Installation / Service Guide
DX1000 / DX1500
Gas Fireplaces
For the latest documentation, visit www.escea.com
630228_21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DX1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Escea DX1000

Summary of Contents for Escea DX1000

  • Page 1 Installation / Service Guide DX1000 / DX1500 Gas Fireplaces For the latest documentation, visit www.escea.com 630228_21...
  • Page 2 Young children should be supervised to ensure that they do not play with the appliance. Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 478 8220. For contact details of your local Escea distributor or dealer in New Zealand, please visit: www. escea.com, call NZ: 0800 17 3000, or email: info@escea.com.
  • Page 3 Please contact Escea if you require warranty work. Warranty repair work must be carried out by a recognised gas fire technician. It is recommended that recognised Escea Gas Fire Technicians are also used to carry out annual servicing requirements (particularly during the warranty period).
  • Page 4 DX1000 PRODUCT SPECIFICATION DX1000 MODEL NAME Description of Appliance Gas Fire Heater Star Rating 4.8 Stars Max. Heat Output 8.4 kW A/NZ Approval No. AS/NZS 5263.1.3:2016 Gas Type Natural Propane ULPG Gas input High 33 MJ/hr 33 MJ/hr 33 MJ/hr...
  • Page 5 Appliance Dimensions (mm) Width 1828 mm Height 774 mm Depth 382 mm Weight 120 kg Ignition System Electronic Ignition to pilot system Escea PCB Flame Safeguard Flame Rectification Remote controls Timers Clock Function lock / child Temperature control Connections Electric 230V AC 1/2"...

  • Page 6: Table Of Contents

    Installation Process and Product Description Product Description Recommended Installation Process Product Dimensions Creating the Cavity Cavity Shape Designing the Cavity Framing Dimensions Cavity Base Hearth Wall Linings Fascia Mantle Clearance Television Clearances Ducting Duct Fan Mounting Installing the Electricity and Gas to the Appliance Power Supply Network Cable Gas Pipe Sizing...
  • Page 7 Installing the Appliance Double Sided Conversion Installing the Appliance Connecting the Flue Connecting the Ducting Connecting the Network Cable Connecting the Powerflue and Duct Fan Cables Removing (and Replacing) the Glass Remove the Fuelbed Tray & Burners Gas Type Conversion Checking the Gas Operating Pressure Operating the Appliance Auxillary On/Off button...

  • Page 8: Installation Process And Product Description

    Installation Process and Product Description Product Description The Escea DX1500 / DX1000 gas fire is a direct vent (fan draught balanced flue), room sealed gas appliance designed to be built into a cavity. This appliance is flued using a co-linear flexible aluminium flue connected to a powerflue terminal.

  • Page 9: A3 Product Dimensions

    Product Dimensions NOT TO BE MISTAKEN FOR CAVITY DIMENSIONS. All dimensions are in mm. Gas, Power, Internet Connections Ø75 Ø250 Ø100 For more detail, view architectural drawings at www.escea.com DX1000 DX1500 664mm 914mm 1328mm 1828mm...

  • Page 10: Creating The Cavity

    Creating the Cavity Cavity Shape The DX1500 / DX1000 is suitable for timber framed cavities. Most existing masonry cavities will not be suitable. The cavity design & shape will be dependent on a number of things, detailed below Designing the Cavity The following aspects must be considered when designing this installation: •...

  • Page 11: B3 Framing Dimensions

    B8 on page 13. These dimensions indicate the opening required in any wall lining. These dimensions are for DX1500 / DX1000 without fascia; if using a fascia then please check the following section of this manual for separate wall lining dimensions.

  • Page 12: B7 Fascia

    All air ducts will make noise no matter how well the system is designed. Increasing the number of outlets is a simple strategy to reduce this noise. The plasterboard is to protrude beyond framework as shown in the following diagram. 1062 DX1000: 1562 DX1500: WALL OPENING...

  • Page 13: B8 Mantle Clearance

    Television Clearances The following are the recommended minimum clearances for the location of any electrical equipment (such as a Plasma TV, LCD TV or home theatre system) above an Escea DX Series gas fire. NOTE: The above television clearance recommendations are to be treated as a suggestion of a suitable installation only.

  • Page 14: B11 Duct Fan Mounting

    Ductwork must not be crushed or exposed to excessive heat sources. For installations with the duct fan installed in the appliance cavity we recommend: - Contact Escea’s free Architectural Advice Service at aa@escea.com and forward them a copy of the intended design for comment.

