM PNNI SVCC RCC Security Configuration Window (Continued) Field Name Field Values Descriptions Confidentiality Security Service Panel Note: The fields on this panel are displayed only when you select one of the following service profiles in the Service Profile field: •...
Page 448: Viewing Atm Security Agent Statistics For An Atm Pnni Svcc Rcc Node
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Table 10-8. Field Descriptions for the ATM PNNI SVCC RCC Security Configuration Window (Continued) Field Name Field Values Descriptions [Sec Admin Status] Default: OutOfSer- Displays the operational status of the ATM secu- vice rity agent.
Page 449: Pnni Svcc Rcc Information Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Figure 10-9. PNNI SVCC RCC Information Window Figure 10-10. ATM PNNI SVCC RCC Security Statistics Window Table 10-9 describes the commands on this window. ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0...
Page 450: Commands For The Atm Pnni Svcc Rcc Security Statistics Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Table 10-9. Commands for the ATM PNNI SVCC RCC Security Statistics Window Command Function Apply Session Key Update for Requests a session key update for integrity security services. Integrity Security Services Apply Session Key Update for Requests a session key update for confidentiality security ser-...
Page 451 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI SVCC RCC Nodes Table 10-10. Field Descriptions for the ATM PNNI SVCC RCC Security Statistics Window (Continued) Field Name Field Values Description Display Only Fields Security Agent Default: Null Displays the current state of the ATM security State agent.
Page 452: Configuring Atm Security For Atm Pnni Interfaces
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-10. Field Descriptions for the ATM PNNI SVCC RCC Security Statistics Window (Continued) Field Name Field Values Description SDU with Bad MAC Default: 0 Displays the number of service data units received from the lower layer with an incorrect Range: N/A message authentication code.
Page 453: Atm Pnni Interface Atm Security Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces The ATM PNNI Interface ATM Security window is displayed (see Figure 10-11). The commands and fields are described in Table 10-11 and Table 10-12. 3 To configure an ATM security agent for the ATM PNNI interface, go to one of the following procedure: •...
Page 454: Configuring An Atm Security Agent For An Atm Pnni Interface-Signaling Pvc
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-12 describes the fields on this table. Table 10-12. Field Descriptions for the ATM PNNI Interface ATM Security Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on...
Page 455: Atm Pnni Interface Atm Security Configuration Window - Signaling Pvc (Integrity Security Service Only)
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Note: If you select the value Integrity-Confidentiality-172 or Integ- rity-Confidentiality-ReplayReorderProtection-172 in the Service Profile field, the Confidentiality Security Service panel is displayed on the window (see Figure 10-13) 3 To view the statistics for this ATM security agent, go the procedure in the next section, “Viewing ATM Security Agent Statistics for an ATM PNNI Interface—Signaling PVC”.
Page 456: Atm Pnni Interface Atm Security Configuration Window - Signaling Pvc (Both Integrity Security And Confidentiality Services)
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Figure 10-13. ATM PNNI Interface ATM Security Configuration Window - Signaling PVC (Both Integrity Security and Confidentiality Services) Table 10-13 describes the commands on this window. Table 10-13. Commands for the ATM PNNI Interface ATM Security Configuration - Signaling PVC Window Command Function...
Page 457: Pvc Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-14. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Signaling PVC Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on security is being configured.
Page 458: Field Descriptions For The Atm Pnni Interface Atm Security Configuration - Signaling Pvc Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-14. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Signaling PVC Window (Continued) Field Name Field Values Description Master Key Default: 0 Specifies the master key that is shared between two peer security agents for integrity and/or con- Range: N/A fidential security services.
Page 459 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-14. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Signaling PVC Window (Continued) Field Name Field Values Description SKU Time Interval Default: No-Auto- Specifies the frequency of the session key update matic-SKU for integrity security service for communication...
Page 460: Viewing Atm Security Agent Statistics For An Atm Pnni Interface-Signaling Pvc
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-14. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Signaling PVC Window (Continued) Field Name Field Values Description SKU Time Interval Default: No-Auto- Specifies the frequency of the session key update matic-SKU for confidentiality security service for communi-...
Page 461: Atm Pnni Interface Atm Security Statistics - Signaling Pvc Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Figure 10-14. ATM PNNI Interface ATM Security Statistics - Signaling PVC Window Table 10-15 describes the commands on this window. Table 10-15. Commands for the ATM PNNI Interface ATM Security Statistics - Signaling PVC Window Command Function...
Page 462 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-16. Field Descriptions for the ATM PNNI Interface ATM Security Statistics - Signaling PVC Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on security is being configured.
Page 463: Field Descriptions For The Atm Pnni Interface Atm Security Statistics - Signaling Pvc Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-16. Field Descriptions for the ATM PNNI Interface ATM Security Statistics - Signaling PVC Window (Continued) Field Name Field Values Description Display Only Fields Security Agent Default: Null Displays the current state of the ATM security State...
Page 464: Configuring An Atm Security Agent For An Atm Pnni Interface-Routing Pvc
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-16. Field Descriptions for the ATM PNNI Interface ATM Security Statistics - Signaling PVC Window (Continued) Field Name Field Values Description SDU Received Default: 0 Displays the number of service data units received from the lower layer Range: N/A Format: Numeric...
Page 465: Atm Pnni Interface Atm Security Configuration - Routing Pvc Window (Integrity Security Service Only)
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces 3 To view the statistics for this ATM security agent, go the procedure in the next section, “Viewing ATM Security Agent Statistics for an ATM PNNI Interface—Routing PVC”. Figure 10-15.
Page 466: Commands For The Atm Pnni Interface Atm Security Configuration - Routing
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-17 describes the commands on this window. Table 10-17. Commands for the ATM PNNI Interface ATM Security Configuration - Routing PVC Window Command Function Bring Sec Admin Status Into Brings the security configuration on the specified interface Service into service, making the encryption operational.
Page 467 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-18. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Routing PVC Window (Continued) Field Name Field Values Description Service Profile Default: Integrity- Specifies the service type that is provided by the ATM security agent on this signaling or routing PVC according to the ATM Forum Specification Range: N/A...
Page 468 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-18. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Routing PVC Window (Continued) Field Name Field Values Description SessKeyLength Default: Key-128- Specifies the length of the integrity session key. bits Select a value from 40 to 256 bits (in increments of 8 bits).
Page 469: Viewing Atm Security Agent Statistics For An Atm Pnni Interface-Routing Pvc
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-18. Field Descriptions for the ATM PNNI Interface ATM Security Configuration - Routing PVC Window (Continued) Field Name Field Values Description InitSessKeyA Default: 0 Specifies the initial session key for confidentiality security service for communication from this Range: N/A security agent to the peer security agent (side A...
Page 470: Atm Pnni Interface Atm Security Statistics - Routng Pvc Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces 3 To view all configured ATM security agents in the PSAX system, go the procedure in the section, See “Viewing All ATM Security Agents in the System” on page 45. Figure 10-17.
Page 471: Field Descriptions For The Atm Pnni Interface Atm Security Statistics - Routing Pvc Window
Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-20. Field Descriptions for the ATM PNNI Interface ATM Security Statistics - Routing PVC Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on security is being configured.
Page 472 Chapter 10 Configuring ATM Security Agents Configuring ATM Security for ATM PNNI Interfaces Table 10-20. Field Descriptions for the ATM PNNI Interface ATM Security Statistics - Routing PVC Window (Continued) Field Name Field Values Description Display Only Fields Security Agent Default: Null Displays the current state of the ATM security State...
Page 473: Viewing All Atm Security Agents In The System
Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System Table 10-20. Field Descriptions for the ATM PNNI Interface ATM Security Statistics - Routing PVC Window (Continued) Field Name Field Values Description SDU Received Default: 0 Displays the number of service data units received from the lower layer Range: N/A...
Page 474: Atm Security Agents Table Window (Populated)
Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System 3 To view statistics for an ATM security agent, select a line containing the interface ID of the interface for which an ATM security agent was config- ured, and press Enter.
Page 475: Field Descriptions For The Atm Security Agents Table Window
Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System Table 10-22 describes the fields for this window. Table 10-22. Field Descriptions for the ATM Security Agents Table Window Field Name Field Values Description Intf ID Default: N/A Displays the identification (index) number of the interface.
Page 476 Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System Table 10-22. Field Descriptions for the ATM Security Agents Table Window (Continued) Field Name Field Values Description Security Agent Default: Null Displays the current state of the ATM security State agent.
Page 477: Atm Security Statistics Window
Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System Figure 10-19. ATM Security Statistics Window Table 10-23 describes the commands on this window. Table 10-23. Commands for the ATM Security Statistics Window Command Function Apply Session Key Update for Requests a session key update for integrity security services.
Page 478: Field Descriptions For The Atm Security Statistics Window
Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System Table 10-24. Field Descriptions for the ATM Security Statistics Window Field Name Field Values Description Slot Default: N/A Specifies the slot number containing the module, which contains the interface for which ATM Range: Depends on security is being configured.
Page 479 Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System Table 10-24. Field Descriptions for the ATM Security Statistics Window (Continued) Field Name Field Values Description Integrity Current Default: 0 Displays the number of minutes since the session Session Key A key for integrity security service for communica- Range: N/A...
Page 480 Chapter 10 Configuring ATM Security Agents Viewing All ATM Security Agents in the System ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 10-52 255-700-447...
Page 481: Using System Diagnostics
Using System Diagnostics Overview of This Chapter The PSAX system diagnostic functions give you the ability to: • View the status of the PSAX system including: ~ Version of the PSAX system software currently running ~ Status of the system disk on the CPUn module ~ CPUn module and memory utilization details ~ Statistics on the message pool and the cell buffers •...
