Thank you for purchasing Erica Synths Pico Series module!

With Pico Series we challenged ourselves – can we make ANY

superior functionality synth module 3HP wide and affordable?

Erica Synths Pico Multi is an advanced replacement for

stackable patchcables – it's highly accurate active buffered

multiple that will work for signal splitting in any circuit,

including driving several VCOs in tune from one CV source.

Two independent active buffered multiples

1-3+1-2 or 1-5 configuration

Max input level

-10V - +10V

Power consumption

+20mA, -14mA

Module width

3HP

Module depth

35mm

Need help?

Do you have a question about the pico MULTI and is the answer not in the manual?

Page 1 With Pico Series we challenged ourselves – can we make ANY superior functionality synth module 3HP wide and affordable? Erica Synths Pico Multi is an advanced replacement for stackable patchcables – it’s highly accurate active buffered multiple that will work for signal splitting in any circuit, including driving several VCOs in tune from one CV source.
Page 2 PICO MULTI MULTI Apply signal, you wish to split here! Input is DC coupled, so you can use it for splitting CV, clock or audio IN A signals. The second input is normaled to the first output, so if nothing is plugged in the second input, you get one signal split to 5 outputs, OR if you plug a patchcable in INPUT2,...
Page 3 Erica Synths. Water is lethal for most of the electric devices, unless they are made waterproof. This Erica Synths module is NOT intended for use in a humid or wet environment. No liquids or other conducting substances must get into the module.
