Sumo Enclosure
Assembly Instructions
Tools Required:
Socket Driver
Sheet Code:
BP-IM-049_REV1
Release Date:
01/10/2019
Copyright 2016 Spotspot Ltd. (T/A
Bouncepad) all rights reserved.
Confidential, no part of this publication
may be reproduced or transmitted in any
form without the written permission of the
copyright holder.
M6x14mm Pan
PZ3 Driverbit
head screw
Case Washer
Tighten screw(s) using hand tools, using electric
tools may damage your Bouncepad.
Secure the Sumo Case to
2
the Sumo Stalk.
Locate the Sumo Faceplate onto the
6
Sumo Case - pressing the Faceplate
firmly down to ensure correct locking.
Fixings Kit
Pair of Keys
Sumo
Faceplate
Sumo
Case
In the Box
Unlock & remove the
3
Sumo Faceplate from the
Sumo Case.
Click
Connect to
7
power & turn
on.
4x M6x14mm
Pan head screw
1x Case Washer
* Due to the modular nature of
our product range you may receive
additional fixings in the fixings kit
1
Fixings List
Feed the tablet power
4
cable through the Sumo
Case and Sumo Stalk.
Installation of the Sumo
8
Case upon the Sumo
Stalk is now complete.
Locate the Sumo Case onto the Sumo
Stalk in your chosen orientation.
Install the tablet into the
5
Sumo Case & connect it
to the power cable.
Key number here
*We recommend recording the key number so
you can purchase additional keys in the future.
Installation is now
9
complete.
