PacketStar

PSAX 6-Port DS1 IMA Module

User Guide

®

for PacketStar

PSAX Multiservice Media

Gateways

Issue 1, August 2001

System Software Release 7.0

®

AQueView

EMS Software Release 5.0

Doc. No.: 255-700-166

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the PSAX 20 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lucent Technologies PSAX 20

Page 1 ® PacketStar PSAX 6-Port DS1 IMA Module User Guide ® for PacketStar PSAX Multiservice Media Gateways Issue 1, August 2001 System Software Release 7.0 ® AQueView EMS Software Release 5.0 Doc. No.: 255-700-166...
Page 2 Copyright © 2001 by Lucent Technologies. All rights reserved. For trademark, regulatory compliance, and related legal information, see the "Copyright and Legal Notices" section.
Page 3: Copyright And Legal Notices
This material is protected by the copyright laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to Lucent Technologies), except in accordance with applicable agreements, contracts or licensing, without the express written consent of the originating organization and the business management owner of the material.
Page 4: Warranty Warnings
EMC standards when configured with the following PacketStar PSAX systems: • PSAX 20 base system, 110 V ac (models 02S00 and 02S01) • PSAX AC 60 base systems: ~ PSAX AC 60 system, 110 V ac (models 50S01 and 51S01)
Page 5: Telecommunications
PSAX chassis is a label that contains the FCC registration number, in addition to other information. You must provide this information to the telephone company, if they request it. The FCC requires Lucent Technologies to provide you with the following information: 1.
Page 6: Canadian Regulatory Statements
Regulatory Statements 6. If you experience trouble with this equipment, or need repairs or warranty information, please refer to the Lucent Technologies InterNetworking Systems Global Warranty that accompanied your PSAX product shipment for instructions on obtaining technical support in your area.
Page 7: Version 8
Copyright and Legal Notices Regulatory Statements The REN for the Voice 2-Wire Office module when used in the PSAX system is 0.7B. SH-03 Version 8 Le label Industrie Canada permet de reconnaître les équipements homologués. Cette homologation indique que l’équipement satisfait certaines règles de protection, d’exploitation et de sécurité...
Page 8 Copyright and Legal Notices Regulatory Statements The marking for the 6-Port DS1 IMA module is as follows: D00-0807 ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar viii 255-700-166...
Page 9: Safety Warnings And Information
CAUTION: Do not make electrical or mechanical modifications to any of the components in the PSAX system. Lucent Technologies is not responsible for the safety or the performance of a modified Lucent product. Do not attempt to repair any failed Power Supply module, Stratum 3–4 module, CPU module, I/O, or server module.
Page 10 Safety Warnings and Information ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 11: Table Of Contents
Related Reading ............1-1 .1-1 Lucent Technologies Information Products ....... . .1-1 .1-1 Product Information Library .
Page 12 Contents Electroststic Discharge Precautions ......... 1-6 Grounding Wrist Straps .
Page 13 Contents Copying a Port Configuration .........4-10 .4-10 Channel Configuration .
Page 14 Contents ATM IMA Interface ........... . . 6-1 Automatic Use of IMA Links .
Page 15 Contents Viewing ATM-to-ATM VCC PVC Statistics......7-12 .7-12 Adding/Viewing a Backup PVC Connection .......7-14 .7-14 Adding ATM-to-ATM VPC PVC Connections .
Page 16 Contents Creating an ATM-to-ATM VCC SPVC Connection ..... . . 7-99 7-99 Viewing Connection Statistics........7-106 7-106 Adding NSAP Addresses .
Page 17 Contents Statistics Page ..........8-30 .8-30 Polling Statistics Using the Odometer Delta .
Page 18 Contents Backup Page..........8-117 8-117 Utilization Page .
Page 19 Contents Appendix A: Pin Configurations ........A-1 Overview of This Appendix .
Page 20 Contents ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 21: Getting Started
• Data network design • Telephony network design Related Reading Lucent Technologies Information Products Product Information To install and configure your Multiservice Media Gateway system and I/O or Library server modules, read the PSAX publications provided on your Lucent ®...
Page 22: Printed Documents
For More Information ® To learn more about the PacketStar PSAX family of ATM Multiservice Media Gateways and the complete line of Lucent Technologies products, visit our Web site at www.lucent.com. ® About the PacketStar PSAX Product Family Lucent Technologies provides a complete range of PSAX Multiservice Media ®...
Page 23 This scal- Premises ability enables service providers to meet the demands of a growing enterprise customer with a single-edge solution. The PSAX 20 system is nonredundant. Supporting two slots for I/O and server modules and two factory-...
Page 24: Text Conventions
Chapter 1 Getting Started Text Conventions ® Table 1-1. PacketStar PSAX Product Family Target Market Device Name Application/Description ® Carrier-Class PSAX 2300 The PacketStar PSAX 2300 Multiservice Media Gateway offers car- Office rier-grade, high-density multiservice ATM access functions. Designed as the multiservice media gateway for the central office or for a large ®...
Page 25: Icons And Symbols
Chapter 1 Getting Started Text Conventions resemble what you see on the screens and equipment. The following table shows how each typographical convention is used. Appearance How it is used SANS SERIF BOLD, ALL CAPS Labels on module panels, chassis face- plates, or other hardware Message text displayed on the user Fixed-width normal...
Page 26: Electroststic Discharge Precautions
Chapter 1 Getting Started Electroststic Discharge Precautions Electroststic Discharge Precautions The room where the Multiservice Media Gateway system is located must have built-in precautions to provide protection from electrostatic discharge damage to electronic components. The following sections provide details on these necessary precautions.
Page 27: Clothing
Technical Support If you experience a problem with your Multiservice Media Gateway system, refer to the Lucent Technologies InterNetworking Systems Global Warranty, which accompanied your shipment, for instructions on obtaining support in your area. Comments on This Guide ®...
Page 28 Chapter 1 Getting Started Before You Begin • Carefully read the safety cautions listed in the section, “Safety Information,” at the beginning of this guide. • Record your site-specific specifications such as the IP addresses you will use, and the connections and interfaces you will need. Decide which user names and passwords you will assign.
Page 29: Module Description
Module Description Overview of This Module The 6-Port DS1 IMA module (see Figure 2-1) has six physical RJ-45 ports. Inverse multiplexing over ATM permits a user to strap two to six of the physical ports together to create ATM interfaces that support 3–9 Mbps of bandwidth.
Page 30: Software Features
Chapter 2 Module Description Software Features FAIL ACTIVE Figure 2-1. DS1 IMA Module Software Features The 6-Port DS1 IMA module offers native DS1 ATM services and DS1 IMA services, including permanent virtual circuits, soft permanent virtual circuits, and switched virtual circuits. The module supports UNI v3.a, IISP, PNNI, and ILMI.
Page 31: Hardware Features
Chapter 2 Module Description Hardware Features Hardware Features The 6-Port DS1 IMA module provides the following hardware features: • Number of ports: 6 • Connector type: RJ-45 • Line rate: 1.544 Mbps • Line encoding mode: B8ZS • Loopback capabilities: local loopback, line loopback, payload loopback •...
Page 32: Led Indicators
Chapter 2 Module Description Hardware Features Table 2-2. Chassis Speed, Power Consumption, and Memory Allocation Specifications Maximum Total Module Input Chassis Amount of Program and Output Power Con- Module SDRAM Data Space Buffer Buffer Speed sumption 16–64 MB 8 MB 1 MB Total 18 W...
Page 33 Chapter 2 Module Description Hardware Features Table 2-3. LED Indicators for the 6-Port DS1 IMA Module Module Status One or More Initial Configured Configured No Cable on Cable on Power-On Ports Ports Port Port Lights Lights • Does not [Loss of light if sig- briefly Signal]...
Page 34 Chapter 2 Module Description Hardware Features ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 35: Configuring Ports And Channels Using The Console
Configuring Ports and Channels Using the Console Overview of This Chapter This chapter describes how to set the values for the port and channel configuration for the 6-Port DS1 IMA module using the PSAX Multiservice Media Gateway system console interface. Before You Begin Be sure to complete the following actions first before configuring the 6-Port DS1 IMA module:...
Page 36: Loopback Configuration Options
Chapter 3 Configuring Ports and Channels Using the Console Loopback Configuration Options Loopback Configuration Options To aid network troubleshooting and testing, loopback capability is provided for the 6-Port DS1 IMA module. The loopback option on the module’s port and channel configuration window for the module enables you to verify the integrity of a port by transmitting a received signal back to the source.
Page 37: Configuring The Module
Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module • 6-Port Enhanced E1 Multiservice module • 6-Port E1 IMA module • 21-Port High-Density E1 Multiservice module • 1-Port Channelized DS3 Multiservice and CES modules • 1-Port Channelized Channelized STS-1e, T1 Format module •...
Page 38 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Configuring the Ports Begin 4 On the Console Interface Main Menu window (see Figure 3-2), select the Equipment Configuration option and press Enter. Figure 3-2. Console Interface Main Menu Window (Equipment Configuration Selected) The Equipment Configuration window is displayed (see Figure 3-3 and Figure 3-4) .
Page 39 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Figure 3-3. Equipment Configuration Window (As Displayed on the PSAX 20, and AC 60 Console) Figure 3-4. Equipment Configuration Window (As Displayed on the PSAX 1250 and PSAX 2300 Console) ®...
Page 40 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module 5 On the Equipment Configuration window, select a 6-Port DS1 IMA module in the list and press Enter. The DS1 IMA Card Configuration window is displayed (see Figure 3-5 on page 3-6).
Page 41 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Command Function • Take All Interfaces Out Takes the in-service configured interfaces for all the ports to out-of-service status. The value 0 Of Service displays in the # Interfaces In Service field for all six ports.
Page 42: Ima Port And Channel Configuration
Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Command Function • Apply Port Configura- For a specified port number value, applies tion the port configuration field values you set • Reset Display Resets the port configuration fields to the last set of saved values.
Page 43 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Table 3-1. Field Values for the DS1 IMA Port and Channel Configuration Window Field Name Values Description Line Type Default: Esf Extended Super Frame DS1 format. (display only) D4 format.
Page 44 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Table 3-1. Field Values for the DS1 IMA Port and Channel Configuration Window Field Name Values Description negative15Db Indicates the T1 signal level range at which the DS1 is configured is negative 15 dB negative22-5Db Indicates the T1 signal level range at which the DS1 is configured is negative...
Page 45 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Table 3-1. Field Values for the DS1 IMA Port and Channel Configuration Window Field Name Values Description [Admin Status] Unconfigured The interface for the port is not config- ured.
Page 46: Port Statistics
Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Port Statistics Viewing DS1 IMA Port Statistics Begin To view statistics for this port, perform the steps in the following procedure. 1 Select the View Port Statistics command and press Enter. The DS1 IMA Port Statistics window (see Figure 3-7) is displayed.
Page 47: Ima Groups
Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Data Fields for the Descriptions of the data fields for the DS1 IMA Port Statistics window are Port Statistics given in Table 3-2 on page 3-13 Table 3-2. Data Field Descriptions of the DS1 IMA Port Statistics Window Field Names Description...
Page 48 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module 2 On the DS1 IMA Port and Channel Configuration window, select the Go Back to Card Configuration command (or press Ctrl+B) to return to the DS1 IMA Card Configuration window (see Figure 3-5 on page 3-6). 3 On the DS1 IMA Card Configuration window, select port 7, which is a virtual port, and press Enter.
Page 49 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Command Function • Take All Out of Service Takes the in-service configured interfaces to out-of-service status. An asterisk denoting in-service is removed from the status field, indicating out-of-service sta- tus.
Page 50 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Command Function • Bring Interface Into Brings the out-of-service configured interface Service for the channel to in-service status. You must first configure the interface before you can use this command. •...
Page 51 Chapter 3 Configuring Ports and Channels Using the Console Configuring the Module Table 3-3. Field Values for the DS1 IMA Group Configuration Window Field Name Values Description Link Delay Diff Default: 25 The maximum number of milliseconds of delay differential Range: 1–200 among the links that will be tolerated on this surface.
Page 52: Saving Equipment Configuration And Logging Off
Chapter 3 Configuring Ports and Channels Using the Console Saving Equipment Configuration and Logging Off 8 Repeat steps 1–7 under “Setting Up DS1 IMA Groups” on page 3-13 for the remaining two IMA groups, as needed. All six physical ports may belong to one group.
Page 53 Chapter 3 Configuring Ports and Channels Using the Console Saving Equipment Configuration and Logging Off retention feature and the result of saving the configuration changes you have made. 3 Select the Leave Console Interface command and press Enter. You are now logged off the PSAX Multiservice Media Gateway system console interface.
Page 54 Chapter 3 Configuring Ports and Channels Using the Console Saving Equipment Configuration and Logging Off ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 3-20 255-700-166...
Page 55: Configuring Ports And Channels Using The Aqueview ® System
Configuring Ports and Channels ® Using the AQueView System Overview of This Chapter This chapter describes how to set the values for the port and channel ® configuration for the 6-Port DS1 IMA module using the AQueView Element Management System (EMS). Before You Begin Be sure to complete the following actions first before configuring the 6-Port DS1 IMA module:...
Page 56: Using The Right-Click Menu
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu If configuring a pair of 6-Port DS1 IMA module in the primary and standby setup, the desired loopback option must be configured by the user on both the primary and standby modules prior to bringing the pair into service.
Page 57: Context-Sensitive Help
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Figure 4-2. Sample Channel Configuration (Displaying Right-Click Menu) Table 4-1. Descriptions of the Port and Channel Configuration Right-Click Menu Options Option Function Configure Opens the port and channel configuration window of a module.
Page 58: Configuring The 6-Port Ds1 Ima Module
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Figure 4-3. Sample of Context-Sensitive Help (Displayed on a Port and Channel Configuration Window) Configuring the 6- You must first configure the 6-Port DS1 IMA module before you can set up Port DS1 IMA Module connection provisioning.
Page 59: Configuring The Module
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Figure 4-4. Provisioning Window (Displaying a Typical Setup) Configuring the Module IMA Port Perform the steps in the following procedure to configure ports on the 6-Port Configuration DS1 IMA module.
Page 60 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu ~ In the Device Tree, select a port then click the right mouse button on the Device Tree and a menu appears. Click Configure. Figure 4-5. Front Panel View of the DS1 IMA Module The DS1 IMA Port and Channel Configuration window appears (see Figure 4-6).
Page 61 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu • Select and apply port settings • View port statistics, which display line errors and coding violations • View line status ~ The Channel Configuration page allows you to do the following: •...
Page 62 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-2. Field Values for the DS1 IMA Port and Channel Configuration Window Field Name Values Description LocalLoop The signal is received from another module in the chassis, sent through the module circuitry, including the segmen- tation and reassembly (SAR) function, and the chassis backplane to the origi-...
Page 63 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-2. Field Values for the DS1 IMA Port and Channel Configuration Window Field Name Values Description Line Status Indicates the line status of the interface: loopback, failure, received (display only) and transmitted alarm information.
Page 64: Copying A Port Configuration
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-2. Field Values for the DS1 IMA Port and Channel Configuration Window Field Name Values Description Oper Status Unconfigured This channel is not operational because the interface is not configured.
Page 65: Channel Configuration
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Figure 4-7. Sample Copy Port Configuration Window Buttons The buttons in this window have the following functions: Button Function • Close Closes this window. • Copy Copies this interface to a range of channels.
Page 66 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Figure 4-8. Channel Configuration Page Buttons The buttons in this window have the following functions: Button Function • Apply to Selected Applies the configuration field value you set .
Page 67: Viewing Port Statistics
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu 8 Repeat this procedure to configure additional ports, as desired. 9 When finished configuring, click Close. Viewing Port Statistics You can view the port statistics for the 6-Port DS1 IMA module on the Port Statistics panel of the DS1 IMA Port and Channel Configuration window (see Figure 4-6).
Page 68: Ima Virtual Channel Configuration
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu ~ You can assign all six of the physical ports to channel 1 ~ You can assign ports 1, 3, 5 to channel 1, and ports 2, 4, and 6 to channel 2, and so on IMA Virtual Channel Perform the steps in the following procedure to configure virtual channels on...
Page 69 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Figure 4-9. IMA Virtual Channel Configuration Window Field Descriptions 4 Select the values for the fields in this window as described in Table 4-4. Table 4-4. Field Values for the IMA Virtual Channel Configuration Page Field Name Values Description...
Page 70 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-4. Field Values for the IMA Virtual Channel Configuration Page Field Name Values Description Port Group Range: Displays the ports which are configured to be in the current IMA virtual chan- 1–6 nel.
Page 71 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-4. Field Values for the IMA Virtual Channel Configuration Page Field Name Values Description Alpha Value Default: 2 Indicates the alpha value, measured in (cells) Range: 1–2 cells,, measured in cells, used to specify...
Page 72: Viewing Channel Details
® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Viewing Channel Details Perform the steps in the following procedure to view channel details for the 6-Port DS1 IMA module. IMA Channel Details On the IMA Virtual Channel Configuration window, click the Channel 1 Details tab (or whichever channel number of which you wish to view statistics).
Page 73 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Button Function Poll+ initiates the continuous update of • Poll- or Poll+ statistics. Poll- suspends polling. • Close Closes this window. Field Descriptions The field values for this window are described in Table 4-5. Table 4-5.
Page 74 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-5. Field Values for the IMA Channel Details Page Field Name Values Description StartUpAck When both groups start up, they move through this transitional state to the Insufficient-Links state.While in this state, indications from the near-end that it is in start-up are ignored.
Page 75 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-5. Field Values for the IMA Channel Details Page Field Name Values Description CfgAbt Configuration aborted. This state is entered when the near-end tries to use the following unacceptable configura- tion parameters .
Page 76 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-5. Field Values for the IMA Channel Details Page Field Name Values Description Failure Status The current failure status of the IMA group (the reason why the group state (display only) machine is in the down state).
Page 77 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu Table 4-5. Field Values for the IMA Channel Details Page Field Name Values Description Number of Default: 0 Minimum number of receive links Active Rx Links required to be Active for the IMA group Range 1–32 to be in the Up state.
Page 78 ® Chapter 4 Configuring Ports and Channels Using the AQueView System Using the Right-Click Menu ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 4-24 255-700-166...
Page 79: Configuring The Interfaces Using The Console
Configuring the Interfaces Using the Console Overview of This Chapter This chapter provides instructions for configuring the 6-Port DS1 IMA module for the ATM IMA interface. Before you can set interface configuration values, you must select an interface type value other than Unconfigured in the Interface Type field on the DS1 IMA Port and Channel Configuration window.
Page 80: Atm Ima Interface
Chapter 5 Configuring the Interfaces Using the Console ATM IMA Interface ATM IMA Interface This section provides instructions for configuring an I/O module for the ATM Inverse Multiplexing over ATM (IMA) interface. You may configure the following I/O modules for the ATM IMA interface: •...
Page 81: Accessing The Atm Ima Interface
