- Page 1 GRUNDFOS INSTRUCTIONS SMART Digital XL DDA and DDE From 60 to 200 l/h Service instructions Installation and operating instructions Installation and operating instructions http://net.grundfos.com/qr/i/98767821 http://net.grundfos.com/qr/i/98767824...
-
Page 2: Table Of Contents
2.2 Notes operating instructions of the product. 2.3 Diaphragm leakage Installation and operating instructions DDA Special tools • http://net.grundfos.com/qr/i/98767821 3.1 PC Tool for E-Products 3.2 Profi tester Installation and operating instructions DDE 3.3 Hydraulic test unit • http://net.grundfos.com/qr/i/98767824... -
Page 3: Special Tools
See section 6. Firmware update, analog I/O calibration, store/restore settings 3.2 Profi tester The Profi tester is a special tool to check the inputs and outputs of Grundfos dosing pumps. Product number: 99600937 Fig. 2 I/O board plug connector 3.3 Hydraulic test unit The hydraulic test unit is used to check the hydraulic performance 8. -
Page 4: Replacing The Control Cube
5. Replacing the control cube 10. Carefully open the side cover (7) at the front side of the pump, until you can reach the hall sensor plug connector (5) on the 1. Read section 2.2.1 Safety instructions. main circuit board. 2. -
Page 5: Dielectric Voltage Withstand Test
20. Install the side cover again. 6. Firmware update, analog I/O calibration, store/restore settings – Make sure that the cables do not have any sharp bends and are not pinched. 6.1 Required equipment – Make sure the I/O board cable is placed correctly for subsequent I/O board installation. - Page 6 (part. no. 96562934) is required. • The multimeter must have a DC current measuring range of 0- You can find the "PC Tool E-Products" page in GTI (Grundfos 200 mA or 0-400 mA. Technical Information), where you can download the software and find more information: •...
-
Page 7: Updating The Firmware
6.2 Updating the firmware 6.3 Updating the GUI data This kind of update does not affect the pump This kind of update does not affect the pump settings. settings. 1. Make sure you have installed and configured the hardware 1. Make sure you have installed and configured the hardware and software according to section 6.1 Required equipment. -
Page 8: Updating The Motor Controller
6.4 Updating the motor controller 6.5 Calibrating the analog input 1. Make sure you have installed and configured the hardware and software according to section 6.1 Required equipment. This kind of update does not affect the pump 2. Start "PC-Tool E-Products" and click the "Firmware update" settings. -
Page 9: Calibrating The Analog Output
6.6 Calibrating the analog output 6.7 Storing and restoring the pump settings Calibration of the analog output is a two-step process: 1. Make sure you have installed and configured the hardware and software according to section 6.1 Required equipment. • Set the analog output to a reference value of 20 mA and measure the actual current, using a multimeter (expected 2. -
Page 10: Service Kits And Spare Parts
7. Service kits and spare parts For the full range of service kits and spare parts, see the service kit catalogue: • http://net.grundfos.com/qr/i/96488862_23 or the Grundfos Product Center: • https://product-selection.grundfos.com... - Page 11 Phone: +55-11 4393 5533 20th km. Athinon-Markopoulou Av. Telefax: +64-9-415 3250 Turkey Telefax: +55-11 4343 5015 P.O. Box 71 GRUNDFOS POMPA San. ve Tic. Ltd. Sti. Norway Bulgaria GR-19002 Peania Gebze Organize Sanayi Bölgesi GRUNDFOS Pumper A/S Grundfos Bulgaria EOOD...
