2561665B REV. B 611
Safety Message to Installers of Federal Signal Products
People's lives depend on your proper installation and servicing of Federal Signal products. It is important to
read and follow all instructions shipped with this product and the original product. Listed below are some
other important safety instructions and precautions you should follow:
•
To properly install a light assembly, you must have a good understanding of automotive electrical
procedures and systems, along with proficiency in the installation and use of safety warning equipment.
•
When drilling into a vehicle structure, be sure that both sides of the surface are clear of anything that
could be damaged.
•
You should frequently inspect the light system to ensure that it is operating properly and that it is
securely attached to the vehicle.
•
Refer to the instruction sheets packed with related products for additional precautions and information.
•
File these instructions in a safe place and refer to them when maintaining and/or reinstalling the product.
Failure to follow all safety precautions and instructions may result in property damage, serious injury,
or death.
Product Overview
This publication provides directions for installing the Federal Signal Arjent
A vehicle-specific mounting hook, purchased separately, is required to complete the installation.
Unpacking the Kit
After unpacking the product, inspect it for damage that may have occurred in transit. If it has been damaged,
do not attempt to install or operate it. File a claim immediately with the carrier, stating the extent of damage.
Carefully check all envelopes, shipping labels, and tags before removing or destroying them. Ensure that the
parts listed in Table 1 are included in the package. If you are missing any parts, contact Customer Support at
1-800-264-3578, 7 a.m. to 5 p.m., Monday through Friday (CT).
Qty.
Table 1 Kit contents (continues on next page)
Description
1
Hook, Hardware Kit, Arjent
8
Bolt, TORX
Hd., 5/16‑18 x 5/8
®
8
Lockwasher, Split, 5/16
4
Lockwasher, Split, 3/8
8
Washer, Flat, 5/16
4
Pad, Mounting, Rubber
4
Nut, Hex, 3/8‑16
Installation Instructions for the
Arjent
Model XHK-SD Mounting Kit
®
Series lightbar on a vehicle roof.
®
Part No.
8583193
7000434‑10
7074A020‑01
7074A046
7072234
8572029
7059A063
Advertisement
Table of Contents
Related Manuals for Federal Signal Corporation XHK-SD
Summary of Contents for Federal Signal Corporation XHK-SD
- Page 1 Installation Instructions for the Arjent Model XHK-SD Mounting Kit ® 2561665B REV. B 611 Safety Message to Installers of Federal Signal Products People’s lives depend on your proper installation and servicing of Federal Signal products. It is important to read and follow all instructions shipped with this product and the original product. Listed below are some other important safety instructions and precautions you should follow: •...
-
Page 2: Mounting Foot
Figure 1 Mounting feet attached to mounting bracket MOUNTING PAD (2) 5/16" SPLIT BOLT, 5/16-18 x 5/8" LOCKWASHERS (4) TORX PAN HEAD (4) 5/16" FLAT MOUNTING FOOT (2) WASHERS (4) BOTTOM OF SLOT MOUNTING BRACKET 290A6696 Model XHK-SD Mounting Kit... - Page 3 Figure 2 Carriage bolts and mounting‑bolt stop installed in extrusion CARRIAGE BOLTS (TWO ON EACH END OF THE EXTRUSION) #8-32 SET SCREW MOUNTING BOLT STOP WIRE EXIT HOLE 290A6695 7. Install a mounting bracket assembly on the lightbar using 3/8"-16 hex nuts, flat washers, and split lockwashers as shown in Figure 4 on page 4. Tighten the nuts only enough to hold the mounting bracket assembly in place. NOTE: When installing the mounting bracket assembly, use hole A and the hole (B or C) closest to the end of the extrusion (Figure 4). 8. Align and apply the supplied label along the edge of the aluminum extrusion on the side opposite the wire exit hole and approximately one inch from the lip of the extrusion as shown in Figure 4. 9. Repeat steps 7 and 8 with the other mounting bracket assembly. Model XHK-SD Mounting Kit...
-
Page 4: Carriage Bolt
Lightbar on a Vehicle Roof ® Figure 3 Detail of mounting‑bolt stop MOUNTING BOLT STOP 290A6697 Figure 4 Carriage bolts and mounting‑bolt stop in extrusion MOUNTING BRACKET VINYL CAP PLUG (2) MOUNTING FOOT CARRIAGE BOLT (2) EXTRUSION LABEL 290A6694 Model XHK-SD Mounting Kit... - Page 5 4. Remove the lightbar assembly from the vehicle roof and place it on soft rags or cardboard to avoid marring the plastic domes. Turn the lightbar assembly over so that the bottom of the lightbar faces up. 5. Secure the mounting assembly to the lightbar using the eight #10 hex head thread-forming screws. Tighten the 3/8"-16 hex nuts (two on each mounting bracket) installed in step 7 in “Preparing the Lightbar” on page 2. 6. Press a vinyl cap plug on each of the four carriage bolts (Figure 4 on page 4). 7. Place the lightbar assembly on the vehicle’s roof in the selected position. 8. To fasten the mounting hook and complete the installation, refer to the hook hardware kit instructions (Federal Signal Part No. 2562480) that is included in the kit. 9. For instructions for the electrical installation, see the Installation and Maintenance Instructions included with the Arjent lightbar. 10. After the electrical installation, test the lightbar for proper operation as well as the emergency warning system to ensure that it is operating properly. See the next two sections starting on page 6 for warnings and instruction Model XHK-SD Mounting Kit...
-
Page 6: Testing The Installation
Do not test the sound and light system of the vehicle while driving. operating the vehicle warning systems may pose a hazard to the operator and other drivers if the systems do not function as expected. Test the vehicle only in a controlled environment. After testing is complete, provide a copy of these instructions to the instructional staff and all operating personnel. Getting Technical Support and Service For technical support and service, contact: Federal Signal Corporation Service Department Public Safety Systems Phone: 1-800-433-9132 Fax: 1-800-343-9706 Email: empserviceinfo@fedsig.com Ordering Replacement Parts To order replacement parts, contact your local dealer/distributor or: Customer Support Federal Signal Corporation Phone: 1-800-264-3578 Model XHK-SD Mounting Kit... -
Page 7: Returning A Product To Federal Signal
• Your Federal Signal customer or account number. • The purchase order number under which the items were purchased. • The shipping method. • The model or part number of the product being returned. • The quantity of products being returned. • Drop ship information as needed. • Any estimate required. When you receive your RMA Number: • Write the RMA number on the outside of the box of returned items. • Reference the RMA number on your paperwork inside of the box. • Write the RMA number down, so that you can easily check on status of the returned equipment. Send all material with the issued RMA Number to: Federal Signal Corporation Public Safety Systems 2645 Federal Signal Drive University Park, IL 60484-3167 Attn: Service Department RMA: #__________ 800-433-9132 800-343-9706 (fax) www.fedsig.com Model XHK-SD Mounting Kit... - Page 8 2645 Federal Signal Drive, University Park, IL 60484‑3167 Tel.: (800) 264-3578 • Fax: (800) 682-8022 © 2011 Federal Signal Corporation Arjent is a registered trademark of Federal Signal Corporation ® www.fedsig.com TORX ® is the registered trademark of Textron Inc..
