Simons Voss Technologies 3066 Manual page 12

VdS Shunt lock Function 3066
2.3.2. Connecting Power Supply, Switch Contacts and Sabotage Contacts:
Power supply
Connect the positive pole of a direct current source between +8 ... + 16 V (recommended:
+12 V) to soldering terminal 1. Note that the voltage is not permitted to exceed a value of
+16 V under any circumstances.
Connect soldering terminal 2 to ground.
External light emitting diode
You can connect an external light emitting diode to soldering terminals 3 and 4 for visual
signaling. When the transponder is operated successfully, the LED blinks. Maximum length of
the line: 10 m (33 feet).
Switch contacts
Connect them to the alarm system. Soldering terminal 5 is the common contact, 6 is for the
electric strike and 7 for the make contact. Refer to the BAS installer instructions for the wiring
and values for the terminating resistor(s).
Rx : wire jumper; Ry : wire jumper; Rz : terminating resistor
Sabotage contacts
Connect them to soldering terminals 8 to 11. Solder the Rs resistor (terminating resistor or
short circuit) to soldering pins X27 and X28 (refer to the drawing).
Global activation suppression (optional)
Applies ground (such as pin 15 or pin 2) to pin 13 over a floating contact so that the system
cannot be activated.
2.3.3. Connecting Deactivation Request, Deactivation Acknowledgement and
Activation Request
Refer to Chapter 2.5.
VdS Version E12
Version: December, 2003
