Thank you for purchasing Erica Synths Pico Series module!

With Pico Series we challenged ourselves – can we make ANY

superior functionality synth module 3HP wide and affordable?

Yes, we can.

Want some extreme, distorted drums and pads but you are short

in rack space? Pico Drive is the answer! Pico Drive is combined wavefolder-

overdrive module that features manually adjustable Gain and Drive

level, CV control over Gain and Drive adds more expression, while built

in limiter prevents output signal to run into undesired clipping.

Manual Gain and Drive controls

CV control over Gain and Drive

Wavefolder

Output signal limiter

Input and output protection against undesired overvoltage

Audio output level

CV level (full span)

Power consumption

Module width

Module depth

PICO

DRIVE

-5...+5V

-5V - +5V

29mA @ +12V, 29mA @ -12V

3HP

35mm

Need help?

Do you have a question about the Pico DRIVE and is the answer not in the manual?

Page 1 Yes, we can. Want some extreme, distorted drums and pads but you are short in rack space? Pico Drive is the answer! Pico Drive is combined wavefolder- overdrive module that features manually adjustable Gain and Drive level, CV control over Gain and Drive adds more expression, while built in limiter prevents output signal to run into undesired clipping.
Page 2 PICO DRIVE DRIVE Adjust the Overdrive level manually DRIVE Adjust the Gain manually. At settings above 9 ‘o'clock the original waveform is folded and overtones are added GAIN This is the Gain CV level attenuator GAIN CV Tis is the Drive CV input DRIVE CV Tis is the Gain CV...
Page 3 Erica Synths. Water is lethal for most of the electric devices, unless they are made waterproof. This Erica Synths module is NOT intended for use in a humid or wet environment. No liquids or other conducting substances must get into the module.