  • Page 15: Installing The Electricity And Gas To The Appliance

    Installing the Electricity and Gas to the Appliance Power Supply While the cavity is being created, consideration must be given to the location of an appropriate power supply. An earthed 230/240 volt mains power connection (typically a standard 3 pin outlet) must be available within 1m of the bottom right of the appliance.

  • Page 16: C3 Gas Pipe Sizing

    DX1500 Gas Consumption = 42MJ/hr DX1000 Gas Consumption = 33MJ/hr C4 Gas Pipe Position The gas connection is inside the appliance and is ½” male BSPT on the lower right of the appliance as shown.

  • Page 17: Installing The Flue

    Any joints within the flue system must be sealed adequately with a sealing agent used if necessary. The flue system for the DX1500 / DX1000 is zero rated, so no spaces are required between the flue and any timber framing.

  • Page 18: D2 Flue Configuration (For More Than 4M Length)

    12m MAX Y Maximum = 1.5m Y Minimum = 0m X Maximum = 12m X Minimum = 0m ESCEA WALL X + Y Maximum = 12m TERMINAL X + Y Minimum = 0.6m Ø80mm / Ø100mm PP Tube 12m MAX Ø100mm...

  • Page 19: D3 Installing The Horizontal Powerflue Wall Terminal Option

    D3 Installing the Horizontal Powerflue Wall Terminal Option The horizontal powerflue wall terminal must be installed in the correct orientation (the small horizontal slot should be at the bottom). This allows for the correct operation of the flue system and prevents the ingress of water.
  • Page 20 Creating the Hole in the Outside Wall When cutting the hole in the outside wall, be mindful of how the installation of the horizontal powerflue wall terminal will be finished; the installation must be weatherproof. Ideal Hole/Cavity Size for Horizontal Powerflue Without Side Brackets With Side Brackets 298mm...
  • Page 21 The following diagrams are excerpts from the Escea architect drawings and are available in full on our sill cover to cladding to comply website. These diagrams are recommendations, and your installation must comply with any local or...

  • Page 22: D4 Installing The Internal Vertical Powerflue (Uvp)

    D4 Installing the Internal Vertical Powerflue (UVP) NOTE: For information regarding an external install of the UVP, go to section D5 on page 24. The Universal Vertical Powerflue (UVP) internal configuration is designed to have the fan, mounted within the roof space of the house, and the vertical Ø225mm diameter liner, containing a Ø100mm flexi, penetrate through the roof.
  • Page 23 The UVP-Internal kit is intended for use within an accessible roof space or ‘chimney’ construction. Service access must be provided. Ensure installation complies with relevant building codes and regulations. Typical Installation UVP Cowl 1.2m F-F Liner ‘Decktite’ or similar ashing Roof Space Ensure Power Flue unit is securely braced using...

  • Page 24: D5 Installing The External Vertical Powerflue (Uvp)

    D5 Installing the External Vertical Powerflue (UVP) Note: For information regarding an internal install of the UVP, go to section D4 on page 22. The UVP is designed to have the enclosure containing the fan unit mounted externally; an example is shown below.

  • Page 25: D6 Removing The Restrictor Plate

    D6 Removing the Restrictor Plate For every DX-series installation with an EVP, UVP-External or UVP-Internal, the attached restrictor plate must be removed . To do this: □ ø Turn the unit on its head and identify the restrictor plate attached to the 75mm spigot.

  • Page 26: D7 Installing In Accordance With Relevant Codes

    D7 Installing in Accordance with Relevant Codes The location of the Powerflue Terminal must be installed in accordance with AS/NZS 5601.1 and any other relevant building codes. Avoid installing the Powerflue Terminal in areas exposed to high winds and extreme weather, if possible. Some of those minimum clearances for a fan assisted terminal are listed below;...

  • Page 27: D8 Running The Flue

    Horizontal Powerflue Wall Terminal will be installed in the outside wall. The flue system for the DX1500 / DX1000 is zero rated, so no spaces are required between the flue and any timber framing. Allow enough stretch in the flexible aluminium flue to allow it to be able to sit just outside of the wall.

  • Page 28: D9 Running The Powerflue Electrical Cable

    D9 Running the Powerflue Electrical Cable Note: The powerflue terminal is powered from the appliance and must be connected to the appliance with the supplied electrical cable only. Note: Ensure that the appliance power supply is disconnected before making the connection to the terminal The supplied electrical cable is 7m long;...

