Installation Instructions for the
Fire Extinguisher Alarm
Battery Installation:
1.
Remove the (4) phillips head
screws to open the battery
compartment as shown in the
diagram below.
2.
Insert the key, push in and
turn clockwise.
(This places the Alarm in the
"Stand-by" position).
Note: The key can only be
removed in the "ON" position.
3.
Attach a 9-volt alkaline battery
(Not Supplied) to the
connector, and insert the
battery into the compartment.
4.
Replace the cover plate and
the (4) phillips head screws.
(Note: Tighten screw until it
stops–Do Not Over-Tighten).
Fire Extinguisher Alarm System w/Key, Sensor, Adhesive & Strap
SP-1909
(2) 1" x 2" Adhesives
w/ Alcohol Prep Pads
(4) Phillips Head (Cover Plate) Screws
9-volt Alkaline
Battery
(Not Supplied)
Sensor Port
SP-102
Alarm Sensor
Special Beaded Strap
SP-1483
Extra Key
SP-101
SP-101
SP-103
SP-909NP
Sensor Adhesive with
Neoprene
Cover
Plate
Battery
Connector

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP-101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Se-Kure Controls SP-101

  • Page 1 Installation Instructions for the Fire Extinguisher Alarm SP-101 SP-101 Fire Extinguisher Alarm System w/Key, Sensor, Adhesive & Strap SP-102 SP-103 Alarm Sensor Special Beaded Strap SP-1909 SP-909NP SP-1483 (2) 1" x 2" Adhesives Sensor Adhesive with Extra Key w/ Alcohol Prep Pads...
  • Page 2 Your Fire Extinguisher Alarm is now “ON” and ready to )))sound((( an alert when used or tampered. Se-Kure Controls, ® Inc. 3714 Runge Street • Franklin Park, IL 60131 • 1-(800) 322-2435 • (847) 288-1111 • Fax: (847) 288-9999 Rev. 11/21/97 ©1997 Se-Kure Controls, ® Inc. SCI-9596...
