PacketStar
PSAX Multiservice Media Gateways
3-Port Channelized DS3/STS-1e Multiservice Protection Module Description and
Specifications

Purpose of This Document

Identifying the Module

®
PacketStar
PSAX Multiservice Media Gateways
3-Port Channelized DS3/STS-1e Multiservice Protection Module Description and Specifications
Part Number: 582M0A0001Z2
This document identifies and describes the 3-Port Channelized DS3/STS-1e Mul-
tiservice Protection module and related safety information. It also includes proce-
dures for installation and removal of the module from the PSAX chassis and veri-
fication of the initial module startup, as well as references to configuration
documentation and troubleshooting assistance. Regulatory standards compliance
is also described for the module.
Instructions on configuring and operating this module, including details on its
N:1 Protection capabilities, can be found in the PacketStar PSAX 3-Port Channelized
DS3/STS-1e Multiservice Protection Module User Guide.
The 3-Port Channelized DS3/STS-1e Multiservice Protection module is illustrated
in Figure 1.
Figure 1. 3-Port Channelized DS3/STS-1e Multiservice
FAIL
ACTIVE
Protection Module
Document Number: 255-700-529
Page 1 of 8