Chapter 5 Configuring the Interfaces Using the Console ATM IMA Interface there will be less overhead. If you select a smaller frame length, the IMA group has better response in communications with the far end, resulting in faster error detection and recovery. The IMA specification only requires equipment to support a frame length of 128.
Page 82: Atm Ima Values
Chapter 5 Configuring the Interfaces Using the Console ATM IMA Interface Command Function Refreshes the values in the Link States and the Defects • Update Display fields • Bring Interface Into Brings an out-of-service configured interface into service. Service (is displayed The value InService is displayed in the [Admin Status] when the [Admin Sta- field.
Page 83 Chapter 5 Configuring the Interfaces Using the Console ATM IMA Interface Table 5-1. Field Values for the ATM IMA Interface Configuration Window Field Name Values Description Link States panel NotInGroup Interface is not assigned to a group. (display only): [Near- UnusableNo- Does not work;...
Page 84: Activating The Ima Interface
Chapter 5 Configuring the Interfaces Using the Console Interim Interswitch Signaling Protocol (IISP) Interface Table 5-1. Field Values for the ATM IMA Interface Configuration Window Field Name Values Description [Near-end Rx Failures] Count of near end Rx failure alarm conditions has been entered on this link.
Page 85: Configuring The Atm Iisp Interface
Chapter 5 Configuring the Interfaces Using the Console Interim Interswitch Signaling Protocol (IISP) Interface maximum number of SSCOP transmitted since the last PSAX polling of the peer. To optimize call performance, the SSCOP Rx Window Size field of the local ATM interface should be less than the maximum value displayed in the MaxPD credit window at the remote end of the ATM interface.
Page 86 Chapter 5 Configuring the Interfaces Using the Console Interim Interswitch Signaling Protocol (IISP) Interface Commands The commands in this window have the following functions: Command Function • Apply Interface Config- Applies the configuration field value you set. uration • Reset Interface Display Resets the fields to the last set of applied values.
Page 87 Chapter 5 Configuring the Interfaces Using the Console Interim Interswitch Signaling Protocol (IISP) Interface Table 5-2. Field Values for the ATM IISP Interface Configuration Window Field Name Values Description [Oper Status] Indicates whether the interface is operational according to (display only) the Administrative Status below.
Page 88 Chapter 5 Configuring the Interfaces Using the Console Interim Interswitch Signaling Protocol (IISP) Interface Table 5-2. Field Values for the ATM IISP Interface Configuration Window Field Name Values Description UPC Support Usage parameter control (policing) determines if traffic con- trol is performing to negotiated PCR, SCR, or MBS. This fea- ture is supported on these modules: •...
Page 89: Atm User-Network Interface 3.0, 3.1, And 4.0
Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Table 5-2. Field Values for the ATM IISP Interface Configuration Window Field Name Values Description [Mismatched Number of mismatched cells received since the statistics were Cells Rcvd] last reset.
Page 90 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Figure 5-3. ATM UNI Interface Configuration Window Commands The commands in this window have the following functions: Command Function • Apply Interface Config- Applies the configuration field value you set. uration •...
Page 91 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Command Function • ATM UNI Interface Displays the ATM UNI Interface Statistics window. Statistics • ILMI Configuration Displays the ATM UNI ILMI Configuration window. • ILMI Registered User Displays the ILMI Registered User Address Table.
Page 92 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Table 5-3. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description Interface Type Default: Indicates that the NNI format for the cell headers will Network be used.
Page 93 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Table 5-3. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description UPC Support Usage parameter control (policing) determines if traffic control is performing to negotiated PCR, SCR, or MBS.
Page 94: Viewing Atm Uni Interface Statistics
Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Table 5-3. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description [Oper Status] (dis- Unconfigured Indicates that this interface has not been configured. play only) InService Indicates that the interface is operational.
Page 95 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Figure 5-4. ATM UNI Interface Statistics Window Commands The commands on this window have the following functions: Command Function • Continuous Update Continuously updates all fields once every second.
Page 96: Configuring Atm Uni Ilmi
Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Table 5-4. Field Values for the ATM UNI Interface StatisticsWindow Field Name Description [Mismatched Number of mismatched cells received into interface side A during the amount of time shown in Time Elapsed Cells Rcvd] field.
Page 97 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Command Function • Apply ILMI Configura- Applies the configuration field values you tion set. • Go Back to Interface Redisplays the ATM UNI Interface Screen Configuration window.
Page 98: Displaying Registered Addresses
Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Table 5-5. Field Values for the ATM UNI ILMI Configuration Window Field Name Values Description Secure Link Default: ILMI Secure Link Procedure is disabled. It can be enabled only if Connectivity Procedure and Attach- Disabled ment Point Detection fields are enabled.
Page 99: Viewing Ilmi Statistics
Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 The ILMI Registered User Address Table window is displayed (see Figure 5-6). Figure 5-6. ILMI Registered User Address Table Window Commands The commands in this window have the following functions: Command Function •...
Page 100 Chapter 5 Configuring the Interfaces Using the Console ATM User-Network Interface 3.0, 3.1, and 4.0 Figure 5-7. ILMI Statistics Window Commands The commands in this window have the following functions: Command Function • Continuous Update Continuously updates the information in the fields every second.
Page 101: Atm Private Network-Network Interface (Pnni) 1.0
Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Table 5-6. Field Descriptions for the ILMI Statistics Window Field Name Description [AttachPt Verified] Number of times attachment point was verified successfully. (display only) [Secure Link Proc Initiated] Number of times the secure link procedure was initiated.
Page 102: Configuring The Atm Pnni 1.0 Interface
Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 On the ATM IISP Interface Configuration window, the maximum credit window (the SSCOP Rx Window Size field) is configurable for a value up to 32 for all ATM interfaces on the Multiservice Media Gateway. The interfaces of the ATM switches that are connected to an Multiservice Media Gateway should be configured to the same values.
Page 103 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Figure 5-8. ATM PNNI Interface Configuration Window Commands The commands in this window have the following functions: Command Function • Apply Interface Configu- Applies the configuration field value you set. ration •...
Page 104 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Command Function • Delete Interface and Deletes an out-of-service interface and redisplays the Return Port and Channel Configuration window for the mod- ule you are configuring. Note: You must first take interface out of service (using the Take Interface Out of Service command)
Page 105 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Table 5-7. Field Descriptions for the ATM PNNI Interface Configuration Window Field Name Values Description UPC Support Usage parameter control (policing) determines if traffic control is performing to negotiated PCR, SCR, or MBS.
Page 106 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Table 5-7. Field Descriptions for the ATM PNNI Interface Configuration Window Field Name Values Description SSCOP Rx Wnd Size The service-specific connection-oriented protocol (SSCOP) layer. This window shows the total number of packets that must be acknowledged by the receiving side before more packets are sent from the transmitting side.
Page 107 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Table 5-7. Field Descriptions for the ATM PNNI Interface Configuration Window Field Name Values Description [Service NrtVbr (default) Quality of service class type is non-realtime vari- Category] able bit rate service.
Page 108: Configuring Pnni Ilmi
Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 choose a number divisible by 5040, such as 10080, 15120, and so on. If you want to use a value smaller than 5040, choose a multiple of 5040, such as 2, 3, 5, 6, 7, 8, 9, 10, and so on, or their multiples.
Page 109 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Command Function • Apply ILMI Applies the user input values entered on Configuration the window. • Go Back to Interface Returns to the ATM PNNI Interface Screen Configuration window.
Page 110 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Table 5-8. Field Descriptions for the PNNI ILMI Configuration Window Field Name Values Description [Secure Link] This field detects non-ILMI connections that were not dropped when an attachment point changed. (display only) Default: ILMI Secure Link Procedure is disabled.
Page 111: Viewing Pnni Ilmi Interface Statistics
Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Viewing PNNI ILMI Perform the steps in the following procedure to view PNNI ILMI statistics. Interface Statistics Procedure for Viewing PNNI ILMI Interface Statistics Begin 1 To view interface statistics for this connection, select the ILMI Statistics command on the ATM PNNI Interface Configuration window and press Enter (or press Ctrl+I).
Page 112: Viewing Pnni Interface Statistics
Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Command Function • Continuous Update Continuously updates all fields once every second. • Reset Statistics Resets statistics counters for this interface. • Go Back to previous Returns to the ATM PNNI InterfaceConfigura- screen-->...
Page 113 Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Figure 5-11. ATM PNNI Interface Statistics Window Commands The commands on this window have the following functions: Command Function • Continuous Update Continuously updates all fields once every second.
Page 114: Changing Pnni Values
Chapter 5 Configuring the Interfaces Using the Console ATM Private Network-Network Interface (PNNI) 1.0 Table 5-10. Field Values for the ATM PNNI Interface Statistics Window Field Name Description [Valid Cells Rcvd] Number of valid cells received into interface side A during the amount of time shown in Time Elapsed field.
Page 115: Configuring The Interfaces Using The Aqueview ® System
Configuring the Interfaces Using ® the AQueView System Overview of This Chapter This chapter provides instructions for configuring the 6-Port DS1 IMA module for the IMA interface. Before you can set interface configuration values, you must select an interface type value other than Unconfigured in the Interface Type field on the DS1 IMA Port and Channel Configuration window.
Page 116: Ima Configuration Considerations
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM IMA Interface fails, there will be some cell loss on CBR connections as the other links speed up their cell rate to eliminate excess delay, due to their buffering of cells. IMA Configuration Considerations Note: If your PSAX device will be interoperating with a device that has...
Page 117 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM IMA Interface Figure 6-1. IMA Interface Configuration Window Buttons The buttons in this window have the following functions: Button Function • Bring Into Service (dis- Brings an out-of-service configured interface to plays when the Admin- in-service status.
Page 118 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM IMA Interface Button Function • Update Updates the information in the fields. • Clear Removes the values in the Ima Interface Statis- tics panel and resets them to 0. Poll+ initiates the continuous update of statis- •...
Page 119 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM IMA Interface Table 6-1. Field Values for the ATM IMA Interface Configuration Window Field Name Values Description Near-end Tx Link State, NotInGroup Interface is not assigned to a group. Far-end Tx Link State, UnusableNo- Does not work;...
Page 120: Copying An Interface Configuration
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM IMA Interface Table 6-1. Field Values for the ATM IMA Interface Configuration Window Field Name Values Description Near-end Rx Failures Count of near end Rx failure alarm conditions has been entered on this link. Far-end Tx Failures Count of far end transmit failure alarm condi- tions has been entered on this link.
Page 121: Interim Interswitch Signaling Protocol (Iisp) Interface
® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Figure 6-2. Sample Copy Interface Configuration Window Buttons The buttons in this window have the following functions: Button Function • Close Closes this window. •...
Page 122: Setting Up The Interface
® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface 3.0 and ATM UNI 3.1, it uses static routing tables established by the network administrator to route connections around link failures. The IISP interface requires the default range of values 0–255 for the virtual path identifier (VPI) and the virtual channel identifier (VCI) to accept and establish calls.
Page 123 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Button Function • Retrieve from NSAP If you have previously established an NSAP database address database, click this button to retrieve an entry from this list to populate the Local NSAP Address (Hex) field.
Page 124 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Setting the Values for the ATM IISP Interface Begin 1 Select the values for the fields on this window from the values given in Table 6-2.
Page 125 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Table 6-2. Field Values for the ATM IISP Interface Configuration Window Field Name Values Description UPC Support Usage parameter control (policing) determines if traffic con- trol is performing to negotiated PCR, SCR, or MBS.
Page 126: Adding Nsap Addresses
® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Table 6-2. Field Values for the ATM IISP Interface Configuration Window Field Name Values Description Traffic Shaping An input cell selection algorithm (leaky bucket) that smooths bursts of input traffic.
Page 127 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Figure 6-4. Select NSAP Window Buttons The buttons in this window have the following functions: Button Function • Retrieve Enters the NSAP address for a device that is selected on the Select Remote NSAP window into the Remote NSAP Address field of the Interface Configuration window.
Page 128: Copying An Interface Configuration
® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface a. Highlight the Remote Switch IP field and enter the IP address that corresponds to the PSAX device you want to include. b. Type the desired values into the Slot, Port, and Channel fields and c.
Page 129: Viewing Interface Statistics
® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Figure 6-5. Sample Copy Interface Configuration Window Buttons The buttons in this window have the following functions: Button Function • Close Closes this window. •...
Page 130 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Figure 6-6. ATM IISP Interface Statistics Page Buttons The buttons in this window have the following functions: Button Function • Update Updates the information in the fields. •...
Page 131: Interface Utilization
® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Table 6-3. Field Values for the ATM IISP Interface Statistics Page Field Name Description Valid Cells Received Number of valid cells received into interface side A during the amount of time shown in Time Elapsed field.
Page 132 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Figure 6-7. ATM IISP Utilization Page Utilization Page The buttons at the bottom of the window have the following functions: Buttons Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device.
Page 133 ® Chapter 6 Configuring the Interfaces Using the AQueView System Interim Interswitch Signaling Protocol (IISP) Interface Button Function Removes the data in the Average Bits/Sec and • Clear Average Throughput panels. Poll+ continuously updates the statistics and • Poll changes the button label to Poll-. Poll- terminates polling and changes the button label to Poll+.
Page 134: Atm User-Network Interface (Uni) 3.0, 3.1, And 4.0
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 This section provides instructions for configuring an I/O module for the ATM user-to-network interface (UNI) 3.0, 3.1, 4.0 and Integrated Link Management Interface (ILMI) interfaces.
Page 135 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-9. ATM UNI Interface Configuration Window (4.0) Buttons The buttons in the ATM UNI windows have the following functions: Button Function •...
Page 136 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Button Function • Bring Into Service (dis- Brings an out-of-service configured interface to plays when the Admin- in-service status. The value InService appears istrative Status field is in the Administrative Status field.
Page 137 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Table 6-4. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description Note: For the maximum and minimum VPI and VCI values below, always enter or change the maximum value before the minimum value.
Page 138 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Table 6-4. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description User Address Default: User address displays when the value User is selected 2020.2020.2020 in the Interface Type field.
Page 139 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Table 6-4. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description Ingress Avail BW Default: 0 This represents the total ingress bandwidth available (cps) for virtual interfaces.
Page 140: Adding Nsap Addresses
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Table 6-4. Field Descriptions for the ATM UNI Interface Configuration Window Field Name Values Description Traffic Shaping An input cell selection algorithm (leaky bucket) that smooths bursts of input traffic.
Page 141 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-10. Select NSAP Window Buttons The buttons in this window have the following functions: Button Function • Retrieve Enters the NSAP address for a device that is selected on the Select Remote NSAP window into the Remote NSAP Address field of the Interface Configuration window.
Page 142: Copying An Interface Configuration
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 a. Highlight the Remote Switch IP field and enter the IP address that corresponds to the PSAX device you want to include. b.
Page 143: Viewing Atm Uni Interface Statistics
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-11. Sample Copy Interface Configuration Window Buttons The buttons in this window have the following functions: Button Function • Close Closes this window. •...
Page 144 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-12. ATM UNI Interface Statistics Page Buttons The buttons on this window have the following functions: Button Function • Update Updates the information in the fields. •...
Page 145: Interface Utilization
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Table 6-5. Field Values for the ATM UNI Interface Statistics Page Field Name Description Valid Cells Number of valid cells received into interface side A dur- Received ing the amount of time shown in Time Elapsed field.
Page 146 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-13. ATM UNI Utilization Page Utilization Page The buttons at the bottom of the window have the following functions: Buttons ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar...
Page 147 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: •...
Page 148: Configuring The Integrated Link Management Interface (Ilmi)
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 The Total Bandwidth (bps) panel displays the total width of the channel in bits per second. Note: The Multiservice Media Gateway EMS polls the PSAX device and displays this data, but does not store it.
Page 149 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-14. ILMI Configuration Page Buttons The buttons in this window have the following functions: Button Function • Registered User Displays the Registered User Address Address Table Table.
Page 150 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 ILMI Interface Values 2 Select the values for the fields on this window from the values given in Table 6-6. Table 6-6. Field Values for the ATM UNI ILMI Configuration Window Field Name Values Description...
Page 151: Viewing Registered Addresses
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Table 6-6. Field Values for the ATM UNI ILMI Configuration Window Field Name Values Description Timer S Default: 1 Timer S in seconds. Used to poll when link is not operational.
Page 152: Viewing Ilmi Statistics
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM User-Network Interface (UNI) 3.0, 3.1, and 4.0 Figure 6-15. Registered User Address Table The NSAP Address (Hex) column displays the user’s registered addresses. The Org Scope column displays the scope of the registered addresses.
Page 153: Atm Private Network-Network Interface (Pnni) 1.0
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-7. Field Descriptions for the ILMI Statistics Page Field Name Description Cold Starts Transmitted Number of times a Cold Start trap message was transmitted. (display only) Cold Starts Received Number of times a Cold Start trap message was received.
Page 154 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Figure 6-16. ATM PNNI 1.0 Interface Configuration Window Buttons The buttons in this window have the following functions: ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 6-40...
Page 155 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Button Function • Retrieve from NSAP If you have previously established an NSAP database address database, click this button to retrieve an entry from this list to populate the Local NSAP Address (Hex) field.
