Norco BPC-7971 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BPC-7971
USER' Manual V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPC-7971 and is the answer not in the manual?

Questions and answers

Related Manuals for Norco BPC-7971

Summary of Contents for Norco BPC-7971

  • Page 1 BPC-7971 USER' Manual V1.0...
  • Page 2 BPC-7971 USER' Manual V1.0 SZ HQ: 0755-27331166 Beijing Office: 010-82671166 Shanghai Office: 021-61212081 Chengdu Office: 028-85259319 Shenyang Office: 024-23960846 Xi’an Office: 029-88338386 Nanjing Office: 025-58015489 Wuhan Office: 027-87858983 Tianjin Office: 022-23727100 Singapore: 65-68530809 For more information, please visit：www.norco.com.cn...
  • Page 3 Shenzhen NORCO Intelligent Technology Co.,Ltd. BPC-7951 Digital Signage Special Board Shenzhen NORCO Intelligent Technology Co.,Ltd. Place/Date: HONG KONG/2018...
  • Page 4 Trade Name： Shenzhen NORCO Intelligent Technology Co.,Ltd. Model Name：BPC-7951 Responsible Party： Shenzhen NORCO Intelligent Technology Co.,Ltd. Equipment Classification：FCC Class B Subassembly Type of Product：BPC-7951 Digital Signage Special Board Manufacturer： Shenzhen NORCO Intelligent Technology Co.,Ltd. Date: 2018...
  • Page 5 Before ordering products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD. The ownership of other trademarks involved in this manual is owned by its...
  • Page 6 Safety Instructions 1． Please read the product manual carefully before using this product. 2．Put all the unused or uninstalled boards or electronic components in a static dissipative surface or static shielding bag. 3．Always ground yourself to remove any static discharge before touching the board, to place your hands on grounding metal object for a while or wear a anti-static wrist strap at all times.

  • Page 7: Table Of Contents

    Content Chapter One Product Introduction ....................1 1.1 Product Introduction........................1 1.2 Hardware Specificattion......................1 Chapter Two Hardware Function ...................... 4 2.1 Interface Location and Dimensional Drawing............... 4 2.2 Installation Steps........................4 2.3 Memory Installation........................5 2.4 Jumper Settings.........................5 2.4.1 CMOS Clear/Hold Jumper Setting（JCC）..............6 2.4.2 Auto Boot upon Restore AC Power（JAT）..............
  • Page 8 2.6.5 In the Network and Sharing Center interface, click "Connect to the Network" as shown below........................... 23 2.6.6 Select the signal source and click on the connection..........23 2.6.7 Click Continue and wait for a while (there is no need to fill in the access point name, username, password here)..................
  • Page 9 Appendix 1：Watchdog Watchdog Programming Guide............47 Appendix 2: Glossary........................48 Appendix 3：Driver Installation....................50...
  • Page 10 Packing List Thanks for purchasing NORCO products. Please check the accessories as per the packing list when you open its package. If you find any defect components or anything damaged or lost, please contact your vendor ASAP. ■BPC-7971 1 pcs ■Drive CD...
  • Page 11 Chapter Product Introdu ction...

  • Page 12: Chapter One Product Introduction

    BPC-7971 User's Manual Chapter One Product Introduction 1.1 Product Introduction BPC-7971 applies INTEL H110 chipset，supports the 6 generation INTEL Core I3/I5/I7 processor. On board 4GB/8GB DDR4 memory chip+1xDDR4 DIMM slot ， memory slot maximum support 16 GB，the whole motherboard up to 24GB；Support VGA+DP display port，...
  • Page 13 BPC-7971 User's Manual ●VGA：VGA+DP display port， ●DVI：Support DVI port via expansion board，support independent dual display Ethernet ●Model：INTEL I211 ●Speed：100/1000MBps ●2xRJ45 network interface ● Support Wake On LAN（WOL） Storage ●Provide 2xSATA3.0 port ●Independent 1xpower supply socket（5 Pin connector） AUDIO ●Apply ALC662 audio control chip，support dual track，stereo；...
  • Page 14 BPC-7971 User's Manual ●Provide one 2x 25PIN 2.0mm JLPC（with AFC-990113 expansion board） ； ●Provide one 2x 25PIN 2.0mm JCOMUSBDDI（with AFC-967 expansion board） Power Supply ●Support single supply+12V Watchdog ●Supports hardware and software switch for system auto boot upon power on BIOS ●BIOS：64M bit SPI...
  • Page 15 Chapter Hardware Function...

