Attach blade to TUFFBRACE by Inserting 4 hex bolts (1/4"x3/4") (A) into the 4 holes in the middle of the
blade and fasten to TUFFBRACE with 4 locknuts (B)
2.
Insert remaining hex bolt (A) in the top blade hole and fasten to TUFFBRACE with locknut (B).
3. Insert handle into TUFFBRACE.
4. Drill a 1/4" hole in middle dimple on the backside of
the TUFFBRACE with provided 1/4" Drill Bit (E).
5. Secure handle to TUFFBRACE with 2 screws (3/4") (C)
Insert Hex Bolt (1/4"x2") (D) in drilled hole and fasten
with locknut (B).
NOTE: Screw the two self tapping screws
in the dimple sections on the back of the
TUFFBRACE handle.
THE SNOW PLOW SNOW PUSHER BOSS EDITION
ASSEMBLY INSTRUCTIONS
B
B
B
A
A
B
A
C
B
C
B
A
A
E
D