Page 482: Viewing System Status
Chapter 11 Using System Diagnostics Viewing System Status Table 11-1. Menu Option Descriptions for the Diagnostics Menu Window (Continued) Menu Options Description Remove Deletes all user-created configuration data from the PSAX sys- Configuration Files tem. However, IP addresses that you set up on the System Iden- tification panel of the Site-Specific Configuration window are not deleted.
Page 483: Console Interface Main Menu Window (Diagnostics Option Selected)
Chapter 11 Using System Diagnostics Viewing System Status Figure 11-1. Console Interface Main Menu Window (Diagnostics Option Selected) Figure 11-2. Diagnostics Menu Window ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 255-700-447 11-3...
Page 484: System Information Window
Chapter 11 Using System Diagnostics Viewing System Status Figure 11-3. System Information Window The commands on this window are described in Table 11-2. Table 11-2. Commands for the System Information Screen Command Function Go to Module ConnCount Table Displays the Module Connection Count Table window. This window can be used as a troubleshooting aid by technical support personnel.
Page 485 Chapter 11 Using System Diagnostics Viewing System Status Table 11-3. Field Descriptions for the System Information Window Field Name Field Values Description [System Up Time] Default: N/A Displays the amount of time the PSAX system has been running since the last time you applied Range: N/A power to the system, or booted (initialized) the Format: Numeric...
Page 486 Chapter 11 Using System Diagnostics Viewing System Status Table 11-3. Field Descriptions for the System Information Window Field Name Field Values Description [Disk Status] Default: Ok Displays the checking status of the system disk on the CPU module. Range: N/A Format: Indicates that no errors on the system disk are detected.
Page 487: Checking The Module Connection Count
Chapter 11 Using System Diagnostics Checking the Module Connection Count Table 11-3. Field Descriptions for the System Information Window Field Name Field Values Description [Error Cells Rx] Default: 0 Displays the number of errored cells (BIP16) received since the last time you applied power to Range: N/A the system, or booted (initialized) the CPU mod- Format: Numeric...
Page 488: Module Connection Count Window
Chapter 11 Using System Diagnostics Checking the Module Connection Count Figure 11-4. Module Connection Count Window Table 11-4. Commands for the Module Connection Count Table Window Command Function Continuous Update Continuously updates the information in the fields every sec- ond. Use this command to turn continuous updating on and off as needed.
Page 489: Running Cell Test Diagnostics
Chapter 11 Using System Diagnostics Running Cell Test Diagnostics Table 11-5. Field Descriptions for the Module Connection Count Table Window (Continued) Field Name Field Values Description I/O Input Default: N/A Displays the count of input connections on the I/O module. Range: -1–2 Format: Numeric I/O Output...
Page 490: Cell Test Diagnostics Window
Chapter 11 Using System Diagnostics Running Cell Test Diagnostics 7 Select the Send Payload Once or the Send Payload Continuously command. The system displays the protocol, cells transmitted or the cells received or both, depending on the type of flow selected on the Cell Test Diagnostics window (see Figure 11-5).
Page 491: Field Descriptions For The Cell Test Diagnostics Window
Chapter 11 Using System Diagnostics Running Cell Test Diagnostics Table 11-7. Field Descriptions for the Cell Test Diagnostics Window Field Names Values Description Slot Default: N/A The slot number containing the I/O module configured with the ATM UNI interface that you want to test. Range: Chassis specific Format: numeric...
Page 492 Chapter 11 Using System Diagnostics Running Cell Test Diagnostics Table 11-7. Field Descriptions for the Cell Test Diagnostics Window (Continued) Field Names Values Description AdminStatus Default: InService Indicates whether conditions are currently affecting the opera- (display only) tional status of this interface. Range: N/A Format: Predefined InService...
Page 493: Cell Test Payload Configuration Window
Chapter 11 Using System Diagnostics Running Cell Test Diagnostics Figure 11-6. Cell Test Payload Configuration Window The commands on this window are described in Table 11-8. Table 11-8. Commands for the Cell Test Payload Configuration Window Command Function Apply Transmit Payload Applies the values you enter in the Transmitted Pay- load field.
Page 494: Field Descriptions For The Cell Test Payload Window
Chapter 11 Using System Diagnostics Running Cell Test Diagnostics Table 11-8. Commands for the Cell Test Payload Configuration Window (Continued) Command Function Stop Cell Test Stops a continuously running test and deletes the connection you set up on the Cell Diagnostics win- dow.
Page 495: Rebooting Psax Hardware Components
Chapter 11 Using System Diagnostics Rebooting PSAX Hardware Components Rebooting PSAX Hardware Components Specific hardware components may need to be restarted for several reasons, including: • When you want to revert back to a saved configuration • When a module is not adhering to its configuration •...
Page 496: Commands For The Remote Reboot Configuration Window
Chapter 11 Using System Diagnostics Rebooting PSAX Hardware Components The VxWorks shell is restarted in a process called the auto-boot. If you press a key during the auto-boot process, the auto-boot process will stop. You can resume the auto-boot process by pressing Shift+2 (the @ sym- bol).
Page 497 Chapter 11 Using System Diagnostics Rebooting PSAX Hardware Components Table 11-10. Commands for the Remote Reboot Configuration Window (Continued) Command Function Reboot Primary CPU WARNING: Rebooting the PSAX system with a single (nonredun- dant) CPU module or component will interrupt all traffic running through the PSAX chassis.
Page 498: Removing Configuration Files
Chapter 11 Using System Diagnostics Removing Configuration Files Removing Configuration Files To remove configuration files, perform the following procedure. WARNING: The following procedure removes all configuration files from the CPU and restores the CPU to its factory default settings. All data will be removed except the CPU IP address, gateway IP address, and SNMP trap destinations.
Page 499: Operations Administration And Maintenance (Oam)
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) This command corrects a telnet lock-up condition, and enables you to access the specified PSAX system. 6 To verify that access has been restored to the specified PSAX system, select the Ping Remote Machine command. This command sends a ping command to the remote PSAX system speci- fied in the IP Address field or to another switching device to indicate whether or not you can connect to that remote device.
Page 500: Oam Loopback Table Window
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Begin 1 On the Console Interface Main Menu window, select the Diagnostics option. The Diagnostics Menu window is displayed (see Figure 11-2). 2 On the Diagnostics Menu window, select the OAM Loopback option. The OAM Loopback Table window is displayed (see Figure 11-9).
Page 501: Commands For The Oam Loopback Window
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-11. Commands for the OAM Loopback Table Window (Continued) Command Function Total: 0/0 The first number in this field indicates the number of the connection table entry on the first line of the cur- rently displayed window.
Page 502: Field Descriptions For The Oam Loopback Window
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-12. Commands for the OAM Loopback Window (Continued) Command Function Apply Action Applies the values you enter in this window. Go Back to OAM Loopback Redisplays the OAM Loopback Table window. Table Screen Table 11-13.
Page 503: Oam Activation And Deactivation
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-13. Field Descriptions for the OAM Loopback Window (Continued) Field Name Field Values Description [Cells Received] Default: 0 Indicates the number of loopback cells received cor- rectly on the specified connection since the last Range: N/A reset.
Page 504: Oam Activate & Deactivate Table Window
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) To enable OAM Activation-Deactivation, perform the following procedure. Begin 1 On the Console Interface Main Menu window, select the Diagnostics option. The Diagnostics Menu window is displayed (see Figure 11-2). 2 On the Diagnostics Menu window, select the OAM Activate and Deacti- vate option.
Page 505: Oam Activation -Deactivation Window
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-14. Commands for the OAM Activate & Deactivate Table Window Command Function Page Up Scroll up one page. Page Down Scrolls down one page. Displays entries at the top of the table. Bottom Displays entries at the bottom of the table.
Page 506: Field Descriptions For The Oam Activation-Deactivation Window
Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-15. Commands for the OAM Activate & Deactivate Table Window (Continued) Command Function Deactivate Terminates the OAM test. Go Back to Table Screen Redisplays the OAM Activate and Deactivate Table window. Table 11-16.
Page 507 Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-16. Field Descriptions for the OAM Activation-Deactivation Window (Continued) Field Name Field Values Description Direction of Flow Default: Towards- Specifies in which direction the OAM cells are near-end transmitted. Range: N/A Format: Predefined alphanumeric...
Page 508 Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-16. Field Descriptions for the OAM Activation-Deactivation Window (Continued) Field Name Field Values Description Block Size B-A Default: 1024 Specifies the size of the block of OAM cells taken into consideration for performance monitoring in Range: N/A the B to A direction (from far end to near end of...
Page 509 Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-16. Field Descriptions for the OAM Activation-Deactivation Window (Continued) Field Name Field Values Description [Src Point ETE PM] Default: Deactivated Specifies whether source point end-to-end per- formance monitoring is active or not. The current Range: N/A status of the request for performance monitoring Format: Predefined...
Page 510 Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-16. Field Descriptions for the OAM Activation-Deactivation Window (Continued) Field Name Field Values Description [Src Point SEG CC] Default: Deactivated Specifies whether source point segment continu- ity checking is active or not. The current status of Range: N/A the source point’s segment continuity check acti- Format: Predefined...
Page 511 Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) Table 11-16. Field Descriptions for the OAM Activation-Deactivation Window (Continued) Field Name Field Values Description [Snk Point SEG Default: Deactivated Specifies whether sink point segment perfor- PMBR] mance monitoring/backward reporting is active Range: N/A or not.
