IEI Technology TANK-XM81 Series User Manual

Expansion chassis / backplane / power module
Hide thumbs Also See for TANK-XM81 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL:
MODEL:
TANK-XM81 Series
External Expansion Accessories for TANK-XM81 Series
Internal Expansion Modules for TANK-XM81 Series
External Expansion Accessories for TANK-XM81 Series
Expansion Chassis / Backplane / Power Module
M.2 Slot Expansion Module / 2.5G LAN Module
Expansion Chassis / Backplane / Power Module
User Manual
Rev. 1.00 – May 9, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TANK-XM81 Series and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology TANK-XM81 Series

Summary of Contents for IEI Technology TANK-XM81 Series

  • Page 1 MODEL: MODEL: TANK-XM81 Series External Expansion Accessories for TANK-XM81 Series Internal Expansion Modules for TANK-XM81 Series External Expansion Accessories for TANK-XM81 Series Expansion Chassis / Backplane / Power Module M.2 Slot Expansion Module / 2.5G LAN Module Expansion Chassis / Backplane / Power Module User Manual Rev.

  • Page 2: Revision

    Internal expansion products Revision Date Version Changes May 9, 2023 1.00 Initial release Page II...

  • Page 3: Copyright

    Internal expansion products Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Manual Conventions

    Internal expansion products Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.

  • Page 5: Table Of Contents

    Internal expansion products Table of Contents REVISION ........................II COPYRIGHT ........................III MANUAL CONVENTIONS ..................IV TABLE OF CONTENTS ....................V LIST OF FIGURES ...................... VII LIST OF TABLES ......................VIII 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................
  • Page 6 Internal expansion products 4.1.4 M.2 B-Key Slot ....................19 4.1.5 M.2 B-Key Slot ....................21 4.1.6 PCIe Mini Slot ....................23 4.1.7 SIM Card Slot ....................25 4.2 GPOE-XM81-8P ..................... 26 4.2.1 Layout ......................26 4.2.2 Peripheral Interface Connectors ..............26 4.2.3 2.5GbE Connector ...................

  • Page 7: List Of Figures

    Internal expansion products List of Figures Figure 1-1: TANK-XM81 Internal Expansion Modules ..............2 Figure 1-2: GPOE-XM81-8P Physical Dimensions ..............4 Figure 1-3: TXIOB-XM81-A Physical Dimensions ................ 5 Figure 3-1: Remove the Cover .....................11 Figure 3-2: TXCBP-XM81-2A Installation ...................11 Figure 3-3: Securing TXCBP-XM81-2A ..................12 Figure 3-4: GPOE-XM81-8P Installation ..................12 Figure 3-5: Securing the GPOE-XM81-8P ...................13 Figure 3-6: Remove the Knockout ....................13...
  • Page 8 Internal expansion products List of Tables Table 1-1: TANK-XM811 Series External expansionInternal Expansion Modules ....2 Table 1-2: GPOE-XM81-8P Technical Specifications ..............3 Table 1-3: TXIOB-XM81-A Technical Specifications ..............3 Table 4-1: Peripheral Interface Connectors ................16 Table 4-2: M.2 A-Key Slot Pinouts ....................18 Table 4-3: M.2 B-key Slot Pinouts ....................20 Table 4-4: M.2 B-key Slot Pinouts ....................22 Table 4-5: PCIe Mini Slot Pinouts ....................24...

  • Page 9: Introduction

    Internal expansion products Chapter Introduction Page 1...

  • Page 10: Overview

    1.1 Overview Figure 1-1: TANK-XM81 Internal Expansion Modules The TANK-XM81 Series Products allows you to add various functionality through internal IO expansion modules. The internal IO expansions can support up to 8 PCIe x1 and 5 USB 2.0, and is compatible with various combinations, for example, multiple network cards and M.2 B key modules, giving users more flexibility for solution integration.

  • Page 11: Technical Specifications

    Internal expansion products 1.3 Technical Specifications The technical specifications of the GPOE-XM81-8P are listed below. Specifications Interface 8 x PCI Express® x1 Ethernet 8 x Intel® I225-V controller PoE capability IEEE 802.3at with 30W / 52V per port (total power: 60W) Operating Temperature 0°...

  • Page 12: Physical Dimensions

    Internal expansion products 1.4 Physical Dimensions The physical dimensions of the GPOE-XM81-8P are shown below. Figure 1-2: GPOE-XM81-8P Physical Dimensions Page 4...

