Switching on the alarm system (burglar alarm system, BAS)
The person with switching authorization presses his or her transponder near an activation
unit two times in quick succession (within 2 sec.). This sends a signal to all deactivation units
present. If lock contacts are connected to the deactivation units, the DAs first verifies that the
doors have been correctly locked. The digital locking cylinders or Smart Relays are not
deactivated unless this is the case, so that it is no longer possible to enter the secured area.
The activation unit does not receive a positive acknowledgement until all lockings have been
successfully deactivated. It then uses a floating contact to activate the alarm system
externally (compelled signaling). The light emitting diodes of the activation units signal this by
lighting for 2.5 seconds. The light emitting diode(s) on the deactivation unit(s) go out. The
BAS acoustically signals - for example, on the activation unit - that the system has been
successfully activated.
Switching off the alarm system
The person with switching authorization again presses his or her transponder twice in quick
succession within transmitting range of the activation unit. The deactivation units signal this
to the digital locking cylinders or the digital Smart Relays. The LEDs on the activation units
visually signal that the system has been successfully deactivated by blinking 1x short-long.
The LEDs on the deactivation unit(s) light again. (The LEDs on the deactivation units are
used only for testing purposes, so they do not have to be brought out where they can be
seen). Now it is possible to access the doors again with all authorized transponders.
☺
By simply clicking the transponder button within transmitting range of activation units,
you can determine the activation state of the alarm system if the LEDs on the
activation units are brought out where they can be seen.
1 x short-long blinking means "deactivated",
1 x long (2.5 sec.) blinking means "activated"
Activation transponder
For emergencies, you can use the locking plan software to program a transponder that
cancels the deactivation of the locking cylinder so that the doors can be opened with an
authorized transponder. However the alarm system remains activated externally and the
alarm will be triggered.