Page 156 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Setting the Values for the ATM PNNI 1.0 Interface Begin 1 Select the values for the fields on this window from the values given in Table 6-8.
Page 157 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-8. Field Descriptions for the ATM PNNI Interface Configuration Window Field Name Values Description Over Default: 10 Range: The risk factor for this function. This factor indi- Subscription 1–100 cates the factor of oversubscription allowed for...
Page 158 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-8. Field Descriptions for the ATM PNNI Interface Configuration Window Field Name Values Description Operational InService Indicates that the interface is operational. Status OutOfService Indicates that the interface is not operational.
Page 159: Adding Nsap Addresses
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-8. Field Descriptions for the ATM PNNI Interface Configuration Window Field Name Values Description Service NrtVbr (default) Quality of service class type is non-realtime vari- Category able bit rate service.
Page 160 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 2 To add or retrieve an NSAP address, enter a valid NSAP address in the Local NSAP Address (Hex) field and click Retrieve from NSAP database.
Page 161: Copying An Interface Configuration
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 The list of NSAP addresses previously configured for that PSAX device is displayed in the table. 4 Select the desired entry (slot, port, channel, and NSAP address) and click Retrieve.
Page 162: Viewing Interface Statistics
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Figure 6-18. Sample Copy Interface Configuration Window Buttons The buttons in this window have the following functions: Button Function • Close Closes this window. •...
Page 163 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Figure 6-19. ATM PNNI 1.0 Interface Statistics Page Buttons The buttons in this window have the following functions: Button Function • Update Updates the information in the fields. •...
Page 164: Interface Utilization
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-9. Field Values for the ATM PNNI Interface Statistics Page Field Name Description Valid Cells Received Number of valid cells received into interface side A during the amount of time shown in Time Elapsed field.
Page 165 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Figure 6-20. ATM PNNI 1.0 Utilization Page Utilization Page The buttons at the bottom of the window have the following functions: Buttons ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 166 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec •...
Page 167: Configuring The Integrated Link Management Interface (Ilmi)
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 The Total Bandwidth (bps) panel displays the total width of the channel in bits per second. Note: The Multiservice Media Gateway EMS polls the PSAX device and displays this data, but does not store it.
Page 168 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Figure 6-21. ILMI Configuration Page Buttons The buttons in this window have the following functions: Button Function • Registered User Displays the Registered User Address Address Table Table.
Page 169 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 ILMI Interface Values 2 Select the values for the fields on this window from the values given in Table 6-10. Table 6-10. Field Descriptions for the PNNI ILMI Configuration Window Field Name Values Description...
Page 170 ® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-10. Field Descriptions for the PNNI ILMI Configuration Window Field Name Values Description Auto Configura- Default: The automatic configuration procedure is the ability to tion Disabled automatically configure the actual VPI/VCI range based...
Page 171: Viewing Registered Addresses
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Viewing Registered To set values for ILMI registered addresses, perform the steps in the following Addresses procedure. Viewing Registered User Addresses Begin 1 Click Registered User Address Table on the ILMI Configuration page. The ILMI Registered User Address Table window appears (see Figure 6-22).
Page 172: Changing Pnni Values
® Chapter 6 Configuring the Interfaces Using the AQueView System ATM Private Network-Network Interface (PNNI) 1.0 Table 6-11. Field Descriptions for the ILMI Statistics Page Field Name Description Attachment Point Verified Number of times attachment point was verified successfully. (display only) Secure Link Proc Initiated Number of times the secure link procedure was initiated.
Page 173: Provisioning Connections Using The Console Interface
Provisioning Connections Using the Console Interface Overview of This Chapter This chapter describes how to set up permanent virtual circuit (PVC), switched virtual circuits (SVCs), and soft permanent virtual circuit (SPVC) connections in the Multiservice Media Gateway systems for service provisioning and how to view statistics data for billing and performance monitoring.
Page 174: Data Flow In Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Data Flow in PVC Connections For a matrix of connections and supporting interface types, see the Interface Types by Connection Types Table in the Reference Tables appendix of your ® PacketStar PSAX User Guide. Data Flow in PVC Connections PVCs consist of connections between ports on the various Multiservice Media Gateway I/O modules.
Page 175 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-1. Console Interface Main Menu Window (Connection Configuration Selected) 2 Select the Connection Configuration command and press Enter. The Connection Configuration Menu window (see Figure 7-2) is displayed. ®...
Page 176: Adding Atm-To-Atm Vcc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-2. Connection Configuration Menu Window (ATM-to-ATM VCC Option Selected) Follow the appropriate procedures in the sections of this chapter for the types of connections you want to configure. Adding ATM-to-ATM VCC PVC Connections Perform the steps in the following procedure to add an ATM-to-ATM VCC PVC connection, starting at the Connection Configuration Menu window.
Page 177 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections 1 Select ATM-to-ATM VCC on the Connection Configuration Menu window and press Enter. The ATM-to-ATM VCC PVC Table window is displayed (see Figure 7-3). Figure 7-3. ATM-to-ATM VCC PVC Table Window The ATM-to-ATM VCC PVC Table window provides a way to view, create, delete, and monitor connections and connection statistics.
Page 178 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Add a Connection Displays the ATM-to-ATM VCC PVC Connection window. • Go Back to Redisplays the Connection Configuration Menu Connection Menu window. Display Fields The display fields on this window provide the following information about all the ATM-to-ATM VCC PVC connections in the Multiservice Media Gateway system: Field...
Page 179 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-4. ATM-to-ATM VCC PVC Connection Window Commands The commands on this window have the following functions: Command Function • Display Next Connection Displays the next connection of this type in the table.
Page 180 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-1. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description ATM Interface A Side A of the connection that will send and receive signals. ATM Interface B Side B of the connection that will send and receive signals.
Page 181 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-1. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description Conformance The type of traffic control option used for ATM cells. Type The traffic descriptor combination specifies which traffic parameters are used for traffic control, deter- mines the number and type of cells that are admit- ted into a congested queue, and determines...
Page 182 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-1. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description Frwd Error Default: None The values Eighth Rate, Quarter Rate, and Half Rate are a Reed-Solomon encoding rate with a spe- Correct Eighth Rate, cific error-correction capability.
Page 183 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-1. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description Oam Status Default: Unsupp OAM is not in use. End-Pt The PSAX system is used as a termination point for ATM traffic, and will process AID/RDI cells.
Page 184: Viewing Atm-To-Atm Vcc Pvc Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Viewing ATM-to- On the ATM-to-ATM VCC PVC Connection window, select the View ATM VCC PVC Connection Statistics command. Statistics The ATM-to-ATM VCC PVC Statistics window is displayed (see Figure 7-5). Figure 7-5.
Page 185 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Field Descriptions Table 7-2. Field Descriptions for the ATM-to-ATM VCC and ATM-to-ATM VPC Connection Statistics Window Field Name Description AIS Rx/Tx Number of alarm indication signal (AIS) cells received and trans- (display only) mitted..
Page 186: Adding/Viewing A Backup Pvc Connection
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Adding/Viewing a Backup PVC Connection Procedure for Adding/Viewing a Backup PVC Connection Begin 1 From the ATM-to-ATM VCC PVC Connection window, select the Add/View Backup PVC command. The ATM-to-ATM VCC Backup PVC Connection window is displayed (see Figure 7-6).
Page 187 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-3. Field Values for the ATM-to-ATM Backup VCC PVC Connection Window Field Name Values Description ATM Interface Panel (display only) [Slot] Varies depending on Current primary connection slot in use. (display only) equipment [Port]...
Page 188: Adding Atm-To-Atm Vpc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-3. Field Values for the ATM-to-ATM Backup VCC PVC Connection Window Field Name Values Description [Switch Back to Yes (default) CPU monitors primary connection. If pri- Primary mary connection becomes available, backup Automatically] will switch back connection to primary.
Page 189 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-7. ATM-to-ATM VPC PVC Table Window The ATM-to-ATM VPC PVC Table window provides a way to view, create, delete, and monitor connections and connection statistics. This table loads and displays all current ATM-to-ATM VPC PVC connections.
Page 190 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Add a Connection → Displays the ATM-to-ATM VPC PVC Con- nection window. • Go Back to Connection Redisplays the Connection Configuration Menu → Menu window. Display Descriptions The display-only fields on this window provide the following information about all the ATM-to-ATM VPC PVC connections in the PSAX system: Field...
Page 191 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-8. ATM-to-ATM VPC PVC Connection Window Commands The commands on this window have the following functions: Command Function • Display Next Connection Displays the next connection of this type in the table.
Page 192 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-4. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description ATM Interface A One side of the connection that will send and receive sig- nals.
Page 193 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-4. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description Conformance The type of traffic control option used for ATM cells. The Type traffic descriptor combination specifies which traffic param- eters are used for traffic control, determines the number and type of cells that are admitted into a congested queue, and determines whether high-priority cells are tagged as...
Page 194 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-4. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description SCR/PCR(0) Default: 1 cps When setting this value, take into account the line rate for the module and the amount of bandwidth you are setting up for each interface for the module.
Page 195: Viewing Atm-To-Atm Vpc Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-4. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description [Backup PVC] Default: No, This field displays a backup PVC, if one has been config- ured.
Page 196 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-9. ATM-to-ATM VPC PVC Statistics Window Commands The commands on this window have the following functions: Command Function • Reset Odometers Returns all statistics odometers to zero. • Continuous Update Updates the values in the fields every second.
Page 197: Adding/Viewing A Backup Atm-To-Atm Vpc Connection
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-5. Field Descriptions for the ATM-to-ATM VCC and ATM-to-ATM VPC Connection Statistics Window Field Name Description cell Drop/Tag Number of cells dropped and tagged on incoming side of interface (display only) A or B.
Page 198 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-10. ATM-to-ATM VPC Backup PVC Connection Window Commands The commands on this window have the following functions: Command Function • Add This Connection Adds the connection entered on backup ATM interface right panel.
Page 199 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-6. Field Descriptions for the ATM-to-ATM Backup VPC PVC Connection Window Field Name Values Description [Channel] Determined by the Current primary connection channel on port on (display only) number of chan- module on slot in use.
Page 200: Adding Bridge-To-Atm Vcc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Adding Bridge-to-ATM VCC PVC Connections Creating a Bridge-to- This type of connection supports all non-CBR service types. Perform the steps ATM VCC Connection in the following procedure to create a bridge-to-ATM PVC connection. Creating a Bridge-to-ATM VCC PVC Connection Begin Note:...
Page 201 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Commands The commands on this window have the following functions: Command Function • Find . . . To find a particular connection, enter val- ues in the Slot, Port, Channel, VPI, and VCI fields.
Page 202 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections The Bridge-to-ATM VCC PVC Connection window will display (see Figure 7-12). Figure 7-12. Bridge-to-ATM VCC PVC Connection Window Commands The commands on this window have the following functions: Command Function •...
Page 203 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-7. Field Values for the Bridge-to-ATM VCC PVC Connection Window Field Names Values Description Bridge Interface The bridge side of the connection that will send and receive signals. ATM Interface B The ATM interface side of the connection that will send and receive signals.
Page 204 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-7. Field Values for the Bridge-to-ATM VCC PVC Connection Window Field Names Values Description Conformance The type of traffic control option used for ATM cells. The traf- Type fic descriptor combination specifies which traffic parameters are used for traffic control, determines the number and type of cells that are admitted into a congested queue, and deter-...
Page 205: Viewing Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-7. Field Values for the Bridge-to-ATM VCC PVC Connection Window Field Names Values Description Max Burst Size 1 (default) Maximum burst size. The maximum number of cells that can (cells) be received at one time.
Page 206 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections The Bridge-to-ATM VCC PVC Statistics window will display (see Figure 7-13). Figure 7-13. Bridge-to-ATM VCC PVC Statistics Window Commands The commands on this window have the following functions: Command Function •...
Page 207 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-8. Field Values for the Bridge-to-ATM VCC Connection Statistics Window Field Name Description Channel Channel identifier for either Interface A or Interface B. (display only) Virtual path identifier of the ATM side (SVC side) of the connection. (ATM Interface panel only) (display only)
Page 208: Creating Backup Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-8. Field Values for the Bridge-to-ATM VCC Connection Statistics Window Field Name Description In Odometer Total number of cells encoded going into interface side B since this counter was reset.
Page 209 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Add This Connection Adds connection entered on Backup ATM interface. • Delete Connection Deletes selected connection. • Go Back to Primary Returns to Bridge-to-ATM VCC PVC Con- PVC Connection –>...
Page 210: Adding Circuit Emulation-To-Atm Vcc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-9. Field Values for the Bridge-to-ATM VCC Backup PVC Connection Window Field Name Values Description [Switch Back to Yes (default) CPU monitors primary connection. If primary connec- Primary tion becomes available, backup will switch back con- Automatically] nection to primary.
Page 211 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-15. Circuit Emulation-to-ATM VCC PVC Table Window Note: At the time of initial installation, the Circuit Emulation-to-ATM VCC PVC Table window is empty. After you have set up connections, this window displays all the connections of this type in the system.
Page 212 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Display Fields The display fields on this window provide the following information about all the circuit emulation-to-ATM VCC PVC connections in the Multiservice Media Gateway system: Display Field Description •...
Page 213 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-16. Circuit Emulation-to-ATM VCC PVC Connection Window Commands The commands on this window have the following functions: Command Function • Display Next Connec- Displays the next connection of this type in the tion table.
Page 214 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-10. Field Descriptions for the Circuit Emulation-to-ATM VCC PVC Connection Window Field Names Values Description Circuit Emulation Field values in this panel relate to the circuit emu- Interface lation side of the connection that will send and receive signals.
Page 215 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-10. Field Descriptions for the Circuit Emulation-to-ATM VCC PVC Connection Window Field Names Values Description Silence Disabled (default) If you want data traffic for this connection to be Detection processed through the DSP2x Voice Server mod- Enabled...
Page 216 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-10. Field Descriptions for the Circuit Emulation-to-ATM VCC PVC Connection Window Field Names Values Description Conformance Type The type of traffic control option used for ATM cells. The traffic descriptor combination specifies which traffic parameters are used for traffic con- trol, determines the number and type of cells that are admitted into a congested queue, and deter-...
Page 217 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-10. Field Descriptions for the Circuit Emulation-to-ATM VCC PVC Connection Window Field Names Values Description Flow Duplex (default), Direction of the flow of data traffic in this connec- SimplexA2B, tion.
Page 218: Connection Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections 8 Select Save Configuration, and press Enter to store the values to the Multiservice Media Gateway system database. Connection Statistics Viewing Connection Statistics Begin 1 From the Circuit Emulation-to-ATM VCC PVC Connection window, select the View Connection Statistics command press Enter.
Page 219 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Field Descriptions The fields on this window are described in Table 7-11. Table 7-11. Field Values for the Circuit Emulation-to-ATM VCC PVC Statistics Field Names Values Description Circuit Emula- The circuit emulation side of the connection that will send and tion Interface receive signals.
Page 220: Backup Connection
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-11. Field Values for the Circuit Emulation-to-ATM VCC PVC Statistics Field Names Values Description Cells Received 6.5000 e1 The total number of received OAM cells going into interface side A during the amount of time shown in the Time Elapsed (default) field (i.e., since the circuit was created).
Page 221 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Commands The commands on this window have the following functions: Command Function • Add This Connection Adds connection entered on Backup ATM inter- face right panel. • Delete Connection Deletes backup connection.
Page 222: Adding Frame Relay-To-Atm Vcc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-12. Field Descriptions for the Circuit Emulation-to-ATM VCC Backup PVC Window Field Name Values Description Port Determined by the Select the port number on the module for number of ports which you are creating a backupconnection.
Page 223 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections The Frame Relay-to-ATM VCC PVC Table window (see Figure 7-19) is displayed. Figure 7-19. Frame Relay-to-ATM VCC PVC Table Window Note: At the time of initial installation, the Frame Relay-to-ATM VCC PVC Table window is empty.
Page 224 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Display Field Description • Frame Relay Interface This panel displays the information for all interface A sides of the connections. The connection entries are displayed in ascending numerical order by slot, then by port, channel, and DLCI or VPI.
Page 225 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Commands The commands on this window have the following functions: Command Function • Display Next Connec- Displays the next connection of this type tion in the table. • Delete Connection Deletes the connection having the values currently displayed on the window.
Page 226 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-13. Field Descriptions for the Frame Relay-to-ATM VCC Connection Window Field Names Values Description Range: 0–65535 Virtual channel identifier. 0 (default) Virtual interface, which provides bandwidth alloca- tion restrictions. Currently available only on the OC- Range: 0–255 3c APS, and STM-1 MSP modules.
Page 227: Configuring Traffic Parameters
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-13. Field Descriptions for the Frame Relay-to-ATM VCC Connection Window Field Names Values Description Flow Duplex, Direction of the flow of data traffic in this connection. SimplexA2B, Note: Only Duplex and Simplex are applicable for SimplexB2A, DS3 IMA.
Page 228 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-21. Frame Relay-to-ATM PVC Traffic Parameters Window Commands The commands on this window have the following functions: Command Function • Add This Connection Adds a connection having the values cur- rently displayed on the window.
