OneSpace is a Trademark of Comfort Products, Inc.
ASSEMBLY INSTRUCTIONS
MODEL 50-JN173SHLFCO
SUPPLIER CODE: JNFF
Wood and Steel 3-Shelf Display, Classic Oak
CUSTOMER SERVICE
For fastest service on claims, requests for replacement parts,
or questions, please visit our website at:
www.comfortproducts.net/support
e-mail: customerservice@comfortproducts.net
Keep your sales receipt as documentation of your ownership.
Advertisement
Related Manuals for Onespace 50-JN173SHLFCO
Summary of Contents for Onespace 50-JN173SHLFCO
- Page 1 ™ OneSpace is a Trademark of Comfort Products, Inc. ASSEMBLY INSTRUCTIONS MODEL 50-JN173SHLFCO SUPPLIER CODE: JNFF Wood and Steel 3-Shelf Display, Classic Oak CUSTOMER SERVICE For fastest service on claims, requests for replacement parts, or questions, please visit our website at: www.comfortproducts.net/support...
-
Page 2: Assembly Overview
ASSEMBLY OVERVIEW Shelf weight capacity = 110 lbs. -
Page 3: Parts List
PARTS LIST THE PART NUMBER CAN BE FOUND ON THE SIDE OF THE PART, EITHER STAMPED OR ON A STICKER. ITEMS ARE NOT SHOWN TO SCALE. NOTE THAT THE BOARDS BELOW ARE SHOWN UPSIDE DOWN. DESCRIPTION STOCK Back Board 51-JN173COBB Shelf 51-JN173COSH Left Side Board... -
Page 4: Hardware Kit
HARDWARE KIT EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE. STOCK # 51-JN173HA PART DESCRIPTION QTY. - READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING. - REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION. M6 X 35MM - OPEN THE HARDWARE AS NEEDED . - ASSEMBLE IN AN AREA WITH PLENTY OF SPACE. - Page 5 ASSEMBLY INSTRUCTIONS STEP 1 Attach the Back Board (1) to the Shelf (2) using two Bolts (C) and two Cams (D). Make sure the arrow on the cam is facing the bolt. Using a screwdriver, turn the cam clockwise 180 degrees to lock the bolt into place. Repeat for the other two shelves. The drawing below shows the bottom of the shelf.
- Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Attach the Back Frame (5) to the Front Frame (6) using three M6 x 35mm Screws (A). Repeat with the other two frames. A x 6...
- Page 7 ASSEMBLY INSTRUCTIONS STEP 4 Attach the assembled shelves to the frames using twenty-four M6 x 30mm Screws (B). Note that in the drawing below the according to which screws you are fastening. B x 24...
- Page 8 110 pounds. For claims or questions concerning this warranty, please visit: www.comfortproducts.net or email us at: customerservice@comfortproducts.net MODEL: 50-JN173SHLFCO Comfort Products, Inc. 122 Gayoso Avenue, Suite 101 Memphis, TN 38103 Product made in China. www.comfortproducts.net ™ OneSpace is a Trademark of Comfort Products, Inc.
