SIDEMOUNT PULLOUT 150 MM
TOOLS REQUIRED:
3
mm
ESTIMATED ASSEMBLY TIME:
30 MIN
CARE AND MAINTENANCE:
• Clean with a damp cloth and
wipe parts dry
• Lubricate pivot points as
needed
#2
A.
B.
INSTALLATION INSTRUCTIONS: SIDEMOUNT PULLOUT
Parts List
No.
Description
A
Slide
B
Basket
C
Door Mounting Bracket
D
M5 x 20 mm Machine Screws
E
4G x 18 mm Pan Head Screws
F
4G x 18 mm Flat Head Screws
G
M5 x 15 mm Flat Head Screws
C.
D.
E.
Qty
1 Set
1
1 Set
2
8
6
4
F.
G.
I-5776-150-0518
Advertisement
Related Manuals for Rev-A-Shelf SIDEMOUNT PULLOUT 150 MM
Summary of Contents for Rev-A-Shelf SIDEMOUNT PULLOUT 150 MM
-
Page 1: Parts List
SIDEMOUNT PULLOUT 150 MM TOOLS REQUIRED: Parts List Description ESTIMATED ASSEMBLY TIME: Slide 1 Set Basket 30 MIN Door Mounting Bracket 1 Set M5 x 20 mm Machine Screws 4G x 18 mm Pan Head Screws 4G x 18 mm Flat Head Screws... - Page 2 FIGURE A CHOOSING THE DESIRED BOTTOM SHELF The shelf on the basket is reversable. You can have a white or gray bottom. To change the color remove the retaining clips. Flip the board over and put clips back into place (See Figure A).
- Page 3 STEP 3 FIGURE D Using the dimensions in Figure D, mount the door mounting brackets to the door using (6) 4G x 18 mm flat head wood screws. STEP 4 FIGURE E Secure the unit to the door mounting brackets by using the (4) M5 x 15 mm flat head screws (See Figure E).
- Page 4 FIGURE D-1 DOOR ADJUSTMENT If the cabinet door is not lining up correctly, use the images in Figures D-1 through D-3 to loosen and tighten the door mounting screws to properly adjust the cabinet door. FIGURE D-2 FIGURE D-3...
