Installation / Service Instructions

DS Series

Gas Fireplace

For the latest documentation, visit www.escea.com

630358_9

Table of Contents

Need help?

Do you have a question about the DS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Escea DS Series

Page 1 Installation / Service Instructions DS Series Gas Fireplace For the latest documentation, visit www.escea.com 630358_9...
Page 2 AUS: Certificate of Compliance NZ: Certificates that comply with the latest legislation in accordance with national and/or local codes. If these are not issued then the Escea warranty may be void. Warranty Repair and Annual Servicing: Warranty repair work must be carried out by a recognised gas fire technician.
Page 3: Product Specification
1693 mm Height 788 mm Appliance Dimensions (mm) Depth 352 mm Weight 150 kg Electronic Ignition to pilot system Ignition System Escea PCB Ignition Activation 20 secs (approx) Flame Safeguard Flame Rectification Consumption 160W @ 0.69A 230V Remote controls Timers Clock...
Page 4 1401mm Height 788 mm Appliance Dimensions (mm) Depth 352 mm Weight 130 kg Electronic Ignition to pilot system Ignition System Escea PCB Ignition Activation 20 secs (approx) Flame Safeguard Flame Rectification Consumption 160W @ 0.69A 230V Remote controls Timers Clock...
Page 5 1987mm Height 788 mm Appliance Dimensions (mm) Depth 352 mm Weight 130 kg Electronic Ignition to pilot system Ignition System Escea PCB Ignition Activation 20 secs (approx) Flame Safeguard Flame Rectification Consumption 160W @ 0.69A 230V Remote controls Timers Clock...
Page 6: Table Of Contents
Installation Process and Product Description Product Description Recommended Installation Process Product Dimensions Creating the Cavity Cavity Shape Designing the Cavity Hearth Cavity Base Wall Linings Television & Mantel Clearances Installing the flue Flue Configuration (For less than 4m length) Flue Configuration (For more than 4m length) Installing the Horizontal Powerflue Wall Terminal option Installing the Internal Vertical Powerflue (Duravent) Installing the Universal Vertical Powerflue (Internal Install)
Page 7 Woodland Fuelbed Installation Flame Picture Wall Lining Fitting the Fascia Locating Wall Mount Cradle for Wireless Control Operating the Appliance Normal Operating Sounds and Smells Installation Checklist Service Manual Annual Service Procedure Error Codes Cleaning the Fuelbed and Glass Cleaning the Fascia Checking Operating Pressure Replacing a Remote Control Replacing the Burners...
Page 8: A Installation Process And Product Description
Product Description and Installation Process Product description The Escea DS-Series gas fire is a room sealed gas appliance designed to be built into a false cavity. The appliance is flued using co-linear flexible aluminium flue and Polypro plastic piping beyond 4m. The user will control their fire with the Radio Frequency (RF) remote that will normally be located in it’s...
Page 9: A3 Product Dimensions
Product Dimensions NOT TO BE MISTAKEN FOR CAVITY DIMENSIONS All dimensions are in mm For more detail, view architectural drawings at www.escea.com Model DS1150 1401 1067 DS1400 1693 1359 DS1650 1987 1653...
Page 10: Creating The Cavity
• Home automation network connections - Ethernet cable layout This DS Series fires are to be installed prior to any wall lining. The wall lining is the very last task to be completed in this installation. The cavity and wall linings may be constructed from standard timber framing materials and do not need to be non-combustible.
Page 11: B3 Hearth
The diagram (shown right) shows the recommended minimum clearances for the location of any electrical equipment (such as Plasma TV, LCD TV or home theatre) above a DS Series gas fire. A mantel/recess is not required to comply with our recom- mendation of TV installation.
Page 12: Installing The Flue
The horizontal offset of the terminal can be any amount up to the total flue length listed below. Please consult with Escea’s technical staff if your intended flue configuration steps outside of the bounds of the flue configurations shown below.
