STI Exit Stopper -6400 Series Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Features:
·
Alarm helps prevent unauthorized exits/entries through doors.
·
Easy to install.
·
Select volume, duration and immediate or 15 second delay for arming and trip.
·
May be mounted on top, right, left or next to almost any door.
·
User can select on-site whether to use an alarm or annunciator.
·
Less expensive than heavy horizontal bar type units and practical for all
emergency doors.
·
Contact STI for custom applications.
Exit Stopper
STI-6400 Series
- 1 -
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Exit Stopper STI-6400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for STI Exit Stopper STI-6400 Series

Summary of Contents for STI Exit Stopper STI-6400 Series

  • Page 1 May be mounted on top, right, left or next to almost any door. · User can select on-site whether to use an alarm or annunciator. · Less expensive than heavy horizontal bar type units and practical for all emergency doors. · Contact STI for custom applications. - 1 -...

  • Page 2: Table Of Contents

    All units are recommended for indoor use, not for outdoor use. Unit must be tested periodically to verify the life of battery. STI recommends you change the 9 Volt battery twice a year. Installer may need to purchase a simple audio-meter, typically available at your local electronics store, to measure the sound in areas where the alarm is expected to be heard during normal noise environment.

  • Page 3: Specifications

    Alarm Current 50mA at 95 dB/ 200 mA at 105 dB * Power source for the STI-6403 Remote Horn uses a separate power source from the STI-6400 alarm. The Remote Horn contains an internal 9 volt battery. Horn operates when the Form C contact at main unit is activated on alarm.

  • Page 4: Circuit Board Set-Up

    Circuit Board Set-up (ON) ALARM VOLUME SWITCH TERMINAL BLOCK (OFF) TRIP DELAY SWITCH (OFF) ALARM DURATION SWITCH (OFF) (FACTORY DEFAULT SETTINGS) (ON) ARMING SWITCH PC BOARD FACTORY DEFAULT SETTINGS FOR COMPLETE ALARM OPTIONS AND SWITCH SETTINGS SEE CHART ON REVERSE SIDE. NC COM NO GD KEYSW (ON)

  • Page 5: Alarm Feature Description

    In “OFF” position delay arming will allow 15 seconds for you to exit through the door without sending alarm signal. Installation Instructions Note: STI recommends setting up unit and testing settings prior to mounting. 1. Make sure key switch is in the OFF 19014 MOUNTING SCREW position.

  • Page 6: Mounting Options

    6400 SWING *Note: When mounting reed switch on door and the main unit on wall, wire service loop must be used. DOOR Figure 5 SWING TYPICAL DOUBLE DOOR INSTALLATION STI-6402 INTERNAL REED SWITCH Figure 6 (RS1) - 6 - TO KEY...

  • Page 7: Sti-6402 Double Door Additional Install Notes

    Figure 8 STI-6404 Double Door with Remote Horn Install Notes The STI-6404 is a combination unit for double doors with a remote horn. Reference the installation instructions for the main unit, the STI-6402 and the STI-6403 for complete installation. STI-6405 Exit Stopper with Momentary Reset The STI-6405 uses a momentary switch.
