MANUAL
Automatic Switch-Mode Battery Charger
IMPORTANT
Read, understand, and follow these safety rules and operating instructions before
using this battery charger. Only authorized and trained service personnel shall be
permitted to operate or perform any maintenance or service. This manual should
be considered a permanent part of your machine and should remain with the
machine at all times. This manual is a supplement to the manuals and
information provided by AQ-TRON
CONTENTS
Safety-------------------------------------------
Operation--------------------------------------
Maintenance----------------------------------
Troubleshooting----------------------------
Replacing the Charger--------------------- 10
Specifications--------------------------------
www.aqtron.com - info@aqtron.com
Part Number AQHF12-15
- 1 -
AQHF12-15
Page
2
5
7
8
11
®
Advertisement
Related Manuals for AQ-Tron AQHF12-15
Summary of Contents for AQ-Tron AQHF12-15
-
Page 1: Table Of Contents
MANUAL AQHF12-15 Automatic Switch-Mode Battery Charger Part Number AQHF12-15 IMPORTANT Read, understand, and follow these safety rules and operating instructions before using this battery charger. Only authorized and trained service personnel shall be permitted to operate or perform any maintenance or service. This manual should be considered a permanent part of your machine and should remain with the machine at all times. -
Page 2: Safety
MANUAL AQHF12-15 Safety Danger Failure to obey the safety rules and instructions in this manual will result in death or serious injury. Label and Safety Rules Legend DANGER Indicates the presence of a hazard that will cause death or serious injury... - Page 3 MANUAL AQHF12-15 Safety: General • Do not operate a charger that is not working correctly. An electric shock hazard or battery explosion hazard from overcharging may exist. • Make sure the charger is the correct voltage and type for the battery or battery pack to be charged.
- Page 4 MANUAL AQHF12-15 Safety: Power • To reduce the risk of an electric shock, connect only to a properly grounded single phase (3wire) outlet. • Ensure that the AC voltage supplied to the charger is within the ranges in the specification table. Voltages outside this range, particularly high voltages, can result in an electric shock and fire hazard.
-
Page 5: Operation
MANUAL AQHF12-15 • Do not touch battery terminals or any exposed electrical parts. Contact with battery terminals or other exposed electrical parts may cause an electric shock. Remove all watches, rings, and jewelry to avoid arcing and electric shock. Initial Installation Only trained technicians with knowledge of the equipment and batteries the charger will be used with should install the charger. - Page 6 MANUAL AQHF12-15 CAUTION: To reduce the risk of fire, use this charger only on AC circuits and extension cords capable of handling the AC Input currents (Max. Amps) defined in the electrical specifications. Use must be in accordance with all National and Local Electrical Codes for the location of use.
- Page 7 MANUAL AQHF12-15 Charging State & LED Display 100% Charging State 0 to 50% charged Blinking 50% to 75% charged Blinking 75% to 100% charged Blinking 100% charged Charge for flooded type batteries Charge for Sealed type batteries See Troubleshooting Blinking Note: X in the table means “don’t care”, LED may be off, blinking, or on.
-
Page 8: Maintenance
MANUAL AQHF12-15 Maintenance WARNING: Disconnect from AC voltage before doing any service. When plugged-in the AC wiring is an electric shock hazard. Disconnecting the DC output wires near the batteries when the charger is ON may cause the batteries to explode resulting in serious injury or death. -
Page 9: Troubleshooting
MANUAL AQHF12-15 Troubleshooting WARNING: Do not operate the charger if it is malfunctioning. Personal injury or property damage could result. Electric shock hazard may cause serious injury or death. WARNING: Do not disassemble the charger. High voltages inside the charger are an electric shock hazard and may result in serious injury or death. - Page 10 MANUAL AQHF12-15 THE AC VOLTAGE IS TOO LOW OR TOO HIGH. CORRECT. (See the electrical specification table for the allowable AC voltage input ranges. This is an unusual problem and would most likely occur with a very poorly regulated engine-generator set providing the AC voltage to the charger) ▶...
-
Page 11: Replacing The Charger
MANUAL AQHF12-15 Replacing the Charger WARNING: Disconnect from AC voltage before doing any service. When plugged-in the AC wiring is an electric shock hazard. Disconnecting the DC output wires near the batteries when the charger is ON may cause arcing and the batteries to explode resulting in serious injury or death. -
Page 12: Specifications
MANUAL AQHF12-15 Specifications Electrical Specifications Item AC Input DC Output 115V (85-132V) Max. 15.3V for Flooded Voltage 230V (170-264V) (14.8V @ 26C for flooded) (Automatically Selects) (14.2V@26°C for GEL/AGM) 4A at 85V Max. Current Max. 15 ADC 2A at 170V...