Page 512 Chapter 11 Using System Diagnostics Operations Administration and Maintenance (OAM) ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 11-32 255-700-447...
Page 513: Backing Up And Restoring Psax System Files
Backing Up and Restoring PSAX System Files Overview of This Chapter This chapter describes how to back up and restore PSAX system database configuration files as follows: • Backing up PSAX system, module, and connection database configuration files by using the following methods: ~ Backing up files by using the console interface ~ Backing up files using FTP ~ Backing up files using XModem/YModem file transfer...
Page 514: Choosing The Configuration Files Transfer Method
Chapter 12 Backing Up and Restoring PSAX System Files Choosing the Configuration Files Transfer Method Choosing the Configuration Files Transfer Method Backing up and restoring your database configuration files involves selecting one of the methods listed in Table 12-1 for copying these files between the CPUn module system disk and the computer workstation (a remote storage medium) on which you will store the backup database configuration files.
Page 515: Backing Up System Database Files
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files • The YModem protocol is a slower method of transmission, but is more reli- able because it acknowledges receipt of packets. You can receive all files grouped under a subdirectory at one time.
Page 516: Remote Database Operation Window
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files 5 Select RemoteSave in the Operation field, and enter values in the other fields on this window according to the information provided in Table 12-3. The commands for this window are described in Table 12-2. The PSAX system saves the configuration files to your designated remote storage medium.
Page 517: Field Descriptions For The Remote Database Operation Window
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Table 12-3. Field Descriptions for the Remote Database Operation Window Field Name Field Values Description Remote Host IP Default: 000.000.000. Specifies the IP address of the remote host com- Addr puter, for example, a Unix or Windows-based workstation.
Page 518 Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Table 12-3. Field Descriptions for the Remote Database Operation Window (Continued) Field Name Field Values Description [Oper Status] Default: NoActivity Displays the operational status indicating what activity is currently taking place.
Page 519: Backing Up Database Files Using Ftp
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Backing Up Database Files Using FTP To back up your PSAX system database files to a remote storage medium, perform the steps in the following procedure, which is a manual method in which you copy each configuration database file in sequence to the storage medium.
Page 520: Psax System Database Files
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files tion, the error message is displayed because you are not using a particular feature that would have created that file on your sys- tem. 8 To exit the FTP session, enter: PSAX System Database Files The files containing the PSAX system configuration data, which is located in the scsi/current/ directory on the CPUn module system disk, are listed in...
Page 521: Backing Up Database Files Using Xmodem/Ymodem Transfer
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Table 12-4. PSAX System Configuration Files (Continued) PSAX Database or Description Definition Filename spclconn.db Special connections configuration database (signaling connections) spvc.db SPVC configuration database spvcaal2.db Standard AAL2 SPVC configuration database tasm.db Tones and announcements configuration database trap.db...
Page 522: Copying The Database Files To A Remote Storage Medium
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files 4 Using the terminal emulator modem communication function, return the telephone number of the line connected to the modem connected to the PSAX system. Copying the Perform the following procedure to copy the database files to a remote stor- Database Files to a age medium.
Page 523 Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files 5 Select the Send Files command on the XMODEM/YMODEM File Trans- fer window. The terminal emulator displaying the PSAX system interface window scrolls the XMODEM/YMODEM File Transfer window out of view. A message is displayed indicating that you can cancel the transfer by press- ing Ctrl+X several times.
Page 524: Xmodem/Ymodem File Transfer Window (Send Options Panel Selected)
Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Figure 12-3. XMODEM/YMODEM File Transfer Window (Send Options Panel Selected) Table 12-5. Commands for the XMODEM/YMODEM File Transfer Window Command Function Send File Initiates the send function of the file transfer process from the CPUn module system disk to a storage medium (such as a Unix or PC workstation system disk).
Page 525 Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Table 12-6. Field Descriptions for the XMODEM/YMODEM File Transfer Window (Continued) Field Names Field Values Description Receive Options Panel Protocol Default: YModem Specifies the type of modem protocol used for receiving data.
Page 526 Chapter 12 Backing Up and Restoring PSAX System Files Backing Up System Database Files Table 12-6. Field Descriptions for the XMODEM/YMODEM File Transfer Window (Continued) Field Names Field Values Description Filename Default: N/A Specifies the filename on the CPUn module sys- tem disk where the software upgrade files are Range: N/A received (stored).
Page 527: Restoring System Database Files
Chapter 12 Backing Up and Restoring PSAX System Files Restoring System Database Files Table 12-6. Field Descriptions for the XMODEM/YMODEM File Transfer Window (Continued) Field Names Field Values Description Packet Size Default: 1024 Specifies the size (in bytes) of the packet that will be transmitted in the data stream.
Page 528: Restoring Database Files Using Ftp
Chapter 12 Backing Up and Restoring PSAX System Files Restoring System Database Files 3 On the Console Interface Main Menu window, select the Remote Data- base Operation option. The Remote Database Operation window is displayed (see Figure 12-1). 4 Select RemoteLoad in the Operation field, and enter values in the other fields on this window according to the information provided in Table 12-3.
Page 529: Restoring Database Files Using Xmodem/Ymodem File Transfer
Chapter 12 Backing Up and Restoring PSAX System Files Restoring System Database Files Note: When you are entering put commands for each individual con- figuration file listed in Table 12-4, an error message might be dis- played stating that the particular file does not exist. In this situa- tion, the error message would be displayed because you are not using a particular feature that would have created that file on your system.
Page 530: Copying The Backup Files To The Psax System
Chapter 12 Backing Up and Restoring PSAX System Files Restoring System Database Files 3 If you have a redundant modem kit, connect cables from the switching modem to the CONSOLE ports on both CPUn modules, and set up the switching modem to establish a connection with the primary CPUn mod- ule.
Page 531: Restoring Backup Files To The Standby Cpun Module
Chapter 12 Backing Up and Restoring PSAX System Files Restoring Backup Files to the Standby CPUn Module Be sure you enter the directory name (or the directory and filename if using XModem) exactly so that it matches the names you previously entered on the PSAX system XMODEM/YMODEM File Transfer window.
Page 532: Rebooting The Psax System
Chapter 12 Backing Up and Restoring PSAX System Files Rebooting the PSAX System Table 12-7. Connecting a Cable to the Standby (Backup) CPU Module If you are using... do the following: a redundant modem kit set up the switching modem to establish a connection with the standby CPU2 module.
Page 533: Upgrading Psax System Software
Upgrading PSAX System Software Overview of This Chapter This chapter describes how to upgrade the PSAX system software and firmware. Before You Begin Be sure to read the Release Note for Release 9.0.0 Controlled Introduction of the PacketStar PSAX 4500, PSAX 2300, PSAX 1250, and PSAX 1000 Multiservice Media Gateways before beginning the PSAX system software upgrade.
Page 534: Choosing The System Software File Transfer Method
Chapter 13 Upgrading PSAX System Software Choosing the System Software File Transfer Method It is recommended that you periodically back up your PSAX system configu- ration database files, which reside on the system disk of the CPUn module to a remote storage medium located on a computer workstation or PC. To backup the database configuration files, select a method from Table 12-1.
Page 535: Upgrading Using The File Transfer Protocol Method
Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method CAUTION: Upgrading the software on your PSAX system might affect some aspects of its operation. See the Release Note for Release 9.0.0 of the PacketStar PSAX 4500, PSAX 2300, PSAX 1250, and PSAX 1000 Multiservice Media Gateways for more information.
Page 536 Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method Begin 1 On the Console Interface Main Menu window (see Figure 13-1), select the Software Version Configuration option. Figure 13-1. Console Interface Main Menu Window The Software Version Configuration window (see Figure 13-2) is dis- played.
Page 537: Srd Download Configuration Window
Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method 2 Select the FTP Software Release Distribution option. The SRD Download Configuration window (see Figure 13-3) is dis- played. Figure 13-3. SRD Download Configuration Window Commands The commands on the SRD Download Configuration window are described in Table 13-2.
Page 538: Field Descriptions For The Srd Download Configuration Window
Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method Table 13-3. Field Descriptions for the SRD Download Configuration Window Field Name Field Values Description IP Address Default: 000.000.000.000 Specifies the IP address of the computer that contains the CD-ROM drive and is Range: N/A running the FTP client.
Page 539: Error Status Code Values For The [Error Status] Field On The Srd Download Configuration Window
Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method Table 13-3. Field Descriptions for the SRD Download Configuration Window (Continued) Field Name Field Values Description [Copy Status] Default: NoActivity Displays the status of the file copying during the FTP download.
Page 540 Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method Table 13-4. Error Status Code Values for the [Error Status] Field on the SRD Download Configuration Window (Continued) Field Value Description FailureToRemoveNextTree Displayed when the directory containing an earlier software release could not be removed, for example, the disk drive failed.
Page 541 Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method Table 13-4. Error Status Code Values for the [Error Status] Field on the SRD Download Configuration Window (Continued) Field Value Description UnableToMakeFtpConnec- Displayed when the PSAX system cannot make a connection to tion the host workstation running the FTP server software.
Page 542: Upgrading The Psax System Software
Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method Upgrading the PSAX System Software To upgrade your PSAX system software to Release 9.0.0 from an earlier release, perform the steps in the following procedures. Begin 1 On the SRD Download Configuration window, select the Go Back to Version Configuration command.
Page 543: Saving Your System Configuration Before System Upgrade
Chapter 13 Upgrading PSAX System Software Upgrading Using the File Transfer Protocol Method The migration of system software libraries and the database during the soft- ware upgrade process is shown in Figure 13-4. Software Upgrade Process FTP File Transfer Process (Second Stage) (First Stage) Fallback Directory...