Page 13 Overall ue length: 0.4m Min. 4m Max. Vertically Terminated: (utilises the escea vertical power flue enclosure kit) 1.2m Co-axial Flue 4m MAX Vertical PowerFlue UVP Cowl Cowl (Duravent) 1.2m F-F Liner 1.2m Co-axial Flue 4m MAX 4m MAX...
Page 14: C2 Flue Configuration (For More Than 4M Length)
Ø80mm / Ø100mm Flexible Flue Flexible Flue Vertical Power ue 12m MAX Ø80mm / Ø100mm PP Tube Ø100mm Condensate Trap ESCEA WALL TERMINAL Ø80mm / Ø100mm Ø80mm / Ø100mm Flexible Flue PP Tube Ø100mm FOR MORE INFORMATION ON 12m MAX...
Page 15: C3 Installing The Horizontal Powerflue Wall Terminal Option
Installing the Horizontal Powerflue Wall Terminal option The Horizontal Powerflue Wall Terminal must be installed in the correct orientation. This allows for the correct operation of the flue system and prevents the ingress of water. The Horizontal Powerflue Wall Terminal must be weather-tight when installation is complete to prevent damage to the dwelling.
Page 16 Creating the Hole in the Outside Wall When cutting the hole in the outside wall, be mindful of how the installation Horizontal Powerflue Wall Terminal will be finished, the installation must be weatherproof. Ideal hole/cavity size for Horizontal Powerflue Without Side Brackets With Side Brackets 298mm 360mm...
Page 17 IMPORTANT: Ensure that flashings do not restrict the air intake slot around the periphery of the cowl How to flash the Horizontal Powerflue The following diagrams are excerpts from the escea architect drawings, and are available in full on our website. These diagrams are recommendations, and your installation must comply with any local or...
Page 18: C4 Installing The Internal Vertical Powerflue (Duravent)
C4 Installing the Internal Vertical Powerflue (Duravent) The internal vertical flue (duravent) is designed to have the box containing the fan and electronics mounted within the roof space of the house, and the vertical 200mm diameter twin wall flue penetrate through the roof. The standard kit comes with 1.2m of twin wall flue (post fan).
Page 19: Typical Installation
The Vertically terminated flue kit is intended for use within an accessible roof space or accessible ‘chimney’ construction. Service access must be provided. Ensure installation complies with relevant building codes and regulations. Typical Installation Vertical High Wind Terminal Ø203mm / 8” Co-axial Flue ‘Decktite’...
Page 20 How to flash the Internal Vertical Powerflue...
Page 21: C5 Installing The Universal Vertical Powerflue (Internal Install)
Installing the Universal Vertical Powerflue (Internal Install) Note: For information regarding an external install of the UVP, go to section The UVP Internal configuration is designed to have the fan, mounted within the roof space of the house, and the vertical ø225mm diameter liner, containing a ø100mm flexi, penetrate through the roof.
Page 22 The UVP-Internal kit is intended for use within an accessible roof space or ‘chimney’ construction. Service access must be provided. Ensure installation complies with relevant building codes and regulations Typical Installation UVP Cowl 1.2m F-F Liner ‘Decktite’ or similar ashing Roof Space Ensure Power Flue unit is securely braced using...
Page 23: C6 Installing An External Vertical Powerflue (Evp Or Uvp)
C6 Installing an External Vertical Powerflue (EVP or UVP) Note: For information regarding an internal install of the UVP, go to section C5. The EVP and UVP are designed to have the enclosure containing the fan unit mounted externally. The cowl surround should be fixed in place as shown. Depending on the kit purchased, mount the EVP/UVP kit to the top of a chimney flashing plate or penetrate the roof with an optional flue liner accessory and fit the EVP or UVP kit over the flue liner;...
Page 24: C7 Installing In Accordance With Relevant Codes
Installing in Accordance with Relevant Codes: The location of the Horizontal Powerflue Wall Terminal must be installed in accordance with AS/NZS 5601 and any other relevant building codes. If possible, avoid installing the Horizontal Powerflue Wall Terminal in areas exposed to high winds and extreme weather. Some of the minimum clearances for a fan assisted wall terminal are listed below;...