Page 229: Viewing The Statistics Window
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-14. Field Descriptions for the Frame Relay-to-ATM VCC PVC Traffic Parameters Window Field Name Values Description Committed Info Default: 0 Committed information rate is the rate of traffic Rate (measured in bits per second) for a given connection that the system will attempt to provide guaranteed delivery.
Page 230 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-22. Frame Relay-to-ATM PVC Statistics Window Commands The commands on this window have the following functions: Command Function Resets the Encoded Odometer, Decoded • Reset Odometers Odometer, In Odometer, and Out Odom- eter fields to zero.
Page 231 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-15. Field Descriptions for the Frame Relay-to-ATM VCC Connection Statistics Window Field Name Description Cells Encoded Number of cells encoded going into Frame Relay Interface side A during the amount of time shown in Time Elapsed field since the circuit was established.
Page 232: Adding An In-Band Management Atm Pvc Connection
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Adding an In-Band Management ATM PVC Connection You can create an in-band management PVC connection between a configured in-band management address and any module that supports ATM interfaces. This connection supports the UBR and VBR-express service types. Perform the steps in the following procedure to create an in-Band management-to-ATM VCC connection.
Page 233 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections connections, this window displays all the connections of this type in the system. Commands The commands on this window have the following functions: Command Function • Find . . . To find a particular connection, enter val- ues in the Slot, Port, Chnl, VPI, and VPI/VCI fields.
Page 234 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-24. In-Band ATM PVC Connection Configuration Window Commands The commands on this window have the following functions: Command Function • Add Connection Adds a connection having the values cur- rently displayed on the window.
Page 235 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-16. Field Descriptions for the In-Band ATM PVC Connection Configuration Window Field Name Values Description Slot, Port, Varies Enter the values for slot, port, channel, VPI, VCI, and VI for Channel, VPI, the interface in the Multiservice Media Gateway chassis to VCI and VI...
Page 236 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-16. Field Descriptions for the In-Band ATM PVC Connection Configuration Window Field Name Values Description Sustained Rate Default: 1 When setting this value, take into account the line rate for (cps) the module and the amount of bandwidth you are setting up for each interface for the module.
Page 237 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Setting PVC Steps to Setting Connections for Direct In-band Connections Connections for Begin Direct In-band Connections Perform the steps in the following procedure, which is a test to verify the working of console interface screens for configuring the in-band management IP address and the PVC connection.
Page 238 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-25. INBAND-ATM PVC Connection Configuration Window The commands on this window have the following functions: Commands Command Function • Add This Connection Adds the backup connection for the specified slot, port, channel, VPI, VCI, and VI •...
Page 239: Adding Vbr-To-Atm Vcc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-17. Field Descriptions for the Inband-to-ATM VCC Backup PVC Connection Window Field Name Values Description Port Determined by the Select the port number on the module for which you number of ports are creating a backup connection.
Page 240 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Steps to Create a VBR-to-ATM VCC Connection Begin Note: On the DS1 IMA and E1 IMA modules, PVC connections must be provisioned on the virtual port (port 7). You can use up to three groups on port 7 (the groups you provision on port 7.) Note: On the DS3 IMA module, PVC connections must be provisioned...
Page 241 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Find . . . To find a particular connection, enter val- ues in the Slot, Port, Channel, VPI, and VCI fields. If the connection exists, it will display on the first line of the table.
Page 242 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Display Next Connec- Displays the next connection of this type tion in the table. • Add This Connection Adds a connection having the values cur- rently displayed on the window. •...
Page 243 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-18. Field Values for the VBR-to-ATM VCC PVC Connection Window Field Names Values Description 0 (default) Virtual interface, which provides band- width allocation restrictions. Currently Range: 0–255 available only on the OC-3c APS and STM-1 MSP modules.
Page 244 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-18. Field Values for the VBR-to-ATM VCC PVC Connection Window Field Names Values Description Service Type Ubr (default), Multiservice Media Gateway system- Vbr-nrt2, supported quality of service (QoS) class. Vbr-nrt1, See the appendix for a detailed descrip- Vbr-rt2,...
Page 245 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-18. Field Values for the VBR-to-ATM VCC PVC Connection Window Field Names Values Description Conformance The type of traffic control option used Type for ATM cells. The traffic descriptor combination specifies which traffic (displayed on parameters are used for traffic control,...
Page 246: Viewing The Vbr-To-Atm Connection Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-18. Field Values for the VBR-to-ATM VCC PVC Connection Window Field Names Values Description OAM Status Default: Unsupp OAM is not in use. End-Pt The PSAX system is used as a termina- tion point for ATM traffic, and will pro- cess AIS/RDI cells.
Page 247 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections The VBR-to-ATM VCC PVC Statistics window is displayed, as shown in Figure 7-28. Figure 7-28. VBR-to-ATM VCC PVC Statistics Window Commands The commands on this window have the following functions: Command Function •...
Page 248 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-19. Field Descriptions for the VBR-to-ATM VCC PVC/SPVC Connection Statistics Window Field Name Description Port Port number of VBR interface Channel Channel number on port of VBR interface. Cells Encoded Number of cells encoded going into interface side Aor B during the amount of time shown in Time...
Page 249: Adding/Viewing A Backup Pvc Connection
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-19. Field Descriptions for the VBR-to-ATM VCC PVC/SPVC Connection Statistics Window Field Name Description In Odometer Total number of cells encoded going into interface side B since the connection statistics were reset. (display only) Out Odometer Total number of cells decoded going out of inter-...
Page 250 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-20. Field Descriptions for the VBR-to-ATM VCC Backup PVC Window Field Name Values Description Slot Listed as avail- Select the slot containing the module able from the for which you are creating a connec- (display only for PSAX device tion.
Page 251: Adding Vbr-To-Vbr Vcc Pvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Adding VBR-to-VBR VCC PVC Connections Perform the steps in the following procedure to create a VBR-to-VBR VCC connection. Steps to Create a VBR-to-VBR PVC Connection Begin 1 On the Connection Configuration Menu window, select VBR-to-VBR Connection and press Enter (or press Ctrl+O).
Page 252 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Find . . . To find a particular connection, enter val- ues in the Slot, Port, Channel, VPI, and VCI fields. If the connection exists, it will display on the first line of the table.
Page 253 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Command Function • Display Next Connec- Displays the next connection of this type tion in the table. • Add This Connection Adds a connection having the values cur- rently displayed on the window. •...
Page 254 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-21. Field Values for the VBR-to-VBR PVC Connection Window Field Names Values Description Sustained Rate Default: 1 When setting this value, take into account the line (cps) rate for the module and the amount of bandwidth you are setting up for each interface for the module.
Page 255 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-21. Field Values for the VBR-to-VBR PVC Connection Window Field Names Values Description Conformance The type of traffic control option used for ATM cells. Type The traffic descriptor combination specifies which traffic parameters are used for traffic control, deter- mines the number and type of cells that are admitted into a congested queue, and determines whether...
Page 256 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections 4 To add (apply) the connection configuration, select the Add This Connection command and press Enter (or press Ctrl+A). 5 To review this connection, select the Go Back to Connection Table command and press Enter (or press Ctrl+B).
Page 257 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-31. VBR-to-VBR PVC Statistics Window Commands The commands on this window have the following functions: Command Function • Reset Odometers Returns all statistics odometers to zero. • Continuous Update Updates the values in the fields every second.
Page 258: Adding Aal-2 Trunking To A Connection
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-22. Field Values for the VBR-to-VBR VCC Connection Statistics Window Field Name Description Encoded Odometer Total number of cells encoded going in interface side A or B since the connection was created. (display only) Decoded Odometer Total number of cells decoded going out interface...
Page 259: Configuring An Aal2 Trunking Connection With Dsp Parameters
Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections • Assign up to 128 connections in DSP2A or DSP2B mode in up to 64 trunk groups. Each DSP on the DSP2C Voice Server module can be assigned 4 DS0 connections in DSP2A or DSP2B mode.
Page 260 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Adding Circuit Emulation to an ATM PVC Connection procedure in Chapter 8 of the DSP2x Voice Server Module User Guide, or the Reference Table appendix. Note: On GR-303 applications, you cannot split an AAL2 trunk across DSP2C modules.
Page 261 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Figure 7-34. AAL2 Trunk Table Commands The commands on this table have the following functions: Command Function • Page Up Scroll up one page. • Page Down Scroll down one page. •...
Page 262 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-23. Field Descriptions for the AAL2 Trunk Table Window Field Names Values Description Total: The first number in this field indicates (display only) the identification number of the con- nection table entry on the first line of the currently displayed window.
Page 263 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Commands The commands on this window have the following functions: Command Function • Display Next Displays the next connection of this type Connection in the table. • Add This Connection Adds a connection having the values cur- rently displayed on the window.
Page 264 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-24. Field Descriptions for the AAL2 Trunk Connection Window Field Name Values Description Default: 0 VI support must be enabled on the appropriate Interface Configuration window. Use this field to set a virtual inter- Range: 0–255 face, providing bandwidth allocation restrictions for the ATM output side.
Page 265 Chapter 7 Provisioning Connections Using the Console Interface Provisioning PVC Connections Table 7-24. Field Descriptions for the AAL2 Trunk Connection Window Field Name Values Description Conformance This field indicates the type of traffic control option used for Type ATM cells. The traffic descriptor combination specifies which traffic parameters are used for traffic control, deter- mines the number and type of cells that are admitted into a congested queue, and determines whether high-priority...
Page 266: Provisioning Svc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-24. Field Descriptions for the AAL2 Trunk Connection Window Field Name Values Description Flow Default: Duplex This field presents the direction of the flow of data traffic in this connection.
Page 267: Enabling Svc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-36. ATM-to-ATM VCC SVC Table Window Commands The commands on this window have the following functions: Command Function • Find To find a particular connection, enter val- ues in the Slot, Port, Chnl, VPI, and VCI fields If the connection exists, it is dis- played on the first line of the table.
Page 268: Setting Up An Iisp Link
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections For instructions on PNNI node configuration, the appropriate ® PacketStar PSAX Multiservice Media Gateway User Guide. 2. Configure a channel on an I/O module with the ATM PNNI interface, and bring the interface into service.
Page 269 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-37. IISP CBR Routing Table Commands The commands on this window have the following functions: Command Function • Find Finds the routing entry with the specified NSAP address. •...
Page 270: Adding Entries To The Atm Iisp Vbr Routing Table
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections 5 Select Save Configuration, and press Enter to store the values to the Multiservice Media Gateway system database. Adding Entries to the ATM IISP VBR Routing Table Creating IISP VBR Use the steps in the following procedure to add an entry to the VBR routing Entries table, starting at the Connection Configuration Menu window.
Page 271: Provisioning Spvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections 2 Select the Add an Entry field, and press Enter. a. Type a network service access point (NSAP) address in hexadecimal format up to 20 bytes (160 bits) long (10 groups of 4 characters each), and press the Tab key.
Page 272 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Steps to Create an ATM-to-ATM VCC SPVC Connection Begin 1 On the Connection Configuration Menu window, select SPVC Configuration Screen (y) and press Enter. The SPVC Connection Configuration Menu window is displayed (see Figure 7-39). Figure 7-39.
Page 273 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-40. ATM-to-ATM VCC SPVC Table Window Note: At the time of initial installation, the ATM-to-ATM VCC SPVC Table window is empty. After you have set up connections, this window is displayed all the connections of this type in the system.
Page 274 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Display Field Description • ATM PVC Interface This column displays the information for all interface A (PVC) sides of the connections. The connection entries are shown in ascending numerical order by slot, then by port, channel, VPI, and VCI.
Page 275 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Commands The commands on this window have the following functions: Command Function • View Connection Sta- Displays the ATM-to-ATM VCC SPVC Sta- tistics → tistics window. • Continuous Update Updates the values in the fields every sec- ond.
Page 276 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-25. Field Values for the ATM-to-ATM VCC SPVC Connection Window Field Names Values Description Conn Type Default: The type of connection. ActiveSvc attempts calls. Pas- siveSvc accepts calls. ActiveSvc PassiveSvc Note:...
Page 277 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-25. Field Values for the ATM-to-ATM VCC SPVC Connection Window Field Names Values Description Service Type Default: Ubr Multiservice Media Gateway system-supported quality Vbr-nrt2, of service (QoS) class. Vbr-nrt1, Vbr-rt2, Vbr-rt1,...
Page 278: Viewing Connection Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections 5 To add (apply) the connection configuration, select the Add This Connection command and press Enter. 6 To review this connection, select the Go Back to Connection Table command and press Enter (or press Ctrl+B). The ATM-to-ATM VCC SPVC Table window is returned, displaying the values you just applied.
Page 279 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Command Function Resets the Encoded Odometer, Decoded • Reset Odometers Odometer, In Odometer, and Out Odom- eter fields to zero. Note: If a call is disconnected, all odometers are reset to zero. •...
Page 280: Adding Nsap Addresses
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-26. ATM-to-ATM VCC SPVC Statistics Window Field Name Description Transmitted Number of valid cells transmitted since this counter was reset. Odometer Note: This counter serves as an odometer while the cells Tx/Rx counters track usage for the life of the circuit.
Page 281: Adding Circuit Emulation-To-Atm Vcc Spvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Commands The commands on this window have the following functions: Command Function • Find . . . Finds the specified NSAP address. • Go Back to Connection Redisplays the ATM-to-ATM VCC SPVC Table →...
Page 282 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-44. Circuit Emulation-to-ATM VCC SPVC Table Window Note: At the time of initial installation, the Circuit Emulation-to-ATM VCC SPVC Table window is empty. After you have set up connections, this window will display all the connections of this type in the system.
Page 283 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Display Field The display-only fields on this window provide the following information Descriptions about all the circuit emulation-to-ATM VCC SPVC connections in the PSAX system: Display Field Description • Circuit Emulation Side This column displays the information for all cir- cuit emulation sides of the connections.
Page 284 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-45. Circuit Emulation-to-ATM VCC SPVC Connection Window Commands The commands on this window have the following functions: Command Function • Display Next Connec- Displays the next connection of this type in the tion table.
Page 285 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Field Descriptions 3 Select the values for the fields on this window from Table 7-27. Table 7-27. Field Descriptions for the Circuit Emulation-to-ATM SPVC Connection Window Field Names Values Description Circuit Emula- The circuit emulation side of the connection that will send and...
Page 286 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-27. Field Descriptions for the Circuit Emulation-to-ATM SPVC Connection Window Field Names Values Description SAR Type Default: Non-multiplexed AAL2. Non-Mux-Aal2 Note: Note: If you Choose this type to configure an SPVC if using DSP are upgrading parameters with the connection.
Page 287: Viewing Connection Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections modules: Channelized DS3 (multifunction), 1-port Channelized DS3 CES, 3-port Channelized DS3 CES (Release 7.0 CPU software required), Channelized STS-1e CES, Channelized STS-1e T1, Enhanced DS1, Enhanced E1, High-Density E1 (21 port), and Medium Density DS1 (12-port).
Page 288 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Commands The commands in this window have the following functions: Command Function • Reset Odometers Returns all statistics odometers to zero. • Continuous Update Updates the values in the fields every second.
Page 289: Adding Vbr-To-Atm Vcc Spvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-28. Field Descriptions for the Circuit Emulation-to-ATM VCC SPVC Statistics Window Field Names Values Description Decoded Odom- 0.0000 e0 Total number of cells decoded going out of either inter- eter (default) face side since the odometer was last reset.
Page 290 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections The VBR-to-ATM VCC SPVC Table window is displayed (see Figure 7-47). Figure 7-47. VBR-to-ATM VCC SPVC Table Window Note: At the time of initial installation, the VBR-to-ATM VCC SPVC Table window is empty.
Page 291 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-29. VBR-to-ATM VCC SPVC Table Display Field Description • VBR Side This panel is displayed the slot, port, and chan nel information for all VBR interface sides of the connections. •...
Page 292 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Commands The commands on this window have the following functions: Command Function • View Connection Sta- Displays the VBR-to-ATM VCC SPVC Statis- tistics tics window. • Continuous Update Updates the values in the fields every second. •...
Page 293 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-30. Field Values for the VBR-to-ATM SPVC Connection Window Field Names Values Description Service Type Ubr (default), Multiservice Media Gateway system-supported quality of Vbr-nrt2, service (QoS) class. Vbr-nrt1, See the appendix for a detailed description of the values for Vbr-rt2, this field, including representative examples.
Page 294: Viewing Connection Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-30. Field Values for the VBR-to-ATM SPVC Connection Window Field Names Values Description [Oper Status] Default: Other None of the types specified below. (display only) Establishment Connection is not operational, but call attempts are ongoing. InProgress Connected Connection is currently operational.
Page 295 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-49. VBR-to-ATM VCC SPVC Statistics Window Commands The commands on this window have the following functions: Command Function Resets the Encoded Odometer, Decoded • Reset Odometers Odometer, In Odometer, and Out Odometer fields to zero.
Page 296: Adding Frame Relay-To-Atm Vcc Spvc Connections
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-31. Field Descriptions for the VBR-to-ATM VCC SPVC Statistics Window Field Name Description Channel Channel identifier of the ATM interface for either Interface A or Interface B. Virtual path identifier of the ATM side (SVC side) of the connection. (ATM Interface panel only) Virtual channel identifier of the ATM side (SVC side) of the connection.
Page 297 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Steps to Create a Frame Relay-to-ATM VCC SPVC Connection Begin Use the steps in the following procedure to add a Frame Relay-to-ATM VCC SPVC connection, starting at the Connection Configuration Menu window. 1 On the Connection Configuration Menu window, select SPVC Configuration Screen(y), and press Enter.
