Dolphin™ CN80
powered by Android™ 7
Quick Start Guide
CN80-A7-EN-QS Rev (a)



  Also See for Honeywell Dolphin CN80

  Summary of Contents for Honeywell Dolphin CN80

  • Page 1 Dolphin™ CN80 powered by Android™ 7 Quick Start Guide CN80-A7-EN-QS Rev (a) 2/18...
  • Page 2: Memory Card Specifications

    Out of the Box Make sure that your shipping box contains these items: • Dolphin CN80 mobile computer (Model CN80L0N or CN80L1N) • Rechargeable 3.85 VDC Li-ion battery • Product documentation If you ordered accessories for your CN80, verify that they are also included with the order.
  • Page 3: Mobile Computer Features

    Mobile Computer Features Battery Status /Notification LED Receiver Speaker Good Read LED Power Power Button Button Touch Panel Scan Button Scan Button Keyboard (model dependent) Speakers Microphone I/O Connector...
  • Page 4 Note: Hand strap not shown. Imager (LED / Laser Aperture) Laser Safety Label Location Camera Lens and Flash Volume Buttons Scan Button microSIM/ microSIM/ microSD Card microSD Card Door Door Door Screws Battery Battery Latch...
  • Page 5: Install A Microsd Card (Sd)

    Install a microSD Card (SD) Note: Format the microSD card before initial use. Always power off the computer before attempting to install or remove a card. Remove the two screws holding the card access door closed. Pull gently on the tab to open the door. Press down gently on the center card holder.
  • Page 6: Install A Microsim Card (Sim 1 Or Sim 2)

    Install a microSIM Card (SIM 1 or SIM 2) Note: Model CT60L0N only supports UICC SE NFC technology through the SIM 1 card socket. On CT60L1N models, the SIM 1 socket supports both cellular and NFC UICC SE functionality. Always power off the computer before attempting to install or remove a card.
  • Page 7: Install The Battery

    22.3 watt-hour battery manufactured for Honeywell International Inc. We recommend use of Honeywell Li-ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. Ensure all components are dry prior to placing the battery in the computer. Mating wet components...
  • Page 8: Charge The Mobile Computer

    4 hours. Using the computer while charging the battery increases the time required to reach a full charge. We recommend the use of Honeywell accessories and power adapters. Use of any non-Honeywell accessories or power adapters may cause damage not covered by the warranty.
  • Page 9: Turn Power On/Off

    Turn Power On/Off To turn the computer on: • Press and release the Power button. To turn the computer off: Press and hold the Power button until the options menu appears. Touch Power Off. When prompted to shut down the computer, touch OK. Note: You should always power off the computer before removing the battery.
  • Page 10: About The Home Screen

    About the Home Screen Notification / Status Bar Search Bar Touch initiate a voice search or command. Home Screen Panel Touch access all apps. Favorites Tray Navigation Buttons To learn how to customize the Home screen, see the user guide.
  • Page 11: Navigation And Function Buttons

    Navigation and Function Buttons Button Description Back Return to the previous screen. Home Return to the Home screen. Recent Apps View and switch between recently used apps. Volume Raise or lower the volume of the speaker. Scan Press right or left scan button to trigger the scanner.
  • Page 12: Scan A Bar Code With The Scan Demo

    Scan a Bar Code with the Scan Demo Note: For optimum performance, avoid reflections by scanning the bar code at a slight angle. Touch > Demos > Scan Demo. Point the computer at the bar code. Touch Scan on the touch screen or press and hold a Scan button.
  • Page 13 Sync Data To move files between your CN80 and a computer: Connect the CN80 to your computer using a USB charge/ communication accessory. By default, the CN80 is in USB charging only mode. To enable file transfers, swipe down from the top of the Home screen to access the Notifications panel.
  • Page 14: Restart The Mobile Computer

    Restart the Mobile Computer You may need to restart the mobile computer to correct conditions where an application stops responding to the system or the computer seems to be locked up. Press and hold the Power button until the options menu appears.
  • Page 15: Limited Warranty

    Microsoft Corporation in the United States and/or other countries. Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made.
  • Page 16 This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII. Copyright © 2018 Honeywell International Inc. All rights reserved.