Page 25: C8 Running The Flue
Notes: 1) Should the flue not extend past the apex, the top of the flue should extend at least 400mm from the roof (or 500mm in regions with heavy snow). 2) The installation of a flue into a carport is not recommended. 3) The flue terminal will get very hot when in use.
Page 26: C9 Running The Powerflue Electrical Cable
FOR MORE INFORMATION ON INSTALLATION OF THE POLYPRO FLUE, SEE ‘POLY PRO FLUE INSTALLATION INSTRUCTIONS’ AVAILABLE ON: WWW.ESCEA.COM OR SUPPLIED WITH THE FLUE. FOR POLY PRO COMPONENT GUIDES, THESE ARE AVAILABLE ON: WWW.ESCEA.COM TITLED: HORIZONTAL FLUE COMPONENT GUIDE & VERTICAL FLUE COMPONENT GUIDE...
Page 27: Installing The Electricity And Gas To The Appliance
Installing the Electricity and Gas to the Appliance Power Supply While the cavity is being created consideration should be given to appropriate location of a standard 3 pin, EARTHED 230/240V power outlet. This must be within 1.0m of the bottom right of the appliance.
Page 28: D3 Gas Pipe Sizing
D3 Gas Pipe Sizing Gas pipe should be sized as per the requirements of AS/NZS 5601.1. The pipe sizing must be sufficient to deliver the following volume of gas to the heater with all other gas appliances in the home running at the same time: Maximum DS1150 Gas Consumption = 34MJ/hr Maximum DS1400 Gas Consumption = 40MJ/hr...
Page 29: D5 Gas Isolating Valve
D5 Gas Isolating Valve A gas isolating valve must be installed in the gas line as close to the appliance as possible. Fix it in a convenient position to allow it to be closed off quickly and easily during normal operation. Take into consideration access to this valve once the wall linings are on.
Page 30: Installing The Appliance
Installing the Appliance Connecting the Flue Access the top of the appliance and connect both the inlet flue (Ø75mm ID / 85mm OD) and the exhaust flue (Ø100mm ID / 110mm OD) to their respective spigots. Tighten the hose clamps onto the spigots. Ensure the flue connection is air tight.
Page 31 4. Remove the screws (circled in the diagram below) in the back panel of the appliance 5. On the back of the appliance remove the one screw from each of the four red tabs and set each pair of tabs from open position (shown below) to the close position. 6.
Page 32 7. Unscrew the 1/4 turn fasteners and allow the panel to lean forward so you may lift the panel out. Note: if needed, you can relocate the diagnostic bracket as shown in step 3 of section E4. 9. After Removing inner panels and rear firebox panel. Fix the top trim in place with the black machine screws provided (black circles - see below).
Page 33: E4 Front To Back Conversion
Front to Back Conversion 1. Follow section E5 and E6 to remove the glass, infill, and burners. 2. Remove the rear panels by following steps 2, 3, 4, 6 & 7 from section E3 above. 3. Relocate the diagnostic bracket to the opposite side of the appliance by carefully removing the middle screw and feeding it through to the opposite side of the fire (as shown in the diagram below).
Page 34: E6 Removing Infill And Burners
NG to ULPG/Propane or vice versa. WARNING: The regulator that is supplied with the fire MUST NOT BE REMOVED. Removal of the regulator, or replacing it with one not intended for use with this Escea fire, will void the limited appliance warranty.
Page 35 Step 2: Change the three main burner jets with the jets supplied in kitset (see table on next page). Step 3: Replace the pilot jet (see table below). Note: Ensure the pilot jet is joined up to to the olive before inserting the jet into the pilot assembly (as shown below).
