  • Page 1 SOM + SREL3.ADV Manual 27.07.2021...

  • Page 2: Table Of Contents

    Content SOM + SREL3.ADV (Manual) 2 / 27 Content General safety instructions........................ 4 Product-specific safety instructions.................... 6 Meaning of the text formatting ...................... 7 Product description........................... 8 Before placing an order .......................... 9 SmartRelay ................................. 9 Determining the number of required modules .................. 9 Acquiring and configuring power supply units................... 9 Determining installation technology and location ................ 9...
  • Page 3 Content SOM + SREL3.ADV (Manual) 3 / 27 Help and other information .........................  26...

  • Page 4: General Safety Instructions

    1. General safety instructions SOM + SREL3.ADV (Manual) 4 / 27 1 General safety instructions Signal word (ANSI Possible immediate effects of non-compliance Z535.6) DANGER Death or serious injury (likely) WARNING Death or serious injury (possible, but unlikely) CAUTION Minor injury...
  • Page 5 1. General safety instructions SOM + SREL3.ADV (Manual) 5 / 27 Damage as a result of mechanical impact This product contains electronic components that may be damaged by mechanical impacts of any kind. 1. Avoid touching the electronics. 2. Avoid other mechanical influences on the electronics.

  • Page 6: Product-Specific Safety Instructions

    2. Product-specific safety instructions SOM + SREL3.ADV (Manual) 6 / 27 2 Product-specific safety instructions IMPORTANT SimonsVoss Technologies GmbH accepts no liability for any damage caused by incorrect installation. IMPORTANT You must observe the manufacturer's warranty and installation conditions if you use other manufacturers' products with a SmartOutput module.

  • Page 7: Meaning Of The Text Formatting

    3. Meaning of the text formatting SOM + SREL3.ADV (Manual) 7 / 27 3 Meaning of the text formatting This documentation uses text formatting and design elements to facilitate understanding. The table explains the meaning of possible text formatting: Example...

  • Page 8: Product Description

    4. Product description SOM + SREL3.ADV (Manual) 8 / 27 4 Product description The SmartOutput module features eight potential-free relay outputs, which can be actuated using SmartRelay Advanced. Depending on the transponder ID, one or several outputs can be activated for a programmable time interval.

  • Page 9: Before Placing An Order

    5. Before placing an order SOM + SREL3.ADV (Manual) 9 / 27 5 Before placing an order 5.1 SmartRelay At least one SmartRelay is required to operate a SmartOutput module. To order a SmartRelay, read the manual concerned on the required SmartRelay or contact us (see Help and contact).

  • Page 10: Before Installation

    6. Before installation SOM + SREL3.ADV (Manual) 10 / 27 6 Before installation 1. Unpack the SmartOutput module. 2. Check the SmartOutput module for external damage. 3. Connect the SmartOutput module and a reader to a SmartRelay. 4. Power the SmartOutput module.

  • Page 11: Installation

    7. Installation SOM + SREL3.ADV (Manual) 11 / 27 7 Installation Before installation [  10] ü SmartOutput module tested (see DIN rails available for installation. ü 1. Fit the SmartOutput module onto the DIN rail. 2. Switch off the power supply.

  • Page 12: Connections

    8. Connections SOM + SREL3.ADV (Manual) 12 / 27 8 Connections 10 11 12 13 14 Circuit Explanation board Brownout detection: Open collector, connected to GND if supply voltage is sufficient. This output activates if the supply voltage at V falls below 10.0 V...
  • Page 13 8. Connections SOM + SREL3.ADV (Manual) 13 / 27 Circuit Explanation board Relay 4: Potential-free contact (NC treated as NO in software); activated depending on authorisations. Relay 3: Potential-free contact (NC treated as NO in software); activated depending on authorisations.
  • Page 14 8. Connections SOM + SREL3.ADV (Manual) 14 / 27 Circuit Explanation board . Connection for power supply. Equipped with a detachable bridge to K2 (number 23) ex works. AUX relay: Coil's plus connection. AUX relay activates if coil is connected to power.