Page 298 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Figure 7-51. Frame Relay-to-ATM VCC SPVC Table Window Note: At the time of initial installation, the Frame Relay-to-ATM VCC SPVC Table window is empty. After you have set up connections, this window displays all the connections of this type in the system.
Page 299 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Display Field Description • (Frame Relay) This column displays the information for all interface A (PVC) sides of the connections. The connection entries are displayed in ascending numerical order by slot, then by port, channel, and DLCI.
Page 300 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Commands The commands on this window have the following functions: Command Function • Delete Connection Deletes the connection having the values cur- rently displayed on the window. • Continuous Update Updates the values in the fields every second.
Page 301 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-32. Field Values for the Frame Relay-to-ATM SPVC Connection Window Field Names Values Description DLCI Range: 16–1007 Data link connection identifier. DLCI is used when the remote end point is frame relay. The type of connection.
Page 302: Configuring Traffic Parameters
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-32. Field Values for the Frame Relay-to-ATM SPVC Connection Window Field Names Values Description Retry Interval Default: 2 The waiting period before attempting to establish the SPVC (sec) (shown after one call attempt has failed.
Page 303 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Steps to Configure Traffic Parameters Begin 1 On the Frame Relay-to-ATM VCC SPVC Connection window (see Figure 7-50), select Configure Traffic Parameters and press Enter. The Frame Relay-to-ATM VCC SPVC Traffic Parameters window is displayed (see Figure 7-53).
Page 304 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Note to Writers: Woodard: This table is exclusively for the console, not AQV. Please leave the table anchor tagged as “ModuleGuide.” Table 7-33. Field Values for the Frame Relay-to-ATM VCC SPVC Traffic Parameters Window Field Name Values Description...
Page 305: Viewing Connection Statistics
Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Viewing Connection To view the statistics for this connection, perform the steps in the following Statistics procedure. On the Frame Relay-to-ATM VCC SPVC Connection window (see Figure 7-52), select View Connection Statistics and press Enter. The Frame Relay-to-ATM VCC SPVC Statistics window is displayed.
Page 306 Chapter 7 Provisioning Connections Using the Console Interface Provisioning SVC Connections Table 7-34. Field Descriptions for the Frame Relay-to-ATM VCC SPVC Connection Statistics Window Field Name Description Slot Slot identifier of the frame relay interface (Interface A). Port Port identifier of the frame relay interface (Interface A). Channel Channel identifier of the frame relay interface (Interface A).
Page 307: Provisioning Connections Using The Aqueview
Provisioning Connections Using the ® AQueView System Overview of This Chapter This chapter describes how to set up permanent virtual circuit (PVC), switched virtual circuits (SVCs), and soft permanent virtual circuit (SPVC) ® connections using the AQueView system for service provisioning and how to view statistics data for billing and performance monitoring.
Page 308: Data Flow In Pvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Data Flow in PVC Connections ~ ATM IISP CBR connection ~ ATM IISP VBR connection • SPVC connections: ~ ATM-to-ATM virtual channel connection (VCC) (z) ~ Circuit Emulation-to-ATM virtual channel connection (VCC) (y) ~ Variable bit rate (VBR)-to-ATM virtual channel connection (VCC) (w) Before you can provision connections, you must select an interface type value other than Unconfigured in the Interface Type field on the 6-Port...
Page 309: Searching For Specific Connection Entries
® Chapter 8 Provisioning Connections Using the AQueView System Managing Connections • The SPVC NSAP Address page enables you to enter new SPVC NSAP addresses and to view a list of existing SPVC NSAP addresses (see ”SPVC NSAP Addresses” on page 8-12) •...
Page 310 ® Chapter 8 Provisioning Connections Using the AQueView System Managing Connections For example, the Listing page shown in Figure 8-2 has hundreds of connection entries. It is quicker to search this page based on a text string than to scroll up and down the page looking for a specific entry. Perform the steps in the following procedure to search for entries using a text string.
Page 311: Viewing Connection Details
® Chapter 8 Provisioning Connections Using the AQueView System Managing Connections 3 Click Find. The page displays the entries that contain the text string you entered (see Figure 8-3). Figure 8-3. Listing Page (Displaying Search Results) 4 To perform another search, repeat Step 2 and Step 3 as often as needed. 5 To return the page to its original display, click Reset.
Page 312: Display Connection Tabs
® Chapter 8 Provisioning Connections Using the AQueView System Managing Connections ~ Click on any entry in the Listing page, right-click the mouse, and select Display from the right-click menu ~ Create a connection, and the Display Connection window will appear for the selected connection Up to four tabs may be displayed within the Display Connection window: Primary, Statistics, Backup, and Utilization.
Page 313 ® Chapter 8 Provisioning Connections Using the AQueView System Managing Connections Figure 8-4. Copy Connection Configuration Window (ATM) Figure 8-5. Copy Connection Configuration Window (Frame Relay) ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 314 ® Chapter 8 Provisioning Connections Using the AQueView System Managing Connections Figure 8-6. Copy Connection Configuration Window (SPVC Connection Types) Figure 8-7. Copy Connection Configuration Window (GR-303 Connection Type) Buttons The buttons in these windows have the following functions: Button Function •...
Page 315: Filtering Connections In The List
® Chapter 8 Provisioning Connections Using the AQueView System Filtering Connections in the List 3 Select the range of channels which you wish the connection configuration to be copied in the Slot, Port, and Channel fields 4 Enter values in the VPI, VCI, DLCI, Remote VPI, Remote VCI fields as necessary.
Page 316 ® Chapter 8 Provisioning Connections Using the AQueView System Filtering Connections in the List Figure 8-8. Filter Page The Filter page contains the Connection Type and Filter By Interface panels. Buttons The buttons in this window have the following functions: Button Function •...
Page 317: Filtering The Listing Page By Psax Locations
® Chapter 8 Provisioning Connections Using the AQueView System Filtering Connections in the List 3 Remove the check mark next to any connection type that you do not wish to view in the Listing page. 4 If you want to filter the Listing page further, make selections in the Filter By Interface panel (see “Filtering the Listing Page by PSAX Locations”).
Page 318: Spvc Nsap Addresses
® Chapter 8 Provisioning Connections Using the AQueView System SPVC NSAP Addresses 5 When finished selecting all the needed filters, click Apply Filter. Note: Only the types of connections you selected will appear in the Listing page. SPVC NSAP Addresses You can enter new SPVC NSAP addresses and view a list of existing SPVC NSAP addresses on the SPVC NSAP Address page (see Figure 8-9).
Page 319: Aal2 Trunk Configuration
® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Button Function • Find Searches the table and displays a matching text string entered in the Show table entry containing: field. Removes text entered in the Show table entry •...
Page 320 ® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Figure 8-10. AAL2 Trunking Architecture Note: AAL2 trunking with DSP parameters cannot be used on an SPVC connection. You can do the following: • Assign up to 128 connections in DSP2A or DSP2B mode in up to 64 trunk groups.
Page 321: Adding An Aal2 Trunk Entry
® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration a. Assign the slot, port, and channel for the DSP connection you want to multiplex. b. In the same window, select Aal2Std in the SAR Type field. Selecting this value enables you to select connection identifiers (Cids) 8–255 in the AAL2 Cid field on the upper right panel.
Page 322 ® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Figure 8-12. AAL2 Trunk Config Entry Window (ADD) Note: Upon initial configuration, this window displays “ADD” in its title; upon updating this configuration, this window displays “VIEW” in its title.
Page 323 ® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Table 8-1. Field Descriptions for the AAL2 Trunk Config Entry Window Field Name Values Description Slot (Pull-down Use this field to select the module for which you want to menu with list add an AAL2 trunk on the ATM side output.
Page 324 ® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Table 8-1. Field Descriptions for the AAL2 Trunk Config Entry Window Field Name Values Description Peak Rate (cps) Default: 1 Use this field to set the maximum allowed cell transmission rate (in cells per second), defining the shortest time period allowed between cells.
Page 325 ® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Table 8-1. Field Descriptions for the AAL2 Trunk Config Entry Window Field Name Values Description Conformance This field indicates the type of traffic control option used for Type ATM cells.
Page 326: Deleting An Aal2 Trunk Entry
® Chapter 8 Provisioning Connections Using the AQueView System AAL2 Trunk Configuration Table 8-1. Field Descriptions for the AAL2 Trunk Config Entry Window Field Name Values Description Traffic Flow Default: Duplex This field presents the direction of the flow of data traffic in ;...
Page 327: Creating Connections
® Chapter 8 Provisioning Connections Using the AQueView System Creating Connections Figure 8-13. Delete AAL2 Trunk Config Entry Confirmation Window b. Do one of the following: ~ Double-click the entry you want to delete. ~ Click the entry you want to delete, and select Display from the right mouse menu.
Page 328: Using The Right-Click Menu
® Chapter 8 Provisioning Connections Using the AQueView System Using the Right-Click Menu • Attempting to create a connection that already exists • Attempting to use a VCI, VPI, DCLI, or channel that is already allocated elsewhere For more information about these SNMP trap messages, see the appendix ®...
Page 329: Context-Sensitive Help
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Context-Sensitive Help When you right-click on a field in a connection configuration window, a description of that field appears (see Figure 8-15): Figure 8-15. Sample of Context-Sensitive Help (As Displayed on a Display Connection Window) Provisioning PVC Connections Adding ATM-to-ATM VCC PVC Connections...
Page 330 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Creating an ATM-to-ATM VCC PVC Connection Begin Note: On the DS1 IMA and E1 IMA modules, you must provision PVC connections on the virtual port (port 7). You can use up to three channels on port 7 (the channels you provision on port 7).
Page 331 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-17. Create ATM-to-ATM_VCC Connection Window Buttons The buttons on this window have the following functions: Button Function • Close Closes this window. • Create Establishes the connection you configured. •...
Page 332 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-3. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description Interface Side Side A of the connection that will send and receive signals. A:ATM_UNI30, ATM_UNI31, ATM_UNI40,...
Page 333 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-3. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traf- fic descriptor combination specifies which traffic parameters are used for traffic control, determines the number and type of cells that are admitted into a congested queue, and deter-...
Page 334 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-3. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description Peak Rate(0+1) Default: 1 Peak cell rate (PCR) for all cells with both the CLP=0 bit and (cps) the CLP=1 bit.
Page 335: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-3. Field Values for the ATM-to-ATM VCC PVC Connection Window Field Names Values Description OAM Status Default: Unsupp OAM is not in use. End-Pt The PSAX system is used as a termination point for ATM traf- fic, and will process AID/RDI cells.
Page 336: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-18. Display Connection: ATM-to-ATM PVC (Primary Page) Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. •...
Page 337 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-19. Display Connection: ATM-to-ATM_VCC (Statistics Page) Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 338 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Field Descriptions The fields on this window are described in Table 8-4. Table 8-4. Field Descriptions for the ATM-to-ATM VCC and ATM-to-ATM VPC Connection Statistics Page Field Name Description AIS Received Number of alarm indication signal (AIS) cells received.
Page 339: Polling Statistics Using The Odometer Delta
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Polling Statistics Perform the steps in the following procedure to use the odometer on the Using the Odometer Statistics page. Delta Using the Odometer Delta to Poll Statistics Begin 1 Click Odometer.
Page 340: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-21. Odometer Delta Window (Displaying Message) 3 To stop polling, click Display Results. The resulting odometer values are displayed (see the figure below). Figure 8-22. Odometer Delta Window (Displaying Results) 4 To reset the values in this window to zero, click Reset Odometer.
Page 341: Field Descriptions
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-23. Display Connection: ATM-to-ATM_VCC (Backup Page) Backup Page Buttons The buttons on the Backup page have the following functions: Button Function • Create Backup PVC Establishes the backup PVC connection you configured.
Page 342 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-5. Field Values for the Display Connection: ATM-to-ATM_VCC Backup Page Field Name Values Description Slot Listed as available from Select the slot containing the module for the PSAX device which you are creating a connection.
Page 343: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-5. Field Values for the Display Connection: ATM-to-ATM_VCC Backup Page Field Name Values Description Automatic Yes (default) CPU monitors primary connection. If pri- Switchback mary connection becomes available, backup will switch back connection to primary.
Page 344 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec • 10 sec •...
Page 345: Adding Atm-To-Atm Vpc Vcc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 346 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-25. Create Connection Window 3 On the Side A and Side B panels, select the desired slot, port, and channel to identify the connection endpoints within the PSAX system. Based on these parameters, the corresponding connection type appears in the ATM Connection Type field at the bottom of the window.
Page 347 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-26. Create ATM-to-ATM_VPC Connection Window Buttons The buttons on this window have the following functions: Button Function • Close Closes this window. • Create Establishes the connection you configured. •...
Page 348 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-6. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description Interface Side One side of the connection that will send and receive sig- A:ATM_UNI30, nals.
Page 349 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-6. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description Service Type Ubr (default), PSAX system-supported quality of service (QoS) class. See Vbr-nrt2, the Reference Appendix in this guide for more Vbr-nrt1, information.
Page 350 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-6. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description Peak Rate(0+1) Default: 1 cps Peak cell rate (PCR) for all cells with both the CLP=0 bit (cps) and the CLP=1 bit.
Page 351: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-6. Field Descriptions for the ATM-to-ATM VPC PVC Connection Window Field Names Values Description OAM Status Default: Unsupp OAM is not in use. End-Pt The PSAX system is used as a termination point for ATM, and will process AIS/RDI cells.
Page 352 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-27. Display Connection: ATM-to-ATM VPC (Primary Page) Statistics Page The Statistics page displays the statistics for this connection (see Figure 8-28). ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 8-46...
Page 353 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-28. Display Connection: ATM-to-ATM VPC (Statistics Page) Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 354 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-7. Field Descriptions for the ATM-to-ATM VCC and ATM-to-ATM VPC Connection Statistics Page Field Name Description AIS Received Number of alarm indication signal (AIS) cells received. (display only) AIS Transmitted Number of AIS cells transmitted.
Page 355: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Polling Statistics Perform the steps in the following procedure to use the odometer on the Using the Odometer Statistics page. Delta Using the Odometer Delta to Poll Statistics Begin 1 Click Odometer.
Page 356: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-30. Odometer Delta Window (Displaying Message) 3 To stop polling, click Display Results. The resulting odometer values are displayed (see the figure below). Figure 8-31. Odometer Delta Window (Displaying Results) 4 To reset the values in this window to zero, click Reset Odometer.
Page 357 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-32. Display Connection: ATM-to-ATM VPC (Backup Page) Backup Page Buttons The buttons on the Backup page have the following functions: Button Function • Create Backup PVC Establishes the backup PVC connection you configured.
Page 358 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-8. Field Descriptions for the ATM-to-ATM_VPC Backup Page Field Name Values Description Slot Listed as available Select the slot containing the module for which from the PSAX you are creating a connection.
Page 359: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-8. Field Descriptions for the ATM-to-ATM_VPC Backup Page Field Name Values Description Automatic Yes (default) CPU monitors primary connection. If primary Switchback connection becomes available, backup will switch back connection to primary.
Page 360 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec • 10 sec •...
Page 361: Adding Bridge-To-Atm Vcc Pvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 362 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-34. Create Connection Window 3 Select the appropriate slot, port, and channel for each side to select a Bridge and ATM interface. The type of connection appears in the Connection Type field at the bottom of the window.
Page 363 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-35. Create Bridge_to_ATM VCC Connection Window Buttons The buttons on this window have the following functions: Button Function • Close Closes this window. • Create Establishes the connection you configured. •...
Page 364 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-9. Field Values for the Bridge-to-ATM_PVC Connection Window Field Names Values Description Interface Side A: The bridge side of the connection that will send and receive Bridge signals.
Page 365 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-9. Field Values for the Bridge-to-ATM_PVC Connection Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traf- fic descriptor combination specifies which traffic parameters are used for traffic control, determines the number and type of cells that are admitted into a congested queue, and deter- mines whether high-priority cells are tagged as low-priority...
Page 366: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-9. Field Values for the Bridge-to-ATM_PVC Connection Window Field Names Values Description Sustained Cell 1 (default) Sustainable cell rate (SCR) with CLP=0 (high priority) cells or Rate (cps) the peak cell rate with CLP=0 cells.
Page 367: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-36. Display Connection: Bridge-to-ATM PVC (Primary Page) Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. •...
Page 368 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-37. Display Connection: Bridge-to-ATM PVC Statistics Page Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 369 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Field Descriptions 6 Select the values for the fields on this window from the values given in Table 8-10. Table 8-10. Field Values for the Bridge-to-ATM VCC Connection Statistics Page Field Name Description Cells Encoded...
Page 370: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-10. Field Values for the Bridge-to-ATM VCC Connection Statistics Page Field Name Description AIS Transmitted Number of AIS cells transmitted. (display only) Cells Dropped Number of cells dropped on incoming side of interface A or B. (display only) Cells Tagged Number of cells tagged on incoming side of interface A or B.
Page 371 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • Create Backup PVC Establishes the backup PVC connection you configured. Note: You cannot create a backup PVC connection without selecting an ATM interface type in the Backup ATM Interface panel. Therefore, this button is active when the Slot, Port, and Channel fields correspond to an ATM interface type in the Interface field.
Page 372 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-11. Field Values for the Display Connection: Bridge-to-ATM_VCC Backup Page Field Name Values Description Interface AtmUni3_0 The interface type that is configured on the slot, port, and channel (selected in the Slot, Port, and Channel (display only) AtmUni3_1 fields).
Page 373: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Utilization Page The Utilization page measures the amount of traffic running through this connection (see Figure 8-39). Figure 8-39. Display Connection: Bridge-to-ATM PVC (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons Button Function...