Page 544: Module Led Indicators During Booting
Chapter 13 Upgrading PSAX System Software Module LED Indicators During Booting Table 13-6. Determining Whether to Save Your Current System Configuration Before Upgrade If you... do the following: The system... do not want to pro- type N (for no). displays the following message: ceed with an Please save the configuration files from the unsaved configura-...
Page 545: System Events During Booting
Chapter 13 Upgrading PSAX System Software System Events During Booting In a redundant PSAX system, when a standby (backup) CPUn module boots, its red LED is lighted. At the time the PSAX system is initializing, the red LED begins to blink. After the configuration manager has determined that this CPUn module is to become the standby CPUn module, a handshake between the two CPUn modules takes place, and the configuration database files on the primary CPUn module are transferred to the standby CPUn module.
Page 546: Length Of Time Required For Firmware Downloading
Chapter 13 Upgrading PSAX System Software Verifying Successful Downloading of Module Firmware Drivers Table 13-7. Length of Time Required for Firmware Downloading If you are upgrading a... then wait the following period of time for the firmware drivers to download... PSAX 1000, PSAX 1250, or 5 minutes per Stratum 3–4 module PSAX 2300 system...
Page 547: Upgrading Using The Xmodem/Ymodem File Transfer Method
Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method b On the Equipment Configuration window, verify that PSAX system software version to which you just upgraded is displayed in the SW Version field. Be sure to view page 2 of the Equipment Configuration window (Page Down command) also to check the software version of the Stratum 3–4 module(s).
Page 548: Downloading Software Files Using Xmodem/Ymodem
Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method Begin 1 To set up the cabling and connections between the PC workstation, the local modem, and the telephone line, do one of the following as shown in Table 13-8.
Page 549 Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method The Software Version Configuration window (see Figure 13-5) is dis- played. Figure 13-5. Software Version Configuration Window (XMODEM/YMODEM File Transfer Selected) 3 On the Software Version Configuration window, select the XMODEM/YMODEM File Transfer option.
Page 550: Commands For The Xmodem/Ymodem File Transfer Window
Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method Figure 13-6. XMODEM/YMODEM File Transfer Window (Receive Options Panel Selected) Commands The commands on this window are described in Table 13-10. Table 13-10. Commands for the XMODEM/YMODEM File Transfer Window Command Function Send File...
Page 551 Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method Table 13-11. Field Descriptions for the XMODEM/YMODEM File Transfer Window Field Names Field Values Description Note: To upgrade your PSAX system software, use only the fields on the Receive Options panel.
Page 552 Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method Table 13-11. Field Descriptions for the XMODEM/YMODEM File Transfer Window (Continued) Field Names Field Values Description Filename Default: N/A Specifies the filename on the CPUn module sys- tem disk where the software upgrade files are Range: N/A received (stored).
Page 553 Chapter 13 Upgrading PSAX System Software Upgrading Using the XModem/YModem File Transfer Method Table 13-11. Field Descriptions for the XMODEM/YMODEM File Transfer Window (Continued) Field Names Field Values Description Packet Size Default: 1024 Specifies the size (in bytes) of the packet that will be transmitted in the data stream.
Page 554: Upgrading The Psax System Software
Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers 9 Repeat steps 4–8 to specify another subdirectory name (for YModem or YModem-G) or another subdirectory name and filename (for XModem) until you have transferred all files for the PSAX system software upgrade. Note: The new version of the software and the existing database files are now resident in the directory /scsi/next/ (see Figure 13-4).
Page 555: Accessing The Firmware Version Control Window
Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers A firmware driver is a binary file used to initialize (boot) an I/O or a server module. The two types of drivers are the default driver and a nondefault (configurable) driver.
Page 556: Selecting A Firmware Driver
Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers Figure 13-8. The Software Version Configuration Window (Firmware Version Control Selected) Selecting a Firmware Driver To select a firmware driver different from the default driver, or to reselect the default driver on a module that is currently using a nondefault driver, per- form the steps in the following procedure.
Page 557 Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers Table 13-12. Selecting Firmware Drivers If you... do the following: select the default driver, Install any I/O or server module into the PSAX chassis slot. select a nondefault Install only the particular I/O or server module driver, that is meant for this driver into the PSAX chassis...
Page 558: Firmware Version Control Window
Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers Figure 13-9. Firmware Version Control Window Commands The commands on this window are described in Table 13-13. Table 13-13. Commands for the Firmware Version Control Window Command Function Update Screen...
Page 559 Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers Table 13-14. Field Descriptions for the Firmware Version Control Window Field Name Field Values Description Slot Default: N/A Displays the chassis slot in which the I/O, server, or Stratum3–4 module is installed.
Page 560 Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers Table 13-14. Field Descriptions for the Firmware Version Control Window (Continued) Field Name Field Values Description Status Default: N/A Displays the status of the firmware downloading after you select the Start Upgrade command.
Page 561: Downloading A Firmware Driver
Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers Table 13-14. Field Descriptions for the Firmware Version Control Window (Continued) Field Name Field Values Description NextVersion Default: N/A Displays the version of the firmware you select to download to the module.
Page 562 Chapter 13 Upgrading PSAX System Software Manually Selecting I/O and Server Module Firmware Drivers The Equipment Configuration window is displayed. Updated infor- mation in the SW Version field is displayed for the newly updated module. A confirmation message is displayed in the status line at the bottom of the window.
Page 563: Common Equipment Module Connections
Common Equipment Module Connections Overview of This Appendix This appendix describes the connector pin assignments for the common equipment modules installed in the PSAX 2300 chassis. CPU4 Module Connectors CONSOLE Connector connector on the CPU4 module accepts an RJ-12 connector. CONSOLE Pin assignments for the connector are listed in Table A-1.
Page 564: Cpu2 Module Connectors
Appendix A Common Equipment Module Connections CPU2 Module Connectors Table A-2. CPU4 Module ETHERNET1 and ETHERNET2 Connector Pin Assignments Description TD+ (CPU4 transmit+) TD– (CPU4 transmit–) RD+ (CPU4 receive+) Reserved Reserved RD– (CPU4 receive–) Reserved Reserved CPU2 Module Connectors CONSOLE Connector connector on the CPU2 module accepts an RJ-12 connector.
Page 565: Console Cable Adapters
Appendix A Common Equipment Module Connections Console Cable Adapters The CPU2 module ETHERNET connector does not follow the standard Ether- net wiring configuration. Under normal operation, you can only control the system from either the connector or the connector when CONSOLE ETHERNET you use a standard 8-wire Ethernet cable.
Page 566: Stratum 3-4 Connector
Appendix A Common Equipment Module Connections Stratum 3–4 Connector Stratum 3–4 Connector The composite clock signal is a balanced signal, which is transmitted over a shielded twisted pair cable. The cable shield is grounded at the composite clock source. Table A-7 describes the pin assignments for the faceplate RJ-45 connector on the Stratum 3–4 module.
Page 567: Alarm Cable With 26-Pin Connector And Pigtail
Appendix A Common Equipment Module Connections Alarm Module Connectors A shielded 3.7-meter (12-foot) Lucent cable (Part Number 42-20N79004, COMCODE 300164290) is available with a matching connector on one end and a 16-pair twisted wire pigtail on the other end (see Figure A-4). Figure A-4.
Page 568: Status/Control Connector
Appendix A Common Equipment Module Connections Alarm Module Connectors Table A-8. ALARM Connector Pin Assignments and Cable Pigtail Color Code (COMCODE 300164290) (Continued) Connector Description Cable Pigtail Color Code Visible Minor Alarm COM contact Blue/White Visible Minor Alarm NC contact Green/White Visible Minor Alarm NO contact White/Blue...
Page 569: Status/Control Cable With 44-Pin Connector And Pigtail
Appendix A Common Equipment Module Connections Alarm Module Connectors Figure A-6. STATUS/CONTROL Cable with 44-Pin Connector and Pigtail The pin assignments for the connector and the shielded STATUS/CONTROL Lucent cable pigtail color code are described in Table A-9. Table A-9. STATUS/CONTROL Connector Pin Assignments and Cable Pigtail Color Code (COMCODE 300164282) Connector Description...
Page 570 Appendix A Common Equipment Module Connections Alarm Module Connectors Table A-9. STATUS/CONTROL Connector Pin Assignments and Cable Pigtail Color Code (COMCODE 300164282) (Continued) Connector Description Cable Pigtail Color Code Status Input 07 White/Blue Battery Return Blue/White Status Input 08 White/Violet Battery Return Violet/White Status Input 09...
Page 571: Configuring In-Band Management
Configuring In-Band Management Overview of In-Band Management Configurations Three types of in-band management configurations are available: • Direct connection (see “Using the Direct Connection Configuration” on page B-2) The management host connects over an ATM WAN directly to an I/O module port in a remote managed target (the PSAX system being man- aged).
Page 572: Using The Direct Connection Configuration
Appendix B Configuring In-Band Management Using the Direct Connection Configuration Using the Direct Connection Configuration The default gateway through the in-band network can be configured on all Multiservice Media Gateway with the IP address of the NMS machine, or network router, if used in place of an NMS station (see Figure B-1). Node E PSAX ATM PVC Connections...
