SOL paragliders Runner XC Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
DGAC
Version 1 10/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Runner XC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOL paragliders Runner XC Series

Summary of Contents for SOL paragliders Runner XC Series

  • Page 1 Manual DGAC Version 1 10/2019...

  • Page 2: Table Of Contents

    Summary Accelerated flight ................. 30 Active flying ................. 30 WELCOME TO THE SOL TEAM ..............4 Landing with paramotor .............. 31 Symbols ..................4 Landing with paratrike ..............31 IMPORTANT NOTES ..................5 FAST DESCENT MANEUVERS ..............32 RUNNER XC - THE PROJECT ................ 6 B-Stall ...................

  • Page 3: Welcome To The Sol Team

    It is in your responsibility as a pilot to know what your insurance covers. - Sol Paragliders is flying and testing every single paraglider produced, to assure our clients full quality and function of every glider. We recommend that every new or reviewed Symbols paraglider will be tested on the ground and flew from the training hill by his pilot.

  • Page 4: Runner Xc - The Project

    Runner XC - THE PROJECT The Runner XC is our new paramotor wing for experienced pilots looking for comfort and speed paired with engine and fuel economy on long distance flights. Its performance is linked to speed gain and comfort on long flights. In thermal conditions, its stable behaviour provides safety combined with a good soaring.

  • Page 5: Tecnologias

    Tecnologias Cross X battens Greater lift (glide) due to optimization of the central Our double 3D Shaping is a three dimensions modeling Dual Control. s t r e n g t h e n i n g area of the wing with less inclined profiles and a more technology that reduces wrinkles and imperfections on the nose profile.

  • Page 6: Overview Paraglider

    Overview paraglider Overview risers 1. Trailing edge 1. Riser A. 2. Top 2. Riser A'. 3. Leading edge 3. Riser B. 4. Bottom 4. Riser C. 5. Stabilo 5. Riser D. 6. Lines 6. Brake lines. 7. Risers 7. Auxiliary brake lines. 8.

  • Page 7: Line Plan

    Line plan The suspension point design was developed for an ideal weight distribution and long Never and under no circumstances the line length can be altered! life. During all consideration and calculation, security always is our first goal.. The used material mix for the lines of the Runner XC forms an ideal combination: long life with little deformation and aerodynamic drag.

  • Page 8: The Paraglider - Information

    Tandem flight The Runner XC was not designed and is not certified for tandem flight. SOL Paragliders If the distance is not within the range, the glider could have extreme, doesn’t recommend this type of flight.

  • Page 9: Connecting Paraglider And Harness

    Connecting paraglider and harness A’ 45 cm 46,5 cm 48,5 cm 53 cm 55,5 cm Without twisting the risers connect them with the carabiners of the harness. Check if they are connected and positioned in the right way without any twist. The A riser must be in front in flight direction.
  • Page 10 A’ A’ 45 cm 45 cm 45 cm 45 cm 45,5 cm 34 cm 35,5 cm 37,5 cm 41 cm 43 cm No Foot speed System - Closed Trimmer - Open Flaps Foot speed System - Closed Trimmer - Closed Flaps Recommended for downwind or scenic flight Measure without quick links Measure without quick links...

  • Page 11: Brake Toggles

    A’ 34 cm 35,5 cm 37,5 cm 47,5 cm 58 cm Foot speed System - Open Trimmer - Open Flaps Avoid using the brakes Measure without quick links Step 4. Undo the loop. Step 5. Set to setting Step 6. Open the loop. option.

  • Page 12: Commands With Reflex Profile

    COMMANDS WITH REFLEX PROFILE Paramotor wings are generally made with reflex profile (auto stable), the degree of stability is determined by each paramotor wing model. This stability helps to get through small turbulences, so you can take better advantage of wing speed without having to act on the controls. By following the profile commands and their tightness, without first time, the paramotor wing has a tendency to advance, then slowing down with the trimmer open, is practically unnoticeable with the trimmer closed.

  • Page 13: Start

    Start Have the trimmer 2 (cm) open to improve the inflation, the start speed depends on brake use. Using the brakes Without using the brakes: More stability because of the reflex profile, more speed. Normal turn - Pull one of the commands Closed turn –...

  • Page 14: Flaps

    Flaps Forward Take off Used for the best glide on slow and efficient flights for thermal When ready to takeoff, the pilot must have risers (A) and the toggles in hand. The flights. Performance Flap is part of one of the devices that arms must be extended to the side, as if they are extensions of risers (A).

  • Page 15: Reverse Take Off

    If the paramotor wing is rising let the engine accelerate more and pull the paramotor wing up slowly. After visual check accelerate until you take off. Sol Paragliders does not recommend using the engine force to inflate the paramotor wing.

  • Page 16: Power Induced Oscillations

    Power induced oscillations Landing with paramotor Always choose a secure and clean landing side with lots of space, great distance to It is recommended to use the accelerator when flying against the wind or in zones natural obstacles and is not under the influence of turbulent air. with descending air.

  • Page 17: Fast Descent Maneuvers

    The following maneuvers should be used only in emergency situations and need a special training fore safety use. If possible attend a workshop to learn and practice Sol Paragliders does not recommend doing ears with the XC Runner. this maneuvers.

  • Page 18: Extreme Flight Situations

    EXTREME FLIGHT SITUATIONS Lateral closing Active flying almost ever avoids lateral closing. If lateral closing happens, the canopy Front-stall folds predictable and progressively from the tip to the center. This corresponds a collapse of 50% or more and results in a slight tendency for a turn. The paramotor Normally the paramotor wing opens on his own after a front-stall.