Page 36: E8 Operating The Appliance
ULPG Burner Jets Burner Collars Middle Burner Side Burners Pilot Middle Burner Side Burners DS1150 Ø1.3mm Ø0.85mm Spacer 2 x Ø7mm Holes DS1400 Ø1.25mm Ø1.02 Spacer 2 x Ø8mm Holes DS1650 Ø1.2mm Ø1.1mm Spacer 2 x Ø7mm Holes Propane Burner Jets Burner Collars Middle Burner Side Burners...
Page 37: E9 Checking The Operating Pressure
MUST NOT BE REMOVED. Removal of the regulator, or replacing it with one not intended for use with an Escea fire, will void the limited appliance warranty and may be dangerous. The gas valve is shown right with Manometer test points at A, C and D.
Page 38 Operating pressure - Post-Regulator (Point C) 2.3 kPa 2.3 kPa 1.0 kPa Operating Pressure when on high - (Point A or D) 1.67 kPa ±5% 1.67 kPa ±5% 0.67 kPa ±5% Operating Pressure when on low - (Point A or D) 0.82 kPa ±5% 0.82 kPa ±5% 0.34 kPa ±5%...
Page 39 WAIT, allow the appliance to fully light all burners before continuing. The high setting for the currently set gas type is displayed first (indicated in the clock segments at the top). Pressing the plus or minus keys will change the setting up or down respectively and change the gas pressure measured at point A or D.
Page 40: E10 Auxiliary On/Off Button
The AUX button location can be seen in the diagram below. E10 Home Automation Setup Escea D-Series fireplaces have a simple interface for connection to a home automation system. Simply put this allows the fireplace to be woken up and started and then shut down. The “Close to wake” con- nection shown is essentially taking one of the 3.3 volt DC pins on the fireplace micro controller and...
Page 41 µ From Automation system Connector and terminal block supplied by Escea Note: you will need to match the relay coil voltage with the voltage from your automaton system. The home automation connection can be found in your fireplace accessory pack and is shown to the right.
Page 42: Finishing The Installation
Finishing the Installation Coal, Crystallite or Driftwood Fuelbed Installation If using the crystalight, coal, or driftwood fuel beds, first place all the Crystallite/Coal pieces in a single layer atop the Burners and Fuelbed Tray. Cover the entire area except for the pilot shield, ensuring coverage right up to both glass windows and rear of firebox for single sided.
Page 43 Log Index Use the index above as a guide for selecting the correct logs. Log Setup DS1150 Step 1: Step 2: Step 3:...
Page 44 Log Setup DS1400 Step 1: Step 2: Step 3: Log Setup DS1650 Step 1: Step 2: Step 3:...
Page 45: F4 Woodland Fuelbed Installation
Woodland Fuelbed Installation Woodland Log Index Use the index above as a guide for selecting the correct logs: Woodland Log Setup DS1150 Step 1: Step 2: Step 3:...
Page 46 Woodland Log Setup DS1400 Step 1: Step 2: Step 3: Woodland Log Setup DS1650 Step 1 Step 2 Step 3...
Page 47: F5 Flame Picture
An abnormal flame pattern will likely be the result of incorrect settings (jet size, burner aeration collar), you must check these are correct before proceeding. If an abnormal flame pattern is still present, please contact Escea. It is the responsibility of the installer to ensure a correct flame pattern.
Page 48 DS-Series Minimum Wall Lining Dimensions Model DS1150 1401 DS1400 1693 DS1650 1987 Note: The wall lining directly above the appliance will get warm and hence may discolour paint finishes that are susceptible to temperature damage or distort vinyl wall coverings. For durability of finishes and surfaces you should contact the relevant manufacturer for their specification and avoid materials with temperature ratings less than 80deg C.
Page 49 Gib Rondo stopping bead). Note: a 20mm or less wall lining must be used when installing a DS Series fireplace without a fascia. For wall linings of a total thickness of 10mm or larger, a “Linear Trim” may be purchased to cover any exposed wall lining.
Page 50: F7 Fitting The Fascia
. Linear Trim To install the Gib Trim onto the DS Series, Hook the bottom edge over the bottom trim first and push the top edge up and flush with the wall cladding.
