Mircom RAM-2944LCD Installation And Operation Manual page 17

Table 4 Service Terminal Screens
Screen Name
17 Port 1
18 Port 2
29 System Reset
38 Switches
49 Clock
50 Stacks
51* FIFOs
52 Extended Memory
68* Remote Terminal
69* Network Verify
Description
Displays information about the primary network communication
port (COM1).
Level 0 Commands
0 V Clear the network counters.
Level 1 Commands
(1-25) B Set the retry limit for COM1. This is the number of
retries attempted before the unit is considered off-line.
default value is 8.
(baud) B Set the baud rate of COM1. This can be any of 9600
(default), 4800, 2400, 1200, 600, 300 or 150.
Displays information about the secondary network communication
port (COM2). A question mark will appear in front of the baud rate
when the port is off-line.
Level 0 Commands
0 V Clear the network counters.
Displays a list of resettable items. These are the items that are
reset when System Reset is pressed.
Show the current on/off status of each switch and list the timer
associated with each one.
Show the current clock calibration or calibration status.
This screen is for diagnostic purposes.
This screen is for diagnostic purposes.
Level 0 Commands
0 <Ctrl-F> Clear maximum usage counters
Displays the type and amount of extended memory installed in the
system.
Displays the service terminal screens for another panel in the
network. This allows for the troubleshooting of a system from a
single location. This screen will automatically disconnect the
remote connection if memory gets low or if no communication is
received for 15 seconds. The remote panel will stop sending data
after 15 minutes.
Level 0 Commands
(id) N Display the service terminal for Panel id
<Esc> Disconnect remote connection
Displays the detailed status of the Network Verify feature.
Programming
The