Page 573: Setting Up Atm Arp Table Entries
Appendix B Configuring In-Band Management Using the Direct Connection Configuration ifconfig fa0 forecard_Ip_Address netmask Netmask broadcast Bcast_address mtu Mtu_Size up where, forecard_Ip_Address = the IP address of the FORE card (for example, 136.242.140.222) Netmask = the IP subnet mask (for example, 255.255.255.0) Bcast_address = the IP address of the broadcast server (for example, 136.242.140.255) Mtu_Size = maximum transfer unit size [packet size] (for example,...
Page 574: Using The Routed Connection Configuration
Appendix B Configuring In-Band Management Using the Routed Connection Configuration 2 All the remote PSAX systems’ in-band interface IP addresses may or may not be in the same subnet as that of the FORE card’s IP address. 3 If the remote PSAX systems’ in-band interface IP address is not in the same subnet as that of the FORE card’s IP address, then a route entry should be added on the SUN machine for the remote PSAX systems’...
Page 575: Setting Up Connections For A Routed Connection Configuration
Appendix B Configuring In-Band Management Using the Routed Connection Configuration Node E PSAX PSAX PSAX Node C Intermediate PSAX Router PSAX ATM PVC Node B Connections Intermediate PSAX Router PSAX Node D PSAX PSAX Node A PSAX Main Router PSAX Ethernet or ATM PSAX PVC Connections...
Page 576: Setting Pvc Connections For Routed Connection Configuration
Appendix B Configuring In-Band Management Using the Routed Connection Configuration 3 On the PSAX system, the in-band management interface (primary) should be assigned an IP address that should be on a different network than that of its Ethernet interface. 4 Also, for all the PSAX system models (except the main router PSAX sys- tem), the Ethernet interface IP network should be different from the SUN machine’s Ethernet interface IP network.
Page 577 Appendix B Configuring In-Band Management Using the Routed Connection Configuration Begin 1 Configure the primary IP address for in-band management on the CPUn module of the main router PSAX system (Node A) using the console interface: Select the Site Specific Configuration> In-Band Management menu options.
Page 578 Appendix B Configuring In-Band Management Using the Routed Connection Configuration 5 Configure the primary IP Address for in-band management on the CPUn module of the main router PSAX system (Node E) using the console interface: Select the Site Specific Configuration> In-Band Management menu options.
Page 579 Appendix B Configuring In-Band Management Using the Routed Connection Configuration Port: 1 VCI: VCIax IP Mask: 255.255.000.000 Channel: 1 10 Set up in-band management connections on the CPUn module of Node B: Example: Slot: Slot Number VPI: VPIabIP Address: NMS net. addr Port: 1 VCI: VCIab IP Mask: NMS net.
Page 580: Using The Hybrid Connection Configuration
Appendix B Configuring In-Band Management Using the Hybrid Connection Configuration Using the Hybrid Connection Configuration The main router PSAX system (Node A) has two or more connections to remote PSAX systems that are in the same in-band subnet as the Node A PSAX system.
Page 581 Appendix B Configuring In-Band Management Using the Hybrid Connection Configuration 2 In this configuration, only one PSAX system can act as the router to channel traffic from Ethernet to the in-band network. This is the main router PSAX system. The main router PSAX system has direct ATM con- nections to all remote PSAX systems.
Page 582 Appendix B Configuring In-Band Management Using the Hybrid Connection Configuration Example: Primary IP Address: 020.001.001.001 Primary IP Mask: 255.000.000.000 2 Configure the primary and backup IP Address for in-band management on the CPUn module of the intermediate router PSAX system (Node B) using the console interface: Example: Primary IP Address: 020.001.001.2...
Page 583 Appendix B Configuring In-Band Management Using the Hybrid Connection Configuration Slot: Slot Number VPI: VPIac IP Address: 020.001.001.003 Port: 1 VCI: VCIac IP Mask: 255.000.000.000 Channel: 1 Slot: Slot Number VPI: VPIad IP Address: 020.001.001.004 Port: 1 VCI: VCIad IP Mask: 255.000.000.000 Channel: 1 Slot: Slot Number VPI: VPIae IP Address: 020.001.001.005 Port: 1 VCI: VCIae IP Mask: 255.000.000.000...
Page 584 Appendix B Configuring In-Band Management Using the Hybrid Connection Configuration ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 B-14 255-700-447...
Page 585: Reference Information
Reference Information Overview of This Appendix This appendix contains reference information that is helpful while configur- ing your PSAX system. The following types of information are provided: • ATM traffic descriptors • DSP Tone Detection Modes • DSP Channel Reduction Availability Due to Fax Relay Mod •...
Page 586: Types Of Traffic Descriptors
Appendix C Reference Information ATM Traffic Descriptors Types of Traffic Descriptors The types of ATM traffic descriptors supported in the PSAX system are as fol- lows: • Best effort (Best-effort) This traffic descriptor allows the system to attempt to send all cells in a “best effort”...
Page 587: Traffic Shaping Priorities By Configured Feature On Psax Modules
Appendix C Reference Information ATM Traffic Descriptors ~ When the connection is configured for variable bit rate (VBR) traffic, the PSAX system tags all CLP=0 cells violating the value set for the SCR to CLP=1 in bucket 2. ~ When the connection is configured for constant bit rate (CBR) traffic, the PSAX system tags all CLP=0 cells violating the value set for the PCR to CLP=1 in bucket 2.
Page 588: Spvc Connection Cause Codes For Connection Retry
Appendix C Reference Information SPVC Connection Cause Codes for Connection Retry Table C-1. Traffic Processing Options and Priority Queuing for Modules Supporting ATM Interfaces Interport Ingress Traffic Egress Traffic Processing ATM Interface Modules Shared Processing Priority † Priority Queuing † Buffer Queuing 23N34...
Page 589: Connection Release Cause Codes For Spvcs
Appendix C Reference Information SPVC Connection Cause Codes for Connection Retry equipment at the far (remote) end, the PSAX system will try to establish the connection again up to the number of times specified in the Retry Limit field on the SPVC connection configuration windows. The ATM Forum UNI and Frame Relay Forum FRF.4 standards use many (but not all) of the same release cause codes, and these standards reference ITU-T standards for many of the release cause codes.
Page 590 Appendix C Reference Information SPVC Connection Cause Codes for Connection Retry Table C-2. Connection Release Cause Codes for SPVCs (Continued) Release Prompts Referenced Cause Description a Retry Standard Code Number format is not valid (address incomplete). The called ITU-T Q.850 party is unreachable because the number of the called party is not in the proper format or it is not complete.
Page 591 Appendix C Reference Information SPVC Connection Cause Codes for Connection Retry Table C-2. Connection Release Cause Codes for SPVCs (Continued) Release Prompts Referenced Cause Description a Retry Standard Code Service or option is unavailable or unspecified. A service or ITU-T Q.850 option is unavailable, and no other cause code exists to report this event.
Page 592 Appendix C Reference Information SPVC Connection Cause Codes for Connection Retry Table C-2. Connection Release Cause Codes for SPVCs (Continued) Release Prompts Referenced Cause Description a Retry Standard Code Message type is nonexistent or not implemented. The equip- ITU-T Q.850 ment sending the cause code received one of the following message types: •...
Page 593: Dsp Tone Detection Modes
Appendix C Reference Information DSP Tone Detection Modes DSP Tone Detection Modes DSP tone detection modes are selected through the Circuit Emulation-to- ATM VCC PVC Connection . These modes are described in Table C-3. window Table C-3. DSP Tone Detection Modes and Associated Processing Performed Tone Mode Processing Performed...
Page 594: Industry Compliance Specifications
Appendix C Reference Information Industry Compliance Specifications For every fax transmission call, both the originally assigned DSP resource, plus the fax relay DSP resource, are consumed for the duration of the call. Thus, the total remaining DSP connections is reduced by twice the number of con- nections using fax mode service.
Page 595 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes Channelized DS3, Channelized af-pnni-0026.000 STS-1e, DS1 IMA, DS3 IMA, E1 Interim Inter-Switch Signaling IMA, DS3 ATM, E3 ATM, Protocol (IISP) Enhanced DS1, Enhanced E1,High-Density E1, High Speed, Medium-Density DS1, OC-3c MM/SM APS, STM-1...
Page 596 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes Traffic Management (UPC Sup- af-tm-0121.000 Route Server-to-ATM Inter- port) working: Section 5.5 Traffic Management, Usage Route Server-to-ATM Inter- Parameter Control working Channelized DS3, Channelized af-uni-0010.001 STS-1e, DS1 IMA, DS3 IMA, E1...
Page 597 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes Channelized DS3, Channelized af-vtoa-0085.000 STS-1e, Enhanced DS1, and (DBCES) Dynamic Bandwith DSP2x Voice Server modules Utilization in 64 Kbps Time Slot Trunking Over ATM—Using Cir- cuit Emulation Service (CES) •...
Page 598 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes GR-303 DLC Services ANSI T1.401 Interface Between Carriers and Customer Installations- Analog Voice Grade Switched Access Lines Using Loops-start and Ground-start Signaling CSU/DSU loopback ANSI T1.403 Facsimile Demodula-...
Page 599 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes DS3 Frame Relay module CCITT G.704 Synchronous Frame Structures Used at Primary and Secondary Hierarchical Levels DSL Forum TR 017 ATM over ADSL Recommenda- tions Multiserial and Quadserial mod- EIA-232...
Page 600 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes V5.2 ETSI 300 347-1 ITU-T G. 964 and G.965 are functionally equivalent to ETSI V5.2 Interface for the Support of EN 300 324-1 and ETSI EN 300 Access Network (AN) Part 1: 347-1 respectively.