  • Page 29: Installing The Appliance

    Installing the Appliance Double Sided Conversion If the appliance is to be double sided, you will have been supplied with an extra glass panel and steel support frame and wall lining trim brackets. 1. On the rear of the appliance, unscrew the outer shell cover and remove it as shown 2.

  • Page 30: E2 Installing The Appliance

    Installing the Appliance Insert the gas fire into the cavity and bolt down in correct position using the brackets on each end of the appliance. It is a requirement that this appliance be securely fastened at the base. Ensure that the fire is seismically restrained in a manner appropriate to the installation location.

  • Page 31: E6 Connecting The Powerflue And Duct Fan Cables

    Connecting the Powerflue and Duct Fan Cables Connect both the duct fan plug and the powerflue fan electrical cables to the fireplace. Flue Fan Duct Fan If the fans are not plugged in, it will result in an error when starting the appliance. Removing (and Replacing) the Glass Using the supplied 3mm Allen Key (hex drive) remove the bolts around the glass retainer ensuring that the glass does not fall forward.

  • Page 32: E8 Remove The Fuelbed Tray & Burners

    NG to ULPG/Propane or vice versa. WARNING: The regulator that is supplied with the fire MUST NOT BE REMOVED. Removal of the regulator, or replacing it with one not intended for use with this Escea fire, will void the limited appliance warranty.
  • Page 33 Remove the ‘engine’ by lifting up and to the left. This is still connected internally to the gas hose and power cables. Place engine just to the left within firebox as shown. Step 4: Change the two main burner jets with the jets supplied in kitset. DX1500 DX1000 NG (Both jets) Ø2.3mm Ø1.95mm Propane / ULPG (Both jets) Ø1.3mm...

  • Page 34: E10 Checking The Gas Operating Pressure

    MUST NOT BE REMOVED. Removal of the regulator, or replacing it with one not intended for use with an Escea fire, will void the limited appliance warranty and may be dangerous. The gas valve (shown right) has manometer test...
  • Page 35 Gas Pressure Table - DX1000 Gas Type Propane (AUS) Natural Gas or ULPG (NZ) Minimum Inlet Pressure - Pre-Regulator 2.75 kPa 1.13 kPa Maximum Inlet Pressure - Pre-Regulator 5.0 kPa 5.0 kPa Operating Pressure when on high - (Point B or C) 2.32 kPa ±5%...
  • Page 36 Changing the Operating Pressure from the Remote The following instructions must only be undertaken by a suitably approved person. Any tampering by an unauthorised person will void the product’s warranty and may result in a dangerous condition. While the remote is in its “OFF” mode with only the time showing on the display, press the MINUS, PLUS and FAN BOOST buttons simultaneously (as shown right) until the characters “03”...

  • Page 37: E11 Operating The Appliance

    E13 Home Automation Setup Escea D-Series fireplaces have a simple interface for connection to a home automation system. This allows the fireplace to be woken up, started, and then shut down. The “Close to Wake”...
  • Page 38 The home automation connection can be found in your fireplace accessory pack (shown right). This connects to the fireplace via the lower RH outside panel of the fireplace, next to the primary network cable access point, as shown in section C2 on page 15. Home Automation - GREEN WIRES ONLY Home Automation Operation Relay closed...

  • Page 39: Finishing The Installation

    Once the logs and cones have been correctly positioned, scatter the shale evenly across the fire base to cover as much area as possible without obstructing the pilot flame. For the DX1000 you should use the 7x supplied 600ml bags of shale (chips), and for the DX1500 you should use the 10x supplied bags.

  • Page 40: F3 Replace The Glass

    NOTE: If the glass gasket requires a replacement, call your nearest Escea agent, who will ensure the part is replaced with the correct type. In the event that the glass is broken by impact, purchase the replacement from an authorised Escea agent only.

  • Page 41: F5 Fitting The Fascia Panels

    Fitting the Fascia Panels To avoid scratches or knocks to the fascia panels of this heater, they must be fitted at the conclusion of the installation process, after wall linings are in place. NOTE: Never rub the fascia. Step 1: Ensure the plastic spacer is placed on the thread of the studs.

  • Page 42: F6 Locating Wall Mount Cradle For Wireless Control

    Ideally 1.2m to 1.5m from the floor The radio frequency signal will go through some walls but for best results Escea suggest that the cradle position is less than 10 metres away from the heater. The best height off the ground to locate the cradle is about chest height.
  • Page 43 The appliance is turned off by pressing the “POWER” button once more. The remote will display the time only. Run the appliance again and check the operation of the thermostat by increasing and reducing the set temperature. Check the Flame Effect function and the Fan Boost functions work correctly.