Page 374 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function Poll+ continuously updates the statistics and changes • Poll the button label to Poll-. Poll- terminates polling and changes the button label to Poll+. • Show Cells/Sec Calculates and displays the average number of cells per second for a given PVC or SPVC for a given time interval specified in the pull-down menu (see...
Page 375: Adding Circuit Emulation-To-Atm Vcc Pvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Applied, but unsaved configuration data will not be lost unless the PSAX system is restarted, or if power to the PSAX system is lost. Terminating the AQueView EMS will not cause the applied values to be lost because the configuration data is stored on the PSAX system, not in the AQueView EMS.
Page 376 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections 4 Click Create. The Create Bridge_to_ATM_VCC Connection window will appear (see Figure 8-35). Figure 8-41. Create Bridge_to_ATM VCC Connection Window Buttons The buttons on this window have the following functions: Button Function •...
Page 377 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-12. Field Values for the Bridge-to-ATM_PVC Connection Window Field Names Values Description Interface Side A: The bridge side of the connection that will send and receive Bridge signals.
Page 378 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-12. Field Values for the Bridge-to-ATM_PVC Connection Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traf- fic descriptor combination specifies which traffic parameters are used for traffic control, determines the number and type of cells that are admitted into a congested queue, and deter- mines whether high-priority cells are tagged as low-priority...
Page 379: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-12. Field Values for the Bridge-to-ATM_PVC Connection Window Field Names Values Description Sustained Cell 1 (default) Sustainable cell rate (SCR) with CLP=0 (high priority) cells or Rate (cps) the peak cell rate with CLP=0 cells.
Page 380: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-42. Display Connection: Bridge-to-ATM PVC (Primary Page) Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. •...
Page 381 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-43. Display Connection: Bridge-to-ATM PVC Statistics Page Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 382 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Field Descriptions 6 Select the values for the fields on this window from the values given in Table 8-10. Table 8-13. Field Values for the Bridge-to-ATM VCC Connection Statistics Page Field Name Description Cells Encoded...
Page 383: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-13. Field Values for the Bridge-to-ATM VCC Connection Statistics Page Field Name Description AIS Transmitted Number of AIS cells transmitted. (display only) Cells Dropped Number of cells dropped on incoming side of interface A or B. (display only) Cells Tagged Number of cells tagged on incoming side of interface A or B.
Page 384 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • Create Backup PVC Establishes the backup PVC connection you configured. Note: You cannot create a backup PVC connection without selecting an ATM interface type in the Backup ATM Interface panel. Therefore, this button is active when the Slot, Port, and Channel fields correspond to an ATM interface type in the Interface field.
Page 385 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-14. Field Values for the Display Connection: Bridge-to-ATM_VCC Backup Page Field Name Values Description Interface AtmUni3_0 The interface type that is configured on the slot, port, and channel (selected in the Slot, Port, and Channel (display only) AtmUni3_1 fields).
Page 386: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Utilization Page The Utilization page measures the amount of traffic running through this connection (see Figure 8-39). Figure 8-45. Display Connection: Bridge-to-ATM PVC (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons Button Function...
Page 387 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function Poll+ continuously updates the statistics and changes • Poll the button label to Poll-. Poll- terminates polling and changes the button label to Poll+. • Show Cells/Sec Calculates and displays the average number of cells per second for a given PVC or SPVC for a given time interval specified in the pull-down menu (see...
Page 388: Adding Frame Relay-To-Atm Vcc Pvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Applied, but unsaved configuration data will not be lost unless the PSAX system is restarted, or if power to the PSAX system is lost. Terminating the AQueView EMS will not cause the applied values to be lost because the configuration data is stored on the PSAX system, not in the AQueView EMS.
Page 389 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections or if one of the selected channels is unconfigured, None appears in the Connection Type field. 4 Click Create. The Create Frame_Relay-to-ATM_VCC Connection window appears (see Figure 8-47). Figure 8-47.
Page 390 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • Create Establishes the connection you configured. • Copy Copies this configuration information to a range of inter- faces. Field Descriptions 5 Select the values for the fields on this window from the values in Table 8-15.
Page 391 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-15. Field Descriptions for the Frame_Relay-to-ATM_VCC Connection Window Field Names Values Description Excess Burst Size Default: Measured in bits per second. (bits) 45000000 Committed Info Default: 0 Committed information rate is the rate of traffic Rate (measured in bits per second) for a given connection...
Page 392 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-15. Field Descriptions for the Frame_Relay-to-ATM_VCC Connection Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traffic descriptor combination specifies which traffic parameters are used for traffic control, deter- mines the number and type of cells that are admitted into a congested queue, and determines whether...
Page 393: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-15. Field Descriptions for the Frame_Relay-to-ATM_VCC Connection Window Field Names Values Description Connection Status Inactive, Active This field displays the current status of the connec- tion. The value indicates whether the connection is (display only) passing traffic.
Page 394: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-48. Display Connection: Frame_Relay-to-ATM_VCC (Primary Page) Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. • Create Establishes the connection youconfigured.
Page 395 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-49. Display Connection: Frame_Relay-to-ATM_VCC Window (Statistics Page) Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 396 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function Restarts counting in the Cells Transmitted and • Odometer Cells Received fields in the Interface Side A (Only on the and Interface Side B panels, and to view the ATM-to-ATM VCC PVC transmitted cells and received cells in the Inter- face Side A and Interface Side B panels.
Page 397: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-16. Field Descriptions for the Frame Relay-to-ATM VCC Connection Statistics Page Field Name Description cell Drop/Tag Number of cells dropped and tagged on incoming side of ATM interface B. Cells Received Number of cells Received into ATM Interface side B during the amount of time shown in Time Elapsed field since the...
Page 398 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Backup Page Buttons The buttons on the Backup page have the following functions: Button Function • Create Backup PVC Establishes the backup PVC connection you configured. Note: You cannot create a backup PVC connection without selecting an ATM interface type in the Backup ATM Interface panel.
Page 399: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-17. Field Descriptions for the Display Connection: Frame Relay_to_ATM_VCC Backup Page Field Name Values Description Interface AtmUni3-0 The interface type that is configured on the slot, port, and channel (selected in the Slot, (display only) AtmUni3-1 Port, and Channel fields).
Page 400 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-51. Display Connection: Frame_Relay-to-ATM_VCC (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 8-94...
Page 401 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec • 10 sec •...
Page 402: Adding An In-Band Management Atm Pvc Connection
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 403 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-52. Site Specific Page (Displaying Site-Specific Page) 2 Click the In-Band Mgmt tab. The In-Band Mgmt page appears (see Figure 8-53). ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 404 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-53. In-Band Mgmt Page 3 In the In-Band Mgmt page, enter the primary in-band management IP address and IP mask for the PSAX device. Note: This address must be on a different subnet from the subnet that is assigned to the Ethernet interface for the management host.
Page 405 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections AQueView EMS will not cause the applied values to be lost because the configuration data is stored on the PSAX system, not in the AQueView EMS. Creating an In-Band- Creating an In-Band-to-ATM VCC PVC Connection to-ATM Connection Begin...
Page 406 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-55. In-Band_Management_IP_PVC Connection Window Buttons The buttons on this window have the following functions: Button Function • Close Closes this window. • Create Establishes the connection you configured. •...
Page 407 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-18. Field Descriptions for the In-Band ATM PVC Connection Configuration Window Field Name Values Description Destination IP Varies Enter the IP address and the IP mask for one of the follow- Address, and ing depending on your in-band management scheme: Subnet IP Mask...
Page 408 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-18. Field Descriptions for the In-Band ATM PVC Connection Configuration Window Field Name Values Description Cnfrm Type Note: The type of traffic control option used for ATM cells.
Page 409: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-18. Field Descriptions for the In-Band ATM PVC Connection Configuration Window Field Name Values Description Sustained Cell Default: 1 Sustainable cell rate (SCR) with CLP=0 (high priority) cells Rate (cps) or the peak cell rate with CLP=0 cells.
Page 410: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-56. Display Connection: In-Band_Management_IP_PVC (Primary Page) Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. • Create Establishes the connection youconfigured.
Page 411 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-57. Display Connection: In-Band Management IP PVC (Backup Page) Backup Page Buttons The buttons on the Backup page have the following functions: Button Function • Create Backup PVC Establishes the backup PVC connection you configured.
Page 412 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-19. Field Values for the Display Connection: In-Band_Management_IP_PVC Backup Page Field Name Values Description Slot Listed as available Select the slot containing the module for which you from the PSAX are creating a backup connection.
Page 413: Adding Vbr-To-Atm Vcc Pvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-19. Field Values for the Display Connection: In-Band_Management_IP_PVC Backup Page Field Name Values Description Automatic Yes (default) CPU monitors primary connection. If primary con- Switchback nection becomes available, backup will switch back connection to primary.
Page 414 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-58. Create Connection Window 3 Select the appropriate slot, port, and channel for a module that is configured with one of the following interfaces for Side A: ~ HDLC Passthrough ~ Terminal Emulation The interface name is displayed at the bottom.
Page 415 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-59. Create VBR_to_ATM VCC Connection Window Buttons The buttons on this window have the following functions: Button Function • Close Closes this window. • Create Establishes the connection you configured. •...
Page 416 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-20. Field Values for the VBR-to-ATM _VCC Connection Window Field Names Values Description Interface SideA: The VBR side of the connection that will send and receive HDLC_PASS signals.
Page 417 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-20. Field Values for the VBR-to-ATM _VCC Connection Window Field Names Values Description Sustained Cell Default: 1 Sustainable cell rate (SCR) with CLP=0 (high priority) Rate (cps) cells or the peak cell rate with CLP=0 cells.
Page 418 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-20. Field Values for the VBR-to-ATM _VCC Connection Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traffic descriptor combination specifies which traffic (displayed on the parameters are used for traffic control, determines the Traffic Parame-...
Page 419: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-20. Field Values for the VBR-to-ATM _VCC Connection Window Field Names Values Description OAM Status Default: Unsupp OAM is not in use. End-Pt The PSAX system is used as a termination point for ATM traffic, and will process AIS/RDI cells.
Page 420: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-60. Display Connection: VBR-to-ATM_VCC Window (Primary Page) Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. •...
Page 421 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-61. Display Connection: VBR-to-ATM_VCC Window (Statistics Page) Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 422 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function • Close Closes this window. • Restart Restarts connection establishment procedure for the connections that were not previously set up. Field Descriptions The fields on this window are described in Table 8-21: Table 8-21.
Page 423: Backup Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-21. Field Descriptions for the VBR-to-ATM VCC PVC/SPVC Connection Statistics Page Field Name Description AIS Received Number of alarm indication signal (AIS) cells received. (display only) AIS Transmitted Number of AIS cells transmitted.
Page 424 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-62. Display Connection: VBR-to-ATM_VCC Window (Backup Page) Backup Page Buttons The buttons on the Backup page have the following functions: Button Function • Create Backup PVC Establishes the backup PVC connection you con- figured.
Page 425 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-22. Field Descriptions for the Display Connection: VBR-to-ATM_VCC Backup Page Field Name Values Description Slot Listed as available Select the slot containing the module for which from the PSAX you are creating a connection.
Page 426: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-22. Field Descriptions for the Display Connection: VBR-to-ATM_VCC Backup Page Field Name Values Description Automatic Yes (default) CPU monitors primary connection. If primary Switchback connection becomes available, backup will switch back connection to primary.
Page 427 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Utilization Page The buttons on the Utilization page have the following functions: Buttons Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: •...
Page 428: Adding Vbr-To-Vbr Vcc Pvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 429 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-64. Create Connection Window 3 Select the appropriate slot, port, and channel for a module that is configured with one of the following interfaces on the Side A panel: ~ HDLC Passthrough interface ~ Terminal Emulation The interface name appears at the bottom.
Page 430 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-65. Create VBR-to-VBR Connection Window Buttons The buttons on this window have the following functions: Button Function • Close Closes this window. • Create Establishes the connection you configured. •...
Page 431 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-23. Field Values for the VBR-to-VBR PVC Connection Window Field Names Values Description Slot The slot number containing the module for which you are creating a connection. (display only) Port The port number on the module for which you are...
Page 432 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-23. Field Values for the VBR-to-VBR PVC Connection Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traffic descriptor combination specifies which (displayed on traffic parameters are used for traffic control, deter- the Traffic...
Page 433: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Table 8-23. Field Values for the VBR-to-VBR PVC Connection Window Field Names Values Description Service Type Ubr (default) Multiservice Media Gateway system-supported qual- ity of service (QoS) class. See the section, “Quality of Vbr-nrt2, Service Classes for ATM Traffic,”...
Page 434: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Primary Page Buttons The buttons on the Primary page have the following functions: Button Function • Close Closes this window. • Create Establishes the connection youconfigured. • Copy Copies this configuration information to to a range of inter- faces.
Page 435: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function Poll + continuously update the statistics and • Poll changes the button label to Poll-. Poll- terminates polling and changes the but- ton label to Poll+. Restarts counting in the Cells Transmitted and •...
Page 436 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Figure 8-68. Display Connection: VBR-to-VBR PVC (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: •...
Page 437 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning PVC Connections Button Function Poll+ continuously updates the statistics and changes • Poll the button label to Poll-. Poll- terminates polling and changes the button label to Poll+. • Show Cells/Sec Calculates and displays the average number of cells per second for a given PVC or SPVC for a given time interval specified in the pull-down menu (see...
Page 438: Provisioning Svc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Applied, but unsaved configuration data will not be lost unless the PSAX system is restarted, or if power to the PSAX system is lost. Terminating the AQueView EMS will not cause the applied values to be lost because the configuration data is stored on the PSAX system, not in the AQueView EMS.
Page 439: Editing Atm-To-Atm Vcc Svc Connection Entries
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections For instructions on adding IISP VBR and IISP CBR routing entries, see ® the appropriate PacketStar Module User Guide, or the appropriate ® AQueView Element Management System User Guide. After enabling this IISP link, ATM-to-ATM SVC connections can be dynamically created by the PSAX system.
Page 440: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Figure 8-70. Listing Page (Menu Displayed) The Display Connection window appears with tabs that contain details about the connection (see Figure 8-71): Primary, Statistics, and Utilization. Primary Page The Primary page displays the information used to create the connection (see Figure 8-71).
Page 441 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Field Descriptions The values for the fields in this window are described in Table 8-25. Table 8-25. Field Values for the Display Connection: ATM-to-ATM_SVC Window Field Names Values Description Slot Varies depending...
Page 442 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Table 8-25. Field Values for the Display Connection: ATM-to-ATM_SVC Window Field Names Values Description Cnfrm Type The type of traffic control option used for ATM cells. The traf- fic descriptor combination specifies which traffic parameters are used for traffic control, determines the number and type of cells that are admitted into a congested queue, and deter-...
Page 443 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Table 8-25. Field Values for the Display Connection: ATM-to-ATM_SVC Window Field Names Values Description Peak Default: 1 Peak cell rate (PCR) for all cells with both the CLP=0 bit and Rate(0+1) the CLP=1 bit.
Page 444: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Table 8-25. Field Values for the Display Connection: ATM-to-ATM_SVC Window Field Names Values Description OAM Status Default: Unsupp OAM is not in use. End-Pt The Multiservice Media Gateway is used as a termination point for ATM.
Page 445 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Figure 8-72. Display Connection:ATM-to-ATM SVC (Statistics Page) Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 446: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Table 8-26. Field Values for the ATM-to-ATM VCC /VPC SVC/SVP Statistics Window Field Names Values Description Interface A Statistics The ATM interface side of the connection that will send and receive signals.
Page 447 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Figure 8-73. Display Connection:ATM-to-ATM SVC (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: •...
Page 448 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Button Function • Show Cells/Sec Calculates and displays the average number of cells per second for a given PVC or SPVC for a given time interval specified in the pull-down menu (see above).
Page 449: Configuring Iisp Routing Data
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Configuring IISP Routing Data This section describes how to add, modify, and delete routing information for IISP VBR and CBR data. The procedures for these processes begin in the IISP Routing page (see Figure 8-74).
Page 450: Menu Options
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Menu Options When you click the right mouse button in either of the panels, a menu appears (see Figure 8-75 and Figure 8-76) with options as described in Table 8-27.
Page 451 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Creating a VBR or Adding a VBR or CBR Routing Data CBR Routing Table Entry Begin Before you can set up IISP routing, you must configure the port from which you want to route traffic with the ATM UNI or ATM IISP interface.
Page 452 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections The IISP Routing page appears (see Figure 8-74). 8 To create an IISP VBR routing entry, click the right mouse button within the IISP VBR Routing Table panel. To create an IISP CBR routing entry, click the right mouse button within the IISP CBR Routing Table panel.