  • Page 13: Figure 1-3: Txiob-Xm81-A Physical Dimensions

    Internal expansion products The physical dimensions of the TXIOB-XM81-A are shown in Figure 1-3: TXIOB-XM81-A Physical Dimensions Page 5...

  • Page 14: Unpacking

    Internal expansion products Chapter Unpacking Page 6...

  • Page 15: Anti-Static Precautions

    Internal expansion products 1.1 Anti-static Precautions WARNING: Failure to take ESD precautions during installation may result in permanent damage to the TANK-XM811 Series External expansion and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the TANK-XM811 Series External expansion.

  • Page 16: Unpacking Checklist

    Internal expansion products 1.3 Unpacking Checklist NOTE: If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the TANK-XM811 Series External expansion from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.

  • Page 17: Installation

    Internal expansion products Chapter Installation Page 9...

  • Page 18: Installation Precautions

    Internal expansion products 3.1 Installation Precautions CAUTION: The TANK-XM811 Series External expansion has more than one power supply connection point. To reduce the risk of electric shock, disconnect all power sources before installing or servicing the TANK-XM811 Series External expansion. During installation, be aware of the precautions below: ▪...

  • Page 19: Back Cover Removal

    Internal expansion products 3.2 Back Cover Removal Before installing or maintaining the internal components, the bottom cover must be removed from the TANK-XM81 Series Products. Follow the steps below to complete the task. Step 1: Turn the TANK-XM81 Series Products over and remove the 6 screws on the bottom cover.

  • Page 20: Gpoe-Xm81-8P Installation

    Internal expansion products Figure 3-3: Securing TXCBP-XM81-2A Step 3: Install M.2 / PCIe Mini expansion cards onto the TXCBP-XM81-2A. Close the bottom cover and secure it using the screws removed previously (see Section 3.5). 3.4 GPOE-XM81-8P Installation Follow the steps below to install the GPOE-XM81-8P. Step 1: Insert the golden finger of the GPOE-XM81-8P module into the PCIe x16 slot (Figure 3-4).

  • Page 21: Back Cover Installation

    Internal expansion products Figure 3-5: Securing the GPOE-XM81-8P Step 3: Remove the knockouts from the bottom cover, four on the side for LAN ports and four on the top for heat sinks (Figure 3-6). Figure 3-6: Remove the Knockout Step 4: Close the bottom cover and secure it using the screws removed previously (see Section 3.5).

  • Page 22: Figure 3-7: Install External Antenna Connector

    Internal expansion products Step 1: [Optional] Install an external antenna if necessary. You need to remove the knockouts first, and then install the antenna connectors into the knockout holes (Figure 3-7). Figure 3-7: Install External Antenna Connector Step 2: Install the bottom cover and secure it with 6 or 8 screws on the sides (Figure 3-8).

  • Page 23: System Motherboard

    Internal expansion products Chapter System Motherboard Page 15...

  • Page 24: Txcbp-Xm81-A

    Internal expansion products 4.1 TXCBP-XM81-A 4.1.1 Layout Figure 4-1: Connector and Jumper Locations 4.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label M.2 A-key slot M.2 A-key slot M2_A1 M2_B1 M.2 B-key slot M.2 B-key slot M2_B2 SIM slot...

  • Page 25: A-Key Slot

    Internal expansion products 4.1.3 M.2 A-Key Slot CN Label: M.2_A1 CN Type: M.2 A-Key slot CN Location: See Figure 4-2 CN Pinouts: See Table 4-2 The M.2 A-key slot supports PCIe x1 and USB 2.0 interfaces. Figure 4-2: M.2 A-key Slot Location Description Description +V3.3A...

  • Page 26: Table 4-2: M.2 A-Key Slot Pinouts

    Internal expansion products Description Description PCIE_TX+ PCIE_TX- PCIE_RX+ PCIE_RX- CLK_M2_A+ CLK_M2_A- WLAN_PERST# +V3.3A_WLAN +V3.3A_WLAN +V3.3A_WLAN +V3.3A +V3.3A Table 4-2: M.2 A-Key Slot Pinouts Page 18...

  • Page 27: B-Key Slot

    Internal expansion products 4.1.4 M.2 B-Key Slot CN Label: M2_B1 CN Type: M.2 B-key slot CN Location: See Figure 4-3 CN Pinouts: See Table 4-3 The M.2 B-Key slot supports PCIe x1 and USB 3.2 interfaces. Figure 4-3: M.2 B-key Slot Location PIN NO.

