Honeywell CN70 Series Service Work Instructions

Hide thumbs

Advertisement

TITLE
CN70 Service Work Instructions
Revision History
Rev
ECN Number
A
328667
B
332785
C
333989
D
334270
E
335283
Description
Initial release
Added details on new part numbers for Soutwest
Arilines CN70 with the straight shot EA30
imager.
Added details on proper antenna wire routing.
Extensive numerous updates to reflect part
number corrections, changes, and additions since
original release
Updated with details on Government
configurations also added repair and test flow
Added part numbers and repair information for
changes driven by Pasion/refresh program. New
keypads/keyboards, LCD, touch panel, and MLB.
Updated operation section for recommended
repair/test flow. Added scan window operation.
Model
DOCUMENT NO.
CN70A,CN70E
SWICN70-000
Updated Pages
4, 7, 15, 26, 28, 31,
32
PAGE
Page 1 of 45
Released by
Dave Cook
Aaron Ward
Dave Cook
Aaron Ward
Dave Cook

Advertisement

Table of Contents
loading

  Also See for Honeywell CN70 Series

  Related Manuals for Honeywell CN70 Series

  Summary of Contents for Honeywell CN70 Series

  • Page 1 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 1 of 45 Revision History ECN Number Description Updated Pages Released by 328667 Initial release Dave Cook 332785 Added details on new part numbers for Soutwest 4, 7, 15, 26, 28, 31, Aaron Ward Arilines CN70 with the straight shot EA30 imager.
  • Page 2: Table Of Contents

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 2 of 45 Table of Contents Repair & Test Flow ................................... 3 Stylus ........................................ 4 Handstrap ......................................5 Keypad Overlay ....................................7 Bottom Housing ....................................8 Scan Window ....................................11 Camera Windows ....................................
  • Page 3: Repair & Test Flow

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 3 of 45 Repair & Test Flow OPERATION: The following repair and test flow process must be followed to ensure that a unit being repaired is properly tested and configured.
  • Page 4: Stylus

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 4 of 45 Stylus OPERATION: The stylus is attached to the bottom housing. Un-loop it’s tether from the retaining slot in the bottom cover to remove and/or replace it. Installation is reverse order of removal. The CN70A & CN70E use the same part. Do not use the original gray colored stylus.
  • Page 5: Handstrap

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 5 of 45 Handstrap OPERATION: The handstrap is attached to the bottom housing. It can be removed and installed without opening the unit. Tools Required Description Part Number Small straight blade screwdriver tweezers Parts Required...
  • Page 6 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 6 of 45 2. On a CN70A push the webbing through the slot in the battery latch until the retaining pin is exposed. A small straight tipped screwdriver may be useful here since the pin fits tight in the battery latch. Remove the retaining pin and slide the webbing out of the slot in the battery latch.
  • Page 7: Keypad Overlay

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 7 of 45 Keypad Overlay OPERATION: Tools Required Description Part Number Small straight blade screwdriver or Xacto knife Isopropyl alcohol solution Parts Required Item Part Number Description option 355-464-001 CN70A QWERTY Overlay option 355-465-001 CN70A Numeric Overlay...
  • Page 8: Bottom Housing

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 8 of 45 Bottom Housing OPERATION: The bottom housing will need to be removed to access internal assemblies or if it needs to be replaced. The CN70A bottom housing is secured with 8 screws while the CN70E bottom housing is secured with 10 screws. Tools Required Description Part Number...
  • Page 9 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 9 of 45 SWA bottom housing SWA straight imager window Standard angled window Removal 1. Remove the stylus from its storage slot in the back cover. 2. Remove the two plugs that cover a screw at each side of the battery compartment. 3.
  • Page 10 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 10 of 45 4. Gently pull the bottom housing away from the unit at the scan engine end as shown. 5. Rotate the bottom housing away from the rest of the unit exposing the I/O flex cable as shown. 6.
  • Page 11: Scan Window

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 11 of 45 Scan Window OPERATION: The scan window is not replaceable. It is ultrasonically welded to the bottom housing. Any scan window failures will require replacing the entire bottom housing. Refer to the bottom housing operation. Tools Required Description Part Number...
  • Page 12: Camera Windows

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 12 of 45 Camera Windows OPERATION: The camera windows in the bottom housing can be replaced as needed. These will also need to be installed anytime a bottom housing assembly is replaced. There are two identical windows covered by a single trim overlay. The windows can be replaced individually or both at the same time.
  • Page 13: Side Scan Buttons