  • Page 44: F8 Normal Operating Sounds And Smells

    These are all normal operating sounds and should not be considered as defects in your appliance. Escea gas appliances use electric fans to push heated air into the room. It is not unusual for the fan to make a “whirring” sound when ON. This sound will increase or decrease in volume depending on the speed setting of your fan.

  • Page 45: Installation Checklist

    Installation Checklist Go through the following checklist to ensure you have installed the appliance correctly □ Correctly sized cavity to suit your fascia and flue configuration □ Correct clearances to combustibles and mantles around the fascia □ An electrical isolating switch to the appliance, accessible after finished installation □...

  • Page 46: Service Manual

    Service Manual IMPORTANT: • This appliance must be serviced every 12 months. • Any service operation should be carried out only by a suitably qualified and trained person. • Gas and electricity supply MUST be isolated before any service operation is carried out on this appliance.

  • Page 47: S2 Error Codes

    Error Codes This gas fire has been designed to show error codes to help explain and identify any fault situation that occurs. These codes will appear on the wireless remote control in the form of a large letter “E” with a number beside it. Codes can normally be reset by turning the heater off then on again at the wall.
  • Page 48 The valve solenoids have failed the pre-ignition test. A wire may have dislodged or the valve solenoid is faulty. • Check that the connections to each solenoid are secure and in place. The connections on the ends of the wires may need to be tightened (e.g. with Valve Solenoid a pair of pliers) to ensure a robust connection to the valve terminal.

  • Page 49: S3 Cleaning The Fuel Bed, Fascia, And Glass

    ALWAYS USE GLOVES WHEN HANDLING THE FASCIA AND GLASS. The outside of an Escea Fascia must only be cleaned with a soft microfibre cloth. If heavier cleaning is required for the likes of grease or stubborn fingerprint removal we recommend the use of a dedicated stainless steel cleaner for stainless steel fascias or warm soapy water for powder coated fascias.

  • Page 50: S4 Checking Operating Pressure

    Checking Operating Pressure WARNING: The regulator that is supplied with the fire MUST NOT BE REMOVED. Removal of the regulator, or replacing it with one not intended for use with an Escea fire, will void the limited appliance warranty. By law, the original installer has supplied a test point prior to the appliance. With all gas appliances within the house running on full, including this DX1500, check the inlet pressure upstream of the appliance.

  • Page 51: S5 Replacing A Remote Control

    Replacing a Remote Control If the wireless control becomes lost or damaged, a new one can be ordered from any Escea retail agent. When you have the new remote, the following procedure needs to be followed to “teach” the remote to communicate with the fire.

  • Page 52: S6 Replacing The Burners

    Replacing the Burners If a fascia is fitted, remove this first. Using the supplied 3mm Allen Key (hex drive), remove the bolts around the glass retainer, ensuring that the glass does not fall forward. Pull the top of the frame toward you slightly and lift the glass and frame out and away from the fire.

  • Page 53: S7 Accessing The Control Tray

    Accessing the Control Tray Remove the screws in the bottom and the inner side of the firebox as per shown. Remove the ‘engine’ by lifting up and to the left. This is still connected internally to the gas hose and power cables. Place engine just to the left within firebox as shown. Removing the Circuit Board Step 1: Remove the pilot cover and 2 jets circled to the right.
  • Page 54 Step 3: Remove the clear plastic insulation cover from ontop of the circuit board by removing the screws circled below. Step 4: Remove all 5 connections to the circuit board as highlighted below. Step 5: Remove any screws securing the circuit board to the base and remove the circuit board. Take care that the black spacers underneath the board stay in place until the board is replaced.

  • Page 55: S9 Servicing The Horizontal/Universal Vertical Powerflue

    Servicing the Horizontal/Universal Vertical Powerflue Ensure the power to the powerflue is off by disconnecting the power to the appliance inside. If the appliance has been running, allow the powerflue to cool before attempting to service it. Servicing a Horizontal Powerflue: If the powerflue needs servicing, the fan can be accessed from the outside of the installation for horizontal termination and accessed from within the roof space for vertical termination.

  • Page 56: S10 Wiring Diagram

    S10 Wiring Diagram Part No. 620278...