Page 601 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes In-band Management FRF.8 Channelized DS3, Channelized Frame Relay ATM/PVC Service STS-1e, DS3 Frame Relay, Internetworking Implementa- Enhanced DS1, Enhanced E1, tion Agreement High-Density E1, Medium-Den- sity DS1, Multiserial, Quadserial, and Route Server modules...
Page 602 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes D4 Support Stratum DS1 BITS GR-518-CORE Stratum: Does not include the Interfaces ANSI T1.101-compliant Stra- LSSGR: Synchronization, Sec- tum 3–4 module, COMCODE Stratum 3–4 modules tion 18 108484890...
Page 603 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes OC-3c APS modules SR-NWT-001756 Automatic Protection Switching for SONET, issue 1, October 1990 I.610 OAM F4/F5 Processing TR-NWT-00170 (remote defect indication [RDI] Bellcore Digital Cross-Connect and alarm indication signal System Generic Requirements...
Page 604 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes Route Server module IETF RFC 1490 IETF RFC 1490 was replaced by IETF RFC 2427 Multiprotocol Interconnect over Frame Relay IETF RFC 1595 Definitions of Managed Objects for the SONET/SDH Interface Types...
Page 605 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes Ethernet Bridging IETF RFC 2684 Obsoletes RFC 1483 4-Port Ethernet, Ethernet, Multiprotocol Encapsulation RFC 2685 (VPN identification) Enhanced Router, and Route over ATM Adaptation Layer 5 not supported Server modules...
Page 606 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes 1-Port Chan OC-3/STM-1 ITU-T G.707 Unstruct. CES/ATM MM/SM Transmission Systems and modules. Media—Digital transmission sys- tems— Terminal equipment— General: Network node interface for the synchronous digital hier- archy (SDH) DSP2A/B/C/D Voice Server...
Page 607 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes PSAX 1000, PSAX 1250, ITU-T G.783 PSAX 2300, and PSAX 4500 Transmission Systems and Multiservice Media Gateways. Media, Digital Systems and Net- 1-Port Chan OC-3/STM-1 works—...
Page 608 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes STM-4c module ITU-T G.841, Annex A Types and Characteristics of SDH Network Protection Architecture Issue 10/98 Intra-office and short haul ITU-T G.957 Long haul not supported Optical interfaces for equipment and systems relating to the syn-...
Page 609 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes ITU-T I.150 B-ISDN ATM Functional charac- teristics Enhanced DS1 and Enhanced ITU-T I.233 E1 modules Frame Mode Bearer Services ITU-T I.321 Integrated Services Digital Net- work (ISDN) Overall Network Aspects and Functions, ISDN...
Page 610 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes Facsimile Demodula- ITU-T I.366.2 Annex M tion/Remodulation AAL Type 2 Specification on VTOA AAL2 Trunking Narrow- Convergence Sublayer for Nar- band Services row-band Services.
Page 611 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes 1-Port Chan OC-3/STM-1 ITU-T I.432.2 Unstruct. CES/ATM MM/SM B-ISDN User-Network- Physical modules. Layer Specification: 155 520 Kbps and 622 080 Kbps opera- tion ITU-T I.432.3 B-ISDN User-Network Inter-...
Page 612 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes AAL1 Trunking CCS (Q.931) ITU-T Q.931 AAL1 Trunking CCS Switching and Signaling - Digital (Q.931/QSIG), AAL1 Trunking subscriber Signalling System No. 1 - Network layer: Digital Sub- scriber Signaling System No.
Page 613 Appendix C Reference Information Industry Compliance Specifications Table C-5. Industry Compliance Specifications (Continued) Feature Name/Product Name Specification Title Notes ITU-T Q.2971 B-ISDN—DSS 2—User-network interface layer 3 specification for point-to-multipoint call/connec- tion control ITU-T V.8 Procedures For Starting Ses- sions of Data Transmission Over the General Switched Telephone Network ITU-T V.25...
Page 614: Connection Type By Interface Type
Appendix C Reference Information Connection Type by Interface Type Connection Type by Interface Type ® The PacketStar PSAX Multiservice Media Gateways provide a number of connection types and interface types to the network as described in ® Table C-6. Configuring connections are described in the PacketStar PSAX Sys- tem Connections Provisioning Guide that can be found on the PacketStar PSAX Multiservice Media Gateways Product Information Library CD-ROM.
Page 615: Interface Type By Input/Output Module Type
Appendix C Reference Information Interface Type by Input/Output Module Type Table C-6. Connection Type by Interface Type (Continued) Interface Type Connection Type Frame relay-ATM VCC SPVC VBR-to-ATM VCC SPVC VBR-to-ATM Std AAL2 VCC SPVC Interface Type by Input/Output Module Type Table C-7 shows the available interface types for each PacketStar PSAX I/O ®...
Page 616 Appendix C Reference Information Interface Type by Input/Output Module Type Table C-7. Interface Type by I/O Module Type (Continued) Interface Module 23N35 24-Port High- Density DS1 Multiservice 23N69 8-Port HDSL-2 E1 Interface Modules 20N34 6-Port E1 IMA 20N56 6-Port Enhanced E1 Multiservice 23N66 21-Port High-...
Page 617 Appendix C Reference Information Interface Type by Input/Output Module Type Table C-7. Interface Type by I/O Module Type (Continued) Interface Module 23N02 3-Port Unstructured DS3/E3 CES OC-3/STM-1/OC-3c/STM-1 Interface Modules 23N12 1-Port Channelized OC-3/STM-1 CES Multimode 23N13 1-Port Channelized OC-3/STM-1 CES Single-mode ¶...
Page 618 Appendix C Reference Information Interface Type by Input/Output Module Type Table C-7. Interface Type by I/O Module Type (Continued) Interface Module 20N15 1-Port OC-3c Single-Mode with Traffic Shaping 20N72 1-Port OC-3c 1+1 APS Multimode 20N73 1-Port OC-3c 1+1 APS Single-Mode STM-1 Interface Only Modules 20N62 1-Port STM-1...
Page 619: Atm Service Categories In The Psax System
Appendix C Reference Information ATM Service Categories in the PSAX System Table C-7. Interface Type by I/O Module Type (Continued) Interface Module Serial Interface Modules 23N07 Quadserial 20N07 6-Port Multiserial Ethernet Interface Modules 20N40 Ethernet 23N40 4-Port Ethernet The module supports CAS Trunkline in DS1 and E1 modes only. †...
Page 620: Priority Of Atm Service Categories
Appendix C Reference Information ATM Service Categories in the PSAX System Table C-8. PSAX System-Supported Quality of Service Category Descriptions (Continued) ATM Service Category Description Non-Real Time Variable Bit This service allows delay variance between the delivery of cells. VBR- Rate (VBR-nrt) nrt is used for data applications that have potentially bursty traffic characteristics.
Page 621: Traffic Shaping, Upc, And Virtual Interface Configuration Compatibilities
Appendix C Reference Information Traffic Shaping, UPC, and Virtual Interface Configuration Compatibilities Table C-9. Mapping ATM Service Categories to PSAX System Priority Levels (Continued) ATM Forum Traffic Connection AQueMan Priority Management 4.1 ATM Service Category Configuration (Legacy Service Examples Priority (Current Field Value Implementation) Implementation)
Page 622: Combining The Upc Feature And Either The Ts Or Vi Feature On A Connection
Appendix C Reference Information Traffic Shaping, UPC, and Virtual Interface Configuration Compatibilities I/O Module 1 Ingress Path VI or TS Egress Path Chassis Backplane I/O Module 2 Ingress Path VI or TS Egress Path Figure C-1. Combining the UPC Feature and Either the TS or VI Feature on a Connection ATM Traffic Shaping Sample CPS...
Page 623 Appendix C Reference Information Traffic Shaping, UPC, and Virtual Interface Configuration Compatibilities Table C-11. ATM Traffic Shaping CPS Calculation Table (Continued) Actual Rate (in Minimum/Actual Maximum Target Actual CPS bps) Target CPS 767,999 1,811 1,822 1,811 831,999 1,962 1,974 1,962 896,765 2,115 2,129...
Page 624 Appendix C Reference Information Traffic Shaping, UPC, and Virtual Interface Configuration Compatibilities Table C-11. ATM Traffic Shaping CPS Calculation Table (Continued) Actual Rate (in Minimum/Actual Maximum Target Actual CPS bps) Target CPS 2,377,139 5,606 5,698 5,606 2,415,480 5,697 5,791 5,697 2,455,078 5,790 5,888...
Page 625: Psax I/O Module Transmit Clock Options
Appendix C Reference Information PSAX I/O Module Transmit Clock Options Table C-11. ATM Traffic Shaping CPS Calculation Table (Continued) Actual Rate (in Minimum/Actual Maximum Target Actual CPS bps) Target CPS 5,759,991 13,585 14,129 13,585 5,990,391 14,128 14,718 14,128 6,239,990 14,717 15,358 14,717 6,511,294...
Page 626 Appendix C Reference Information PSAX I/O Module Transmit Clock Options Table C-12. I/O Module Transmit Clock Options (Continued) Local Loop Adaptive Model Number and Module Name SRTS Timing Timing Timing 24N64 12-Port Medium-Density DS1/E1/DS0A CES § ¶ 23N35 24-Port High-Density DS1 Multiservice 23N69 8-Port HDSL-2 E1 Interface Modules...
Page 627 Appendix C Reference Information PSAX I/O Module Transmit Clock Options Table C-12. I/O Module Transmit Clock Options (Continued) Local Loop Adaptive Model Number and Module Name SRTS Timing Timing Timing 20N92 1-Port STM-1 1+1 MSP Multimode 20N93 1-Port STM-1 1+1 MSP Single-Mode 23N72 1-Port OC-12c/STM-4c Multimode 23N73...
