6

Putting into and out of Operation

6.1 Putting into Operation

Before starting operation of the unit the transport lock must be removed.
In order to ensure the proper function of the unit, please follow the below outlined points in their order.
Comply with the cleaning regulations defined by local laws before beginning each operation.
Connectors must be cleaned every time prior to attaching a beverage container.
Connect coupling to beverage container.
For soft drink note: gray coupling = CO
Open the valve of the CO
regulator.
It should be within the following standard values:
Syrup:
Carbonator pressure:
Diet/light-beverage:
Set the CO -pressure by turning the control screw:
2
To increase the pressure: Clockwise
To reduce the pressure: Counterclockwise
Afterwards check the CO
displayed at the pressure regulator should not drop. If it does, notify the service technician immediately! Do
not forget to re-open the CO
Open the water feed line and check the flow pressure. Standard value: 0,17-0,35 MPa (1,7-3,5 bar).
Set flow pressure at the control screw on the water pressure regulator:
To increase the pressure: Clockwise
To reduce the pressure: Counterclockwise
Check the beverage/syrup lines for leaks. Only a visual inspection is possible. If liquid is leaking, call a
service technician.
Close the water feed line. The pressure display should not drop. If it does, notify the service technician
immediately! Check the incoming waterline for leaks. Do not forget to re-open the water feed line if no
leakage is evident.

6.2 Turning on the Unit

The water bath must be filled to the overflow with tap water. Refer to the technical data for the amount
required.
Take care, that no water runs into the agitator motor. Reference: Use for this a suitable funnel and filler
tube.
To prevent algae from forming in the water, add the disinfectant Molco (PN 14-9670-150). The 150 ml
container of disinfectant is sufficient for 30 liters of water.
Insert the mains plug for the cooler into the socket outlet with an earthed contact.
Units with water bath are ice bank controlled. These units start working automatically after the water bath is
filled with water. The compressor will cycle off after the ice bank has been built. (full ice bank capacity). The
control board of the unit has a time delay for switching on and off the cooling system when it runs in ice
Cornelius Deutschland GmbH
Document no: TD1009600EN
Version A, 24.09.2019, Index 0
, black coupling =beverage/syrup
2
-cylinder and the pressure regulator. Check the CO
2
0,42-0,49 MPa (4,2-4,9 bar)
0,52-0,58 MPa (5,2-5,8 bar)
0,21-0,28 MPa (2,1-2,8 bar)
-lines for leaks by closing the CO
2
-valve if no leakage is evident.
2
LOOP Style XL CC
-pressure on the pressure
2
cold carbonation
-valve. The pressure (high pressure gauge)
2
Manual operation Countertop Vending Machine
LOOP Style XL CC
Page 11
