MANUAL
Safety Guidance......................................................................................2
Warning................................................................................................ 2
Precaution............................................................................................ 2
1. Product View
1.1 Appearance................................................................................ 3
1.2
Reference Standard............................................................. 4
1.3
Product Specification............................................................4
1.4
Product Package...................................................................4
1.5
Charging principle................................................................. 5
2.1 Environmental Performance.................................................... 6
2.2 Electrical Properties...................................................................6
2.3 Mechanical Properties...............................................................6
2.4 Product Function........................................................................ 7
3.Instructions and Status Display......................................................7
Please check points before use......................................................... 7
How to start charging......................................................................... 7
How to stop charging......................................................................... 8
4. Troubleshooting............................................................................... 9
5.Installation Instructions.................................................................. 10
5.1 Tools list..................................................................................10
5.2 Installation steps.....................................................................10
5.3 Installation Precautions...........................................................12
After Sale service:................................................................................ 12
Nijverheidslaan +50/56, B-8540 Deerlijk - BELGIUM
Tel +32 56 617 977 - Fax +32 56 617 955
info@batterysupplies.be - www.batterysupplies.be
C o n ten t
BAT/49493
Advertisement
Table of Contents
Related Manuals for AQ-Tron BAT/49493
Summary of Contents for AQ-Tron BAT/49493
-
Page 1: Table Of Contents
MANUAL BAT/49493 C o n ten t Safety Guidance..................2 Warning....................2 Precaution.................... 2 1. Product View 1.1 Appearance................3 Reference Standard............. 4 Product Specification............4 Product Package..............4 Charging principle..............5 2. Technology Index 2.1 Environmental Performance............ 6 2.2 Electrical Properties..............6 2.3 Mechanical Properties...............6 2.4 Product Function................ -
Page 2: Safety Guidance
MANUAL BAT/49493 S afety G u id an c e Warning Strictly forbidden for non-professionals to modify, disassemble or repair the equipment. External wires or adapters/converters are strictly prohibited. Stop using the device immediately when charging failure or abnormality occurs. -
Page 3: Appearance
MANUAL BAT/49493 1.Product Descriptions 22KW AC EV CHARGING STATION is an electric car charging equipment.Its appearance is shown in Figure 1. The product meets the requirements of IEC 61851-1:2017 AC charging system. The upper end is main body The upper end is main body equipped with socket according to EN 62196-2:2017. -
Page 4: Reference Standard
MANUAL BAT/49493 Reference Standard Standard No. Standard No. Electric vehicle conductive charging system – Part 1: 61851-1:2017 General requirements Plugs, socket-outlets, vehicle connectors and vehicle inlets – 62196-2:2017 Conductive charging of electric vehicles – Part 2: Dimensional compatibility and interchangeability requirements for a.c. -
Page 5: Charging Principle
MANUAL BAT/49493 Charging principle Figure3.Charging principle Charging Charging Successful signal Explanation status connection charging or not voltage① connected or not Status1 disconnect 12±1V Fail connect the vehicle Status2 disconnect 9±1V S1 switches to the PWM connected state, and R3 is detected. -
Page 6: Technology Index
MANUAL BAT/49493 2.Tec h n o lo g y In d ex 2.1 Environmental performance Item Specification Working temperature -30℃~~60℃ Storage temperature -40℃~~80℃ Working humidity 5%~~95%，No condensation Charging station IP65 Altitude ≤2000m Salt spray test Meet IEC 61851-1：2017 Atmospheric pressure... -
Page 7: Product Function
MANUAL BAT/49493 2.4 Product Function Specification Item Output current 0-32A Leakage Protection（AC 30mA+DC 6mA） Support Under voltage protection Support Over voltage protection Support Over temperature protection Support Over current protection Support Short circuit protection Support Temperature check Support Screen display Support 3. -
Page 8: How To Stop Charging
MANUAL BAT/49493 insert the charging Remove the protective open the vehicle plug into the socket cap of plug socket cover plug Press start button Start charging Ensure connection OK How to stop charging 1. Method 1 Put the cable on the... -
Page 9: Troubleshooting
MANUAL BAT/49493 Status of voltage plug Connecting status Current Status of Charging capacity charging Charging status Voltage /Current Rated current Charging time 4.Tro u b lesh o o tin g Fault： screen display： resolution： Leakage Protection Stop charging immediately. The relay is cut off and the red light flashes. -
Page 10: Installation Instructions
MANUAL BAT/49493 gear position. When the temperature is lower than 75 ° C, the gear position will automatically recover. Overcurrent protection If the maximum current is higher than the limited, the relay will be permanently cut off, the red light will start to flash, and it needs to be manually powered back on. -
Page 11: Installation Steps
MANUAL BAT/49493 5.2 Installation steps a.Charging station inlet connection It is recommended to use power cable no less than 5*6mm²。 b. Installation and Fixation of Charging Station Please confirm the installation location and mark it (using the bracket strip). The center of the charging station is 45 inches from the ground at least. -
Page 12: After Sale Service
MANUAL BAT/49493 The charging station should be installed close to the position where the plug and electric car are parked for future use. Need to consider the length of the charging station entry and exit. After Sale service: Battery Supplies NV company, ensure the production lines of EV charging line are... - Page 13 MANUAL BAT/49493 Warranty card: Information register Product name Model Warranty date User name Contact phone Mail address Dealers shop Email address Nijverheidslaan +50/56, B-8540 Deerlijk - BELGIUM Tel +32 56 617 977 - Fax +32 56 617 955 info@batterysupplies.be - www.batterysupplies.be...