Page 628 Appendix C Reference Information PSAX I/O Module Transmit Clock Options ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 C-44 255-700-447...
Page 629: Psax Module Features
PSAX Module Features Overview of This Appendix This appendix describes the PSAX I/O and server modules that are supported by the PSAX 2300 chassis. The PacketStar PSAX I/O and server modules described in this appendix are also listed in Table D-1. Table D-1.
Page 630 Appendix D PSAX Module Features Overview of This Appendix Table D-1. PacketStar PSAX Multiservice Media Gateway Modules (Continued) Model No. Product Name E1 Interface Modules 20N34 6-Port E1 IMA 20N56 6-Port Enhanced E1 Multiservice 23N34 21-Port High-Density E1 IMA 23N66 21-Port High-Density E1 Multiservice Ethernet Interface Modules 23N40...
Page 631: Ds1/T1 Interface Modules
Appendix D PSAX Module Features DS1/T1 Interface Modules Table D-1. PacketStar PSAX Multiservice Media Gateway Modules (Continued) Model No. Product Name 20N07 6-Port Multiserial 23N07 Quadserial Voice 2-Wire Interface Modules 20N32 4-Port Voice 2-Wire Office 20N30 8-Port Voice 2-Wire Station DS1/T1 Interface Modules 6-Port DS1 IMA Module (20N33) The 6-Port DS1 IMA module has six physical RJ-45 ports.
Page 632: 6-Port Enhanced Ds1/T1 Module (20N36
Appendix D PSAX Module Features DS1/T1 Interface Modules 6-Port Enhanced DS1/T1 Module (20N36) The 6-Port Enhanced DS1/T1 Multiservice module provides six ports, each with a line rate of 1.544 Mbps. The interfaces support American National Stan- dards Institute (ANSI) T1.403, af-phy-0016.000 and af-test-0037.000. Each port can be independently configured to provide services for channelized and unchannelized frame relay configurations, circuit emulation service, dynamic bandwidth circuit emulation service, and ATM service.
Page 633: Hardware Features
Appendix D PSAX Module Features DS1/T1 Interface Modules • ITU-T I.370 (Frame relay policing) • Congestion management • Traffic policing Hardware Features The 6-Port Enhanced DS1/T1 Multiservice module has the following hard- ware features: • Number of ports: 6 • Connector type: RJ-45 •...
Page 634: Software Features
Appendix D PSAX Module Features DS1/T1 Interface Modules Software Features The 8-Port HDSL-2 module supports the following services: • ATM: ATM UNI 3.0, 3.1, and 4.0; Interim inter-switch signaling protocol (IISP) user, IISP network; PNNI 1.0, all with traffic shaping •...
Page 635: Hardware Features
Appendix D PSAX Module Features DS1/T1 Interface Modules Hardware Features The 12-Port Medium-Density DS1 IMA module provides the following hard- ware features: • Number of ports: 12 • Connector type: one Mini-Champ connector that mates with the AMP cable #1324936-1 •...
Page 636: Hardware Features
Appendix D PSAX Module Features DS1/T1 Interface Modules • GR-303 • CAS Trunkline • ITU-T I.370 (Frame relay policing) • Congestion management • Traffic policing Hardware Features The 12-Port Medium-Density DS1 Multiservice module provides the follow- ing hardware features: • Number of ports: 12 •...
Page 637: Hardware Features
Appendix D PSAX Module Features DS1/T1 Interface Modules ~ Channel-associated signaling (CAS) Nx64 ~ Dynamic Bandwidth Allocation (DBA) • Integrated services digital network with primary rate interface service (PRI ISDN) with 64 Kbps clear channel capability for the D-channel • AAL2 cell formatting for interworking with the DSP2A, DSP2B, DSP2C, and DSP2D Voice Server modules.
Page 638: 24-Port High-Density Ds1 Multiservice Module (23N35
Appendix D PSAX Module Features DS1/T1 Interface Modules ~ DS0A: line loopback, transmit pattern, monitor pattern mode, transmit and monitor pattern mode • Line buildout: ~ DS1: up to 133, 266, 399, 533, and 655 feet; -7dB through -5dB, -15dB, and -22dB through -5dB ~ E1: N/A ~ DS0A: up to 1500 feet...
Page 639 Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules • CE: Circuit emulation service (CES) with ISDN PRI using 64 Kbps clear channel; 1x64 Kbps structured CAS; Nx64 Kbps structured CCS; unstruc- tured CES • HDLC passthrough mode (Nx56 and Nx64) with bit inversion •...
Page 640: Hardware Features
Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules work interface to an ATM network. The module can be configured to provide N x 64 Kbps (fractional DS1) structured circuit emulation service. When con- figured for DS1 circuit emulation service, the module interfaces with TDM channelized DS1 circuits.
Page 641 Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules • Line type: C-bit parity, M13 • Loopback capability: local loop, line loop • Transmit clock: local timing, loop timing • Line buildout: short (0–133 feet), long (134–266) 3-Port Channelized DS3/STS-1e CES Module (23N03) The 3-Port Channelized DS3/STS-1e CES module supports circuit emulation services (CES) and primary rate interfaces (PRI) with processing power ×...
Page 642: Software Features
Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules between PSAX central office (CO) products and customer premises equip- ment (CPE) products at the edge of an ATM network. The PSAX system also generates alarm indication signals on all affected DS1 connections whenever a loop is activated.
Page 643: Software Features
Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules 1-Port Channelized STS-1e, T1 Module (23N62) The 1-Port Channelized STS-1e, T1 Format module provides one physical port with a line rate of 51.84 Mbps. The physical port is divided (channel- ized) into 28 virtual DS1 ports.
Page 644: Hardware Features
Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules ~ Frame relay UNI and NNI (FRF.1, FRF.2, FRF.5, and FRF.8) ~ ITU-T I.370 (frame relay policing) ~ Congestion management ~ Traffic policing Hardware Features The 1-Port Channelized STS-1e, T1 Format module has the following hard- ware features: •...
Page 645: Hardware Features
Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules 1-Port Unchannelized DS3 Frame Relay Module (20N03) The 1-Port Unchannelized DS3 Frame Relay module provides an unchannel- ized, high-speed frame relay network interface at digital signal level 3 (DS3), with a line rate of 44.736 Mbps.
Page 646: Hardware Features
Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules 1-Port DS3 IMA Module (23N68) The 1-Port DS3 IMA (Inverse Multiplexing over ATM) module combines the features of the 1-Port Channelized DS3 Multiservice module (see the Packet- ® Star PSAX 1-Port Channelized DS3 Multiservice Module User Guide) and the 6- ®...
Page 647 Appendix D PSAX Module Features DS3, E3, and STS-1e Interface Modules • Line rate: 34.368 Mbps (typical) • Line encoding mode: HDB3 • Line type: G832 • Loopback capabilities: local loop, line loop, payload loop • Cell mapping: direct mapping 3-Port Unstructured DS3/E3 CES Module (23N02) The 3-Port Unstructured DS3/E3 CES module provides a clear channel, high- speed circuit emulation network interface at Digital Signal Level 3 (DS3),...
Page 648 Appendix D PSAX Module Features DSP2 Voice Servers DSP2 Voice Servers DSP2x Voice Server Modules (23N27 (C), 23N29 (D), 23N26 (E), and 23N25 (F)) The DSP2x Voice Server modules Series C through F process voice and other digital data on a PSAX system to provide any or all of the following features to selected DS0 channels: toll quality voice compression, echo cancellation, silence suppression, comfort noise insertion, fax demodulation/remodula- tion, and Packet Pipe AAL5-to-AAL2 Wireless Trunking.
Page 649 Appendix D PSAX Module Features E1 Interface Modules Source data enters the module from the backplane and is divided between the ports within the IMA group specified in the virtual circuit connection. The data leaves the front of the module and is transported across individual E1 lines.
Page 650 Appendix D PSAX Module Features E1 Interface Modules The interfaces support ITU-T G.703 and ITU G.704. The module uses ATM Forum Specification UNI 3.0 or UNI 3.1, which allows the E1 port to act as a user-network interface (UNI), an interim interswitch protocol (IISP) user or IISP network interface to an ATM network.
Page 651 Appendix D PSAX Module Features E1 Interface Modules 21-Port High-Density E1 IMA Module (23N34) The 21-Port High-Density E1 IMA module provides a line rate of 2.048 Mbps per port. The module’s inverse multiplexing for ATM capabilities permit a user to strap 2 to 21 of the physical ports together to create ATM interfaces that support up to 43 Mbps of bandwidth.
Page 652 Appendix D PSAX Module Features E1 Interface Modules 21-Port High-Density E1 Multiservice Module (23N66) The 21-Port High-Density E1 Multiservice module provides 21 ports, each with a line rate of 2.048 Mbps. The interfaces support ITU-T G.703 and ITU G.704. Each port can be independently configured to provide services for channelized and unchannelized frame relay configurations, circuit emulation service, and ATM service.
Page 653 Appendix D PSAX Module Features Ethernet Interface Modules Hardware Features The 21-Port High-Density E1 Multiservice module provides the following hardware features: • Number of ports: 21 • Connector type: two Mini-Champ connectors that mate with the Lucent cable (COMCODE 300550639) •...
Page 654 Appendix D PSAX Module Features Ethernet Interface Modules • LLC and VC Encapsulation • Multicasting • Spanning Tree algorithm (IEEE 801.1 Ethernet) • Maximum number of PVC connections per module: 120 Hardware Features The 4-Port Ethernet module provides the following hardware features: •...