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 13 of 45 7. Re-install bottom housing assembly. Side Scan Buttons OPERATION: The side scan button assemblies in the bottom housing can be replaced as needed. The assemblies can be replaced individually or both at the same time.
  • Page 14: Vibrator Motor

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 14 of 45 Vibrator Motor OPERATION: The vibrator motor is friction fit into the bottom housing assembly. Tools Required Description Part Number T10 Torx driver Parts Required Item Part Number Description 324-024-001 Vibrator motor...
  • Page 15: Core Assembly

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 15 of 45 Core Assembly OPERATION: The core assembly will need to be removed from the top housing in order to access and/or replace assemblies attached to the magnesium frame, to replace the magnesium frame, or to replace the top housing assembly. Tools Required Description Part Number...
  • Page 16: Battery Board

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 16 of 45 Battery Board OPERATION: The Battery board hosts the pogo pin connection to the main battery, the reset switches, and the main unit backup power supercap. The CN70A & CN70E use the same battery board part number. Tools Required Description Part Number...
  • Page 17: Scan Bracket Assembly

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 17 of 45 Scan Bracket Assembly OPERATION: The scan bracket assembly hosts the main unit speakers and scan handle sensor. It also provides the platform to which is attached the EA30 scan engine, camera, WAN/WiFi antenna, and side scan PCB’s. Servicing this assembly will generally require that it be removed from the CN70A.
  • Page 18 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 18 of 45 Removal 1. Remove the bottom housing assembly (refer to Bottom Housing operation). 2. Disconnect the scan switch/speaker harness from the main logic board. 3. Using a T7 torx driver remove 4 screws that secure the scan bracket to the core assembly. Scan switch/speaker harness connector 4.
  • Page 19 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 19 of 45 Installation 1. Position the scan bracket assembly over the main logic board and attach the scanner flex and camera flex cables.. 2. Connect the 802.11 antenna coax to J4 on the main logic board. 3.
  • Page 20: Side Scan Pcb's

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 20 of 45 Side Scan PCB’s OPERATION: The side scan PCB’s are located on the scan bracket assembly one on each side. They can be removed and installed without removing the scan bracket assembly.
  • Page 21: Keyboard Pcb

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 21 of 45 Keyboard PCB OPERATION: There are two styles of keyboard/keypad assemblies that have been produced. Original production used a conductive trace and puck keyboard/keypad combination (shown at left in picture below). Current production uses a snap dome switch and plunger keyboard/keypad combination (shown at right in picture below).
  • Page 22 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 22 of 45 Connection to battery board Connection to main logic board Installation 1. Position the keyboard PCB assembly over the magnesium frame lining its connectors up with mating connectors on the main logic board and battery board.
  • Page 23: Top Housing

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 23 of 45 Top Housing OPERATION: A CN70 top housing includes the plastic housing, keypad, antenna(s), LED light pipe, and cell speaker. None of these items can be individually replaced as they are bonded and heat staked at the factory in order to achieve the IP67 rating for the product.
  • Page 24 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 24 of 45 Parts Required CN70E Top Housings Item Part Number Description option 715-571S-007 Housing,Top Numeric Wan Assy CN70 option 715-693S-001 Housing,Top Dome Num WAN Assy option 715-571S-008 Housing,Top Numeric Lan Assy CN70 option 715-693S-002 Housing,Top Dome Num LAN Assy...
  • Page 25: Lcd Display & Touch Panel

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 25 of 45 LCD Display & Touch Panel OPERATION: The LCD display, touch panel, and boot are individually replaceable. However, due to the assembly stack up of this assembly they will need to be removed and installed together.
  • Page 26 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 26 of 45 Removal 1. Remove the bottom housing assembly (refer to Bottom Housing operation). 2. Remove the core assembly from the top housing (refer to Core Assembly operation). 3.
  • Page 27 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 27 of 45 Installation When reinstalling display assembly parts be careful not to gets scratches, fingerprints, dust, or other contamination on the display surfaces. Assembly in a clean environment using some form of finger protection is required. 1.
  • Page 28 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 28 of 45 5. Connect the LCD flex cable to the main logic board and then position the LCD panel down into the boot. Connect LCD Place LCD panel flex cable into boot 6.
  • Page 29 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 29 of 45 7. Place the core assembly with the touch panel face down on a flat surface. Apply light pressure to hold the magnesium frame snug against the display assembly and, using a #1 Phillips screwdriver, install 2 screws to secure the touch panel to the magnesium frame with 1.5+/-0.2 in-lbs of torque.
  • Page 30: Wan/Gps Radio Assembly