  • Page 28: Table 4-3: M.2 B-Key Slot Pinouts

    Internal expansion products PCIE_WAKE# PSE_I2S1_RXD SAR_DPR_WWAN GNSS_DISABLE_N USB_RXN WWAN_UIM_RST USB_RXP WWAN_UIM_CLK WWAN_UIM_DATA USB_TXN UIM_PWR USB_TXP SSD_DEVSLP PCIE_RXN PCIE_RXP PCIE_TXN PCIE_TXP WWAN_PERST# CLK_M2_B_N WWAN_WAKE# CLK_M2_B_P WWAN_SIM1_DET WWAN_RST WWAN_SUSCLK DET_OS-PCIE/ +3.3V GND-SATA +3.3V +3.3V WWAN_CONFIG2 Table 4-3: M.2 B-key Slot Pinouts Page 20...

  • Page 29: B-Key Slot

    Internal expansion products 4.1.5 M.2 B-Key Slot CN Label: M2_B2 CN Type: M.2 B-key slot CN Location: See Figure 4-4 CN Pinouts: See Table 4-4 The M.2 B-Key slot supports PCIe x2 interface. Figure 4-4: M.2 B-key Slot Location PIN NO. DESCRIPTION PIN NO.

  • Page 30: Table 4-4: M.2 B-Key Slot Pinouts

    Internal expansion products PCIE_WAKE# PSE_I2S1_RXD SAR_DPR_WWAN GNSS_DISABLE_N PCIE_RXN WWAN_UIM_RST PCIE_RXP WWAN_UIM_CLK WWAN_UIM_DATA PCIE_TXN UIM_PWR PCIE_TXP SSD_DEVSLP PCIE_RXN PCIE_RXP PCIE_TXN PCIE_TXP WWAN_PERST# CLK_M2_B_N WWAN_WAKE# CLK_M2_B_P WWAN_SIM1_DET WWAN_RST WWAN_SUSCLK DET_OS-PCIE/ +3.3V GND-SATA +3.3V +3.3V WWAN_CONFIG2 Table 4-4: M.2 B-key Slot Pinouts Page 22...

  • Page 31: Pcie Mini Slot

    Internal expansion products 4.1.6 PCIe Mini Slot CN Label: M_PCIE1 CN Type: PCIe Mini slot CN Location: See Figure 4-5 CN Pinouts: See Table 4-5 The PCIe Mini card slot is for installing PCIe Mini expansion cards. Figure 4-5: PCIe Mini Slot Location PIN NO.

  • Page 32: Table 4-5: Pcie Mini Slot Pinouts

    Internal expansion products PCIE_RXN5 WWAN_UIM_RST PCIE_RXP5 WWAN_UIM_CLK WWAN_UIM_DATA PCIE_TXN5 UIM_PWR PCIE_TXP5 SSD_DEVSLP PCIE_RXN4 PCIE_RXP4 PCIE_TXN4 PCIE_TXP4 WWAN_PERST# CLK_M2_B_N WWAN_WAKE# CLK_M2_B_P WWAN_SIM1_DET WWAN_RST WWAN_SUSCLK DET_OS-PCIE/ +3.3V GND-SATA +3.3V +3.3V WWAN_CONFIG2 Table 4-5: PCIe Mini Slot Pinouts Page 24...

  • Page 33: Sim Card Slot

    Internal expansion products 4.1.7 SIM Card Slot CN Label: SIM1, SIM2, SIM3 CN Type: 7-PIN SIM holder CN Location: See Figure 4-6 CN Pinouts: See Table 4-6 The SIM card slot accepts a SIM card for 3G network communication. NOTE: A WWAN module must be installed in the corresponding M.2 or PCIe Mini slot to provide WWAN communication.

  • Page 34: Gpoe-Xm81-8P

    Internal expansion products 4.2 GPOE-XM81-8P 4.2.1 Layout Figure 4-7: Connector and Jumper Locations 4.2.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label 2.5G LAN Connector RJ45 LAN1, LAN2, LAN3, LAN4 MCU programming connector 3-pin header, p=2.54 mm MCU programming connector 2-pin header, p=2.54 mm...

  • Page 35: Gbe Connector

    Internal expansion products 4.2.3 2.5GbE Connector CN Label: LAN1, LAN2, LAN3, LAN4 CN Type: RJ45 CN Location: See Figure 4-8 CN Pinouts: See Table 4-8 and Table 4-9 The 2.5GbE connector attaches to the board Figure 4-8: 2.5GbE Connector Location Description Description MDIA0+...