  • Page 16: Chapter Two Hardware Function

    BPC-7971 User's Manual Chapter Two Hardware Function 2.1 Interfaces Location and Dimension Following picture illustrates the front interfaces and dimension of board BPC-7971. Please pay attention to the installation process. Improper installation of some components may lead to system failure.

  • Page 17: Jumper Settings

    4．Please first check the power switch is off before connecting the power plug. 2.3 Install Memory BPC-7971 provides 1xdual channel DIMM memory slot ， support DDR4 DIMM memory slot，memory up to 8GB. Please refer to the following steps to install memory：...

  • Page 18: Cmos Clear/Hold Jumper Setting（Jcc

    BPC-7971 User's Manual Remark: How to identify the PIN1 of all jumpers and interfaces: Please observe the word mark on the side of the plug socket, which will be a “1” or bold line or triangular symbol; And please look at the back of PCB, each with a square shape will be the PIN 1; and all the jumpers’ PIN1 have a white arrow on the side.

  • Page 19: Auto Boot Upon Restore Ac Power（Jat

    BPC-7971 User's Manual Setting CLEAR NORMAL Do not clear CMOS when the computer is power on, otherwise, it will cause damage to the motherboard! 2.4.2 Auto Boot upon Restore AC Power（JAT） JAT： Setting Open Non auto boot Close Auto boot 2.5 Interfaces Description...

  • Page 20: Sata Ports（Sata1、Sata2、Jsatapwr

    BPC-7971 User's Manual 2.5.1 SATA Port（SATA1、SATA2、JSATAPWR） Provide 2xstandard 7Pin SATA port and 1xSATA power supply port. SATA2 SATA1 JSATAPWR SATA1： Signal Name SATA_TXP SATA_TXN SATA_RXN SATA_RXP SATA2： Signal Name...

  • Page 21: Usb、Lan Port（Usb 12、Usb1-4、Lanx2

    BPC-7971 User's Manual SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 Signal Name Signal Name VCC3 VCC3 VCC3 +12V +12V +12V JSATAPWR： Signal Name +3.3V +12V 2.5.2 USB、LAN Port（USB 12、USB1-4、LANx2） Provide 8xUSB port ， 1xdouble-deck standard USB3.0 port ； 2xdouble-deck standard USB2.0 port；USB56 is the pin port of 2x5Pin 2.00mm.

  • Page 22: Audio Port（Speaker、 Mic

    BPC-7971 User's Manual USB12 LANx2 USB1-4 USB12： Signal Name Signal Name VCC_USB3 VCC_USB3 USBD_N9 USBD_P9 LAN LED Status： LILED（Green） Function ACTLED（Yellow） Function 100/1000M link Flash Data transfer 10M link/close No data 2.5.3 Audio Port（SPEAKER、 MIC） Adopt ALC662 audio control chip，the green one is audio output port（Line-out） ，and...

  • Page 23: Display Port（Vga、Dp

    BPC-7971 User's Manual the pink one is microphone input port（MIC-in）. SPEAKER 2.5.4 Display Port（VGA、DP） 1xstandard DB15 VGA port，1 x standard DP port. Support VGA+DP display port，it can support DVI port via expansion port，and support independent dual display.
  • Page 24 BPC-7971 User's Manual VGA: Signal Name Signal Name Signal Name VGA_R VGA_G VGA_SDA_R VGA_B MON_HSYNC VGA1_POWE MON_VSYNC VGA_PIN10 VGA_SCL_R DP： Signal Name Signal Name DP0P DP0N DP1P DP1N DP2P DP2N DP3P DP3N...

  • Page 25: Power Interface（Pwr2

    BPC-7971 User's Manual DPC3_AUX_DP DPC3_AUX_DN DDIP_HPD3_DM VCC3 2.5.5 Power Interface（PWR2） PWR2 PWR2： Setting Signal Name +VIN...

  • Page 26: Programmable Input And Output Port（Jgp

    BPC-7971 User's Manual 2.5.6 Programmable Input and Output Port（JGP） JGP： Signal Name Signal Name GP50 GP51 GP54 GP52 GP55 GP53 GP56 GP57 2.5.7 SIM Port Provide 1xSIM port.

