Summary of Contents for DAXOM Navidens 50
- Page 2 DAXOM boilers provide following sufficiency Gas Appliances Directive 2009/142/EEC Boiler Efficiency Directive 92/42/ECC Electromagnetic Compability Directive 2004/108/CE Low Voltage Directive 2006/95/CE...
-
Page 3: Table Of Contents
CONTENTS 1.SECURITY INFORMATIONS AND WARNINGS ..................4 1.1 Warnings ............................4 1.2 Warnings ............................4 2 GENERAL INFORMATIONS ........................5 2.1 General Information ..............Hata! Yer işareti tanımlanmamış. 2.2 Giving Information to Customer While Deliver the Device ............5 2.3 Description ............................5 2.4 Device Dimensions .......................... -
Page 4: Security Informations And Warnings
Company. - Because of boiler is condensing type, be careful - DAXOM / Naviels wall hung condensing boiler that the condensing discharge line is connected must be installed by authorized person according and not blocked. -
Page 5: General Informations
DAXOM Company. 2.3 Description Any person except authorized person or person DAXOM Navidens boilers are condensing boilers who had education from authorized service must that are used by installing wall are designed as not interfere to device. -
Page 6: Device Dimensions
2.4 Dimension of Device Navidens 50-70... - Page 7 Navidens 125-145 a: Safety Valve Outlet b: Plumbing Return c: Gas Inlet d: Plumbing Exit e: Condensing Outlet f: Cable Entry...
-
Page 8: Boiler Installation Distances
2.5 Boiler Installation Distances... -
Page 9: Inside Structure Of The Device
2.6 Inside Structure of the Device 12- Electronic Control Card 1- Automatic Air Relief Cock 13- Circulation Pump 2- Safety Thermostat 14- Safety Valve 3- Manual Air Relief Cock 15- Return Water Temperature Sensor 4- Outlet Water Temperature Sensor 16- Manometer Hour Connection 5- Ionization Electrode 17- Pressure Switch 6- Ignition Electrode... -
Page 10: Technical Specificitions
2.7 Technical Specifications UNIT NAVİDENS50 NAVİDENS70 NAVİDENS125 NAVİDENS145 Fuel Type G20/G30 Pipe Type B23,C13,C33,C43,C83 Max Operation Pressure Maximum Operation ⁰C Temperature Fuel Consumption lt/min 89,5 114,5 lt/min 18,3 20,9 29,5 38,3 Heat Input kW/h 136,7 kW/h Heat Power 30-50 ⁰C Nominal Heat Load kW/h 52,5... - Page 11 Plumbing Connections Heating Cycle Exit inch 1 1/4" 1 1/4" 1 1/2" 1 1/2" Heating Cycle Circulation inch 1 1/4" 1 1/4" 1 1/2" 1 1/2" Gas Line inch 3/4" 3/4" 1" 1" Condensing Outlet Safety Discharge Outlet Fresh Air Inlet Exhaust Gas Outlet Specifications Cascade Connections...
-
Page 12: Installation
3 INSTALLATION 3.1 Installation - Internal circulation pump is located inside boiler. - Installation of the device must be done concerning installation distance determined inside user manual. - In case of plumbing pressure is higher, it is needed to put hydraulic separator between - While installs the device;... -
Page 13: Electrical Installation
- Pipe installation must be made as 1⁰ inclined through the boiler. - In case of combustion air is taken from environment, maximum pipe length is 20m. 90⁰bend correspond with 2 meter pipe and 45⁰bend correspond with 1,5m pipe. - Do not forget that extra connection accessories that will be used for line will also create resistance and will reduce allowed total pipe length distance. - Page 14 Concentric Pipe System Double Pipe System...
-
Page 15: Sample Installation Diagrams
4 Sample Installation Diagram 4.1 Heating System with Boiler... -
Page 16: Cascade Heating System Diagram With Solar System
4.2 Cascade Heating Diagram with Solar Energy... -
Page 17: Pipe Implementations
5 Pipe Implementation B23 When combustion air is taken from environment, exhaust gas transfer to outside with pipe. C13 Combustion air and exhaust gas transfer to outside by pipes which their outlets are interwoven or it can be transferred by separate pipes as maximum 50 cm distance between them. C33 Vertical exit is made from roof by interwoven pipes C43 Connection to common pipe outlet by interwoven pipes. -
Page 18: Electrical Project
6 ELECTRIC PROJECT Navidens 50/70... - Page 19 Navidens 125/145...
- Page 20 INTERIOR CONNECTION DESCRIPTIONS Boiler Return Sensor Boiler Exit Sensor Pressure Switch Pipe Gas Sensor Safety Thermostat Fan Motor Circulation Pump CLEMENS DESCRIPTION Boiler Cycle Pump Heating Cycle Pump Room Thermostat Outside Environment Sensor Optional Sensor Inlet B3/38 Optional Sensor Inlet Optional Sensor Inlet...
-
Page 21: Accesories
7. ACESSORIES PRODUCT DESCRIPTION PHOTO Cascade Communication Module Three Way Valve Connection Module Outlet Air Sensor Room Thermostat Cascade Sensor... - Page 22 PRODUCT DESCRIPTION PHOTO Pipe Set Ø 80/125 mm Ø 100/150 mm 45-90 Degree Bends Ø 80/125 mm Ø 100/125 mm Exhaust Gas Pipe Ø 80 mm Ø 100 mm Additional Pipe Ø 80/125 mm Ø 100/125 mm Fresh Air Inlet Accessory Ø80mm Ø...
-
Page 23: First Operation
8 FIRST OPERATION 1- It is entered to submenu by pressing confirm button (number 7) while it is in home screen of device. 2- It is entered to “Time program of heating cycle 1” menu by pressing OK button. 3- Firstly, it is chosen for which day’s program will make. -
Page 24: Periodic Controls That Users Must Be Made
*It must be checked if any dirt or residue inside heat exchanger which causes blockage. If it is 9.1Periodic Controls That User needed it must be cleaned by pressure water by Must Be Made removing from its place. Installation pressure must be made within year. * Combustion setting of the device must be made Operation pressure must be between 1-5 bars. -
Page 25: Maintenance Warning Codes
9.3 MAINTENANCE WARNING CODES Maintenance Code Description Priority Burner operation hour is exceeded. Burner starting quantity is exceeded. Maintenance interval is exceeded. Heating cycle water pressure is too low. Bottom water pressure limit is reduced under1. Change battery of outside air sensor. Heating cycle water pressure 2 is too low.
