Summary of Contents for Onespace JNFF 50-JN16DSKES
- Page 1 ASSEMBLY INSTRUCTIONS MODEL 50-JN16DSKES SUPPLIER CODE: JNFF LOFT WRITING DESK, ESPRESSO...
- Page 2 Desktop maximum weight capacity = 150 lbs...
-
Page 3: Replacement Parts
PARTS AND HARDWARE LIST EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE. PART DESCRIPTION STOCK NO 51-JN16DSK5DF Desktop Frame 51-JN16DSK5LG 51-JN16DSKESDT Desktop 51-JN16DSK5BB Back Support Bar 51-JN16DSK5SB Side Support Bar 51-JN16CA5 Caster HARDWARE KIT STOCK # 51-JN16DSK5HA DESCRIPTION - READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING. - Page 4 ASSEMBLY INSTRUCTIONS NOTE: Some of the screws are of similar length. Observe carefully which screw is needed before beginning each step. STEP 1 Attach the legs (2) to the desktop frame (1) using eight screws (A). A x 8 STEP 2 (i) Align the side support bars (5) with the legs (2).
- Page 5 ASSEMBLY INSTRUCTIONS STEP 3 Screw a caster (6) into the bottom of each leg. STEP 4 Attach the assembled frame to the desktop (3) with four screws (D) using the brackets on the desktop frame (1). D x 4...
-
Page 6: Safety And Maintenance
SAFETY AND MAINTENANCE • DO NOT stand on the desk. Do not use the desk as a stepladder. • • Every 6 months, check all bolts and screws to ensure they are tight. LIMITED WARRANTY PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR WARRANTY INFORMATION Comfort Products warrants this product to be free from defects in material and workmanship for one (1) year.