  • Page 27: Jlpc Port

    BPC-7971 User's Manual 2.5.8 JLPC Port Provide 1xJLPC port（this interface connects the serial expansion card）.
  • Page 28 BPC-7971 User's Manual JLPC JLPC: Signal Name Signal Name LPC _CLK L_FRA E_N CLK_LPC_48M PLTRST_N L_AD3 L_AD2 VCC3 L_AD1 L_AD0 SMB_CLK SMB_DATA 3VDUAL SER_IRQ LPCPD_N USB_N7 USB_N8 USB_P7 USB_P8 SATA_TXN2 MS_CLK...

  • Page 29: Jcomusbddi Port

    BPC-7971 User's Manual SATA_TXP2 MS_DATA SATA_RXN2 KB_CLK SATA_RXP2 KB_DATA VCC3 5VDUAL VCC3 5VDUAL VCC3 +12V 2.5.9 JCOMUSBDDI Port Provide 1xJCOMUSBDDI port（this interface connects the display expansion card）. JCOMUSBDDI JCOMUSBDDI：...
  • Page 30 BPC-7971 User's Manual Signal Name Signal Name DCD#1 DSR#1 SIN1 RTS#1 SOUT1 CTS#1 DTR#1 RI#1 DCD#2 DSR#2 SIN2 RTS#2 SOUT2 CTS#2 DTR#2 RI#2 USB_N5 USB_N6 USB_P5 USB_P6 DDI1_TXN0 DDI1_TXN2 DDI1_TXP0 DDI1_TXP2 DDI1_TXN1 DDI1_TXN3 DDI1_TXP1 DDI1_TXP3 DDI1_AUX_DN DDPB_CLK DDI1_AUX_DP DDPB_DATA PLTRST_N_BUF...
  • Page 31 BPC-7971 User's Manual JFP： Signal Name Signal Name VCC3 SATALED SPK- RSTBTN+ POWERSW Please follow the table below to connect, pay attention to anode(+)and cathode(-), otherwise , some function cannot be realized. PWR-LED HDD-LED BUZZ RESET BUTTON POWER BUTTON 1）System power LED pins（Pin1、2 for PWRLED）...

  • Page 32: Memory Slot

    BPC-7971 User's Manual Connect system power LED cable with these pins.（pin 1 is LED anode）When system is power on, power LED is on；when system is power off, power LED is off. 2）HDD Status LED Pins（Pin3、4 for HDD LED） There is one HDD LED on panel. When HDD is reading and writing, the LED flashes, indicating the device is working.

  • Page 33: Under The System, You Can See That The Motherboard Has Identified The 4G Module, And Then Installed The 4G Module Driver

    BPC-7971 User's Manual 2.6.2 Under the system, you can see that the motherboard has identified the 4G module, and then installed the 4G module driver. 2.6.3 After the driver is installed, as shown below, there is a modem in the...

  • Page 34: Click "Open Network And Sharing Center

    BPC-7971 User's Manual 2.6.4 In the lower right corner of the system, right-click the wireless network icon and click “Open Network and Sharing Center”.

  • Page 35: In The Network And Sharing Center Interface, Click "Connect To The Network" As

    BPC-7971 User's Manual 2.6.5 In the Network and Sharing Center interface, click "Connect to the Network", as shown below. 2.6.6 Select the signal source and click on the connection.

  • Page 36: Name, Username, Password Here)

    BPC-7971 User's Manual 2.6.7 Click Continue, Wait a minute（There is no need to fill in the access point name, user name, password here.) 2.6.8 Installed Successfully.

  • Page 37: Chapter 3 Bios Setup

    Chapter Three BIOS Setup...

  • Page 38: Ami Bios Refresh

    BPC-7971 User's Manual Chapter Three BIOS Setup AMI BIOS Refresh BIOS functions as a bridge connecting hardware and operating system. Hardware and software are upgrading all the time, so when your system goes wrong, for example, your system cannot support the newest CPU, you need to upgrade BIOS to keep up with the latest technology.

  • Page 39: Main Menu

    BPC-7971 User's Manual menu” please press <DEL> to enter BIOS SETUP Program. 3、Use the “←↑→↓”to choose the option which you want to modify, press <Enter> to go to the sub-menu. 4、 Use the “←↑→↓” and <Enter> to modify the value; press” Enter” to modify BIOS options that you choose.
  • Page 40 BPC-7971 User's Manual BIOS Vendor ：BIOS Vendor，American Megatrends Build Date and Time ：BIOS Date and Time，04/18/2018 11:23:50 ME FW Version ：ME FW Version ME Firmware SKU ：ME FW SKU Information System Language Setting up system language System Date System date format: Week/Month/Date/Year ： Month (Jan.-Dec.) ， Date (01-31) ， Year (maximum 2099)，Week (Mon.～Sun.).