Page 51: F8 Locating Wall Mount Cradle For Wireless Control
Ideally 1.2m to 1.5m from the floor The radio frequency signal will go through some walls but for best results Escea suggest that the cradle position is less than 10 metres away from the heater. The best height off the ground to locate the cradle is about chest height.
Page 52: F10 Normal Operating Sounds And Smells
These are all normal operating sounds and should not be considered as defects in your appliance. Fan: Escea gas appliances use electric fans to push heated air into the room. It is not unusual for the fan to make a “whirring” sound when ON. This sound will increase or decrease in volume depending on the speed setting of your fan.
Page 53: Installation Checklist
Installation Checklist Go through the following checklist to ensure you have installed the appliance correctly □ Correctly sized cavity to suit your fascia and flue configuration □ Correct clearances to combustibles □ An electrical isolating switch to the appliance, accessible after finished installation □...
Page 54: Service Manual
Service Manual IMPORTANT: • This appliance must be serviced every 12 months. • Any service operation should be carried out only by a suitably qualified and trained person. • Gas and electricity supply MUST be isolated before any service operation is carried out on this appliance.
Page 55: S2 Error Codes
Error Codes This gas fire has been designed to show error codes to help explain and identify any fault situation that occurs. These codes will appear on the wireless remote control in the form of a large letter “E” with a number beside it.
Page 56 The bimetallic snap disk mounted on the exhaust collector box has tripped. The possible causes for this could include: • Possibly fascia panels installed incorrectly resulting in restricted air flow. • Room air fans may be slowed or stalled. Check that fans are plugged in, Appliance Over cleaned, and free turning Temperature...
Page 57: S3 Cleaning The Fuelbed And Glass
NEVER RUB THE FASCIA. The outside of the fascia’s must only be cleaned with a clean damp cloth, dry off after cleaning. The high temp silver powder coating that is used on Escea fascia parts contains certain amounts of aluminium that when rubbed too hard will oxidise leaving a black smudge that cannot be removed.
Page 58: S6 Replacing A Remote Control
Replacing a Remote Control If the wireless control becomes lost or damaged, a new one can be ordered from any Escea retail agent. When you have the new remote, the following procedure needs to be followed to “teach” the remote to only communicate with that fire.
Page 59: S9 Removing Or Cleaning Fan
Removing or Cleaning Fan As part of regular service procedure, it is recommended that the fan is removed for cleaning. Dust will build up on the fan rotor and in the cavity where the fan is located. This can be removed by the service person using a hearth brush and a vacuum cleaner.
Page 60 2. Remove the 10 screws (shown in the diagram below) in the access hatch and carefully remove from the firebox. 3. Remove the 2 silicone tubes (making note of which tube goes on each spigot) Disconnect the two wires from the pressure switch and remove the two screws on either side of the pressure switch to remove it from the bracket.
Page 61: S12 Replacing The Thermal Cut Outs (Tco)
S12 Replacing the Thermal Cut Out WARNING - Ensure power is turned off before removing any TCO. There are two thermal cutouts: one in the LH room fan assembly (60°C) and the other attached to the exhaust manifold (120°C). Exhaust TCO (120°C) Access to this TCO can be made by following steps 1 to 2 from section S11.
Page 62 Fan TCO (60°C) Access to this TCO can be made by following S9 and removing the left hand fan (not exhaust side). Once the fan is removed you will see the TCO (circled in the diagram below). To remove this, un- screw the two visible screws and once free remove the two wires connected to the TCO and remove from chassis.
Page 63: S13 Servicing The Horizontal/Vertical Powerflue
S13 Servicing the Horizontal / Vertical Powerflue Ensure the power to the Powerflue is off by disconnecting the power to the appliance inside. If the appliance has been running, allow the Powerflue to cool before attempting to service it. Servicing a horizontal Powerflue: If the Powerflue needs servicing, the fan can be accessed from the outside of the installation for Horizontal termination, and accessed from within the roof space for Vertical termination.
Page 64: S14 Wiring Diagram
S14 Wiring Diagram...
