Cable Installation; Curtain Attachment; Final Assembly - REP FT-3000 Assembly Instructions

Slide weight stack onto the poles (padded side facing
4.
up) and secure at the top.
Attach curtains.
6.
This step is optional as
it is not neccessary
for safe operation.
x16
(M8x20)
x16
Any issues? Please contact us directly by phone: 720-420-1731, email: info@repfitness.com or
morse code...(.-. . .--. ..-. .. - -. . ... ...). We are always here for our Customers! - Team REP
x4
(M8x30)
x4
x2
x4
x2
Start by screwing in the end of the cable to its starting point on
5.
the pulley carriage. Feed the cable through the pulley system (it
may help to remove some of the pulleys to aid in feeding the
cable through) and attach the ball and carabiner to the end.
7.
Attach shrouds, weight pins and any attachments.
x12
(M8x20)
x12