  • Page 41: Advanced

    BPC-7971 User's Manual 3.2 Advanced Launch LAN1/2 PXE OpROM This item is used to set whether the onboard network card PXE is allowed to start. The setting value is : [Enabled] [Disabled] CPU Configuration CPU parameter information and common settings options.
  • Page 42 BPC-7971 User's Manual Hardware Monitor System Monitor, Hardware Monitor, Hardware Monitor S5 RTC Wake Settings System shutdown wake-up settings Serial Port Console Redirection Serial port redirection settings CSM Configuration Compatibility support module control options USB Configuration USB Information and control options.
  • Page 43 BPC-7971 User's Manual Hardware prefetcher Hardware Prefetcher: Before CPU processes instructions or data, it prefetches these instructions or data from memory into L2 cache to reduce memory reading time and help eliminate potential bottlenecks, so as to improve system efficiency.
  • Page 44 BPC-7971 User's Manual 3.2.2 Power & Performance...
  • Page 45 BPC-7971 User's Manual...
  • Page 46 BPC-7971 User's Manual Note：Power settings...
  • Page 47 BPC-7971 User's Manual 3.2.3 PCH-FW Configuration...

  • Page 48: Acpi Settings

    BPC-7971 User's Manual 3.2.4 ACPI Settings Enable ACPI Auto Configuration Automatically configure APCI that allow (Enabled) or close (Disabled) BIOS. The default is Enabled. Enable Hibernation Enabled or Disabled system sleep function (OS/S4 sleep state). This option does not work under some OS.

  • Page 49: F81866 Supper Io Configuration

    BPC-7971 User's Manual 3.2.5 F81866 Supper IO Configuration Serial Port 1 Configuration Serial Port 2 Configuration...
  • Page 50 BPC-7971 User's Manual...
  • Page 51 BPC-7971 User's Manual Serial Port [Enabled] or [Disabled] the serial port Device Setting（Read only） Display the serial port IRQ and I/O address. Change Setting Change serial port I/O address or IRQ settings，Default [Auto]...
  • Page 52 BPC-7971 User's Manual...
  • Page 53 BPC-7971 User's Manual Serial Port 1 Configuration 1）Serial Port [Enabled] or [Disabled] the serial port 2）Device Setting（Read only） Display the serial port IRQ and I/O address. 3）Change Setting This item is used to change the serial port settings. It is recommended that Auto be selected by default.

  • Page 54: Hardware Monitor

    BPC-7971 User's Manual 3.2.6 Hardware Monitor Hardware Security Detection Object PC Health Status Hardware Security Detection，BIOS will display the current system temperature，CPU temperature，Fan speed，and other related voltage values. The above parameters have a certain range, the system cannot run beyond these ranges.

  • Page 55: S5 Rtc Wake Settings

    BPC-7971 User's Manual 3.2.7 S5 RTC Wake Settings Wake system from S5 This item is used to set whether to start at a fixed time, the default value is [Disabled]; setting [Fixed Time], it will start at a specified time; setting [Dynamic Time], it will start after a specified...

  • Page 56: Serial Port Console Redirection

    BPC-7971 User's Manual 3.2.8 Serial Port Console Redirection...
  • Page 57 BPC-7971 User's Manual Console Reditection： The motherboard supports serial port 1,2 console redirection，default Disable. To turn on redirection function, only need to turn on COM1 or COM2 redirection, and don't need to turn on EMS redirection.

  • Page 58: Csm Configuration

    BPC-7971 User's Manual 3.2.9 CSM Configuration CSM Support CSM---Compatibity Support Module. It is a special module of UEFI, which provides compatibility support for systems that do not support UEFI. GateA20 Active Activate A20 Option ROM Messages Setting OpROM Display Mode INT19 Trap Response OpROM trigger Int19 trigger timing，...

  • Page 59: Usb Configuration

    BPC-7971 User's Manual Storage Which type of storage is supported OpROM，such as Efi OpROM or Legacy OpROM，or both. Video Which type of display is supported OpROM，such as Efi OpROM or Legacy OpROM，or both. Other PCI devices This represents the OpROM execution policy for other PCI devices.