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 30 of 45 WAN/GPS Radio Assembly OPERATION: The WAN/GPS radio is located under the scan bracket assembly. The main WAN antenna is located on top of the scan bracket assembly. The GPS/Diversity antenna is located in the top housing assembly. Coax cables, pogo pins, and circuitry on the main logic board route the antenna connections to the WAN/GPS radio card.
  • Page 31 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 31 of 45 Removal 1. Remove the bottom housing assembly (refer to Bottom Housing operation). 2. Remove the scan bracket assembly (refer to Scan Bracket Assembly operation). 3. Disconnect the coax cables from the WAN/GPS radio card. When disconnecting coax cable connectors pull them straight off the board jacks.
  • Page 32 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 32 of 45 Edges of heatsink inserted into grounding fingers 4. Using a #0 Phillips screwdriver install 2 screws to secure the heatsink near the WAN/GPS radio coax connectors. 5.
  • Page 33: Wan/Wifi Antenna

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 33 of 45 WAN/WiFi Antenna OPERATION: The main WAN radio antenna sits on top of the scan bracket assembly. This structure also contains the 802.11 radio antenna. To remove this antenna you will need to remove the scan bracket assembly. Tools Required Description Part Number...
  • Page 34 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 34 of 45 Installation Installation is reverse order of removal. 1. Position the WAN antenna onto the scan bracket assembly. 2. Using a #1 Phillips screwdriver install 3 screws and secure the WAN antenna to the scan bracket assembly with 2.5+/-0.2 in-lbs of torque.
  • Page 35: Camera

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 35 of 45 Camera OPERATION: The camera is located on the scan bracket assembly. To service the camera you will need to remove the scan bracket assembly. Tools Required Description Part Number T10 Torx driver...
  • Page 36 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 36 of 45 Continued on next page… 5. If the camera assembly has the newer, smaller footprint, flash LED be sure the rear housing has a light barrier foam installed around the edge of the flash window as shown below.
  • Page 37: Ea30 Scan Engine

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 37 of 45 EA30 Scan Engine OPERATION: The EA30 scan engine is located on the scan bracket assembly. To service the scan engine you will need to remove the scan bracket assembly.
  • Page 38 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 38 of 45 3. Using a #0 Phillips screwdriver remove two screws that secure the scan engine to the scan bracket assembly. NOTE: On Southwest Airline CN70 one of the two screws is covered by 655-360-001. This needs to be pulled up and away to access the screw.
  • Page 39: Main Logic Board

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 39 of 45 Main Logic Board OPERATION: Different main logic boards have been used to produce CK70’s since it was introduced. Be sure to replace a main logic board with one from the same 234-xxx-xxxx series as already installed in the unit being repaired. See table below: Main Logic Board Used in Keyboard Configurations...
  • Page 40 TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 40 of 45 1. Position the main logic board onto the magnesium frame. 2. Using a T7 torx driver install 3 screws and secure the main logic board to the magnesium frame with 2.5+/-0.2 in- lbs of torque.
  • Page 41: Wan Radio Supercap

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 41 of 45 WAN Radio Supercap OPERATION: The WAN radio supercap is located directly above the 802.11/Bluetooth radio on the main logic board. It is not a component of the main logic board. If it is defective or if you are installing a new main logic board a new WAN radio supercap will need to be installed.
  • Page 42: Magnesium Frame

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 42 of 45 Magnesium Frame OPERATION: Replacement of the magnesium frame will require a complete disassembly of the unit. Tools Required Description Part Number T10 Torx driver T7 Torx driver Phillips screwdriver with #0 tip Parts Required Item Part Number...
  • Page 43: Labeling

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 43 of 45 Labeling OPERATION: The CN70 contains a variety of labels on its bottom housing. These labels consist of both pre-printed labels that are ready to apply off the shelf and print on demand labels that have specific content that must be printed to match the particular unit being serviced.
  • Page 44: Government Hero (Hazards Of Electromagnetic Radiation To Ordnance) Tags

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 44 of 45 Government HERO (Hazards of Electromagnetic Radiation to OPERATION: Ordnance) Tags The CN70 government configurations are required to have HERO hanging tags installed on them. After a repair the tag called out on the configuration build BOM needs to be applied.
  • Page 45: Screws & Torque Settings

    TITLE Model DOCUMENT NO. PAGE CN70 Service Work Instructions CN70A,CN70E SWICN70-000 Page 45 of 45 Screws & Torque Settings OPERATION: 800-570-002 SCREW 4-40X1/2 PH TORX W/NYL CRES 6.0 +/- 0.2 in-lb ROHS T10 Torx Main case screws x8 for CN70A Main case screws x10 for CN70E 800-573-001 SCREW 2-56X0.1875 PH TORX W/NYL CRES...
