Dear Daxom User, For correct operation and safety of this device, follow the instructions in this manual during installation and use. Unauthorised assembly or maintenance of this device will void the warranty, and our company will not be responsible for any defects or accidents that may occur with the product. Please keep this instruction manual in good condition for future reference. - Page 3 2. RECOMMENDATIONS FOR ECONOMICAL USE 1.Adjust the indoor temperature settings to your needs. Having the heating operation set according to your intended use will increase energy savings 3. Savings can be made by adjusting the required temperature value for each section (of the property with thermostatic radiator valves), However, simultaneous use of a room thermostat and thermostatic valves may cause problems.
- Page 4 3. CONFIGURATION OF YOUR DEVICE...
-
Page 5: Technical Information
4. TECHNICAL INFORMATION... -
Page 6: Boiler Assembly
5. BOILER ASSEMBLY The boiler must be installed by a qualified technician. - Page 7 5.1 Installation requirements and safety instructions For ease of maintenance, observe the minimum distances specified in the installation in order to access the boiler. For correct device positioning: • Do not place above a stove hob or similar cooking appliances. •...
- Page 8 5.2. Wall Mounting of the Boiler The appliance must be installed exclusively on a vertical and solid wall that can support the weight of the boiler. M8 screws with appropriate anchors conforming to the type of the wall itself are recommended. 5.2.1.
- Page 9 5.2.1.1. Filling the Heating System for ETT and ETM Models After the hydraulic connections have been made, the heating system must be filled. For UKDAX-xxETT and UKDAX-xxETM models, this process is done via the filling valve connected to the heating system. For this purpose, a connection with a valve must be made from the cold water supply to the heating circuit. Since this valve will be used for filling the heating system, it is advisable to install it close to the device so that the pressure indicator is visible.
-
Page 10: The Electrical Connections
5.2.2. The Electrical Connections The electrical installation must be carried out by a qualified electrician using suitable diameter cable determined according to the boiler capacity and cable length. The MCB and RCD with appropriate characteristics and amperage which can cut the boiler electricity completely should be located separately and be close to the device. If there is no earthing installation in the structure where the boiler is installed, the grounding line for the boiler should be installed by a qualified electrician. -
Page 11: Control Screen
6. STARTING AND USING THE BOILER 6.1. Control Screen The operating status of the device can be viewed on the control panel. -
Page 12: Control Keys
6.2. Control Keys Use the buttons located under the LCD screen to control and program the boiler. 6.3. Operating the Device The boiler installation must be carried out by qualified tradespeople. Our company is not responsible for the damages and accidents that may occur due to installation by unauthorised tradespeople. Before starting the boiler, all mechanical and electrical connections must be checked. -
Page 13: Heating Temperature Adjustment
Press and hold for 2 seconds to switch the device on. If the last setting was heating mode before the device was switched off, the appliance will start heating after approx. 1 minute. will appear on the display. If the setting before the appliance was switched off was hot water mode only, the device switches to standby for hot water use. -
Page 14: Setting The Heating Mode
6.4.5. Room Thermostat Adjustment The boiler can be controlled with the room thermostat so that the boiler operates according to the temperature settings on the room thermostat. The room thermostat connection needs to be activated by the Installer. After connecting the room thermostat to the boiler, turn on the room thermostat in the Boiler setting menu. -
Page 15: Setting The Operating Mode
6.4.8. Setting the Operating Mode The device can operate in 3 different operating modes. 1. Heater Only Mode: The boiler is set to heat only. 2. Hot Water Heating Mode Only: Device only heats domestic water. Also called summer mode. 3. - Page 16 6.6. Switching off 6.6.1. Temporary Shutdown If the boiler will not be used for a short period press the button for 2-3 seconds to switch the device off. The boiler will be protected by the following systems (leaving electricity and fuel supply active): Frost Protection Function: If the water temperature in the boiler falls below 5 ° C, the pump and heating will operate to bring the water temperature back to a safe level (35 °...
-
Page 17: Electrical Diagram
7. ELECTRICAL DIAGRAM... -
Page 18: Repairs And Service
8. REPAIRS AND SERVICE We provide free repairs for material and production defects that occur during the warranty period of the product,. If you encounter any problems during use, please contact our after-sales service department. Unauthorised repair and maintenance of the device will void the warranty. Our company will not be responsible for the failures and accidents that occur as a result of unauthorised repair and maintenance. - Page 20 10. Room Thermostat wiring Ensure the chosen room thermostat is low voltage or voltage free!!