  • Page 60: Chipset Menu

    BPC-7971 User's Manual Port 60/64 Emulation This control USB port 64/60 Emulation function. When this function is enabled, the USB keyboard can make some special key combinations. The setting value is：Disabled, Enabled. USB Transfer time-out Timeout of setup control, batch, and interrupt transfer. The default is 20 seconds.

  • Page 61: Graphics Configuration

    BPC-7971 User's Manual options. PCH-IO Configuration South Bridge Configuration. Including sound card, network card, switch for system auto boot upon power on and other options. 3.3.1 System Agent (SA) Configuration VT-d Intel I/O virtual technology needs to be supported by chipset, and some of the chipsets support it while some not.

  • Page 62: Lcd Control

    BPC-7971 User's Manual 3.3.2 Graphics Configuration LCD Control LCD screen control setting...
  • Page 63 BPC-7971 User's Manual 3.3.3 LCD Control Primary IGFX Boot Display Main display settings...

  • Page 64: Usb Configuration

    BPC-7971 User's Manual 3.3.4 USB Configuration XHCI Disable Compliance Mode...

  • Page 65: Pch-Io Configuration

    BPC-7971 User's Manual 3.3.5 PCH-IO Configuration USB configuration USB Setting Restore AC Power Loss This option is to setup the system status while connecting the power again after the AC Power Loss. <Power Off>: System remains the status of power off. Users need to press the power button to start the computer.

  • Page 66: Sata And Rst Configuration

    BPC-7971 User's Manual 3.3.6 SATA and RST Configuration Serial-ATA Controller(S) To set the SATA controller to be enabled or disabled. The setting values are: [Disabled]， [Enhanced]，[Compatible]. SATA Mode selection To set the SATA configuration mode.，The setting values are: [AHCI]，[RAID] SATA Test Mode This is SATA test mode，the setting value is [Disabled].

  • Page 67: Security Menu

    BPC-7971 User's Manual 3.4 Security Menu The password length: Min: 1 character, Maximum: 20 characters. Administrator Password To setup administrator password User Password To setup User’s Password.

  • Page 68: Boot Menu

    BPC-7971 User's Manual 3.5 Boot Menu Setup Prompt Timeout The timeout period to press Setup button. If Setup button is not pressed in setting time, then the computer should continue to turn on. Bootup Numlock State The function allows the numeric key lock function after system power on DOS. The default setting is On and the system will unlock the numeric key, and if Off is set, then the keypad will be controlled by cursor.

  • Page 69: Save&Exit Menu

    BPC-7971 User's Manual This option includes hard disk which can be used as startup device. If there are many hard disks, then you should place the hard disks in order. The hard disk in priority will be displayed on Boot Option #1.
  • Page 70 BPC-7971 User's Manual Do not save the currently changed settings. Restore Defaults Load optimization settings. If this option is selected, the system will be set according to the factory optimization values. Save as User Defaults Saved as the user's default value...

  • Page 71: Appendix

    Appendix...
  • Page 72 ATX-6971 User's Manual Appendix Appendix 1：Watchdog Programming Guide watchdog reference code（C） ----------------------------------------------------------------------------------------------------------------------------- Set the port to realize watchdog function. In C programming language, different functions of Watchdog Timer can be realized by operating ports by writing data to corresponding ports. Port specification：...
  • Page 73 ATX-6971 User's Manual Appendix 2：Glossary ACPI Advanced Configuration and Power Management. ACPI specifications allow operating system to control most power of the computer and its add-on. Windows 98/98SE，Windows 2000 and Windows ME supports this specification. BIOS Basic input/output system. It is software including all in/out control code interface in PC. The software will detect hardware when it auto boot, operate OS, and provide an interface between OS and hardware.
  • Page 74 ATX-6971 User's Manual applications. For example: SDRAM/DDR SDRAM/RDRAM. Local Area Network. Network grouped by correlative computers in a small area, generally in a company or a building. Local area network is buildup by sever, workstation, some communications links. Terminals can access data and devices anywhere through cables, which enables users to share costly devices and resource.
  • Page 75 Please install the driver in the following way： 1. When the driver CD-ROM of the motherboard is put into the CD-ROM, the dialog box “NORCO Drivers Installer”will pop up automatically; 2. Find the corresponding motherboard name and click to enter the driver list interface;...