  • Page 19: Parachutal

    Parachutal Negative spiral The Runner XC has a long way on the brakes and difficulties to enter in a negative This paramotor wing does not have parachutal flight tendencies and recovers on spiral. But if one of the brakes is extremely pulled downwards it can happen. its own from an intentional parachutal flight induced by braking commands.

  • Page 20: Line Over

    PACKING YOUR PARAMOTOR WING Line Over If the tip of the wing is trapped in lines it could cause a positive spiral, which is difficult There are different ways who can help to extend the life of your paramotor wing. to control.

  • Page 21: Traditional - Method

    Traditional - Method Step 3: Now do it in the same way with the leading edge profiles. Put the Step 1: Bundle up your paramotor wing reinforcements of top and bottom in the in form of a cabbage. This way you’re right way, don’t close the cell openings avoiding that the paramotor wing drags and push out the fabric.

  • Page 22: Storing

    Storing Step 4: Fold the paramotor wing like an accordion from both sides and put one side over the other. Now all reinforcements are laying side-wise one above the other. Most part of the paramotor wing fabric is Nylon. As all other synthetic materials it suffers and deteriorates under the influence of ultraviolet radiation (UV).

  • Page 23: Tips For Care

    TIPS FOR CARE - Over-stressing of individual lines, more than normal load in flight, should be avoided. An excessive deformation is irreversible and can’t be undone. For the same reason avoid stepping on the lines, bending or folding them, especially the main lines. Step 3: Close all parts and pockets of the back pack.

  • Page 24: Inspection

    INSPECTION WARRANTY Your paramotor wing has strictly to follow the required inspection intervals. The first Every paramotor paraglider has a Warranty of 1 Year or 100 Hours of Flight, whichever inspection check is mandatory completing 24 months or 100 hours flights, whichever comes first.

  • Page 25: Environment And Recycling

    OPERATION LIMITS In order to make a plea for repair or equipment exchange, which shall be decided and performed only by SOL Paragliders, the owner must send the paraglider to the manufacturer with the following documents: Based on LTF standard:...

  • Page 26: Technical Data

    TECHNICAL DATA Weight, measure and data Model Cells Real Surface 15,03 16,5 18,0 19,5 21,1 22,5 24,1 m² Real Span 9,48 10,4 10,8 11,2 11,6 12,0 Real A/R Projected Surface 13,02 14,3 15,6 16,9 18,2 19,5 20,9 m² Projected Span 7,66 Projected A/R Height...

  • Page 27: Parts And Materials

    Parts and materials WTX 40 PU + Silicon 40 gr/sm - WTX 29 PU + Silicon 29 gr/sm WTX 40 PU + Silicon 40 gr/sm - WTX 29 PU + Silicon 29 gr/sm Bottom Profiles/Diagonal tapes Pro-Nyl High Tenacity Nylon rip-stop Hard finish 36 gr/sm Nylon Meada 2,5 mm / Nylon Maxfios Meada 1,6 - 2,0 mm Reinforcements Cetim Polyester 25 mm...

  • Page 28: Line Lengths

    Line lengths Runner XC 150 Runner XC 180 5387 5379 5407 5403 5879 5872 5904 5917 5436 5421 5439 5449 5934 5917 5939 5968 5646 5629 5646 5545 6161 6143 6164 6071 5706 5685 5712 5612 6226 6203 6236 6145 5777 5751 5786...
  • Page 29 Runner XC 210 Runner XC 240 6336 6330 6365 6135 6764 6759 6798 6843 6396 6379 6404 6191 6829 6811 6839 6904 7089 7068 7098 7021 6637 6617 6644 6301 6706 6682 6721 6379 7162 7136 7179 7103 6787 6756 6805 6453 7248...

  • Page 30: Line Lengths Individually

    Line lengths individually Runner XC 150 Runner XC 150 Name Line reference Diameter / mm Number of lines Length / mm Name Line reference Diameter / mm Number of lines Length / mm Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12100 Cousin vectran 12240...
  • Page 31 Runner XC 165 Runner XC 165 Name Line reference Diameter / mm Number of lines Length / mm Name Line reference Diameter / mm Number of lines Length / mm Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12240...
  • Page 32 Runner XC 180 Runner XC 180 Name Line reference Diameter / mm Number of lines Length / mm Name Line reference Diameter / mm Number of lines Length / mm Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12240...
  • Page 33 Runner XC 195 Runner XC 195 Name Line reference Diameter / mm Number of lines Length / mm Name Line reference Diameter / mm Number of lines Length / mm Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12100 Cousin vectran 12240 Cousin vectran 12240...
  • Page 34 Runner XC 225 Runner XC 225 Name Line reference Diameter / mm Number of lines Length / mm Name Line reference Diameter / mm Number of lines Length / mm Cousin vectran 12100 Cousin vectran 12240 1028 Cousin vectran 12100 Cousin vectran 12240 Cousin vectran...
  • Page 35 Runner XC 240 Runner XC 240 Name Line reference Diameter / mm Number of lines Length / mm Name Line reference Diameter / mm Number of lines Length / mm Cousin vectran 12100 Cousin vectran 12240 1073 Cousin vectran 12100 Cousin vectran 12240 1012...
  • Page 36 Sol Sports Ind. e Com. Ltda. Rua Walter Marquardt, 1180 cp 370 89259-565 Jaraguá do Sul, SC BRAZIL Telefone (+55) 47 3275 7753 E-mail: info@solsports.com.br www.solparagliders.com.br facebook: solparagliders instagram @solparagliders...

This manual is also suitable for:

Runner xc 150Runner xc 210Runner xc 225Runner xc 165Runner xc 240Runner xc 195 ... Show all