Page 453 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Buttons The buttons in these windows have the following functions: Button Function • Add Saves the entry into the system. • Delete Deletes the entry from the table. (appears only after the routing entry has been created)
Page 454: Deleting A Routing Table Entry
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Table 8-28. Field Values for the IISP VBR and IISP CBR Routing Entry Windows Field Name Values Description Interface Unconfigured The interface for this channel is not configured. (display only) AtmUni3-0, Indicates that the channel is configured for the...
Page 455 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SVC Connections Deleting a Routing Entry Begin 1 Click the IISP Routing tab in the Provisioning window. The IISP Routing page appears (see Figure 8-74). 2 In the IISP Routing table, do one of the following (a or b): a.
Page 456: Provisioning Spvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-82. Delete Confirmation Window (Using the Delete Button) 3 Click Yes. The entry is removed from the routing table. 4 On the VBR IISP Routing Entry window or CBR IISP Routing Entry window, click Close.
Page 457 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-83. Create Connection Window 3 On the Side A panel, select the appropriate slot, port, and channel for a module that is configured with an ATM interface. The interface name appears in the Interface field.
Page 458 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-84. Create ATM-to-ATM_SPVC Connection Window Buttons The buttons on this window have the following functions: Button Function • Retrieve Remote If you have previously established an NSAP address NSAP Address database, click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex)
Page 459 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-29. Field Values for the ATM-to-ATM VCC SPVC Connection Window Field Names Values Description Interface Side Side A (PVC side)of the connection that will send and A:ATM_UNI30, receive signals.
Page 460 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-29. Field Values for the ATM-to-ATM VCC SPVC Connection Window Field Names Values Description Peak Cell Rate Default: 1 Peak cell rate (PCR) for all cells with both the CLP=0 bit (cps) and the CLP=1 bit.
Page 461 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-29. Field Values for the ATM-to-ATM VCC SPVC Connection Window Field Names Values Description Connection Default: The type of connection. ActiveSvc attempts calls. Pas- Type ActiveSvc siveSvc accepts calls. PassiveSvc Note: Many fields disappear in this mode.
Page 462: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-29. Field Values for the ATM-to-ATM VCC SPVC Connection Window Field Names Values Description Last Releases Last release diagnosis. Explains how the connection was Diagnostic released and reported by the far end of the connection. (displays only On the Display Connection...
Page 463 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-85. Display Connection:ATM-to-ATM_SPVC (Primary Page) Primary Page Buttons The buttons at the bottom of the window have the following functions: Button Function • Retrieve Remote If you have previously established an NSAP address NSAP Address database, click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex)
Page 464 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • Restart Restarts the connection. • Poll Continuously update the statistics and changes the button label to Poll-. Terminates polling. Changes the button label to Poll+. Statistics Page The Statistics page displays the statistics for this connection (see Figure 8-86).
Page 465 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function Restarts counting in the Cells Transmitted and • Odometer Cells Received fields in the Interface Side A (Only on the and Interface Side B panels, and to view the ATM-to-ATM VCC PVC transmitted cells and received cells in the Inter- face Side A and Interface Side B panels.
Page 466: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-30. ATM-to-ATM VCC SPVC Statistics Window Field Name Description Cells Dropped Number of cells transmitted out of interface side B during the amount of time shown in Time Elapsed field. Time Elapsed Time, in hours, minutes, and seconds, since last reset.
Page 467 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec • 10 sec •...
Page 468: Adding Circuit Emulation-To-Atm Vcc Spvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 469 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-88. Create Connection Window 3 On the Side A panel, select the appropriate slot, port, and channel for a module that is configured with an circuit emulation interface. The interface name appears in the Interface Type field.
Page 470 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-89. Create Circuit Emulation_to_ATM SPVC Connection Window Buttons The buttons on this window have the following functions: Button Function • Retrieve Remote If you have previously established an NSAP address NSAP Address database, click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex)
Page 471 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Field Descriptions 6 Select the values for the fields on this window from the values given in Table 8-31. Table 8-31. Field Descriptions for the Circuit Emulation-to-ATM SPVC Connection Window Field Names Values Description...
Page 472 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-31. Field Descriptions for the Circuit Emulation-to-ATM SPVC Connection Window Field Names Values Description Coding Transla- None (default), If you want data traffic for this connection to be processed tion MuLaw2muLa through the DSP2x Voice Server modules, do not use the...
Page 473 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-31. Field Descriptions for the Circuit Emulation-to-ATM SPVC Connection Window Field Names Values Description Provision Pas- Automatic Enables automatic end-to-end provisioning (provisioning sive (default) SPVCs in at two different points). When an active SPVC con- End-Point nection is created using the ®...
Page 474: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-31. Field Descriptions for the Circuit Emulation-to-ATM SPVC Connection Window Field Names Values Description Last Release Default: 0 Last release cause. Release cause for a failed call attempt. See Cause the ATM UNI 3.0 specification for more information.
Page 475 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-90. Display Connection: Circuit_Emulation-to-ATM SPVC (Primary Page) Primary Page Buttons The buttons at the bottom of the window have the following functions: Button Function • Retrieve Remote If you have previously established an NSAP address NSAP Address database, click this button to retrieve an entry from...
Page 476: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • Delete Deletes the connection. • Restart Restarts the connection. • Poll Continuously update the statistics and changes the button label to Poll-. Terminates polling. Changes the button label to Poll+. Statistics Page The Statistics page displays the statistics for this connection (see Figure 8-91).
Page 477 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • Update Refreshes the statistics manually. • Clear Resets the resetable statistics to zero. Poll + continuously update the statistics and • Poll changes the button label to Poll-. Poll- terminates polling and changes the but- ton label to Poll+.
Page 478: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-32. Field Descriptions for the Circuit Emulation-to-ATM VCC SPVC Statistics Window Field Names Values Description Received 6.5000 e1 Total number of ATM cells received since odometer was Odometer (default) last reset.
Page 479 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-92. Display Connection: Circuit_Emulation-to-ATM SPVC (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 480 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec • 10 sec •...
Page 481: Adding Vbr-To-Atm Vcc Spvc Connections
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 482 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-93. Create Connection Window 3 Select the appropriate slot, port, and channel for a module that is configured with one of the following interfaces for Side A: ~ HDLC Passthrough ~ Terminal Emulation The interface name appears at the bottom.
Page 483 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-94. Create VBR_to_ATM SPVC Connection Window Buttons The buttons on this window have the following functions: Button Function • Retrieve Remote If you have previously established an NSAP address NSAP Address database, click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex)
Page 484 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-33. Field Values for the VBR-to-ATM _SPVC Connection Window Field Names Values Description Interface Side A The VBR side of the connection that will send and receive signals.
Page 485 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-33. Field Values for the VBR-to-ATM _SPVC Connection Window Field Names Values Description Service Type Ubr (default), Multiservice Media Gateway system-supported quality of Vbr-nrt2, service (QoS) class. Vbr-nrt1, See the appendix for a detailed description of the values for Vbr-rt2,...
Page 486 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-33. Field Values for the VBR-to-ATM _SPVC Connection Window Field Names Values Description Operational Sta- Default: Other None of the types specified below. Establishment Connection is not operational, but call attempts are ongo- (displayed on InProgress ing.
Page 487: Primary Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections If the parameters are valid, the Connections window appears with the new connection in the Listing page, and the Display Connection window appears with tabs that contain details about the connection (see Figure 8-95): Primary, Statistics, and Utilization.
Page 488: Statistics Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • Retrieve Remote If you have previously established an NSAP address NSAP Address database, click this button to retrieve an entry from this list to populate the Remote NSAP Address (Hex) field.
Page 489 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-96. Display Connection: VBR-to-ATM_VCC Window (Statistics Page) Statistics Page The buttons on the Statistics page have the following functions: Buttons Button Function • Update Refreshes the statistics manually. •...
Page 490 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function Restarts counting in the Cells Transmitted and • Odometer Cells Received fields in the Interface Side A (Only on the and Interface Side B panels, and to view the ATM-to-ATM VCC PVC transmitted cells and received cells in the Inter- face Side A and Interface Side B panels.
Page 491: Utilization Page
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Table 8-34. Field Descriptions for the VBR-to-ATM VCC PVC/SPVC Connection Statistics Page Field Name Description Time Since Reset Time elapsed since the last time the Clear button was used. (display only) Note: The Clear button on the statistics page resets only the odometer fields (labelled as Odometer) and the...
Page 492 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-97. Display Connection: VBR-to-ATM_VCC Window (Utilization Page) Utilization Page The buttons on the Utilization page have the following functions: Buttons ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 8-186...
Page 493 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Button Function • 60 sec Time, in seconds or minutes, to poll the PSAX device. Select a time interval from the pull-down menu: • 5 sec • 10 sec •...
Page 494: Deleting A Connection
® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections The Out B or Decoded B column displays cells or bits transmitted from side A to side B (also displayed on the Statistics page in the Cells Transmitted field on the Interface B Statistics panel).
Page 495 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections Figure 8-98. Sample Delete Connection Confirmation Window 3 Click Yes to delete the connection. ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166 8-189...
Page 496 ® Chapter 8 Provisioning Connections Using the AQueView System Provisioning SPVC Connections ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 8-190 255-700-166...
Page 497: Appendix A: Pin Configurations
Pin Configurations Overview of This Appendix This appendix describes the pin assignments for the connectors on the 6-Port DS1 IMA module module. Use the following information to connect correctly configured cables to this module. Configuration for the DS1/T1/E1 Interface Cable Connector This section describes the pinout configuration on the 6-Port DS1 IMA module.
Page 498 Appendix A Pin Configurations Configuration for the DS1/T1/E1 Interface Cable Connector ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar 255-700-166...
Page 499: Appendix B: Reference Tables
Reference Tables Overview of This Appendix This appendix contains reference tables that are helpful while configuring your PSAX Multiservice Media Gateway system. The following types of information are provided: • ATM Traffic Descriptors • ATM User-Network Interface Specification Cause Codes Table, Version 3.1(for Connection Retry) •...
Page 500 Appendix B Reference Tables ATM Traffic Descriptors • Bridge-to-ATM VCC PVC connection • Circuit Emulation-to-ATM VCC PVC connection • Frame Relay-to-ATM VCC PVC connection • In-band ATM PVC connection • VBR-to-ATM VCC PVC connection Traffic Descriptors Supported The available traffic descriptors available are as follows. •...
Page 501: Atm User-Network Interface Specification Cause Codes Table
Appendix B Reference Tables ATM User-Network Interface Specification Cause Codes Table ~ When the connection is configured for variable bit rate (VBR) traffic, the Multiservice Media Gateway drops all CLP=0 cells violating the value set for the SCR in bucket 2. ~ When the connection is configured for constant bit rate (CBR) traffic, the Multiservice Media Gateway drops all CLP=0 cells violating the value set for the PCR in bucket 2.
Page 502 Appendix B Reference Tables ATM User-Network Interface Specification Cause Codes Table Table B-1. ATM User-Network Interface Specification, Version 3.1, Cause Codes Prompts a Number Meaning Retry destination out of order invalid number format (address incomplete) response to STATUS ENQUIRY normal, unspecified requested VPCI/VCI not available VPCI/VCI assignment failure user cell rate not available...
Page 503: Dsp Tone Detection Modes Table
Appendix B Reference Tables DSP Tone Detection Modes Table DSP Tone Detection Modes Table Table B-2. DSP Tone Detection Modes and Associated Processing Performed Tone Mode Processing Performed Disabled Ignores fax tones and modem tones Bypass If a fax tone or modem tone is received, the firmware switches to G.711 mode (64 Kbps) and bypasses echo cancellation, if enough bandwidth is available.
Page 504 Appendix B Reference Tables Industry Compliance Specifications Table Table B-3. Channel Reduction Availability Caused by Fax Relay Connections vs. Voice Processing Connections on a DSP2C Module Number Percent of All DSP Remaining Voice of DSPs Total Connections Connections Processing Available for Fax Assigned for Assigned for Fax...
Page 505 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes Channelized DS3 module af-phy-0054.000 DS3 Physical Interface Specifica- tion E1 IMA module af-phy-0064.000 E1 Physical Layer Specification DS1 IMA, DS3 IMA, and E1 af-phy-0086.000 IMA modules Inverse Multiplexing over ATM...
Page 506 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes ATM Maintenance Mode af-pnni-0066000 In-band Management SVC Private Network-Network Inter- face (PNNI) Addendum (Soft PVC) Channelized DS3, Channelized af-sig-0061.000 STS-1e, DS1 IMA, DS3 IMA, E1 User-Network Interface (UNI) IMA, DS3 ATM, E3 ATM, Enhanced DS1, Enhanced E1,...
Page 507 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes Carrier Group AIS Alarm af-vtoa-0078.000 Includes 56 (DS1), Nx64 (DS1, I.610 OAM F4/F5 Processing Circuit Emulation Service 2.0 (remote defect indication [RDI] and alarm indication signal [AIS]) Channelized DS3, Channelized...
Page 508 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes Unstructured DS3/E3 CES mod- ANSI T1.102 DS3 Electrical Interface Charac- teristics CSU/DSU loopback ANSI T1.105 Enhanced DS1, DS3 ATM, OC- Synchronous Optical Network- 3c Single-Mode/Multi- Basic Description...
Page 509 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes GR-303 DLC Services ANSI T1.409 Network-to-Customer Installa- tion Interfaces- Analog Voice Grade Special Access Lines Using E&M Signaling GR-303 DLC Services ANSI T1.602 VTOA AAL2 Trunking Narrow- Integrated Services Digital Net-...
Page 510 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes High Speed, Multi-serial mod- EIA-530 ule, and Quadserial modules Defines mechanical/electrical interfaces between DTEs and DCEs that transmit serial binary data ETSI 300 012-1 Integrated Services Digital Net-...
Page 511 Internetworking Implementa- Enhanced DS1, Enhanced E1, tion Agreement High-Density E1, Medium-Den- sity DS1, Multi-Serial, Quadse- rial, and Route Server modules AC 60, PSAX 20, PSAX 1250, GR-63-CORE PSAX 2300, PSAX 4500 Network Equipment Building Standards (NEBS): Physical Pro- tection Tones and Announcements...
Page 512 Section 5.2.5 T1.207a Server modules and Section 6.1.2.3 For type 108 termination test, refer to Section 5.3.1 T1.207a and Section 6.1.2.4 AC 60, PSAX 20, PSAX 1250, GR-1089-CORE (NEBS) PSAX 2300, PSAX 4500 Electromagnetic Compatibility and Electrical Safety—Generic Criteria for Network Telecom-...
Page 513 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes I.610 OAM F4/F5 Processing GR-2980-CORE Coordination protocol cell is (remote defect indication [RDI] used for automatic protection General Criteria for ATM Layer and alarm indication signal switching (APS) Protection Switching Mecha-...
Page 514 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes IETF RFC 1595 Definitions of Managed Objects for the SONET/SDH Interface Types IETF RFC 1661 Point-to-Point Protocol IETF RFC 1662 PPP in HDLC-like Framing IETF RFC 1700 Assigned Numbers...
Page 515 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes DSP2C/D Voice Server modules ITU-T G.164 Fax/modem detection Transmission Systems and Media Apparatus Associated with Long-Distances Telephone Circuits and Other Terminal Equipment: Echo Suppressors DSP2A, B, C, D Voice Server ITU-T G.165...
Page 516 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes DSP2A, B, C, D Voice Server ITU-T G.711 modules General Aspects of Digital Trans- 64 Kbps fax encoding mission Systems Terminal Equipment: Pulse Code Modu- lation (PCM) of Voice Frequen- cies...
Page 517 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes OC-3c APS modules ITU-T G.783 Transmission Systems and Media, Digital Systems and Net- works— Digital Transmission Systems—Terminal Equip- ment—Principal Characteristics of Multiplexing Equipment for the Synchronous Digital Hierar- chy: Characteristics of Synchro-...
Page 518 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes ITU-T G.964 ITU-T G. 964 and G.965 are functionally equivalent to ETSI V-Interfaces at the Digital Local EN 300 324-1 and ETSI EN 300 Exchange (LE)- V5.1 Interface 347-1 respectively.
Page 519 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes ITU-T I.321 Integrated Services Digital Net- work (ISDN) Overall Network Aspects and Functions, ISDN User-Network Interfaces: B- ISDN Protocol Reference Model and its Application ITU-T I.356 ABR not supported...
Page 520 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes Channelized DS3, Channelized ITU-T I.371 ABR not supported STS-1e, DS3 Frame Relay, High- Traffic control and congestion Density E1, Medium-Density control in B-ISDN DS1, Multi-Serial and Quadse- rial modules...
Page 521 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes ITU-T I.432.3 B-ISDN User-Network Interface: Physical Layer Specification for 1.544 Mbps and 2.048 Mbps ITU-T I.432.4 B-ISDN User-Network- Physical Layer Specification: 51 840 Kbps Operation Carrier Group AIS Alarm ITU-T I.610...
Page 522 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes • AAL1 Trunking CCS (Q.931) ITU-T Q.931 • AAL1 Trunking CCS Switching and Signaling - Digi- (Q.931/QSIG), AAL1 Trunk- tal subscriber Signalling System ing CAS No.
Page 523 Appendix B Reference Tables Industry Compliance Specifications Table Table B-4. Industry Compliance Specifications Feature Name/ Product Name Specification Title Notes ITU-T Q.2971 B-ISDN—DSS 2—User-network interface layer 3 specification for point-to-multipoint call/con- nection control ITU-T V.8 Procedures For Starting Sessions of Data Transmission Over the General Switched Telephone Network ITU-T V.25...
Page 524: Interface Type By Connection Type Table
Appendix B Reference Tables Interface Type by Connection Type Table Interface Type by Connection Type Table Table B-5. Interface Type by Connection Type Table Interface Connection AAL2 Trunking ATM-to-ATM vir- tual channel con- nection (VCC) PVC ATM-to-ATM vir- tual path connec- tion (VPC) PVC Bridge-to-ATM VCC PVC...
Page 525: Interface Type By I/O Module Type Table
Appendix B Reference Tables Interface Type by I/O Module Type Table Table B-5. Interface Type by Connection Type Table Interface Connection Circuit emulation- to-ATM VCC SPVC Frame relay-ATM VCC SPVC VBR-to-ATM VCC SPVC Indicators in this column apply only to the OC-3c APS 1+1 MM/SM modules and the STM-1 MSP 1+1 MM/SM modules Interface Type by I/O Module Type Table Table B-6 shows the available interface types for each PacketStar PSAX I/O...
Page 526 Appendix B Reference Tables Interface Type by I/O Module Type Table Table B-6. Interface Types by I/O Module Types Interface Module E1 Interface Modules 6-Port E1 IMA ( IMA E1 6-Port Enhanced E1 Multiservice ( E1 ENH 21-Port High-Density E1 Multiservice ( HD E1 DS3 and E3 Interface Modules 1-Port Channelized...
Page 527 Appendix B Reference Tables Interface Type by I/O Module Type Table Table B-6. Interface Types by I/O Module Types Interface Module OC-3c Interface Modules 1-Port OC-3c Multimode with AQueMan ( OC-3C (MM 1-Port OC-3c Single-Mode with AQueMan ( OC-3C (SM 1-Port OC-3c Multimode with Traffic Shaping (...
Page 528 Appendix B Reference Tables Interface Type by I/O Module Type Table Table B-6. Interface Types by I/O Module Types Interface Module 1-Port STM-1 Multimode with Traffic Shaping ( STM-1 (MM 1-Port STM-1 Single-Mode with Traffic Shaping ( STM-1 (SM TS) 1-Port STM-1 1+1 MSP Multimode ( STM-1 MM...
Page 529: Minimum Aal2 Trunk Size Requirements Tables
