FAQ
Instrument Solution – FAQ
Date:11.16.2011
Solution: The DM3068 has an internal webpage for verification of remote
operation via Ethernet. Here are the steps to begin operating the instrument via the
Ethernet connection.
Connect the power cord to the instrument and power on.
1.
Connect an ethernet cable to the instrument and to an operational ethernet
2.
connection (switch, PC, router, etc..)
Check the IP address of the DM3068
3.
Press Utility > T/C softkey > Info
•
Solution Title
Using the DM3068 Internal Webpage
Advertisement
Related Manuals for Rigol DM3068
Summary of Contents for Rigol DM3068
- Page 1 Solution Title Using the DM3068 Internal Webpage Date:11.16.2011 Solution: The DM3068 has an internal webpage for verification of remote operation via Ethernet. Here are the steps to begin operating the instrument via the Ethernet connection. Connect the power cord to the instrument and power on.
- Page 2 Open a browser on your PC Enter the IP Address for the instrument in the address area and press Enter on the computer keyboard.
- Page 3 6. The Instrument Web Page should open:...
- Page 4 7. Press the Web Control button on the DM3068 Webpage. This will enable web control of the instrument. NOTE: The Web Control Panel is a JAVA Applet. You may need to allow the JAVA Applet permission to run on your system in order to see the following screens.
- Page 5 8. The DM3068 Web page will open. Configure the function, range, and other parameters. When you are finished and want to collect data, press Apply as below.