  • Page 15: Connection To The Smartrelay

    9. Connection to the SmartRelay SOM + SREL3.ADV (Manual) 15 / 27 9 Connection to the SmartRelay This is how you connect the SmartOutput module to a third-generation SmartRelay controller (SREL3.ADV or SREL3.ADV.ZK). 1(1) < 1(2) 2(1) < 2(2) Controller...

  • Page 16: Connecting A Fire Alarm System Emergency Release

    9. Connection to the SmartRelay SOM + SREL3.ADV (Manual) 16 / 27 SmartOutput module Power supply unit 9.2 Connecting a fire alarm system emergency release If the relay in the fire alarm system opens, this interrupts the SmartOutput module's power supply, closing Outputs 1 to 8.
  • Page 17 9. Connection to the SmartRelay SOM + SREL3.ADV (Manual) 17 / 27 SmartOutput module Actuator Power supply unit for SmartOutput- module Power supply unit for actuator...

  • Page 18: Programming And Configuration

    10. Programming and configuration SOM + SREL3.ADV (Manual) 18 / 27 10 Programming and configuration 10.1 General information 1. Connect the SmartOutput module with a SmartRelay. 2. Connect the components to the power supply. 3. Programme the controller. NOTE The SmartOutput module can only be programmed on the controller.

  • Page 19: Setting The Pulse Length

    10. Programming and configuration SOM + SREL3.ADV (Manual) 19 / 27 Module Address Module 8 Module 9 Module 10 Module 11 Module 12 Module 13 Module 14 Module 15 1. Press the sides of the transparent inlay together. 2. Remove the transparent inlay.
  • Page 20 10. Programming and configuration SOM + SREL3.ADV (Manual) 20 / 27 IMPORTANT Only invert when the power supply is connected If the power supply fails, the relay contacts on the SmartOutput module will also remain closed (NC) when switching behaviour has been inverted.

  • Page 21: Signal

    11. Signal SOM + SREL3.ADV (Manual) 21 / 27 11 Signal 11.1 LEDs for each output Each of the eight outputs has an assigned LED. This LED indicates the output's status. Green Output closed Output open 11.2 Status LED There is also a three-colour RGB LED which indicates the SmartOutput module's status.

  • Page 22: Technical Specifications

    12. Technical specifications SOM + SREL3.ADV (Manual) 22 / 27 12 Technical specifications Housing Housing: Polycarbonate plastic, fibre-reinforced  Material Cover: Polycarbonate plastic  Housing: green similar to RAL 6021 (pale green)  Colour Cover: transparent  Standard protec- IP20...
  • Page 23 12. Technical specifications SOM + SREL3.ADV (Manual) 23 / 27 Contact material AgNi+Au Service life (elec- 12 V  / 10 mA: typ. 5 × 10 switching cycles trics) Service life Typically 100 × 10 switching cycles (mechanical) Bounce time Typically 1 ms, max. 3 ms 15 G for 11 ms, 6 shocks as per IEC 68-2-27; not tested...
  • Page 24 12. Technical specifications SOM + SREL3.ADV (Manual) 24 / 27 IMPORTANT Take voltage drop into account The resistance in copper produces a voltage drop, the size of which de- pends on the cable gauge, current flow and cable length. The power supply lines must be adequately dimensioned.

  • Page 25: Eu/Uk Declaration Of Conformity

    13. EU/UK Declaration of conformity SOM + SREL3.ADV (Manual) 25 / 27 13 EU/UK Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article MOD.SOM8 complies with the following guidelines: 2014/30/EU "EMC"  as well as the corresponding UK statutory 2016 No. 1091 "EMC"...
  • Page 26 14. Help and other information SOM + SREL3.ADV (Manual) 26 / 27 14 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: www.simons-voss.com/en/documents.html Declarations of conformity You will find declarations of conformity and other certificates on the website: www.simons-voss.com/en/certificates.html...
  • Page 27 This is SimonsVoss SimonsVoss, the pioneer in remote-controlled, cable-free locking technology provides system solutions with a wide range of products for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems combine intelligent functionality, high quality and award- winning design Made in Germany. As an innovative system provider, SimonsVoss focuses on scalable systems, high security, reliable components, powerful software and simple operation.