Appendix B Reference Tables Minimum AAL2 Trunk Size Requirements Tables Table B-6. Interface Types by I/O Module Types Interface Module Quadserial ( QUAD SERIAL 6-Port Multiserial SERIAL Ethernet Interface Module Ethernet ( ENET Port 2 only. Minimum AAL2 Trunk Size Requirements Tables Setting up channels with multiplex structure helps reduce delay of traffic.
Page 530: Example Using Table B-7 Data For 32 Kbps
Appendix B Reference Tables Minimum AAL2 Trunk Size Requirements Tables Example Using Table B-7 Data for 32 Kbps At 32 Kbps compression rate (from Table B-7): For sending 4,000 voice samples (bytes) per second, including the AAL2 header in cells per second (cps) in the calculation: 4,000 samples / 20 samples received from DSP x 23 bytes to be packed into an AAL2 cell, where 23 bytes = 20 bytes of data in the cps packet and 3 bytes...
Page 531 Appendix B Reference Tables Module Alarm Status Table Fax relay mode contains 20 msec of data for every CPS packet, so the cell rate is more efficient than for voice codec. The change in bandwidth is controlled by the DSP host code. If insufficient bandwidth is available on the AAL2 trunk, the fax will be forced to a lower rate.
Page 532 Appendix B Reference Tables Quality of Service (QoS) Information Tables Table B-11. Alarm Status Descriptions for PSAX Modules Num- Module Type Alarm Status Affected Description Minus48vFailed Power Supply The -48 V dc Power Supply has failed. UnknownAlarm The reason for failure is not known.
Page 533 Appendix B Reference Tables Quality of Service (QoS) Information Tables Table B-13 illustrates the attributes of the classes of service supported by the Multiservice Media Gateway system software. Table B-13. Class of Service Descriptions Variable Bit Rate Real Variable Bit Constant Bit Time Rate Non-real...
Page 534 Appendix B Reference Tables Quality of Service (QoS) Information Tables Table B-14. Cell Loss and Cell Delay Characteristics of ATM Service Classes QoS Classes ATM Classes of Supported by Cell Loss Cell Delay Internal Service PSAX Systems Tolerance Tolerance Priority Variable Bit Classes 3, 4 Medium...
Page 535: Glossary
Glossary Numeric 1+1 APS (automatic protection In a North American SONET, 1+1 protection switching is switching) commonly referred to as automatic protection switching (APS). See APS for additional information. 1+1 MSP (multiplex section protec- In a European synchronous digital hierarchy (SDH) network, tion) 1+1 protection switching is commonly referred to as multi- plex section protection (MSP).
Page 536 Glossary available bit rate. ABR changes after a connection is estab- lished, and allows the receiving device to accept data from a variety of transmitting devices which are operating at differ- ent speeds, without the need to set up data rates in advance. ACELP algebraic code excited linear prediction.
Page 537 Glossary A-Law This ITU-T companding standard used in PCM systems for conversion between analog and digital signals. The A-Law standard is primarily used in European telephone networks. algebraic code excited linear predic- See ACELP. tion alterable mark inversion See AMI. alternating current See AC.
Page 538 Glossary AQueMan algorithm A traffic management system that also supports ATM Forum classes of service. This adaptive algorithm allocates bandwidth by statistically multiplexing traffic within two sets of queues according to weighted priorities. One set of queues addresses the avoidance of cell loss, which is normally a concern for data traffic, while the other manages cell transfer delay, which is critical to voice and some video traffic.
Page 539 Glossary ATM edge switch A device that resides at the edge of a carrier network and pro- vides access from the end user to a carrier’s ATM network backbone. ATM Forum This organization is a consortium of corporations who develop hardware and software products using ATM to facili- tate the development, deployment, and standardization of ATM protocols and specifications.
Page 540 Glossary B8ZS bipolar 8-zero substitution. This encoding scheme is used for transmitting data bits over T1 transmission systems. This scheme is “smarter” than the B7ZS scheme, because it trans- parently adds a one-bit as needed to ensure that no more than seven zero-bits are ever transmitted in a row.
Page 541 Glossary bearer channel This basic communication channel has no enhanced or value- added services other than bandwidth transmission capability. Bellcore (this organization is now The research and development arm formed by the Regional known as Telcordia Technologies) Bell Operating Companies (RBOCs). Bellcore, now Telcordia Technologies, focused on developing standards and proce- dures for the RBOCs.
Page 542 Glossary basic rate interface. This interface is composed of two B-chan- nels (bearer channels) at 64 Kbps and a data D-channel (data channel) at 16 Kbps. The bearer B-channels are designed for PCM voice, slow-scan video conferencing, Group 4 facsimile data, or other types of data that can fit into a full-duplex 64,000 bps channel.
Page 543 Glossary call control A term used by the telephone companies to describe the set- ting up, monitoring, and tearing down of telephone calls. First Person Call Control is done by a person or a computer via a desktop telephone, or a computer attached to that tele- phone, or the computer attached to the desktop phone line.
Page 544 Glossary common-channel signaling. A high-speed, packet-switched communications network, distinctive from public packet switched and message networks. CCS is used to carry addressed signaling messages for individual trunk circuits and/or database-related services between signaling points in the CCS network. CD-ROM Compact Disk, Read-Only Memory. A disk on which large amounts of digitized read-only data can be stored.
Page 545 Glossary cell-aging A capability that prevents the lowest-priority data (for exam- ple, IP data) from being buffered in the PSAX system indefi- nitely. The AQueMan algorithm keeps track of how long each cell stays in the buffer. The lower the priority of the traffic, the longer its cell-aging timer;...
Page 546 Glossary chassis A reference to the physical hardware, frame, and mother- board into which are inserted the power supply, stratum, CPU, and I/O modules. The supporting legs and brackets are not considered to be part of the chassis. checksum The sum of a group of data items used for checking errors. chip Short for microchip, an very complex, yet tiny module that stores computer memory or provide logic circuitry for micro-...
Page 547 Glossary cell loss priority. A bit in the ATM cell header set to 0 or 1. CLP=1 cells may be discarded in congested transmission to preserve the cell loss ratio of CLP=0 cells. Some service categories generate traffic flows with cell loss priority markings, CLP=0 (higher priority) and CLP=1 (lower priority).
Page 548 Glossary conformance type The type of traffic control option used for ATM cells. A traffic descriptor combination that specifies which traffic parameters are used for traffic control; determines the number and type of cells that are admitted into a congested queue; and deter- mines whether high-priority cells are tagged as low-priority cells when traffic exceeds the traffic parameter thresholds.
Page 549 Glossary core switch A Broadband Switching System (BSS) which is located in the core of the network. Conceptually equivalent to a Tandem Office in the voice world, a core switch serves to interconnect "edge switches," which provide user access to the broadband network much as Central Offices do in the circuit switched voice world.
Page 550 Glossary channel service unit. Along with a Data Service Unit (DSU), a CSU is a component of Data Circuit-terminating Equipment (DCE). A CSU connects a digital telephone line to a cus- tomer’s network-access equipment. It can be built into the network interface of the network-access equipment, or it can be a separate device.
Page 551 Glossary DB-25 The standard 25-pin connector used for RS-232 serial data communications. This connector has 13 pins in one row, and 12 in the next. DBCES dynamic bandwidth circuit emulation service. This feature is used with voice PVC connections to best utilize the available network bandwidth.
Page 552 Glossary digital signal processor See DSP. digital signal, level 1 See DS1. digital signal, level 3 See DS3. digital signal, level zero See DS0. digital subscriber line access multi- See DSLAM. plexer digital subscriber lines See DSL. DIP switch Dual In-line Position switch. A small switch used to select the operating mode of a device.
Page 553 Glossary digital Signal, level 3. The North American Digital Hierarchy signaling standard transmission at 44.736 Mbps that is used by a T3 carrier. DS3 supports 28 DS1s plus overhead. In a channel application, it supports 672 channels, each at 64 kbps.
Page 554 Glossary dual-tone multi-frequency See DTMF. duplex Simultaneous two-way transmission in both directions. dynamic bandwidth circuit emula- See DBCES. tion service The European equivalent of the North American 1,544 Mbps T1, except that E1 carries information at the rate of 2.048 Mbps.
Page 555 Glossary EEPS End-to-End Provisioning Server. A server that provides ser- vice-level provisioning, and allows a network management system to issue commands that will set up connections to go throughout the network without needing to set up connec- tions on each individual switching device. egress The direction of traffic leaving a device (for example, sent out of the line card).
Page 556 Glossary error-tolerant addressing scheme A way to protect the cell header by establishing multiple vir- tual circuits to the same destination. The addresses for the cir- cuits are within the error space of the principal address used for actual transmission. Thus, the most probable error pat- terns occurring in the address field simply changes the address to another valid one.
Page 557 Glossary fault monitoring In network management, the set of functions that (a) detect, isolate, and correct malfunctions in a telecommunications network, (b) compensate for environmental changes, and (c) include maintaining and examining error logs, accepting and acting on error detection notifications, tracing and identifying faults, carrying out sequences of diagnostics tests, correcting faults, reporting error conditions, and localizing and tracing faults by examining and manipulating database information.
Page 558 Glossary flash A type of nonvolatile memory. Flash memory is functionally similar to EPROM memory, but it must be erased in blocks, whereas EPROM can be erased one byte at a time. Because of its block-oriented nature, flash memory is commonly used as a supplement to, or a replacement fork in, hard disks in per- sonal computers.
Page 559 Glossary Frame Relay/ATM PVC Service See FRF.8. Interworking Implementation Agreement framing The data-formatting conventions that allow a receiver to syn- chronize with the transmitting end of a circuit. For example, T-1 frames contain an 8-bit sample from each of the 24 chan- nels on the interface (192 bits total) plus a framing bit (for a total of 193 bits).
Page 560 T1 circuits. This standard allows a remote terminal such as a central office PacketStar PSAX Multiservice Media Gateway to interface with a central office voice switch, such as the Lucent Technologies 5ESS switch. graphical user interface See GUI.
Page 561 Glossary Greenwich Mean Time See GMT. guaranteed bit rate See GBR. guaranteed frame rate See GFR. graphical user interface. This type of user interface uses graphics such as windows, icons, pull-down menus, and a pointer icon; for example, the Windows, Macintosh, and UNIX operating systems use this interface.
Page 562 Glossary HP OpenView A Hewlett-Packard application often referred to in Release ® Notes with the AQueView system. A wiring device that has multiple connections of network and internetworking modules. Active hubs amplify or repeat sig- nals to extend a LAN’s distance, while passive hubs split up the transmission signal, allowing the administrator to add users to a LAN.
Page 563 Glossary IISP Interim Inter-Switch Signaling Protocol. An ATM Forum defined protocol employing UNI-based signaling for switch- to-switch communication in private networks. Unlike PNNI, IISP relies on static routing tables and makes support for QoS an alternate routing option. ILEC Incumbent Local Exchange Carrier. One of the Baby Bell companies, for example.
Page 564 Glossary interface 1. Hardware microprocessor (chip) on a DSPx voice process- ing module. Also see channel. 2. An end-to-end connection protocol that governs the trans- mission parameters of a configured port or channel interface. Examples: ATM UNI 4.0, PNNI, IISP. Interface management entity See IME.
Page 565 Glossary IP Address A unique numerical identifier that is assigned by a system administrator to any station or other device that uses IP. Each address is a 32-bit string expressed in four octets in decimal notation, such as 323.34.45.67, with one portion for the net- work number and another the host address.
Page 566 Glossary A kilobyte, defined as 1024 bytes. Kbps Kilobits per second, the amount of data transferred in a sec- ond between two end points. For example, 1 Kbps is 1024 bits per second. keep alive/heartbeat timer A polling method a PSAX chassis uses to ensure connections are up;...
Page 567 Glossary link Another name for a communications channel or circuit. The ATM Forum defines a link as an entity that defines a topolog- ical relationship (including available transport capacity) between two nodes in different subnetworks. Synonymous with logical link. link access procedure-D See LAPD.
Page 568 Glossary loop emulation This service uses the ATM AAL-2 network to essentially cre- ate an extension cord between voice ports on the CPE and the corresponding voice ports on the class 5 switch, that termi- nates on the GR-303-based voice gateway. The interface between the CPE and the first ATM-based edge switch or DSLAM may be T1 or xDSL.
Page 569 Glossary megabits per second See Mbps megabyte See MB. megaohm A resistance of 1,000,000 ohms. Management Information Base. A database of network per- formance information. millisecond See msec. mixed circuit emulation Mixed voice/data traffic on a single private access line. MMAQ A Multi-Mode module which uses the AQueMan algorithm MMTS...
Page 570 IP to be routed over a single ATM VCC using the MAC header. Multiservice Media Gateway A Lucent Technologies ATM access concentrator/switch that efficiently forwards data, handling incoming calls for a net- work point of presence (POP). In general, a Multiservice...
Page 571 Glossary NEBS Network Equipment Building Standard. A standard that defines a rigid, extensive set of performance, quality, environ- mental, and safety standards. They range from fire spreading and extinguishability tests to earthquake tests, thermal shock measures, cyclic temperature, mechanical shock, and electro- static discharge standards.
Page 572 Glossary nonscrambled An undistorted or scrambled voice or data communication type. non-switched mode The setting fused to establish a point-to-point line. NRTL Nationally Recognized Testing Laboratory NSAP network service access point. The Open Systems Interconnec- tion (OSI) generic standard for a network address consisting of 20 octets.
Page 573 ® ® PacketStar PSAX family of products The Lucent Technologies PacketStar PSAX Multiservice Media Gateways are a product line of scalable, flexible multi- service ATM access devices offered to service providers’ cen- tral offices, and small to large enterprises.
Page 574 Glossary payload scrambling The removal of long strings of 1s and 0s that could be mis- taken as error conditions. payload type indicator See PTI. private branch exchange. Originally a switch inside a private business, part of a manual device that requires an operator to complete the call.
Page 575 Glossary PING packet internet groper. A utility program, originally used in the Internet, to test whether a destination can be reached by sending it an Internet Control Message Protocol (ICMP) echo request and waiting for a reply; it also tests for delay. PING server A utility serving PINGs;...
Page 576 Glossary PRI ISDN Integrated Services Digital Network with Primary Rate Inter- face service. A network with 24 B (bearer) channels, each of which is a full 64,000 bits per second. One of these channels is typically used to carry signaling information for other 23 channels.
Page 577 Glossary PTSP PNNI Topology State Packet. The PNNI routing packet used to exchange reachability and resource information between ATM switches. It is also designed to ensure that a connection request is routed on a path with high probability of meeting quality of service standards.
Page 578 Glossary rate shaping The transmission of ATM cells onto the ATM network at a peak cell rate, based on an algorithm. For frame relay traffic, the PSAX system software automatically calculates egress peak cell rate based on frame relay traffic parameters. For Ethernet traffic, the user must configure the egress peak cell rate.
Page 579 Glossary routing information protocol. A set of rules based on dis- tance-vector algorithms that measure the shortest path between points on a network. Each router maintains a rout- ing table or database with this information and periodically broadcasts it to neighboring routers. RJ-11, registered jacks.
Page 580 Glossary RSRS-232RS-449RS-530 recommended standard. Standards often set by the EIA (Elec- tronic Industries Association), the TIA (Telecommunications Industry Association), or both (EIA/TIA). RS-232 is a set of standards specifying three sets of interfaces (electrical, functional, and mechanical) for communicating between computers, terminals, and modems. Once only available on a 25-pin connector, they now come in a variety of configurations that aren’t always compatible to other devices without add-ons.
Page 581 Glossary sustained cell rate. A parameter defined by the ATM forum for ATM traffic management. The SCR is an upper bound on the conforming average rate of an ATM connection over time scales which are long enough relative to those for which the peak cell rate (PCR) is defined.
Page 582 Glossary service types A category of data transmission provided by a public data net- work in which the data signaling rate, the terminal operating mode, and the code structure, are standardized. Note: Class of service (service types) are defined in CCITT Recommendation X.1.
Page 583 Glossary simplex The operation of a channel in only one direction with no abil- ity to operate in the other direction. single in-line memory module See SIMM. single-mode See SM. single-mode fiber A fiber that allows only a single mode of light to propagate. single mode.
Page 584 Glossary software release distribution See SRD. SONET Synchronous Optical Network. An optical multiplexing inter- face for wideband, high-speed transmission (up to 13.22 Gbps), used mainly in carrier and telecommunications networks. source routing See SR. SPVC SemiPermanent Virtual Circuit. A PVC-type connection in which SVCs are used for call setup and (automatic) rerouting.
Page 585 Glossary Stratum3–4 timing, Stratum 3–4 These terms refer to the stratum level, the clock that lets a module digital network transmission know where it begins and ends. These levels were established by ANSI/TI.101.1987, “Syn- chronization Interface Standards for Digital Networks.” Level one is best, and is usually based on atomic clock or reference oscillator.
Page 586 Glossary Switched Virtual Circuit. A network connection that is cre- ated only as needed, and lasts only the duration of the mes- sage transfer. Used extensively in X.25 and frame relay networks, SVCs are far more complex than permanent virtual circuits, as they automatically consider the level of network congestion, including at both end points, and dynamically balance the network, by transmitting on a route specifically...
Page 587 Glossary time-division multiplex. A method of transmitting a number of separate voice, data, and/or video signals simultaneously over one communications medium by interleaving a piece of each signal, one after another. TDMA time-division multiplex access. One of several technologies used to separate multiple conversation transmissions over a finite allocation of bandwidth.
Page 588 Glossary toll routing The intra-switching of long distance telephone calls. tone detection A signal provided by a network or modem. When a CO detects this signal, it is sent through the network to an active call center. topology The configuration of a communication network. The physical topology is the way the network looks.
Page 589 Glossary tree A data structure containing zero or more nodes that are linked together in a hierarchical fashion. If there are any nodes, one node is the root; each node except the root is the child or one and only one other node; and each node has zero or more nodes as children.
Page 590 Glossary usage parameter control. Network actions used to monitor and control traffic at the end system. UPS detects negotiated parameters violations, and it can take appropriate action to protect against malicious or unintentional misbehavior. Its actions include cell tagging and cell discarding. uplink The connectivity between an ATM border node and an upn- ode.
Page 591 Glossary VBR-NRT variable bit rate-non-real time. A voice service that operates on both a connection and connectionless basis and allows delay variance between the delivery of cell. VBR-NRT is used for data applications that have potentially bursty traffic char- acteristics, including LAN interconnect, CAD/CAM, and mul- timedia.
Page 592 Glossary virtual path identifier See VPI. virtual private network See VPN. virtual router A virtual router is a grouping of IP interfaces. Each virtual router with IP interfaces has its own associated IP routing table, IP ARP table, IP route cache, and IP address pools, and maintains it’s own routing and packet statistics.
Page 593 Glossary xDSL A generic term standing for a variety of digital subscriber line services (the lowercase x standing for generic): ADSL, HDSL, IDSL, SDSL, and VDSL. This family of services provides extremely high bandwidth over the telephone company unshielded twisted-pair lines. Telephone companies are offer- ing these services to compete with the cable TV industry’s high speed access via modem as a way to provide high speed Internet services to consumers.
Page 594 Glossary ® PSAX 6-Port DS1 IMA Module User Guide, Issue 1 Release 7.0 PacketStar Glossary-60 255-700-166...
Page 596 Part Number: 507M0A7001D1 Copyright © 2001 Lucent Technologies All rights reserved.

This manual is also suitable for:

Psax 2300 Psax 1250 Psax 4500 Packetstar ac 60