Page 655 Appendix D PSAX Module Features Ethernet Interface Modules Ethernet Module (20N40) The Ethernet module provides five ports on the faceplate and a sixth virtual port. The first of these ports has the ability to autosense and operate at either 10BASE-T or 100BASE-T. The remaining four ports operate at 10BASE-T. Each of the ports can be configured independently to operate within shared or separate bridge groups.
Page 656 Appendix D PSAX Module Features Fiber-Optic Interface Modules ~ Per port: • port 1 supports 10 Mbps (10BASE-T) or 100 Mbps (100BASE-T); • ports 2, 3, 4, and 5 each support 10 Mbps ~ Aggregate bandwidth of all ports, maximum: 30 Mbps throughput •...
Page 657: 1-Port Channelized Oc-3/Stm-1 Unstructured Ces/Atm Module
Appendix D PSAX Module Features Fiber-Optic Interface Modules ~ Structured DS1 signal transport ~ Nx64 Kbps circuit emulation (where 1<=N<=24) ~ Channel-associated signaling (CAS) 1x56 • AAL2 cell formatting for interworking with the DSP2x Voice Server mod- ules. The following feature is provided with limited support by the module: •...
Page 658: Hardware Features
Appendix D PSAX Module Features Fiber-Optic Interface Modules The 1+1 APS/MSP protection is supported in either mode. The 1+1 APS/MSP linear protection architecture consists of a far-end signal that is continuously bridged (at the electrical level) to the APS working and APS protection I/O modules so that the same payloads are transmitted identically to the near- end working and protection I/O modules.
Page 659 Appendix D PSAX Module Features Fiber-Optic Interface Modules Table D-3. 1-Port Channelized OC-3/STM-1 Unstructured CES/ATM Module Optical Specifications Module Feature CH OC-3/STM-1 CH OC-3/STM-1 UNSTR/ATM SM UNSTR/ATM MM Transmitter minimum optical output power -15 dBm -20 dBm (average) Transmitter maximum optical output power -8 dBm -14 dBm (average)
Page 660: Hardware Features
Appendix D PSAX Module Features Fiber-Optic Interface Modules Software Features The modules support ATM traffic shaping, and conform to af-tm-0121.000, Traffic Management Specification 4.1 (see the appropriate PSAX module user guide for more details). Hardware Features The 4-Port OC-3c/STM-1 modules have the optical specifications shown in Table D-4.
Page 661: 1-Port Oc-3C Module With Aqueman (20N12 (Mm)/20N13 (Sm)) Or Traffic Shaping (20N14 (Mm)/20N15 (Sm
Appendix D PSAX Module Features Fiber-Optic Interface Modules • Single-mode (SM) module (23N73) is intended for long-reach applications, typically between LANs. This module is frequently used to connect high- speed LAN devices (such as routers) to an ATM network. • Multimode (MM) module (23N72) is intended for short-reach applications, for example, interoffice or intraoffice sections of a local area network (LAN).
Page 662: Software Features
Appendix D PSAX Module Features Fiber-Optic Interface Modules • Multimode (MM) module (20N12/20N14) is intended for short-reach applications, for example, interoffice or intraoffice sections of a local area network (LAN). Software Features These modules are available in two variations, which differ according to the firmware installed in the module.
Page 663: 1-Port Oc-3C 1+1 Aps Module (20N72 (Mm)/20N73 (Sm
Appendix D PSAX Module Features Fiber-Optic Interface Modules 1-Port OC-3c 1+1 APS Module (20N72 (MM)/20N73 (SM)) The 1-Port OC-3c 1+1 Automatic Protection Switching (APS) modules pro- vide connection redundancy, enabling reliable data transport. These modules provide a fiber-optic interface operating in the concatenated mode of the SONET-defined line rate of 155 Mbps.
Page 664: 1-Port Stm-1 Module With Aqueman (20N62 (Mm)/20N63 (Sm)) Or
Appendix D PSAX Module Features Fiber-Optic Interface Modules 1-Port STM-1 Module with AQueMan (20N62 (MM)/20N63 (SM)) or Traffic Shaping (20N64 (MM)/20N65 (SM)) The 1-Port STM-1 with AQueMan (20N62 (MM)/20N63 (SM)) or Traffic Shaping (20N64 (MM)/20N65 (SM)) modules provide a fiber optic interface operating in the concatenated mode of the SONET-defined line rate of 155 Mbps.
Page 665 Appendix D PSAX Module Features Fiber-Optic Interface Modules Table D-8. 1-Port STM-1 Module Optical Specifications (Continued) Module Feature STM-1 (SM TS) or STM-1 (MM TS) or STM-1 (MM AQ) STM-1 (MM AQ) Fiber-optic cable reach (approximate, 15 km 2 km depending on fiber makeup) (9.3 miles) (6,560 feet or 1.2...
Page 666 Appendix D PSAX Module Features Fiber-Optic Interface Modules Hardware Features The 1-Port STM-1 1+1 MSP modules have the optical specifications shown in Table D-9. Table D-9. 1-Port STM-1 1+1 MSP Module Optical Specifications Module Feature STM-1 SM MSP STM-1 MM MSP Number of ports Type of connector (two for each module, transmit and receive)
Page 667: Software Features
Appendix D PSAX Module Features Fiber-Optic Interface Modules to select the traffic, based on switch initiation criteria. Because of the contin- uous far-end bridge, the 1+1 APS/MSP architecture does not allow an unpro- tected extra traffic channel to be provided. The modules provide connection redundancy between parallel ports on both APS/MSP-protection modules on a strict one-to-one mapping, enabling reli- able data transport.
Page 668 Appendix D PSAX Module Features Other Server Modules Other Server Modules Enhanced Router Module (23N41) The Enhanced Router module is the premier IP routing platform for the PacketStar PSAX Multiservice Media Gateway systems. In addition to support- ing existing PSAX multiservice interworking capabilities, the module pro- vides routing, aggregation, and adaptation capabilities.
Page 669: Hardware Features
Appendix D PSAX Module Features Other Server Modules • IP filtering • Interoperability with other basic routers Hardware Features The Enhanced Router module has the following hardware features: • Number of ports: 0 (server module) • IP forwarding performance of 540 Mbps simplex cell bandwidth at 64 bytes, IP packets •...
Page 670: Software Features
Appendix D PSAX Module Features Other Server Modules Release 6.3.0 software, supporting RIP v2.0, allows you to divide networks to a further extent than the traditional subnet classes (Class A, B, and C) avail- able with RIP v1.0. RIP v2.0 enables authentication and multicasting, and allows you to run different masks on different subnets.
Page 671: Channel Associated Signaling (Cas
Appendix D PSAX Module Features Other Server Modules • Maximum frame size: 1518 bytes; that is, the maximum Ethernet, frame relay, or ATM frame that can be received by the Route Server module is 1518 bytes • Maximum traffic into/out of module: 30 Mbps Tones and Announcements Server Module (23N28) The Tones and Announcements Server (TAS) module offers these tests in a switch-to-switch capacity:...
Page 672: Tones
Appendix D PSAX Module Features Serial Interface Modules ~ Wink-start, 2-way and User ~ Off-premises station (OPS) Tones • Busy tone Hardware Features The Tones and Announcements Server module has 32 digital signal processer chips. All TAS modules connect to the CPU and other modules by a back- plane connection.
Page 673: Software Features
Appendix D PSAX Module Features Serial Interface Modules configured for frame relay, circuit emulation, terminal emulation, HDLC passthrough, and asynchronous transfer mode (ATM) (using limitless ATM network [LANET] protocol). Software Features The 6-Port Multiserial module provides the following software features: •...
Page 674: Atm
Appendix D PSAX Module Features Serial Interface Modules HDLC Passthrough Each port on the 6-Port Multiserial module can be configured to perform adaptation for high-level data link control (HDLC) pass-through. Without this feature, AAL-1 adaptation would be required for data from HDLC devices connected to a port on the 6-Port Multiserial module.
Page 675: Software Features
Appendix D PSAX Module Features Serial Interface Modules mum aggregate port rate is 32 Mbps. The Quadserial interfaces support synchronous RS-232, EIA-449, EIA-530, EIA-530A, V.35 , X.21, and Kg. Each port can be independently configured as either data terminating equip- ment (DTE) or data communications equipment (DCE).
Page 676: Voice 2-Wire Interface Modules
Appendix D PSAX Module Features Voice 2-Wire Interface Modules • Line encoding mode: N/A • Loopback capabilities: line loopback and local loopback from console, Tel- net, or EMS interfaces • Line buildout: N/A • Framing modes: HDLC checksum, LANET Voice 2-Wire Interface Modules 4-Port Voice 2-Wire Office Module (20N32) The 4-Port Voice 2-Wire Office module (20N32) provides support for the office (central office or PABX switch) end of a two-wire analog telephone...
Page 677: Software Features
Appendix D PSAX Module Features Voice 2-Wire Interface Modules The module has three types of light emitting diode (LED) indicators: ACTIVE, FAIL, and LOS (loss of signal). On the faceplate, each port has a LOS LED that illuminates when the port goes off-hook. It also flashes in synchroniza- tion with an incoming ringing signal to the port.
Page 678 Appendix D PSAX Module Features Voice 2-Wire Interface Modules ® PacketStar PSAX 2300 Multiservice Media Gateway User Guide, Issue 1 Release 9.0.0 D-50 255-700-447...
